MVP-5200i Battery Replacement Guide
ATTENTION - READ THIS FIRST!
Lithium-Polymer batteries are small, compact, and ideal for providing long
lasting power. However, they must be used and charged properly. Improper use
can result in serious injury, fire, or explosion.
Please read and understand the following warnings. If you have any questions or
concerns with this product, please contact AMX.
WARNING: This installation requires opening the case of the MVP-5200i
and working within its internal components. If you are unwilling or unable
to replace the battery, please return the device to AMX for battery
replacement.
WARNING: Misuse of a Lithium-Polymer battery may result in overheating,
fire, or explosion!
To Avoid Injury, Never:
• Use near open flame or other heat source
• Puncture or disassemble battery
• Damage external contacts
• Dispose of battery in fire, water, or container with temperature above
100ºC (212ºF).
Always:
• Use only with AMX approved battery charger
• Store in dry place with temperature between 0° C (32° F) and 40° C
(104° F)
WARNING: Care must be taken to install the battery without damaging the
battery.
IMPORTANT NOTES!
NOTE: Lithium-Polymer battery technology degrades in capacity over time,
unless the battery is periodically charged and discharged. AMX recommends
installing all Lithium-Polymer batteries in functional AMX products within 6
months of receipt.
NOTE: Please dispose of all used batteries in a proper fashion as required by
municipal or federal regulations.
Overview
The MVP-5200i uses a MVP-BP-5X Lithium-Polymer microbattery (57-0016-SA)
for power away from a standard power source. The battery can be deep-charged
up to 300 times before it loses the ability to retain more than 70 percent of its
charge, at which time battery replacement should be considered.
Specifications
READ THESE INSTRUCTIONS FIRST!
To minimize the risk of damage to the battery during installation, all replacement
batteries come in a protective metal cover. This cover cannot be removed from
the battery.
Replacing the battery
IMPORTANT: Do NOT discharge the battery before installing the latest
MVP-5200i firmware (v2.66.17 or later), available at www.amx.com. Prior to
battery removal, run the device until the battery is completely discharged.
To remove an old battery and replace it:
1. Remove the battery from its packaging, remove the protective film from the
battery, and inspect it for any damage or distortion. If the battery shows
evidence of damage, contact AMX for replacement and proper disposal
information.
2. Place the device face-down on a surface that will not scratch the unit and
remove the five screws from the back of the device (FIG. 1).
• Two of the screws are at the upper corners of the device, underneath
rubber feet that also act as screw covers. Remove the rubber feet to
access the screws.
• Lift up the kickstand and remove the label to reach the remaining three
screws.
NOTE: The three bottom screws are shorter than the top two screws. The
screws must be re-assembled in their original location or the device can be
damaged during reassembly.
3. Discharge all static electricity that may have built up on your body, either by
using a static discharge strap or by touching a nearby piece of metal.
4. Carefully remove the back of the device and detach the battery lead at the
battery connector (FIG. 2). This will allow the back cover to be detached
from the device.
MVP-BP-5X Battery Pack Kit (FG5966-01BAT) Specifications
Dimensions: 4 1/8” x 2 1/2” x 3/8” (10.48 cm x 6.35 cm x 0.95 cm)
Weight: 0.35 lbs (158.76 g)
Certifications: • CE (pending)
• IEC/EN-60950
•RoHS
• UN/IATA
• UL (pending)
Operating/Storage
Environment • Operating Temperature: 0° C (32° F) to 45° C (113° F)
• Operating Humidity: 20% - 85% RH
• Storage Temperature: -20° C (-4° F) to 60° C (140° F) for
periods of less than one month, -20° C (-4° F) to 45° C
(113° F) for less than three months but greater than one
month, and -20° C (-4° F) to 20° C (68° F) for less than
one year but greater than three months
• Storage Humidity: 5% - 85% RH
Included Parts • Replacement MVP-5200i battery (57-0016-SA)
• Upper rubber feet (screw covers, black, 60-5966-13BL;
and grey, 60-5966-13GR)
• Replacement label to cover lower screws:
black (91-5966-01BL) and white (91-5966-01WH)
• Bottom rubber feet (black, 60-5966-12BL;
and grey, 60-5966-12GR)
FIG. 1 Screw placement at the back of the MVP-5200i-GW
FIG. 2 Interior of MVP-5200i, including female battery connector
Upper screws (underneath
Lower screws (underneath
Kickstand
IR emitter panel
label)
rubber feet)
Battery Connector

For full warranty information, refer to the AMX Instruction Manual(s) associated with your Product(s).
12/12
©2012 AMX. All rights reserved. AMX and the AMX logo are registered trademarks of AMX.
AMX reserves the right to alter specifications without notice at any time.
3000 RESEARCH DRIVE, RICHARDSON, TX 75082 • 800.222.0193 • fax [phone] • technical support 800.932.6993 • www.amx.com
93-5966-27 REV: B
Remove the old battery
1. Remove the two screws holding the battery case to the back cover
(FIG. 3). Retain these screws, as they will be used to hold the new
battery.
2. Carefully remove the battery from the back cover. Please dispose of the
battery in a proper fashion as required by municipal or federal regulations.
Install the new battery
1. Open the plastic bag containing the MVP-BP-5X kit, taking care not to
use sharp instruments near the battery itself.
2. Remove the protective film on the battery case. DO NOT install the
battery without removing this film.
3. Attach the new battery to the back cover, using the two screws used to
hold the previous battery to the cover..
Reconnecting the battery to the device
1. On the back cover, make sure that the battery connector wiring runs to
the right. Make sure that the excess battery wiring fits in the space to the
bottom left of the battery placement (FIG. 4). The battery wiring may be
looped around the support if necessary; make sure that the battery is not
crimped or damaged upon closure of the case.
2. Make sure to seat fully the battery plug to the connector in the device
(FIG. 2). If fingers cannot be used, use a clean, nonconductive stick or
probe to seat the connectors.
NOTE: Special care must be taken to seat the battery plug so that it does
not damage or rub against the two resistors near the battery connector.
When connecting the battery, do not allow the battery plug to rub against
the circuit board.
3. Reattach the back of the device, engaging the hook on the lower left of
the case (near the speaker) and using it to swing the back down into
place.
WARNING: When reassembling the device, take especial care not to
pinch or squeeze the connector wiring or the battery. Do not force the
back cover onto the device, as this can damage the device
4. Insert the five screws and replace the rubber feet atop the two upper
screws, using the replacement rubber feet included in the Battery Pack
Kit (FIG. 5). Replace the bottom label over the three bottom screws, using
the replacement label included in the Battery Pack Kit.
NOTE: The three bottom screws are shorter than the top two screws. The
screws must be re-assembled in their original location or the device can be
damaged during reassembly.
5. Restart the device to confirm that the new battery is functioning correctly.
For more information on battery replacement and installation, please refer to
the MVP-5200i Modero Touch Panel Operator/Reference Guide, available from
www.amx.com.
FIG. 3 MVP-5200i back cover with battery installed
FIG. 4 Path of excess battery wiring
MVP-BP-5X battery Battery plug
Battery screws
MVP-BP-5X battery placement
Excess battery wiring path
Resistor location
FIG. 5 MVP-5200i back plate installation
Rubber feet
Upper screws
Bottom label
Bottom screw
holes
Front of MVP-5200i
Back cover
Bottom
screws
Speaker
