Argos 044 0502 Series User manual

Assembly Instructions -Please keep for future reference
Width - 66.8cm
2 Door Cupboard
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08450613967
Please turn to back page for important information when contacting Customer Helpline.
Dimensions
Depth - 34.8cm
Height - 72cm
Rev B - 30.09.10
044 xx 0502
PDF processed with CutePDF evaluation edition www.CutePDF.com

Important - Please read these instructions fully before starting assembly
Safety and Care Advice
Check you have all the
components and tools listed on
pages 2 and 4.
Remove all fittings from the
plastic bags and seperate them
into their groups.
Keep children and animals
away from the work area, small
parts could choke if swallowed.
Make sure you have enough
space to layout the parts before
starting.
Do not stand or put weight on
the product, this could cause
damage.
Assemble the item as close
to its final position (in the same
room) as possible.
Assemble on a soft level
surface to avoid damaging the
unit or your floor.
Parts of the assembly will be
easier with 2 people.
We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
Care and maintenance
Always lift furniture when
moving it (do not drag)
otherwise the joints may be
damaged.
From time to time check that
there are no loose screws on
this unit.
This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
1
Dust surfaces with a soft, dry,
lint free cloth.
More stubborn marks can be
removed using a damp
(not wet) cloth. Wipe the
surface dry immediately
using a soft lint free cloth.
Do not use detergants, abrasive
cleaning products or cleaning
products that contain ammonia,
solvents or silicone as these
may damage the surface finish.
To protect the furniture,
position the furniture out of
direct sunlight and away from
direct heat sources such as
radiators and fires.
Do not place the furniture in
excessively dry and humid
conditions.
Do not place hot or cold
objects on the surface, always
use protective mats to avoid
marking the furnture.
Clean spills up immediately
Dispose of all packaging
carefully and responsibly
when assembly complete.
Do Not dispose of packaging
until assembly complete.

Please check you have all the panels listed below
Components -Panels
Left hand end (66x33cm) Right hand end (66x33cm)
Code - Code -
2
Important - Thick lines indicate finished edges
7530 7531
Top (66.8x34.8cm)
Backpanel (67x64.4cm)
Code - 7534
Shelf (63.4x31cm)
Code - 7532
Bottom (66.8x34.8cm)
Door x 2
(65.4x32.9cm)
Code -
7533
7529
7528
Code - Code -

3
Components -Exploded View
Important - Thick lines indicate finished edges
7528
7529
7530
7531
7534
7533 7532
7533

70 80 90 100 110 120
010 20 30 40 50 60
mm
130 140 150 160 170
Ruler - Use this ruler to help correctly identify the screws
Please check you have all the fittings listed below
Components-Fittings
Note: The quantities below are the correct amount to complete the assembly, In some case more fittings
may be supplied than are required.
Tools required
If you have damaged or missing components, call the
Customer Helpline: 0845 0613967 Please turn to back page
for important information when contacting Customer Helpline.
4
Cross headed screwdriver
(medium & large )
Small Hammer
Tape Measure
Eye protection
(when using a
hammer)
Large cam x 8 - Code 760001103 Metal dowel x 8 - Code 760003004 12mm screw x 8 - Code 690001008
25mm screw x 4 - Code 690001021
Handle x 2
Code 644396000
ABD
GJ
L
45mm screw x 4 - Code 690001075
K
N
22mm screw x 4 - Code 690001018
Glide feet x 4
Code 720001904
Bradawl
M
Wooden dowel x 4
Code 770001006
O
Straight arm 26mm
hinge x 4
Code 652001128
P
Hingeplate x 4
Code 653006000

Step 1
Assembly Instructions
5
Fittings you will need for this step:
B
B
B
B
B
(x4)
Note: Insert metal
dowels as far as
shown by arrows.
Do not over tighten.
B
Note: Ensure cam
arrow points towards
the edge with hole.
A
Fittings you will need for this step:
A
(x4)
Fitting dowels to top
panel
Step 2
Fitting cams to
shelf
Large
7528
B
A
A
A
A
7532

Step 3
Assembly Instructions
6
Fittings you will need for this step:
B
B
(x2)
Note: Insert metal
dowels as far as
shown by arrows.
Do not over tighten.
B
Note: Ensure cam
arrow points towards
the edge with hole.
A
Fittings you will need for this step:
A
(x2)
Fitting cams, metal
dowels and wooden
dowels to left end
Step 4
Large
7530
B
A
Fitting hingeplates to
left hand end panel
P
(x2)
A
B
Notch in Hingeplate points
towards front finished edge.
P
Front
finished
edge
P
M
M
M
(x2)
Use a hammer to
knock in wooden dowels
into inner holes.
M
M
P
7530

Step 5
Assembly Instructions
7
Fittings you will need for this step:
B
B
(x2)
Note: Insert metal
dowels as far as
shown by arrows.
Do not over tighten.
B
Note: Ensure cam
arrow points towards
the edge with hole.
A
Fittings you will need for this step:
A
(x2)
Fitting cams, metal
dowels and wooden
dowels to right end
Step 6
Large
7531
B
A
Notch in Hingeplate points
towards front finished edge.
Fitting hingeplates to
right hand end panel
P
(x2)
P
P
P
A
B
M
M
M
(x2)
Use a hammer to
knock in wooden dowels
into inner holes.
M
M
7531

