Aquatic BLUECUBE6 BC6 MINI Guide

PLEASE READ THIS INSTRUCTION MANUAL BEFORE
INSTALLATION AND OPERATION
USER / INSTALLATION MANUAL
BC6 MINI
BLUECUBE ‘HIDE-AWAY’ MEDIA PLAYER
for Bluetooth Audio & MP3 devices

1 Getting Started....................................................................................................................
1.1 Contents........................................................................................................................
1.2 Connections...................................................................................................................
1.3 12-pin Harness Connection...........................................................................................
1.4 Mounting the BC6 MINI..................................................................................................
1.5 Bluetooth Antenna Installation......................................................................................
1.6 Power Attenuation Wires................................................................................................
1.7 Electronic Crossover Mode.............................................................................................
1.8 Power On.......................................................................................................................
1.9 Handheld Remote Control Charging..............................................................................
1.10 Handheld Remote Control Synchronizing.....................................................................
2 Location of Controls............................................................................................................
2.1 Wireless Handheld Remote Control.................................................................................
3 Listening to Devices............................................................................................................
3.1 Switch Input Mode without Using Remote Control.........................................................
3.2 Listening via Bluetooth Audio Using Remote Control.....................................................
3.2.1 Pair with Bluetooth Audio Device............................................................................
3.2.2 Listening via Bluetooth Audio Device......................................................................
3.2.3 Bluetooth Multi-link................................................................................................
3.3 Listening via Auxiliary Input Using Remote Control.......................................................
3.4 Adjust Volume Level without Using Remote Control.......................................................
3.5 Adjust Volume Level Using Remote Control...................................................................
4 Additional Features.............................................................................................................
4.1 Audio Menu....................................................................................................................
4.2 Virtual Bass (VBass)......................................................................................................
4.3 External 12V Triggers.....................................................................................................
4.4 Bluetooth Halo Aerial Technology...............................................................................................
5 Specifications & Dimensions..............................................................................................
5.1 Specifications................................................................................................................
5.2 Dimensions....................................................................................................................
6 Warranty Information..........................................................................................................
3
3
3
4
5
5
5
6
7
7
7
8
8
9
9
9
9
9
9
10
10
10
11
11
11
11
11
12
12
12
13
Table of Contents BlueCube Media Player BC6 MINI
2www.aquaticav.com

1.2 Connections (see Diagram 1.2.1)
1. 12-pin Watertight Harness
The 12-pin harness supplies power and ground connections to the BC6 MINI and four (4)
speaker channel output connections from the BC6 MINI (see Wiring Diagram 1.3.1).
Do not cut or modify the 12-pin harness on the BC6 MINI side or warranty will be void.
2. RCA (Rear) Outputs
Allows external amplifiers to be connected to power additional speakers.
3. Auxiliary Inputs
Allows an additional RCA input source from a standalone unit or another stereo source.
4. Remote 8-pin DIN Cable (x2)
Allows connection of the optional wired and wireless Remote Controls (sold separately).
5. 12V DC External Trigger (x2)
Allows for external lighting or relays to be triggered (3A max load). This feature is only
available when using the optional Remote Controls (sold separately).
6. Power On LED
When the BC6 MINI is powered On the LED will illuminate red.
7. Bluetooth Halo Aerial Connector
Connect the Bluetooth Halo Aerial Technology Antenna (AQ-BTANT-1) to the male SMA
connector. Do not apply excessive torque on the SMA connector (no more than 0.5N-m). Use
hands to tighten the connection (do not use a wrench). See section 1.5.
8. Electronic Crossover Wire
Allows the left and right rear channels to be used to power a dual voicecoil passive subwoofer
(e.g. Aquatic AV AQ-SWP8-2) instead of speakers. See section 1.7 for further details.
9. Power Attenuation Wires
Allows the output level to be adjusted from a factory preset of -3dB to either -6dB, 0dB or
+6dB. See section 1.6 for further details.
Aquatic AV does not recommend the wired Remote Control for use in spa applications.
1.1 Contents
• BC6 MINI BlueCube Media Player
• Wiring Harness (AQ-UNH-2)
• Four (4) Stainless Steel Mounting Screws
• User/Installation Manual
• Mounting Template
• Bluetooth Antenna
Getting Started BlueCube Media Player BC6 MINI
3www.aquaticav.com

