AMGO SPL-6 Manual

SINGLE POST PARKING LIFT
Address:
SC Division: 1931 Joe Rogers Jr Blvd, Manning, SC 29102, USA
TX Division: 4310 Adler Dr., Suite #200, Dallas, TX 75211, USA
MODEL: SPL-6
Original
Cargo Claims
If there is any missing or damaged
product during transportation, the
buyer must notate on the shipping
paperwork or refuse the shipment.
NOTATE ALL DAMAGE OR REFUSE
DAMAGED SHIPMENT!
△
!DANGER
Read the entire contents of this manual before
using this product. Failure to follow instructions
and safety precautions could result in serious
injury or even death. Make sure all other
operators also read this manual. Keep this
manual near the machine so that it can be seen
by all users. By proceeding with installation and
operation, you agree that you are fully
understand the contents of this manual and take
full responsibility for the use of the product.

CONTENTS
PROFILE AND WARRANTY ............................................................... 2
SAFETY INSTRUCTION ....................................................................4
I. PRODUCT FEATURES AND SPECIFICATIONS......................................5
II. INSTALLATION REQUIREMENT ......................................................7
III. INSTALLATION STEPS .................................................................9
IV. EXPLODED VIEW........................................................................22
V. TEST RUN .................................................................................27
VI. OPERATION INSTRUCTIONS........................................................28
VII. MAINTENANCE SCHEDULE.........................................................29
VIII. TROUBLE SHOOTING ..............................................................30
IX. CAR LIFT SAFETY TIPS...............................................................31
X. LIFT DISPOSAL........................................................................................31
Explanation of the safety warning symbols used in this manual
⚠DANGER
Risk of death or injury.
⚠WARNING
Dangerous or unsafe practices that may result in death or injury.
⚠CAUTION
Dangerous or unsafe practices that may result in personal
injury, product damage or property damage.
ATTENTION
Conditions that may result in damage to products or property.

1
PROFILE
This instruction manual is specially prepared for you. Your new lift is the product of over a
decade of continuous research, testing and development. AMGO lifts are one of the best
lifts you can purchase!
Please make sure to read through this manual before operating the lift.
Record the information on the nameplate label here:
Model No.:
Serial No.:
Manufacturer date:
WARRANTY
The warranty period for the steel structure part of new car lift is 5 years, hydraulic
components, bronze bushings, sliders are under warranty for 3 years, and electrical
components warranty for 2 years. Rubber pads are without warranty. During the warranty
period, the manufacturer will repair or replace the defective parts free of charge including
shipping costs.
This warranty does not cover damage caused by normal wear and tear, improper use,
damage in transit, or damage caused by lack of maintenance.
This warranty is unique and supersedes what is expressed and implied in all other
warranties. The manufacturer shall not be liable for any particular, indirect or accidental
damage resulting in breach of or delay in the execution of the warranty. The manufacturer
reserves the right to design and improve the product and has no obligation to make notice
of the changes in advance.
The product warranty based on the above clause is based on the model number and serial
number of the equipment. This information must be provided in conjunction with all
warranty information at the time of service and warranty.

2
SAFETY WARNING LABEL
Fig. 1

3
IMPORTANT SAFETY INSTRUCTIONS
In order to properly maintain your product and ensure operator safety, it is the
responsibility of the product owner to read and follow these instructions!
1. Ensure product installation complies with all applicable local regulations and rules,
such as Occupational Safety and Health Administration regulations and electrical codes.
2. Ensure that all operators are properly trained, know how to operate the unit safely, and
are properly supervised.
3. Do not operate the lift until you are sure all parts are in place and operating correctly.
4. Keep your hands and feet away from the machine. Keep hands and feet away from any
moving parts. Keep your feet away from the lift as it descends to avoid pressing on
pointed objects.
5. Keep the work area clean. A cluttered workspace can lead to injuries.
6. The machine is only approved for indoor installation and use. Outdoor installation is
prohibited.
7. Only trained operators are allowed to handle the lift machine. All untrained persons must
stay away from the workplace. Never allow untrained persons to handle or operate the
machine.
8. Use the lift properly. Use the lift in the correct way.
9. Warning! Keep persons and objects from the lift when lifting the a vehicle.
10. If the vehicle is at risk of falling, make sure no one is around the lift.
11. Before preparing to approach or service the vehicle, ensure that the safety device is in
effect.
12. Dress appropriately when operating machines, and wear non-slip steel-toe shoes for
safety consideration.
13. Beware of electric shock. In order to protect the operator from electric shock, the lift in
use must be grounded. Do not connect the green wire to the terminal. This is the ground
wire.
14. Danger! The power supply used in this type of lift has high voltage. Please disconnect
the power supply before any circuit repair. Unplug in case the power supply is
accidentally switched on during maintenance.
15. Warning! There is a risk of explosion. There are parts in the equipment that produce arc
light and spark. Do not operate near flammable gas. This machine should not be placed
in the lounge or basement.
16. Maintain with care. Keep the machine clean for better and safer operation. Perform
proper lubrication and maintenance procedures according to the manual. Keep handles
or buttons clean, dry, and free of oil.

