AnyCubic VYPER User manual

Thank you for choosing ANYCUBIC products.
Maybe you are familiar with 3D printing technology or have purchased
ANYCUBIC printers before, but we still highly recommend that you read this
manual carefully. The installation techniques and precautions in this
manual can help you avoid any unnecessary damage or frustration.
More information please refer to :
1. ANYCUBIC Website: https://www.anycubic.com
ANYCUBIC website provides software, tutorials, models, after-sale service,
etc.
Please visit the website for technical support and we are pleased to
answer the questions or solve all the problems for you!
2. Facebook page and Youtube channel links are shown below.
Facebook page Youtube channel
ANYCUBIC Website
Team ANYCUBIC
Copyrighted by “Shenzhen Anycubic Technology Co., Ltd ”, all rights reserved.

Contents
Safety Instructions
Technical Specification
Packing List
Product Overview
Menu Directory
Installation
Leveling
Loading Filament
Printing Models
Introduction to Slicing
Software
Resume from Outage
Maintenance
Troubleshooting
4
5
7
8
9
14
22
24
27
31
46
47
48

www.anycubic.com
4
Safety Instructions
Please contact our customer service first if you have any
problem after receiving the products.
Be cautious when using the scraper. Never direct the scraper
towards your hand.
In case of emergency, please immediately cut off the power of
ANYCUBIC 3D printer and contact the technical support.
ANYCUBIC 3D printer includes high speed running parts that can
cause injury.
It is recommended to use protection glasses when
cleaning/sanding the printed models to avoid small particles in
eyes.
Keep the ANYCUBIC 3D printer and its accessories out of the reach
of children.
Vapors or fumes may be irritating at operating temperature.
Always use the ANYCUBIC 3D printer in an open and well ventilated
area.
ANYCUBIC 3D printer must not be exposed to water or rain.
ANYCUBIC 3D printer is designed to be used within ambient
temperature ranging 8ºC-40ºC, and humidity ranging 20%-50%.
Working outside those limits may result in low quality printing.
Do not disassemble ANYCUBIC 3D printer, please contact technical
support if you have any question.
To avoid any unnecessary damage to the printer or individual injury,
please always follow the safety instructions when assembling and using
the machine.

www.anycubic.com
5
Technical Specification
Printing
Technology
FDM (Fused Deposition Modeling)
Build Size
245 mm(L) × 245 mm(W) × 260 mm(H)
Print Accuracy
±0.1 mm
Positioning Accuracy
X / Y / Z 0.0125 / 0.0125 / 0.002 mm
Extruder Quantity
Single
Nozzle Diameter
0.4 mm
Print Speed
20~100 mm/s (suggested 80 mm/s)
Supported Materials
ABS, PLA, TPU, PETG, Wood, etc
Temperature
Ambient Operating
Temperature
8 °C - 40 °C
Operational Extruder
Temperature
Max 260 °C
Operational Print Bed
Temperature
Max 110 °C
Software
Slicing Software
Cura
Software Input Formats
.STL, .OBJ, .AMF
Software Output Formats
GCode
Connectivity
Memory card; Data cable (expert users
only)

www.anycubic.com
6
Technical Specification
Electrical
Power Input
110 V / 220 V AC, 50 / 60 Hz
Output rating
24V/14.6A (350W)
Physical Dimensions
Printer Dimensions
508 mm(L) × 457 mm(W) × 516 mm(H)
Net Weight
~10 kg

www.anycubic.com
7
Packing List
Frame
Base
Washers (4PCS)
M5 x 45 Screws (4PCS)
Touchscreen
M5 x 14 Screw
(1PCS)
M5 x 6 Screws
(2PCS)
Filament Holder
Nozzle
Power Cord
Data Cable
Card Reader
Memory Card
Filament (Random
Color)
Assembly
Instruction
Tips: Some accessories are placed in the toolbox on the right front of the
machine base (see the position of toolbox on the next page). Please take
out all the accessories from the toolbox when you check the accessories
list.