1.2.1 Connections Diagram
1. 12-pin Watertight Harness
2. RCA (Rear) Outputs
3. RCA Auxiliary Inputs
5. 12V DC Triggers (2x red, 2x red/black stripe)
4. Wired & Wireless Remote 8-pin DIN
Connectors (Black)
6. Power On LED
7. Bluetooth Halo Aerial Connector
9. Power Attenuation Wires (1x white, 1x black)
8. Electronic Crossover Wire (red/white stripe)
If your BC6 MINI was purchased from an Aquatic AV dealer and/or supplied with retail packaging
it is supplied with the Aquatic AV universal harness AQ-UNH-2 in order to connect the BC6 MINI
to power and speakers. Please proceed to section 1.3.1.
If your BC6 MINI was supplied as a pre-installed waterproof entertainment system it will utilise
3rd party wiring connections and is not supplied with the Aquatic AV 12-pin Harness. Please
proceed to section 1.4.
1.3 12-pin Harness Connection (retail packaged models only)
All open wire connections should be soldered and protected against water and dust for best long-term performance.
1.3.1 12-pin Harness Wiring Diagram
No lower than a 2 Ohm load should be used
or damage may occur to the BC6 MINI.
Make sure the polarity of speakers are
connected correctly.
(Green/Black stripe)
(Green)
(White/Black stripe)
(White)
(Gray/Black stripe)
(Gray)
(Purple/Black stripe)
(Purple)
Getting Started BlueCube Media Player BC6 MINI
4www.aquaticav.com

1. Make sure the outside surface is clean
and clear of debris.
2. The BC6 MINI has four (4) front screws.
Drive the screws using a screw driver.
Make sure screws are snug and do not over
tighten.
1.4. Mounting the BC6 MINI
1.5 Bluetooth Antenna Installation
1. Screw on the provided Bluetooth Antenna,
avoiding bending the cable at a 90° angle.
2. Install the Bluetooth antenna as high as
possible, above the waterline of the spa if possible,
and making sure the arrow is pointing directly
upwards towards the sky to ensure the Bluetooth
range is maximized. If there is no suitable surface
to screw it in, we recommend using a good quality
double sided tape.
1.6 Power Attenuation Wires
The BC6 MINI’s power can be reduced or
increased to suit different applications.
An output level of -3dB or -6dB should be
used to avoid blowing very small speakers,
often used in spa applications.
By cutting only the white wire the output
level will decrease to -6dB below the nominal 0dB.
By cutting both the white and black wires the power/volume will increase to +6dB above the
nominal 0dB.
By cutting only the black wire the power/volume will increase from -3dB to the nominal 0dB.
These modifications should only be carried out by an experienced audio installer.
Black Wire White Wire Output Level
Intact (not cut) Intact (not cut) -3dB
Intact (not cut) Cut -6dB
Cut Intact (not cut) 0dB (reference)
Cut Cut +6dB
Should you cut the wrong wires or wish to reconnect them to further alter the attenuation, the Power Attenuation
Wires can be crimped back together.
Getting Started BlueCube Media Player BC6 MINI
5www.aquaticav.com

