AMGO SL-7 Manual

SINGLE POST LIFT
Model:SL-7
Original

CONTENTS
PRODUCT FEATURES AND SPECIFICATIONS............................................................1
INSTALLATION REQUIREMENT...............................................................................3
STEPS OF INSTALLATION......................................................................................5
EXPLODED VIEW................................................................................................13
TEST RUN..........................................................................................................22
OPERATION INSTRUCTIONS................................................................................23
MAINTENANCE SCHEDULE..................................................................................24
TROUBLE SHOOTING.........................................................................................25
LIFT DISPOSAL.................................................................................................25

1
I. PRODUCT FEATURES AND SPECIFICATIONS
CHAIN-DRIVE SINGLE POST MODEL SL-7 FEATURES
. Compact design.
· High quality cylinders and power units are manufactured to high standards.
. Self-lubricating UHMW Polyethylene sliders and bronze bush.
. Manual release safety lock, two-stage lock system
. Super-symmetric arms design with 3-stages front arms and 2-stages rear arms.
. Stackable and screwed type rubber pad.
Fig.1
MODEL SL-7 SPECIFICATIONS
Model
Style
Lifting
Capacity
Lifting
Time
Lifting
Height
Overall
Height
Overall
Width
Minimum Pad
Height
Motor
SL-7
Chain-drived
7,000 lbs
84S/32S
71 7/8”-77
5/8”
108 7/8”
84 1/2”
43/8”
1.0HP/
2.0HP

2
Arm Swings
View
Fig.2

3
II. INSTALLATION REQUIREMENT
A. TOOLS REQUIRED
Rotary Hammer Drill(Φ19) Carpenter’s Chalk
Hammer Screw sets
Level Bar Tape Measure(7.5mm)
English Spanner(12″) Pliers
Wrench set：(10＃、13＃、14＃、12＃Socket Head Wrench：(4＃、5＃、6＃)
17＃、19#、24＃、30＃)
Fig.3

4
B. Equipment storage and installation requirements.
The equipment should be stored or installed in a shady, normal temperature,
ventilated and dry place.
C. SPECIFICATIONS OF CONCRETE (See Fig. 4)
Specifications of concrete must be adhered to the specification as following.
Failure to do so may result in lift and/or vehicle falling.
1. Concrete must be thickness 5’’ minimum and without reinforcing steel bars and
must be dried completely before the installation.
2. Concrete must be in good condition and must be of test strength 3,500psi
minimum.
3. Floors must be level and no cracks.
D. POWER SUPPLY
The electrical source must be 2.0HP minimum. The source cable size must be
2.5mm² and in good condition of contacting with floor.
Fig.4
Concrete Intensity must be 3,500PSI minimum
73
≥5’’

5
III. STEPS OF INSTALLATION
A. Location of installation
Check and insure the installation location (concrete, layout, space size etc.) is suitable
for lift installation.
B. Check the parts before assembly
1. Packaged lift and hydraulic power unit (See Fig. 5)
Fig.5
Column
Power Unit
Base
Carriage

6
2. Take off the packaging on the machine. Take off the packing rack.
3. Move aside the parts and check the parts according to the shipment parts list.
(See Fig.6 & 7)
4. Check the parts of the parts bag according to the parts bag list (See Fig.8)
Part box （65）
Fig.7
Fig.8
65
Fig.6

7
C .Lay the base on the ground, confirm installation place according to
the ground state, the main purpose is to save space. (See Fig.9)
D. Install column and lift platform
1. Lay the column on the ground. (See Fig.10)
2. Connecting oil hose of cylinder (See Fig. 11)
Fig. 10
Fig. 11
Fig. 9
Pull out the carriage
about 200mm
Connect oil hose to cylinder connector
66
1

8
3. Fix column to the base plate. (See Fig.12)
4. Fix lifting platform to carriage. (See Fig.13)
Fig. 12
Fig. 13
23
30
25
26
27

9
13
E. Install safety device, power unit, oil hose and wire holder (See Fig.14)
Note: Tighten the oil hose fitting and power unit fitting to avoid oil leakage;
Pay attention to the direction of power unit fitting.
4
9
67
Fig.14
17
12
14
15
16
18
5
Tighter the screw with 19#
wrench set after install
power unit fitting.
68

