AMQ ILINE User manual

Iline | Power & Data Beam amqsolutions.com
Power / Data Beam
Ilne

Iline | Power & Data Beam amqsolutions.com
Frame
120° Post
(3-way)
Beam DR End Foot
End Bracket Set SR End Foot
DR Center Foot SR Center Foot
ILINE Wire Tray Cable Management
Track
Linear
48", 60" and 72" widths
120°
with Activ-Pro3
Worksurfaces
Accessores
Screen Mounting Clips
Prvacy Screens & Panels
90°/180° Post
(2-way, 3-way, 4-way)
Soft Cable
Management
Side Screen3F Screens
01062019 01062019
f
Statement of Lne

Iline | Power & Data Beam amqsolutions.com
Frame
Fnshes
Frames
F1
Platinum
F2
White

Iline | Power & Data Beam amqsolutions.com
Electrcal
Each floor entry accepts
up to 24 CAT6 cables or 1
infeed/conduit
3 Circuit
Accepts 24 CAT6 cables, 1 conduit and 1 infeed
4 Circuit
Power Pole
Can accept
42 CAT6 cables,
1 conduit and
1 infeed
Junction Block
Duplex Jumper
Data Cables
Power
Pole
Base Feed
Iline beam technology distributes electrical with either 3 circuit/5 wire or 4 circuit/8 wire.
Jumpers – 4 Circuit/8 WireJumpers – 3 Circuit/5 Wire

Iline | Power & Data Beam amqsolutions.com
Electrcal
3 Circuit/5 Wire
4 Circuit/8 Wire
PLEASE NOTE Only one duplex per
user. Place duplexes in a criss-cross
pattern as shown.
120oILINE 6 Pack
ILINE 8 Pack
Line 2 duplex receptacles
used in each station to be
compliant with California
Title 24.
90oILINE 4 Pack
90oILINE 4 Pack
120oILINE 6 Pack
ILINE 8 Pack

Iline | Power & Data Beam amqsolutions.com
Cable Management Tracks
and Wire Trays
Up-mounted Privacy Screens
Power entry through side and
center legs and power poles
(3 or 4 circuit, 24 CAT cables)
Linear, 90, 120 and 180
configurations
Face Plates and Post Sleeves
Features
Installation Time
15 minutes
Care & Maintenance Instructions
Wipe with a damp cloth using water or gentle, nonabrasive
cleaner. For guaranteed safety, patch test with diluted
cleaner before wiping entire surface. Wipe dry with a clean
cloth.
Warranty
10 years, parts only.
Certifications
ANSI/BIFMA X5.5-2014
Indoor Advantage Gold™