1.7 Electronic Crossover Mode
The BC6 MINI is capable of powering up to eight 4 Ohm speakers, however should you wish to
power a dual-voicecoil subwoofer, in addition to standard speakers, this can be achieved by using
the two rear speaker channels in Electronic Crossover Mode.
In Electronic Crossover Mode you will only be able to power up to four 4 Ohm speakers (two from
the front left channel and two from the front right channel) plus a dual voicecoil subwoofer. See
section 1.7.1.
Cut the Electronic Crossover wire (red/white stripe) to place the BC6 MINI in Electronic Crossover
Mode. You will now be able to use the left and right rear channels in Mono mode to power a dual-
voicecoil passive subwoofer, such as the Aquatic AV AQ-SWP8-2.
These modifications should only be carried out by an experienced audio installer.
1.7.1 Four Speakers & One Dual Voicecoil Subwoofer Set Up
No lower then a 2 Ohm
load in stereo mode, or
4 Ohm load in Electronic
Crossover mode, should be
used. Damage may occur
to the BC6 MINI if incorrect
Ohm load is used.
Make sure the polarity of
speakers are connected
correctly.
FUSE
BOX
ACC (1) (Red)
+12V DC (4) (Yellow)
Power Antenna (7) (Blue)
DC Ground (10) (Black)
Please put a fuse into
the fuse box
Left Rear Speaker
LR- (2) (Green/Black stripe)
LR+ (3) (Green)
Right Rear Speaker
RR- (11) (Purple/Black stripe)
RR+ (12) (Purple)
Left Front Speakers
LF- (5) (White/Black stripe)
LF+ (6) (White)
Right Front Speakers
RF- (8) (Gray/Black stripe)
RF+ (9) (Gray)
4 Ohm
4 Ohm
Dual
Voice Coil
4 Ohm
In Electronic Crossover Mode the rear RCA outputs will also be affected by the crossover and will output only low-
frequencies below the crossover frequency.
Getting Started BlueCube Media Player BC6 MINI
6www.aquaticav.com

The BC6 MINI requires +12V DC to both the red and yellow wires. When both of these wires have
power the BC6 MINI is always powered on, indicated by a red LED on the heatsink of the BC6
MINI. Ground is connected to the black wire.
In a spa application this requires the red and yellow wires to be jumped together and then
connected to the +12VDC output of the power source. In this set up the BC6 MINI will always be
on, with a very low current draw when idle.
In a boat, ATV or other application requiring power from a battery, the yellow wire (constant
power) should be connected to the battery, and the red wire should be connected to the ignition
or a switch.
For detailed instructions you can check out our online video:
‘How to wire your Aquatic AV stereo system’
http://www.aquaticav.com/support/videos
1.8 Power On
The optional remote RF6 REMOTE KIT (sold separately) has a built-in Polymer Lithium re-
chargeable battery and comes with a charging cable. Connect one end of the charging cable
to the charging connection on remote control and connect the USB end of the charging cable
to any USB charger (5V DC) for charging.
Make sure the remote has been charged before used.
1.9 Handheld Remote Control Charging
The optional remote RF6 REMOTE KIT (sold separately) should include an RF receiver and
should already be paired from the factory. Plug the RF receiver into the remote control 8-pin
DIN connections on the BC6 MINI. If you need to synchronize the remote, follow the steps
below.
1. Make sure BC6 MINI is powered ON (red LED)
2. Put the remote within 0.5 meter of the BC6 MINI.
3. Press and hold MODE on remote control until the LCD shows “Pairing in Progress”. Re-
lease the button.
4. Within 2 seconds, the LCD will show “Paired”. If it fails to pair, the LCD will show “Retry
again”. If this happens, wait 5 seconds and repeat steps above.
For any additional remote controls, you will also need to synchronize those remote controls to
the BC6 MINI.
1.10 Handheld Remote Control Synchronizing
If the pairing process is not successful, try again to put your remote close to the remote receiver or charge the remote
control if the battery is low.
Depending on the frequency of usage, the remote may drain its battery. Please charge the remote before use. If the LCD
shows nothing, the battery has been drained and will need charging.
If you have lost or damaged your remote control and buy a new remote control, follow the above steps to pair the
new remote control.
Getting Started BlueCube Media Player BC6 MINI
7www.aquaticav.com

2.1 Wireless Handheld Remote Control RF6 REMOTE KIT (sold separately)
Location of Controls BlueCube Media Player BC6 MINI
8www.aquaticav.com