www.anycubic.com
8
Product Overview
Filament holder Printing platform
Teflon feeding tube
Print head
X motor
Z motor
Z limit switch
Y limit switch
Extruder
Lead screw
Aluminum beam
Front view
Back view
Y motor
Touchscreen
Memory card slot
Data cable port
Filament sensor
Toolbox
Y belt tensioner
X belt tensioner
Extrude
r motor

www.anycubic.com
9
Menu Directory
Main menu

www.anycubic.com
Note: In most cases, there is no need to perform “Z-offset” after auto-
leveling.
Leveling:
Print
10
Menu Directory
Page up Page down
Refresh the list
Return to main menu
File list
Print the selected
file in memory card
Prepare
File List:
Click to level the
platform automatically Click to fine-tune the
distance between nozzle and
platform after auto-leveling
Resume form outage (only valid
for offline print via memory card)

www.anycubic.com
Filament:
Preheat:
11
Menu Directory
Display current /
target temp of nozzle
Click to automatically heat
the print head to target temp,
and click again to feed the
filament
Stop filament
feeding or
retracting
Display current /
target temp of bed
Click to preheat PLA
Click to preheat PLA
Display current /
target temp of
extrusion
23/230
Click to automatically heat the
print head to target temp, and
click again to retract the
filament

www.anycubic.com
Move Axis:
Tools
Temperature:
12
Menu Directory
Move the platform
back
Move the print head down
Click to home all
Move the platform forward
Click to set extrusion temp (170-260℃)
Click to set bed temp (30-110℃)
Display the current temp of bed
Cut off the power to hot-
end and heated bed (only
valid when machine is not
printing)
Set the step distance of motor
Move print head to the
left
Move print head to the
right
Move the print head up
Display the current temp of extrusion
Reduce bed
temp
Raise bed temp
Reduce extrusion
temp
Raise extrusion temp

www.anycubic.com
Light: Turn on/off the light of the print head
About: Display the information about the product.
Voice: Turn on/off the screen sound.
Language: Change language (English / Chinese).
System
Motor: Disable all motors (only valid when machine is not printing).
Speed:
13
Menu Directory
Click to set fan speed(0-100%)
Click to set print rate(0-100%)
Decrease print rate Increase print rate
Decrease fan speed Increase fan speed

www.anycubic.com
14
Installation
1. Be cautious during assembly as some parts may have sharp edges.
2. It is suggested to use a flat desktop and place the parts in an orderly
manner for quick assembly.
3. The color of some parts may be different from what in the manual,
but the assembly is the same.
4. Firmware has been pre-uploaded to the motherboard. After
completing the assembly, please level the platform and load the
filament then you could start the first test print.
Note: Every unit of the printer has been inspected and tested for printing.
Therefore, in some cases, there might be very small marks left on the
print head or on the heated bed. Those will not affect the printing quality
and those mean the printer has been tested for the quality. The aluminum
beam has slight scratches or slight unevenness on the platform, which is
normal if it does not affect normal printing. Thank you very much for your
kind understanding.
Team ANYCUBIC

www.anycubic.com
* Take tools from the toolbox on the front right side of the machine base
for assembly.
15
Installation
1. Install frame.
Washer
M5*45 screw
Z aluminum beams must
align with the groove of
the base aluminum beam.

www.anycubic.com
16
Installation
2. Install touchscreen.
M5*14 screw X
1
M5*6 screw X
2
3. Install the filament holder.

www.anycubic.com
17
Installation
4. Insert the teflon tubing into the extruder.

www.anycubic.com
18
Installation
5. Wiring: connect all these wires to their corresponding ports by the
label respectively.
2. Screen wires
3. Extruder/X motor wires
7. Left Z motor
6. Left Z limit switch
4. Right Z limit switch
5. Right Z motor
2
3
4,
5
6,
7
1
1. Print head wires

www.anycubic.com
19
Installation
6. Use zip ties to fasten the print head wire harness and the Teflon tube.

www.anycubic.com
20
Installation
Check before using
1. Make sure that the 4 zip ties shown below have been cut off before
operating the machine.
2. D-shape wheels of the base may be loosened due to transportation,
please check it after unpacking.
Place the base on a flat desktop. Shake the platform to confirm whether
the printing platform is shaking up and down. If so, please tighten the
hexagonal pillars of the D-shape wheels on the right under the platform.
•Move the platform to the front for tightening the pillar A.
•Move the platform to the rear for tightening the pillar B.
