Argos Designer 2 Tone User manual

MADE IN
BRITAIN
Dimensions
Width - 113.5cm
Depth - 40cm
Height - 61cm
Designer 2 Tone - TV Unit
Assembly Instructions - Please keep for future reference
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Issue 2 - 02/07/14
Important - Please read these instructions fully before starting assembly
ALR3049
249/8593
Issue 2 - 02/07/14 - The Small Upright now has edge tape on the back edge.The relevant steps no longer refer to“Finished front edge”.
Step 25 amended to now show the shelf studs being screwed up into the shelf.

Safety and Care Advice
Important - Please read these instructions fully before starting assembly
• Warning: This unit weighs
approximately 29.5kgs.
Please lift with care.
• Check you have all the
components and tools listed on
pages 2 and 3.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Parts of the assembly will be
easier with 2 people.
• Make sure you have enough
space to layout the parts before
starting.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close to
its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor (use opened
out unit carton).
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• Safety note: If there is any
chance of this unit being pulled
over by children etc. it is
recommended that the unit is
secured to a wall using suitable
fixings (not supplied).
• Dispose of all packaging
carefully and responsibly.
1
Care and maintenance
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
Note: If required the next page
can be cut out and used as
reference throughout the
assembly. Keep this page with
these instructions for future
reference.

Components - Panels
Please check you have all the panels listed below
2
1
80%
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Flyover Top (D2968A)
(900 x 396mm)
Left Side (D2970A)
(398 x 395mm)
Small Upright (D2974A)
(146 x 280mm)
Fixed Shelf (D2976A)
(218 x 329mm)
Base (D2977A)
(1133 x 396mm)
Right Side (D2973A)
(559 x 395mm)
Top (D2969A)
(900 x 396mm)
Loose Shelf (D2975A)
(492 x 390mm) x 2
3
7
4Left Upright (D2971A)
(398 x 395mm)
Right Upright (D2972A)
(398 x 395mm)
Drawer Front (D2978A)
(355 x 194mm) x 2
Drawer Base (T337-367)
(337 x 367mm) x 2
Back (X826-424)
(826 x 424mm)
Drawer Back (W326-124)
(326 x 124mm) x 2
Left Drawer Side (W370-124LH)
(370 x 124mm) x 2
Right Drawer Side (W370-124RH)
(370 x 124mm) x 2
2
5
10 11
8
9
6
12
13
14 15 16

Please check you have all the fittings listed below
Tools required
3
Components - Fittings If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Note: The quantities below are the correct amount to complete the assembly. In some cases
more fittings may be supplied than are required.
A B
Metal dowel (F901) x 14
C
D E
Large locking
nut (F900) x 10
F
H I
Rule Scissors Hammer
Eye protection
(when using a
hammer or drill)
Cross-head
screwdriver
Small locking
nut (F3) x 4
Ruler - Use this ruler to help correctly identify the screws
mm 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170
25mm Screw (F50) x 9
G
J
40mm Screw (F910) x 8
P
Drawer runner (F1004) x 4
9mm Screw (F74) x 4
Knock-in Peg (F171GY) x 8
Nail (F51) x 179mm Screw (F73) x 8
L
Shelf stud (F110) x 8
K
MN
Wedgefix (F639) x 4
Handle (F930) x 2 Feet (F854) x 5
O
Shelf stud (F372) x 4
Mini Block (F25) x 2

11
Assembly Instructions
4
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Step 1
x 2
x 2
x 2
x 2
B
B
B
C
C
CC
13 14
Step 2
Prepare the 2 drawer
fronts
Screw 2 metal dowels
into each of the drawer
fronts .
Note: Tighten the metal
dowels up fully against
the panels.
B
11
Prepare the drawer
sides
Insert a small locking
nut into the hole
shown on the left drawer
side and the right
drawer side .
Note: The arrow on the
locking nut must point
towards the hole in the
edge of the panel.
Step 3
C
13
14
Attach the drawer
sides to the drawer
fronts
Push the left drawer sides
. and right drawer sides
. onto the back of the
drawer fronts .
Turn the small locking
nuts on the left
drawer side and right
drawer side .
Note: Turn the locking
nuts clockwise to
secure panels - more
than 1/2 a turn.
13
14
11
C
C
13
14
13
14
B
B
11

11
Assembly Instructions
5
Step 4
J
J
Fit the drawer base
Slide the drawer base
down the grooves in the
drawer sides and
and down into the
groove in the drawer
front .
Step 5
Fit the drawer back
Fit the drawer back
between the drawer
sides and .
Make sure that the
drawer base fits into
the groove in the drawer
back .
Hold the drawer back
in position and tap the
knock-in pegs
through the holes in the
drawer sides and .
Step 6
15
13 14
11
12
13 14
15
12
12
J
Attach the handles
Attach a handle to
each of the drawer fronts
. using 2 screws .
Note: Do not
overtighten the screws.
M
F
11
13 14
Step 7
Fit the wedgefixes
Turn the drawer
assemblies over and
slide 2 wedgefixes
into the front and back
grooves, as shown, and
tighten up the screws.
K
x 2
x 2
x 2
J
J
x 2
K
KK
15
13
12
13
14
15
14
M
F
F
11

Finished
front edge
Finished
front edge
Assembly Instructions
6
Step 8
Prepare the top
Screw 6 metal dowels
into the top .
B
1
B
B
B
B
B
B
Finished
front edge
1
Insert 2 large locking
nuts into the
right upright .
Note: The arrow on the
locking nut must point
towards the hole in the
edge of the panel.
D
D
D
Step 9
Step 10
D
5
Finished
front edge
5
Fit the right upright to
the top
Push the right upright
onto the top .
Use a screwdriver to
tighten the 2 large
locking nuts fitted to
the right upright .
Note: Turn the large
locking nuts as far as
they will go - more than
1/2 a turn.
1
5
D
D
5
B
D
1
5