3.2.2 Listening via Bluetooth Audio Device
1. Bluetooth Audio mode will be activated once a Bluetooth Audio device is paired in any
mode. Use MODE to change to the Bluetooth Audio mode to listen to music.
2. Play the song from device and the sound will play through the BC6 MINI.
3. Press PLAY/PAUSE to play/pause the song.
4. Press FAST REWIND/FORWARD buttons to play previous/next song file.
5. Press and hold FAST REWIND/FORWARD buttons to fast forward / fast rewind the song
file.
6. Previous/next track and volume up/down can be controlled directly from your Bluetooth
Audio device or directly from the BC6 MINI remote control.
3.2.3 Bluetooth Multi-link
A second Bluetooth Audio device can pair to the BC6 MINI even when music is playing from
the first Bluetooth Audio device.
Once paired, playing music from device 2 will override device 1 and the BC6 MINI will begin
playing music from device 2.
Should you wish to play music from device 1 again, wait 10 seconds and press play on
device 1. This process can be repeated between device 1 and device 2 indefinitely while
both devices are paired.
1. Switch on your Bluetooth Audio device.
2. Select ‘AQUATIC AV’ from the list of available devices to pair (no password is needed).
3.2.1 Pair with Bluetooth Audio Device
3.2 Listening via Bluetooth Audio Using Remote Control (sold separately)
When the BC6 MINI is powered ON, both Bluetooth Audio and Auxiliary inputs are operational.
If a Bluetooth Audio device is connected (paired) first the BC6 MINI will automatically switch into
Bluetooth mode.
If an Auxiliary devices is connected first then BC6 MINI will automatically switch into AUX mode.
In case both Bluetooth Audio and the Auxiliary input are connected at the same time the BC6
MINI will not output any audio.
Pause or disconnect one of the input modes (Bluetooth Audio or Auxiliary) to let the other mode
take priority and audio from the prioritised mode will then begin to play.
3.1 Switch Input Mode without Using Remote Control
Listening to Devices BlueCube Media Player BC6 MINI
9www.aquaticav.com

3.3 Listening via Auxiliary Input Using Remote Control (sold separately)
1. Connect your MP3 device to the RCA inputs.
2. Press MODE on the remote control to select ‘AUX’ mode.
Only one Auxiliary input (RCA) can be used at any one time.
3.4 Adjust Volume Level without Using Remote Control
Use either your Bluetooth Audio or Auxiliary device’s volume control to adjust volume up or down.
3.5 Adjust Volume Level Using Remote Control (sold separately)
1. Press VOLUME UP once to increase the volume.
2. Press VOLUME DOWN once to reduce the volume.
3. Press and hold either VOLUME UP or VOLUME DOWN to increase or decrease audio
volume continuously.
Listening to Devices BlueCube Media Player BC6 MINI
10www.aquaticav.com

4.1 Audio Menu with Handheld Remote Control (sold separately)
When the optional remote control RF6 REMOTE KIT (sold separately) is used with the BC6 MINI
several functions are unlocked. The audio DSP (Digital Signal Processor) provides preset listening
experiences for different music types.
1. To enter audio menu, press once AUDIO
button.
2. Each press of AUDIO button will advance
to the next audio setting as described on
the right.
3. In the audio menu, press and hold
AUDIO to save and exit the audio menu
back to the original mode.
4.2 Virtual Bass (VBass) with Handheld Remote Control (sold separately)
Virtual Bass (VBass) boosts the bass of the audio signal using the latest DSP technology and is
particularly useful when used with very small speakers to create perceived bass frequencies of a
much larger speaker.
Press VBASS once on the remote control to toggle it ON or OFF.
If you have chosen preset equalizer (Rock, Classic,
or Pop), the previous Bass & Treble settings will be
overridden.
Aquatic AV understands the need for more flexible remote applications. With the BC6 MINI
Aquatic AV has provided two independent 12V ‘accessory’ triggers, activated from the remote
control. These could activate any 12V (3A max) based device, such as 12V lighting or 12V
motors.
In any operational mode, press the 12V TRIGGER button on the remote control to activate. Press
again to deactivate.
If using two external trigger wires you can also activate the second external trigger by pressing
and holding the 12V TRIGGER button to activate. Press and hold again to deactivate.
4.3 External 12V Triggers with Handheld Remote Control (sold separately)
Load on External Trigger should not exceed 3A.
Aquatic AV strongly recommend you speak to our technical service staff or your local Aquatic AV dealer if you are
considering using this feature.
4.4 Bluetooth Halo Aerial Technology
The Bluetooth Halo Aerial Technology antenna AQ-BTANT-1 (included) improves the standard
Bluetooth wireless signal and range, for a stronger signal and increased range.
Additional Features BlueCube Media Player BC6 MINI
11www.aquaticav.com