10
F. Install plastic barrier (See Fig.15)
G. Install electrical system
Connect the power source on the data plate of power unit.
Note: For the safety of operators, the power wiring must contact the earth well.
Single phase motor
1. power supply wires (active wire Land neutral wire N) to terminals of AC contactor
marked L1, L3 respectively. Circuit diagram (See Fig. 16).
2. Connecting the earth wire terminal of the motor.
36
The plastic barrier
passes through
here
Clip support
Fig. 16
AC contactor
18
37
16
Switch button
Power Supply
Fig. 15

11
H. Install lifting arms (see Fig.17); Lowing the carriages down to the lowest
position, then use the 6# wrench to loosen the nut (See Fig. 18) Adjust the arm
lock as arrow direction (See Fig. 19). Adjust moon gear and arm lock to make it to
be good engagement, then tighten the nut of arm lock (See Fig. 20).
Operation of Arm Lock Handle
Tighten the screw
Fig.20
Fig.17
Fig.18
Fig.19
Loosen the screw
Adjust the screw and
arm lock
Snap Ring
①
②
①Pull out the control handle.
②Move Left or right to release
the both arm locks.
Fig.21

12
I. Tighten all the hydraulic fittings, and fill the reservoir with hydraulic oil.
Note: In consideration of Hydraulic Power Unit’s durability and keep the
equipment running in the perfect condition, please use Hydraulic Oil 46#.
J. Using level to measure and adjust the column to be vertical.
K. Fix the anchor bolts
1. Prepare the anchor bolts (See Fig. 23).
2. Using the prescribed rotary hammer drill, and drill all the anchor holes and install
the anchor bolts. Make the columns plumpness, and adjusting with the shims if not,
then tighten the anchor bolts (See Fig. 24).
Note:Torque of Anchors is 150N.m. Minimum embedment of Anchors is 4-1/2”
Use level to measure
the column by front
and side to make sure
the column is vertical
Fig.24
73
Fig.22
Drilling
Clearing
Expand
4 3/8’’
Fig.23
72 Level adjusting shim

13
IV. Exploded View
Model：SL-7
1
2
3
4
8
4
6
7
10
19~22
11
5
14~18
12
24
28
31
29
30
25~27
32
33
34
35
37
18
36
38
39
Fig.25
40
41
42
44
45
46
48
47
50
49
51
56
54
55
57
27
74
26
60
53
52
40
58
43
61
75
64
58A
63
64A
61A
62
76
61

14
PARTS LIST FOR SL-7
Item
Part#
Description
QTY
Note
1
11101013
Top Plate assembly
1
2
10206023
Self-Locking Nut M12
4
3
10217069
Hex Bolt M12*30
4
4
10209009
Cap Head Bolt M6*8
6
5
10209012
Spring Pin (φ3.2)
1
6
11203263
Power Side Safety Device
1
7
10209007
Safety Spring (120°angle)
1
8
11209008
Safety Cover
1
9
11217048
wire clip
2
10
11206002
Safety stop pin
1
11
10206003
Rubber handle sleeve
1
12
11203013
Coupling
1
13
81513019
Power unit
1
14
10217013
Hex Bolt M6*20
1
15
10209149
Lock Washer φ6
5
16
10420045
Washer φ6
13
17
11203261
Power-side Safety Block
1
18
10420018
Self Locking Nut M6
3
19
10680003
Hex Bolt M8*12
2
20
10209034
Lock Washer φ8
4
21
10209033
Washer φ8
4
22
11203035
Stackable Adapter Set
1
23
11101040
Column assembly
1
24
11203034
Stackable adapter 3”
4
25
10101002
Hex Bolt M20*50
10
26
10201114
Lock Washer φ20
18
27
10209128
Washer φ20
18
28
11101023
Base
1
29
11101024
Drive-in ramp
1
30
11102608
Carriage
1
31
10217188
Slider Block (46*46*76)
8
32
10207010
Cylinder
1
33
10207008
Chain pulley seat assy.
1
34
10201010A
Chain head
2
35
10101007
Chain
1
36
11101042
Plastic baffle L=2570mm
1
37
10203117
Adjusting screw with hook M6×95
2
38
10201005
Split pin (φ4*50)
1
39
11101025
Drive-in Ramp
1
40
10209020
Plastic ball
3
41
10209021
Hex nut M10
2
42
10209039
Lock Washer φ10
2