Assembly Instructions
7
Step 11
Step 12
Finished
front edge
Finished
front edge
Prepare the left
upright
Note: Do not use the
through holes to fit the
runners.
a: Place 2 runners on
the left upright as
shown. Slide back the
top of runner and use the
2nd hole from the front
to fit the 1st screw .
b: Slide the runner
back the other way and
fit the 2nd screw into
the corresponding hole
in the left upright .
Insert 2 large locking
nuts into the left
upright .
4
H
H
4
P
P
D
4
Finished
front edge
H
P
H
H
H
P
H
P
a:
b:
1
Finished
front edge
Fit the left upright
Push the left upright
onto the top .
Use a screwdriver to
tighten the 2 large
locking nuts fitted to
the left upright .
1
4
D
4
4
4
4
D
D
5

Finished
front edge
Finished
front edge
Finished
front edge
Assembly Instructions
8
Step 13
Step 14
Fit the left side
Push the left side
onto the top .
Use a screwdriver to
tighten the 2 large
locking nuts fitted to
the left side .
1
Prepare the left side
a: Place 2 runners on
the left side as
shown. Slide back the
top of runner and use the
2nd hole from the front
to fit the 1st screw .
b: Slide the runner
back the other way and
fit the 2nd screw into
the corresponding hole
in the left side .
Insert 2 large locking
nuts into the left side
. .
a:
b:
H
H
Finished
front edge
H
P
a:
b:
H
P
P
H
P
3
H
H
3
P
P
D
3
1
3
D
3
3
D
D
3
3

Assembly Instructions
9
Step 15
Step 16
Finished
front edge
Fit the base
Attach the base to
the assembly using 6
screws .
E
E
E
E
E
plain chipboard surface
7
7
E
Prepare the base
Screw the 5 feet onto
the base using
screws .
F
N
F
N
N
7
F
F
N
F
N
Finished
front edge
plain chipboard surface
7
F
N
E

Assembly Instructions
10
Step 17
Step 18
yy
xx
b:
Fit the back
a: Square up the unit by
making sure that
measurement x to x
equals y to y.
b: Place the back
onto the unit, as shown.
Nail around the 3
edges of the back , as
shown.
Note: Nails should be
spaced about 150mm
apart.
16
I
The measurement from top corner X to bottom corner X must be
equal to the measurement from top corner Y to bottom corner Y
a:
16
yy
xx
Note:
This gap is for
cable management.
I
16
A
A
A
A10mm
A
Prepare the fixed shelf
Tap 4 wooden dowels
into the fixed shelf .
Note: Wooden dowels
must not stick out from
the edge by more than
10mm or they may
damage other panels.
A
Finished
front edge
9
9
Prepare the right side
Insert 2 large locking
nuts into the right
side .
D
6
D
D
Finished
front edge
6

Assembly Instructions
11
Step 20
Finished
front edge
9
6
Fit the fixed shelf to
the right side
Push the fixed shelf
down onto the right side
. .
9
6
9
6
5
Step 19
6
Secure the right side
Attach the right side
to the base using 2
screws .
Carefully stand the
unit up for the next
step.
E
E
6
7
E
7
Warning: The
unit is heavy.
Lift with care.
D
Prepare the small
upright
Insert 2 large locking
nuts into the small
upright .
Gently tap the 2 mini
blocks into the holes
in the small upright
orientated as shown.
D
10
10
D
A
10
A
A
Step 21
B
Finished
front edge
B
Prepare the flyover
top
Screw 2 metal dowels
into the flyover top .
B
2
2
A

Assembly Instructions
12
Step 22
Step 23
Finished
front edge
2
10
Fit the small upright
to the flyover top
Position the small upright
so that the screws
from the mini blocks
are over the holes in the
flyover top . .
Tighten up the screws in
the 2 mini blocks into
the holes in the flyover-
top .
10
A
2
A
2
1
Step 1
B
Fit 2 metal dowels to
the top panel
Screw 2 metal dowels
into the top panel as
shown.
Note: Tighten the metal
dowels up fully against
the panels.
B
1
B
B
A10
2

Assembly Instructions
13
Step 24
Fit the flyover top
assembly
Lower the flyover top
and small upright
down onto the unit as
shown.
Use a screwdriver to
tighten the 4 large
locking nuts fitted to
the right side and
small upright .
D
2
10
6
2
10
6
Finished
front edge
10
Step 25
6
Fit the fixed shelf
Push 4 shelf studs for
the fixed shelf into
the right side and
right upright .
Lower the fixed shelf
down onto the shelf
studs and tighten the
screws up into the
bottom of the shelf.
Ox 4
O
O
9
6
5
5
9
9
O

Assembly Instructions
14
Step 26
Lx 4
Fit the shelf studs
For each of the 2 loose
shelves , insert 4 shelf
studs .
Lx 4
L
8
Fit the loose shelves
Lower the 2 loose
shelves down onto
the shelf studs .
L
8
8
8
Step 27

Assembly Instructions
15
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
and quote the reference numbers on the component pages.
Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW
Step 28
Fit the drawers
Starting with the bottom
drawer, slide both the
runners forward and
locate the drawer
sides and
between them, lining up
the holes in the drawer
wrap with the 2nd
'threaded' holes in the
runners .
Working from the inside
of the drawer, insert 2
screws through the
drawer sides and out into
the 2nd threaded hole in
the runner.
Note: Do not overtighten
the screws.
If they catch on the
runner you may need to
loosen them slightly.
Assembly is complete
G
P
P
2nd threaded
hole
P
G
13 14
G
G
ALR3049
