AMGO A430-HP Manual

Model: A430-HP
Fig. 1
FOUR-POST PARKING LIFT
Original

CONTENTS
I. Product Features and Specifications………….………………………....………… 1
II. Installation Requirement ……….……….……….…………………..………………. 2
III. Steps of Installation……………………….………….....................….………….4
IV. Exploded View………………………….…………………...……...…...……...…...…28
V. Test Run………………………...………………………….…………………………………37
VI. Operation Instruction……………………….……..……………………………………38
VII. Maintenance…………………….…………..……………………..…………………….39
VIII. Trouble Shooting………………….………………..………..…………..………..…40
IX. Lift Disposal .................................................................………..……..40

1
I. PRODUCT FEATURES AND SPECIFICATIONS
4-POST MODEL A430-HP FEATURES
●Single point manual safety release.
●Four mechanical locking devices, each equipped with both primary
and secondly safety locks.
●Power-side column can be installed at both side, front or rear.
●Non-skid diamond platforms and adjustable safety lock ladders.
●Optional kits:Sliding jack with hand pump, caster kits, Plastic oil tray.
MODEL A430-HP SPECIFICATIONS
Model
Lifting
Capacity
Lifting
Height
Lifting
Time
Overall
Length (Inc.
Ramps)
Overall Width
Overall
height
Width
Between
Columns
Motor
A430-HP
3000KG
2120mm
35S
5007mm
2409mm
2455mm
2167mm
220V：3.0HP
Fig.1

2
II. INSTALLATION REQUIREMENT
A. TOOLS REQUIRED
Tape Measure（7.5m ）Carpenter’s Chalk
Hammer Screw Sets
Level Bar Pliers
English Spanner (12") Lock Wrench
Wrench set：(12＃、13＃、14＃、15＃、17＃、19#
24＃、30#)
Socket Head Wrench：(3＃、5＃、6＃、8＃)
Fig.2

3
Concrete must be of test strength
210kg/ cm² minimum.
B. Equipment storage and installation requirements.
The equipment should be stored or installed in a shady, normal temperature,
ventilated and dry place.
C. The equipment should be unload and transfer by forklift.
D. SPECIFICATIONS OF CONCRETE (See Fig. 4)
Specifications of concrete must be adhered to the specification as following.
Failure to do so may result in lift and/or vehicle falling.
1. Concrete must be thickness 100mm minimum and without reinforcing steel bars, and
must be dried completely before the installation.
2. Concrete must be in good condition and must be of test strength 3,000psi (210kg/cm²)
minimum.
3. Floors must be level and no cracks.
E. POWER SUPPLY
The electrical source must be 2.2KW minimum. The source cable size must be 2.5mm²
and in good condition of contacting with floor.
Fig.4
Fig.3
≥100mm

4
III. STEPS OF INSTALLATION
A. Check the parts before assembly
1. Packaged lift and Hydraulic Power Unit (See Fig. 5).
2. Open the outer packing carefully, check the parts according to the shipment list. (See Fig.
6).
3. Take off the drive-in ramps and columns (See Fig.7).
4. Loosen the screws of the upper package stand, take off the offside platform, take out the
parts inside the power-side platform, then remove the package stand.
Shipment Parts List
Drive-in
Ramp
Offside
Platform
板
Column
Cross
Beam
Parts
box
Power-side
Platform
Fig.5
Fig.6
Fig.7
(Optional) Plastic oil
tray
Cross
Beam

5
5. Move aside the parts and check the parts according to the shipment parts list
(See Fig. 8).
6. Open the carton of parts and check the parts according to the parts box list
(See Fig. 9).
Fig.8
Fig.9
62

6
7. Check the parts of the parts bag according to the parts bag list (See Fig. 10).
B. Use a carpenter’s chalk line to establish installation layout as per Table 1
Make sure the size is right and base is flat (see Fig. 11).
Note: Reserve appropriate space in front and behind the installation site.
MODEL
A
B
C
A430-HP
4164mm
2409mm
4811mm
B
A
C
Use a carpenter’s chalk line to
establish installation layout
Fig.11
1
2
Fig.10

7
C. Install cross beams (See Fig.12, Fig.13).
Note: Pay attention that the cross beam's slot should be positioned towards inward and
the safety locks connecting assy. should be adjacent to the power unit column.
Hole towards inside
Fig.12
Fig.13
3
6
The power-side column need to be
installed according to the installed position
of the safety lock release handle.

8
D. Install the Safety Ladders.
1. Take off the pulley safety cover and unscrew the four upper nuts of the safety ladders, and
adjust the four lower nuts so they are at the same position. Then insert the safety ladder
(See Fig. 14).
Fig.14
Safety Ladder is inserted between
Limited Pins of the cross-beam
Insert the safety
ladder from up to
the bottom
between the
Limited Pins
Take off the pulley safety cover
Pulley safety cover
Unscrew the upper nut of the safety ladders
Safety ladder
Limited Pin
Limited Pin

9
2. Install Safety Ladders (See Fig. 15)
E. Raise the cross beams at the same height and lock them on the safety ladders
(See Fig. 16).
This height for four threaded
rod of safety ladders should
be the same.
Fig.15
Fig.16
Lift both cross beams to the
same height.
The safety device
on the cross
beam should be
engaged in the
safety ladders at
the same height.
Safety ladder pass through the hole of the
top plate, then tighten the two nuts
18
17
The lifting cross beam height
should be fitted for installing
the platform and its parts .
1m height is recommended.

