AMQ Amobi Desk One User manual

Amobi Desk Warranty Replacement Instructions Guide
This device complies with part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
Important: Changes or modifications to this product not authorized by AMQ could void your authority
to operate the product.
For commercial use only
Do NOT unpack with only one person.
Desk is heavy and can tip over causing serious injury.
Always use two or more people to unpack and set up desk.
Immediately rotate feet to 45 degrees or more.
CAUTION
2 person

amqsolutions.com
IMPORTANT SAFETY INSTRUCTIONS ................................. 3-5
CONTENTS
AMOBI DESK Warranty Replacement Instructions Guide | 2
WORKSURFACE REPLACEMENT .................................... 6-12
REAR PANEL SLOT REPLACEMENT ................................. 13-19
REAR HANDSET REPLACEMENT ................................... 20-30
FRONT & REAR CASTORS REPLACEMENT ........................... 31-41
FOOT LOCK SWITCH REPLACEMENT................................ 42-52
POWER CORD REPLACEMENT..................................... 53-64

amqsolutions.com
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING THIS FURNISHING.
PLEASE SAVE THESE INSTRUCTIONS IN AN OBVIOUS PLACE FOR THE END USER AFTER
ASSEMBLY.
When using an electrical furnishing, basic precautions should always be followed,
including the following:
WARNING – To reduce the risk of burns, fire, electric shock, or injury to persons:
Always unplug this furnishing from the electrical outlet before cleaning or servicing.
1. Close supervision is necessary when this furnishing is used by, or near children, invalids, or disabled
persons.
2. Use this furnishing only for its intended use as described in these instructions. Do not use attachments
not recommended by the manufacturer.
3. Never operate this furnishing if it has a damaged cord or plug, if it is not working properly, if it has been
dropped or damaged, or dropped into water. Return the furnishing to a service center for examination
and repair.
4. Keep the cord away from heated surfaces.
5. Do not use outdoors.
6. To disconnect, turn all controls to the off position, then remove plug from outlet.
7. MAX Loading - 10Amps. Do not overload integrated sockets.
8. For continued protection against risk of fire, replace only with same type and rating of fuse 250V, 10A.
WARNING
WARNING
WARNING
RISK OF INJURY. Do not sit or stand on product. Use only as intended.
Inspect regularly. STOP using if product is damaged or has loose parts.
Only repair with AMQ authorized parts and methods.
Do not adjust feet parallel with frame (0 degrees), desk may fall causing injury.
To move or store desk:
1. Adjust desk to lowest height position.
2. Keep feet at 90 degrees for improved stability
3. Feet may be adjusted to 45 degrees for moving through doors, or for storage
AMOBI DESK Warranty Replacement Instructions Guide | 3

amqsolutions.com
Requires minimum of 2 person for removing Amobi Desk from its packaging & feet deployment.
CAUTION
2 person
X
No children
176 lb
80 kg
WARNING
Crush Hazard - Keep Clear
Locate desk, accessories and nearbyobjects to allow movement of desktop through full range withoutpullingcords,
trapping body partsor colliding with anything (shelves,electrical plugsand cords,doorknobs, window sills, storage
cabinets,etc.).
RISK OF DEATH OR SERIOUS INJURY. Raising or lowering deskcantrap, pinchor crush bodyparts or property.
Not to be used in locations where children, or people with cognitive disabilities are anticipated to be present and not
supervised.
DO NOT ALLOW USE BY CHILDREN
or people unableto understand the risksandto safelyadjust the desk height.
Maintain > 1" (25mm) gap above objectson desk at max. height and between the desk and adjacent objects.
CRUSH HAZARD - DO NOT PLACE FEET, LEGS OR OTHER BODY PARTS ON OBJECTS PLACED UNDER
TABLE TOP OR BELOW MODESTY PANEL.
DO NOT OPERATE THIS EQUIPMENT Unless Properly Trained.
>1"
(25mm)
>1"
(25mm)
X
Max.
Min.
X
X
>1"
(25mm)
[phone]
AMQSolutions.com
?
Read Directions and Manual first
CAUTION
Do NOT unpack with only one person.
Desk is heavy and can tip over causing serious injury.
Always use two or more people to unpack and set up desk.
Immediately rotate feet to 45 degrees or more.
2 person
WARNING
AMOBI DESK Warranty Replacement Instructions Guide | 4

amqsolutions.com
CAUTION
CAUTION
Do NOT install any kind of equipment like wire-tray, wire management systems,
baskets and storage on or below the desk worksurface. FAILURE TO FOLLOW THESE
INSTRUCTIONS COULD RESULT IN PROPERTY DAMAGE OR PERSONAL INJURY.
Crush Hazard - Keep hands and fingers away when closing or opening desk worksurface.
The desk must be positioned near an easily accessible power outlet.
GROUNDING INSTRUCTIONS (for grounded products only)
For products sold in North America and other 120V regions: the product
is for use on a nominal 120-V circuit. These products use a grounded plug
that looks like the plug illustrated in sketch A in Figure 1. Make sure that the
product is connected to an outlet having the same configuration as the plug.
No adapter should be used with this product.
GROUNDED
OUTLET
GROUNDED
OUTLET BOX
GROUNDING PIN
Figure 1
Grounding methods
Products with Grounded Plugs
AMOBI DESK Warranty Replacement Instructions Guide | 5