5.2 Dimensions
Media
Supported media....................................
Device Control.......................................
Inputs
Auxiliary................................................
Outputs
Pre-Out (Rear).......................................
12V Triggers..........................................
Power
Output voltage @ 2 Ohm.........................
Output voltage @ 4 Ohm.........................
Operation voltage....................................
Max current draw....................................
Standby current draw..............................
Multi-Environment Certifications
Waterproof / Dustproof............................
Conformal PCB coating...........................
UV protection.........................................
Salt/Fog protection.................................
Stainless Steel mountings.......................
Bluetooth Audio / MP3 / AUX
via Handheld RF Remote Control or Wired Remote Control (both sold separately)
1x stereo pair RCA
1x stereo pair RCA (2V)
2x 12V DC Triggers (3A)
4x 72W
4x 45W
9.6V - 14.4V DC
7A
6mA
Yes - IP65
Yes
500 hours stable, ASTM D4329 compliant
500 hours stable, ASTM B117 compliant
Yes
5.1 Specifications
107mm
32mm24mm
119.5mm
107mm
168mm76mm
12mm
Specifications & Dimensions BlueCube Media Player BC6 MINI
12www.aquaticav.com

Aquatic AV offers a limited warranty of our products on the following terms:
Length of warranty
2 years on audio systems, electronics, speakers, and accessories (receipt required).
Coverage
This warranty covers only the original purchaser of an Aquatic AV product purchased from an
authorized Aquatic AV dealer. In order to receive service, the purchaser must provide Aquatic AV
with a copy of the receipt stating the customer name, dealer name, product purchased and date
of purchase.
Defective products
Products found to be defective during the warranty period will be repaired or replaced (with a
product deemed to be equivalent) at Aquatic AV’s discretion.
What is not covered
Damage caused by accident, abuse, improper operations or theft. Any cost or expense related to
the removal or reinstallation of product. Service performed by anyone other than an authorized
Aquatic AV service center. Any product with the serial number or tamper labels defaced, altered,
or removed. Subsequent damage to other components. Any product not purchased from an
authorized Aquatic AV dealer.
Limit on implied warranties
Any implied warranties including warranties of fitness for use and merchantability are limited
in duration to the period of the express warranty set forth above. Some states do not allow
limitations on the length of an implied warranty, so this limitation may not apply. No person is
authorized to assume for Aquatic AV any other liability in connection with the sale of the product.
How to obtain service
You must obtain a return material authorization number (RMA) to return any product to Aquatic
AV. You are responsible for shipping charges of returned products to Aquatic AV.
Please record the model and serial number[s] of your equipment in the space provided below as
your permanent record and will assist us with your factory warranty coverage. These numbers can
be found on the rear of the BC6 MINI.
Model number[s]: Serial number[s]:
Warranty Information BlueCube Media Player BC6 MINI
13www.aquaticav.com

FCC ID:
MADE IN CHINA
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
NOTE:
The equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Consult the dealer or an experienced radio/TV technician for help.
The manufacturer is not responsible for any radio or TV interference caused by unauthorized
modifications to this equipment. Such modifications could void the user authority to operate
the equipment.
Product design and specification subject to change without notice. E&OE.
Doc V1.1
FCC Statement BlueCube Media Player BC6 MINI
14www.aquaticav.com

E-mail: [e-mail]
US & Canada: 1 877 579 2782
International: [phone]
Fax: [phone]
www.aquaticav.com
Aquatic AV
282 Kinney Drive
San Jose, CA 95112, USA