10
F. Install power-side platform.
1. Raise the power-side platform above the cross beam by a forklift or crane. Then move the
cross beam outwards until the pulleys of both platforms can be rested into the cross beams’
slots ( see Fig.17 ). Tighten the Power-side Platform to the Cross beams by using bolts.
Illustration for rear pulley in
power-side platform
Offset the cross beam lean
outward when putting the
power-side platform on the
cross beams
Offset the cross beam lean
outward when putting the
power-side platform on the
cross beams
Fig.17
Illustration for front pulley in
power-side platform

11
2. Install the tire stop plate and connecting bolts: Tighten the platform and the cross
beam Bwith bolts. Tighten the tire stop plate , platform and cross beam Awith bolt.
Note: Install the tire stop plate on the drive- in position . And the bolts for connecting with tire
stop plate is longer, pay attention when choosing the bolts. (See Fig.18)
Instruction:
1) This lift is designed to be driven in at any position according to the space. Below is the
instruction for the drive -in position on cross beam B. If it is chosen to be driven in from
cross beam A, install the tire stop plate to the other side only.
2) Power-side column can be installed at any position accordingly. But the power unit must
always be installed adjacent to the safety lock release handle. Pay attention to direction
when installed the safety lock release handle, power unit and hydraulic system.
Fig.18
24
26
25
27
Drive- in direction
28
5
Cross beam B
Cross beam A
Tighten the platform with
hex bolts M16*30, lock
washer and washer
Tighten the plate with hex
bolts M16*35, lock washer
and washer

12
G. Install the offside platform and limit slide block, and platform strengthen bolts.
Check the verticality of columns with level bar and adjust with shims. (See Fig. 19)
Fig.19
4
Level bar
Note: DO NOT completely tighten
the limit slide blocks. Loosen 1/4 lap
after tightening.
33
9
10
32
29
30
31
Install the platform
strengthen bolts.
34
Slip the limit slide block with groove
into the clearance along the bent edge of
column. Connect the limit slide blocks to
the cross beam with bolts.

13
H. Illustration for cable installation
1. Route the cable from the power-side platform via the pulleys according to the number
below and then connect them to the columns.
(See Fig. 20)
NO.
Cable
○
1
○
2
○
3
○
4
Length
(inc. connecting fitting)
4595mm
10156mm
5997mm
8726mm
A
B
C
D
A
C
D
B
Cable installation Instruction
Fig.20
35
36
37
38

14
2. The cable goes through the cross beam to column top plates and tightened with cable nuts
(See Fig. 21)
Fig.21
Cable goes through top plate
and tightened with cable nuts.
Cable goes through the cross
beam pulley and tension
pulley.The cable adjustment
sleeve (17B) need not be
installed for the first use. The
cable may be elongated after
loading, adjusting with the
cable adjustment sleeve (17B)
as actually required.
17
17A
17B
17C

15
3. Illustration for cables under platform . (See Fig. 22)
Cable②
Cable ①
Cable ○
4
Cable ○
2
Cable ○
3
Socket Bolt M10*90
Cable ○
4
Cable ○
2
Fig.22
Cable ④
Cable ①
Cable ②
Cable ④
Cable③

16
I. Install release handle assy. (See Fig. 23)
Noted: Power unit must be installed near the safety release handle.
View B
Cross beam B
Cross beam A
View A
Fig. 23
44
23
45
43
45
45A
43A
Pass through the connecting bar from the
safety lock rotated device of cross beam A/B
assy. of cross beam A/B
According to the above diagram, fix lock release
handle and the safety lock connecting assy. with
M8*35 bolts and washers on cross beam A.
Install extend lock release handle and
plastic ball
View B
According to the above diagram, fix safety lock
connecting bar and safety lock connecting assy. by
M8*35 bolts and washers on cross beam B.
Safety lock
connecting assy.
Safety lock
connecting assy.
Safety lock rotated
device assy.
Safety lock
connecting bar
Fig.23
42
45
45B

17
J. Install power unit and connecting tube (See Fig. 24).
Noted: Power unit must be installed near the safety release handle.
1.Install Power unit on the cross beam A
Cross beam B
Cross beam A
Fig. 24
Drive- in
direction
40
41
40
42
Fix the connecting tube and the connecting
bar for safety device by M8*25 socket bolts
40
63
47A
9
23
47B
16
10
46
9
47

18
K. Install Hydraulic System
1. For power unit attached to the power-side column for cross beam A(See Fig. 25)
Note: Oil hoses connected to oil cylinder must be passed above the cable and oil inlet port
should be inclined upwards to avoid the oil hose scratched by cable.
Retainer
55
54
53
Fig.25
48
4
55
49
50
55
50
51
52
a
b
c、d
a
b
c
d
Oil return
hose
Oil inlet port inclined
upwards
Oil return hose passed
above the cable
52
The oil hose and oil return hose
pass through the protective hose
and connect to the power unit
56
49C
49A