amqsolutions.com
WORKSURFACE REPLACEMENT
AMOBI DESK Warranty Replacement Instructions Guide | 6
COMPONENTS
Worksurface

amqsolutions.com
TOOL REQUIRED
AMOBI DESK Warranty Replacement Instructions Guide | 7
Electric Drill
x 1

amqsolutions.com
AMOBI DESK Warranty Replacement Instructions Guide | 8
Step 1
Use an electric drill to remove 9 screws on the Worksurface.
Step 2
Press and hold the Handle Button (1) and pulll down the Worksurface (2).
Press the Handle Button
1
2
WORKSURFACE REPLACEMENT
(9)
ST4.2 x 16

amqsolutions.com
AMOBI DESK Warranty Replacement Instructions Guide | 9
Step 3
Press down the Worksurface until a “click” can be felt when the Worksurface is rotated to a
horizontal position.
Step 4
Pull out the Worksurface.
the Worksurface
Press down
WORKSURFACE REPLACEMENT

amqsolutions.com
AMOBI DESK Warranty Replacement Instructions Guide | 10
Step 5
Step 6
Place the Worksurface on the cantilever plate, align the opening position and push it in to the end.
Replace the damaged Worksurface.
OLD NEWSWAP
WORKSURFACE REPLACEMENT

amqsolutions.com
AMOBI DESK Warranty Replacement Instructions Guide | 11
Step 7
Step 8
Before securing the Worksurface to the Main Body with screws. Make sure there is no interference between the
Worksurface & Main Body. Both side of the Worksurface & Main Body should have equal gaps and that the
pre-pilot holes on the Worksurface are aligned with the holes on the Cantilever Plate.
Note: To close the Worksurface, first press the Worksurface Lock Button, then lift the Worksurface to close it.
A ‘click’ can be felt when the Worksurface is properly locked and secured.
Lock Button
Gap
Worksurface
WORKSURFACE REPLACEMENT

amqsolutions.com
AMOBI DESK Warranty Replacement Instructions Guide | 12
Step 9
Use an electric drill to reinstall 9 screws(Torque : 1.4~1.8 N*m) to secure the Worksurface.
WORKSURFACE REPLACEMENT
(9)
ST4.2 x 16

amqsolutions.com
REAR PANEL SLOT REPLACEMENT
AMOBI DESK Warranty Replacement Instructions Guide | 13
COMPONENTS
Rear Panel Slot

amqsolutions.com
TOOL REQUIRED
AMOBI DESK Warranty Replacement Instructions Guide | 14
4mm Hex Key
x 1

amqsolutions.com
Step 1
Whiteboard/Felt Tackboard can be unlocked by pressing the Push-Lock Buttons located on
each side as indicated above.
Step 2
Then pull the Whiteboard/Felt Tackboard outwards then downwards to remove it.
2 person
2
1
Notice : To avoid damage,
2 person is required while
installing/removing the
Whiteboard or Felt
Tackboard.
LOCK UNLOCK
AMOBI DESK Warranty Replacement Instructions Guide | 15
REAR PANEL SLOT REPLACEMENT

amqsolutions.com
Step 3
Hold the Rear Panel Slot with your hand, Use a 4mm hex key to remove the two M6x14 screws.
AMOBI DESK Warranty Replacement Instructions Guide | 16
REAR PANEL SLOT REPLACEMENT
Hold the Rear Panel Slot
(2)
M6 x 14
4mm

amqsolutions.com
Step 4
Replace the damaged Rear Panel Slot.
Hold the Rear Panel Slot with your hand, Use a 4mm hex key to tightly the two M6x14 screws.
Step 5
OLD
NEW
SWAP
Hold the Rear Panel Slot
AMOBI DESK Warranty Replacement Instructions Guide | 17
REAR PANEL SLOT REPLACEMENT
(2)
M6 x 14
4mm

Step 6
Align the Whiteboard/Felt Tackboard into the Rear Panel Slot above at a slightly tilted angle.
Step 7
Insert the Whiteboard/Felt Tackboard into the Rear Panel Slot at an angle with a straight trajectory.
2 person
amqsolutions.com
AMOBI DESK Warranty Replacement Instructions Guide | 18
REAR PANEL SLOT REPLACEMENT
Rear Panel Slot
Notice : To avoid damage,
2 person is required while
installing/removing the
Whiteboard or Felt
Tackboard.

amqsolutions.com
Step 8
1. Ensure that the Rear Handset is aligned to the Handset Bezel opening. Press the Handset Bezel against
the frame to ensure that it is magnetically engaged.
2. Ensure that the Push-Lock is aligned with the Push-Lock Socket. Flatten the Whiteboard/Felt Tackboard
against the frame then press the Push-Lock Button on both sides to lock it in place.
Push-Lock
Button
A
B
B
Whiteboard/Felt Tackboard can be
locked or unlocked by pressing
the Push-Lock Button.
AMOBI DESK Warranty Replacement Instructions Guide | 19
LOCK UNLOCK
REAR PANEL SLOT REPLACEMENT

amqsolutions.com
REAR HANDSET REPLACEMENT
AMOBI DESK Warranty Replacement Instructions Guide | 20
COMPONENTS
Rear Handset