4
17. Stay alert. Use common sense to observe what you are doing and stay alert.
18. Check for damaged parts. Check for adjustments to moving parts, damage to parts, or
anything that may affect their operation. Do not use the machine if the parts are
damaged.
19. Do not remove relevant safety parts from the machine. Do not use a lift if it is damaged
or missing.
20. Operate the lift only at temperature between 41°F to 104°F （5°C to 40°C ）
⚠DANGER Be very careful when installing, operating, maintaining or
repairing this equipment. Failure to comply may result in property damage,
product damage, injury or (in very rare cases) death. Ensure that only
authorized personnel operate the equipment. All repairs must be carried out
by an authorized technician. Do not modify the machine, this voids the
warranty and increases the probability of personal injury or property
damage.

5
I. PRODUCT FEATURES AND SPECIFICATIONS
Single-post Parking Lift MODEL SPL-6
· Specially designed for parking.
· Dual safety device, no need air source, manual safety lock release.
· Non slip lifting platform.
· H-shaped lifting platform with reinforced column and base to provide excellent
stability.
· Available for low ceilings garage as low as 110”.
· Suitable for home garages and commercial applications,with limited floor space
required..
Fig.2
Fig.1

6
Specification & Dimension
MODEL SPL-6 SPECIFICATIONS
Model
Lifting
Capacity
Lifting
Time
A
B
C
D
E
F
G
Motor
Overall
Height
Overall
Width
Overall
Length
Incl.
Ramps
Max.
Lifting
Height
Max. lock
height to
top of
runway
Max. height
underneath
runway
Max. lock
height
underneath
runway
Min.
Height
Width
Between
runway
SPL-6
6000lbs
84s(110V)
32s(220V
108 7/8"
111"
192 1/8"
74"
64 7/8"
69 1/4"
66 1/8
6 3/8"
42 3/8"
1.0HP (110V )
2.0HP (220V)
Fig.3

7
II. INSTALLATION REQUIREMENT
A. Tools required
√Carpenter’s Chalk √Hammer
√Screw sets
√Level Bar
√Tape Measure(295”)
√English Spanner(12″)
√Pliers √Socket Head Wrench (3＃5＃8＃)
√Wrench set：(10＃13＃14＃15＃...... √Rotary Hammer Drill (Φ3/4)
17＃19#24＃27＃30＃)
Fig.4

8
B.Storage and installation requirement
1. Store the equipment in a dry, non-moldy and non-flammable environment.
2. The lift is only approved for indoor installation and use. Outdoor installation is prohibited.
3. When installing the machine, take safety precautions according to the instructions to
avoid device damage.
4.The equipment should not be installed outdoors if the installation area is not protected.
5.During installation, all parts should be fastened to ensure the stability and smooth
operation of the machine.
6.After installation, the whole machine should be checked to make sure that every
component is working properly.
C.Specification of concrete (See Fig. 5)
Specifications of concrete must be adhered to the specification as following.
Failure to do so may result in lift and/or vehicle falling.
1. Concrete must be thickness 5” minimum thick and without reinforcing steel bars, and
must be dried completely before the installation.
2. Concrete must be in good condition and must be of test strength 3,500psi minimum.
Solidify at least 15 days.
3. Floors must be level and contain no cracks.
4. Do not install the lift on asphalt or any surface other than concrete.
D.Power supply
1.You are required to use a licensed and qualified electrician for the installation process.
2.The power supply must be 110VAC/60HZ or220VAC/60Hz, with a cord larger than
12AWG, and must be properly grounded.
Fig.5
≥5”
42
Concrete intensity must be 3,500psi minimum

9
III. INSTALLATION STEPS
A. Location of installation
Check and ensure the installation location (concrete, layout, space size etc.) is suitable for
lift installation.
1．Architectural plans. Consult the architectural plans for your desired installation location.
Make sure there are no contradictions between what you want to do and what the plans
show.
2．Available space. Make sure there is enough space for the lift; front, back, sides, and
above. Refer to specifications for specific measurements.(See Fig.9)
3．Overhead obstructions. Check for overhead obstructions such as building supports,
heaters, lights, electrical lines, low ceilings, and so on.
4．Power. You need a 110VAC/60HZ or 220 VAC/60Hz, current 20A, with a cord larger than
12AWG.
5．Installations: AMGO car lifts are approved for indoor installation and use only. Outdoor
installation is prohibited.
6．Floor. The lift should only be installed on a flat, level concrete surface and not on asphalt
or any other type of flooring. It is important to ensure that surface not more than 3°
slope before installation.
△
!DANGER All electrical wiring must be performed by a licensed and
certified electrician. Attempting to connect the circuit without proper
certification may cause damage to the lift or electrocution, resulting in
serious injury or death.
30”
Fig.6
39”

10
ATTENTION: Lift installation and concrete construction must comply with the latest version
of the national standard "Automotive Lifts - Safety Requirements for Construction, Testing
and Verification".
B.Check the parts before assembly
1. Received goods (lift and hydraulic power unit). (See Fig. 7)
2. Move the package of lift with forklift or crane to the side of installation location, cut the
packing strips, take the column down with forklift or manually.
Fig.7
⚠CAUTION Installing the lift on a surface with slopes more than 3° could lead to injury or
even death. AMGO lifts are designed for installation on a flat and level surface only. (Defined as
no more than 3/8 of an inch difference over the installation area). If the floor cannot be leveled,
consider changing installation locations.