15
Item
Part#
Description
QTY
Note
43
10209023A
Arm lock
2
44
11201041
Limit Shim
2
45
11101010
Arm Lock Bar
2
46
10101034
Outside arm assy.
2
47
10520023
Snap ring φ38
2
48
11209030A
Arm pin
2
49
10420175A
Hex nut M20
8
50
10101001
Hex Bolt M20*45
8
51
11101016-01
Platform
1
52
10209025
Spring pin φ4*25
4
53
10209026
Safety spring φ1.4
2
54
10203054
Rubber pad assy.
4
55
10101003
Countersunk Screw M8*12
8
56
11101005
Arm pin
2
57
10101033
Outside Arm Assy.
2
58
1101015001
Spring Φ13*Φ10*Φ1.5*32
2
58A
85090128
Socket bolt M6*20
4
59
10101008
Arm lock
2
60
11101009-0
Arm lock fixing plate
2
61
85090245
Socket bolt M5*12
6
61A
1101012008
Limit Sleeve Φ10*6.2
4
62
1101012002
Connecting block
2
63
1101012004
Arresting Stop
1
64
1101012009
Control handle
1
64A
1101015001
Spring（Φ12.6*Φ1.2*21）
1
65
10102500
Parts box
1
66
10201020
900fitting of cylinder 3/8NPT(M)*1/4JIC(M)
1
67
10101027
Oil hose assy. 1/4’’ *1660
1
68
10209060
900fitting of Power unit
1
69
10209003
Hex bolt M8*25
4
70
10209004
Rubber ring(φ8*φ20*3)
4
71
10209005
Self-locking nut M8
4
72
10620065
Shim（2mm)
10
10201090
Shim（1mm)
10
73
10201140
Anchor bolt 3/4*6-1/2”
8
74
1101012010
Limit cover plate
1
75
10420152
Washer Φ5
6
76
10209143
Lock Washer Φ5
6

16
1. Rubber Pad Assembly(10203054)exploded view:
2. Outside Arm Assembly (10101033)exploded view:
Item
Part#
Description
QTY
1
10420043
Hex Bolt M8*20
8
2
10203043
Rubber pad
4
3
11203026
Support pad assy.
4
4
10203041
Retaining ring
4
5
11203025
Adjusting screw
4
6
10203042
Retaining ring
8
7
11203024
Adjustment Screw
4
Item
Part#
Description
QTY
1
10209032
Socket bolt M8*25
6
2
10209034
Lock washerφ8
6
3
10209033
Washerφ8
6
4
10209035
Moon gear
2
5
11101019
Outer arm - outside
2
6
10201149
Cup head bolt M8*12
2
7
11203101
Inner arm
2
3
1
4
2
7
Fig.25
5
6
Fig.26
1
2
3
6
5
4
7

17
3. Inside Arm Assembly (10101034) exploded view:
4. Cylinder Assy.（10207010）exploded view:
Item
Part#
Description
QTY
1
10209032
Socket bolt M8*25
6
2
10209034
Lock Washer φ8
6
3
10209033
Washer φ8
6
4
10209035
Moon gear
2
5
11203101
Outer arm - Inside
2
6
10201149
Cup head bolt M8*12
2
7
11102006
Inner arm - Inside
2
Cylinder Explode View
Fig.28
2
1
3
4
5
6
7
Fig.27

18
1
2
3
10
5
4
9
6
7
8
Item
Part#
Description
QTY
1
11207027
Piston Rod
1
2
11207028
Piston
1
3
10206069
O-Ring
1
4
10620053
Support Ring
1
5
10620054
Y-Ring OSI
1
6
10630027
O-ring
1
7
10206071
Hex Nut
1
8
11207029
Adjustment Tube
Cylinder Adjustment
1
9
10217078
Dust Ring
1
10
10520058
O-Ring
1
11
11207030
Head Cap
1
12
10201034
silencer
1
13
10207031
O-Ring
1
14
11207032
Cylinder Tube
1
5. Chain Pulley Support Assy.（11207681）exploded view：
Item
Part#
Description
QTY.
1
11207006
Pin for Chain Pulley Φ35*93
1
2
10420132
Bronze Bush Φ41.2*Φ35.1*20
1
3
11530023
Washer Φ44*Φ35.5*2
2
4
11207007
Chain Pulley Φ105*50
1
5
10430138
Socket Bolt M6*16
4
6
10209149
Spring Pad Φ6
4
7
10420045
Washer Φ6
4
8
11207693
Chain limit block
1
9
10530042
Bronze Bush Φ41.2*Φ35.1*28
1
10
11207008
Chain Pulley Seat
1
Fig.29