7533 x 2
Step 7
Assembly Instructions
8
Fittings you will need for this step:
Attach hinges and
handles to doors
a: Insert hinges
into holes, ensure
the hinge is straight
(90 degree angle).
b: Before securing the
hinges , we recommend
you pre - mark the doors
using a bradawl.
Important: (x4)
J
G
(x2)
(x8)
D
(x4)
O
O
O
90
O
98
O
O
7533 x 2
O
Bradawl
O
D
c: Secure hinges to
doors
using screws .
O
7533 x 2
D
d: Secure handle to
doors
using screws .
J
G
G
G
J
O
O
a:
b:
c:
d:
D
D
O
O
D
D
7533 x 2
7533 x 2
7533 x 2
D
O

Insert dowels in left
and right
end panels into cams
in shelf .
Then lock.
B
A
Tu r n cam 180 degrees
to lock
A
9
Attach left hand and
right hand panels to
shelf
Assembly Instructions
Step 8
Attach top to left hand
and right hand panels
Step 9
7530
7531
Locate cams in left
and right
onto dowels in top
panel .
Then lock.
A
B
Tu r n cam 180 degrees
to lock
A
7530
7528
7531
7531
7532
Warning:
Yo u may need
help for this step.
7530
7532
7531
7530
7528
Note: Ensure the shelf
is positioned correctly
with cam fittings to
this side.

10
Assembly Instructions
Step 10
Step 11 Fittings you will need for this step:
(x4)
L
7531
7530
7528
7534
Locate backpanel
into grooves in left hand
end and right hand
end . Ensure the
backpanel goes into
groove in top .
7534
7531
7530
Locate backpanel
into grooves in left
and right hand end
panels and top panel
Important:
2 people required
7528
7531
7530
7534
Secure bottom panel
to left and right hand
ends
L
Locate wooden dowels
already inserted in
ends and
into holes in bottom
panel .
Now locate screw
through holes in bottom
panel and screw
into holes in ends
5 and .
Ensure backpanel
goes into groove in
bottom panel .
N
7530
7529
L
7529
7530
7531
7531
7529
7534
Important:
2 people required
L
L
L
L
7529
Raw face

11
Assembly Instructions
Step 12
To locate feet to the
bottom you will
need to mark position
with a bradawl 30mm in
as shown, then screw
the foot into place.
Repeat in each corner.
Attach glide feet
Bradawl
30mm
30mm
7529
K
(x4)
N
(x4)
Fittings you will need for this step:
7534
7529
K
N
K
N
K
N
K
N

Assembly Instructions
Step 13
12
a: With help, slot door
hinges onto hinge
plates .
Ensure screw on hinge
slides into the slot
on hingeplate .
See Diagrams 1,2 and 3.
Hanging doors
O
b: Tighten screw shown
to lock hinges in
position.
Repeat aand b on
remaining door.
See ‘Hinge adjustment’
in step 14 if the doors
need adjusting.
O
O
P
P
P
O
P
7533
a:
b:
B
B
B
O
O
P
P
Underside view
Ensure the underside of screw
B slides into slot on hingeplate.
Hinge correctly attached to
hingeplate.
Hinge incorrectly attached to
hingeplate.
Diagram 1
Diagram 2
Diagram 3
Please note diagrams
2 & 3 may not reflect the
hinge included in your
pack.
The principal of the hinge
fitting to the hingeplate
shown applies to all our
hinges.

Assembly Instructions
Step 14
13
a: To move doors up
or down: loosen screws
shown and move doors
to suit.
Re-tighten screws.
Hinge adjustment
b: To move doors in or
out: loosen screw
shown and move doors
to suit.
Re-tighten screws.
a:
O
P
b:
O
P
O
P
c:
c: To move doors left
or right: loosen screw
shown and move doors
to suit.
Re-tighten screws.

Congratulations! your unit is complete.
14
Note: Please turn over for
important information.

15
If you need help or have damaged or missing parts, call the Customer Helpline: 08450613967
Please have the following information: Unit Description, Product Code, Product Colour,
Place of Purchase, Catalogue Ref. No., Item Code, and have the assembly instructions close
to hand.
You can also e-mail your requests to us at: customer[email protected].uk
Simply contact us on CUSTOMER HELPLINE : 0845 0613967 Between 8am - 4.30pm
Monday to Thursday and 8am - 2.30p.m friday. Your statutory rights are not affected.
Alternatively Write to us at: Customer Service Department, Addspace Furniture Limited,
Braithwell Way, Hellaby Industrial Estate, Hellaby, Rotherham, South Yorkshire, S66 8QY.
We do have an answer machine should you contact us out of office hours, so in addition to
the above information could you leave your name, address, daytime telephone number and
the nature of your call on the answerphone. All calls will be actioned asap.
Important Information