11
3.Remove the bolts of upper package, move aside the platform at top layer, take out the
parts inside the platform at second layer, and remove the package stand.
Fig.9
4. Move aside all parts to installation site and check the parts according to the shipment
parts list. (See Fig.10)
Safety device cover, tire stop
plate
Fig.10
Parts box
Arm connecting pin
Arms
Arms
Drive-in
ramps
Drive-in
ramps
Guide
ramps

12
5. Open parts box, check the parts according to the parts box list. (See Fig.11)
6. Check the parts of the parts bag according to the parts bag list. (See Fig. 12)
C.Confirm the installation position and place the base onto it. (See Fig.13)
D.Fix anchor bolts.
Using the prescribed rotary hammer drill, and drill all the anchor holes and install the
anchor bolts. Then tighten the anchor bolts. (See Fig. 14)
Note: Torque of anchors is 150N.m . Minimum embedment of anchors is 4 3/8”.
Fig.13
Fig.12
Fig.11
42
25

13
E.Install column and connect the oil hose to cylinder.
1.Lay the column flat on the ground. (See Fig.15)
2. Connecting oil hose to cylinder. (See Fig.16)
A: Pull out the carriage around 8” from
base plate.
B: Pass the oil hose through the hole on the backside
of column, connect it to the cylinder fitting and
tighten.
Fig.16
Fig.14
50
Min.
4 3/8”
Fig.15

14
46
48
12
Slide block fixing plate
49
3. Position the column onto the base, align the mounting holes, and install with bolts.
Check the column plumbness with level bar, adjust with shims if necessary. (See Fig.17)
F.Install platform connection.
1. Connect the slider block with slide bock fixing plate, and fix to the backside of platform
connection. (See Fig.18)
Fig.17
Fig.18
40~41
26
Adjust with 3/64” or 5/64” shims
if necessary.
M20*50 Hex bolt with flat
washer, lock washer
47
M10*15 Hex bolt w/
flat washer, lock
washer.
M10*100 Hex bolt w/ flat
washer, lock washer and nut
Slider block
26

15
M20*40 Hex bolt
w/ flat washer, lock
washer and nut
29
M8*25 Hex bolt w/
φ20*φ8*3 rubber
ring and M8 Nylok
nut
2. Install the platform connection to the carriage.(See Fig.19)
G.Install power unit ,oil hoses and retainer
1.Install power unit, see fig 20
Fig.19
Fig.20
13
After installation, grease
the friction contact
positions between
column and slide block.

16
50
45
90°Fitting for power unit
Install with M6*8 round head
bolt w/ φ6 flat washer
2. Install power unit, see fig 21
Install the 90° fitting to the power unit, then connect it with the oil hose that comes
from the cylinder.
3. Install retainer, see fig 22.
Note: Tighten the oil hose fitting and power unit fitting to avoid oil leakage.
4. Fill the reservoir with hydraulic oil.
In consideration of hydraulic system’s durability, please use hydraulic oil 46#.
H.Install electrical system
Connect the power with schematic circuit diagram according to the requirement on the
motor plate.
Fig.21
32
44
Fig.22

17
Note: To ensure the safety of operators, the lift must be grounded.Test the lift after
installation to check if works fine.
Single phase motor
Connect the two hot wires of power supply respectively to the terminals of AC contactor
marked L1 and L3 . Connect ground wire to ground terminal.(Follow the circuit diagram
show on the back of the motor box for wire connection)
I. Install arms
Raise the carriage to proper position, insert the left and right arms from the window
side into square tubes of platform connection , align the pin hole and fix with pin, then
install the limit clip ring at the bottom.
Fig.17
69
64
Fig.23
Power supply wires
22 Right Arm
21 Left Arm
14
15
Fig.24
Insert from the window side

18
J. Install platform
Hoist the platforms onto the arms, align the mounting holes and connect with bolts (no
need to tighten the bolts at this step, tighten them in turn after the bolts of the lateral sides
are aligned with the holes.)
18
Bolted with M12*35 Hex
bolt w/ 2xflat washer, lock
washer and nut.
Fig.25
Adjust with shims the possible clearance at
connecting junction between platform and arm,
then tighten with bolts.
20
Bolted with M12*35
Hex bolt w/ 2xflat
washer, lock washer and
nut.
Fig.26
