Argos OI WOW Eclipse 147/9726 User manual

OI WOW Eclipse 3 Drawer Cabinet
147/9726
Issue 1 - 10/10/13
35cm
30cm
80cm

Components - Panels
Please check you have all the panels listed below
2
If you have damaged or missing components,
call the Customer Helpline:08456 400800
124
7
11
Side panel x 2
Left drawer side x 3
12
Right drawer side x 3
Upper drawer front Middle drawer front Under drawer front
10
Corner piece x 4
Drawer bottom x 3
Drawer back x 3
9
8
Back panel
5
3
6
Bottom panel
Top panel

Components - Fittings
Please check you have all the fittings listed below
Note:The quantities below are the correct amount to complete the assembly .In some cases more
fittings may be supplied than are required.
3
D
A
G
J
H
E
B C
F
I
8mm Bolt x 6 Runner x 6
30mm Screw x 13
Φ4 x 12mm Screw x 35
Hanger Bracket x 1 Φ3 x 12mm Screw x 10
Wall plug(for solid walls only) x 1
Locking Pin x 28 Locking Nut x 28
Ruler - Use this ruler to help correctly identify the screws
Tools required
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 110 115 120 125 130 135 140 145 150 155 160 165 170
105
0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150
0 1 2 3 45 6
(medium & large)
Phillips screwdriver Small
hammer
Ruler/tape
measure
Flatblade screwdriver
(medium)
6mm Suitable drill bit
(for use with wall plug)
Eye protection
(when using a
hammer or glue)
Metal leg x 4
Hammer Drill
(Only for dril hole on the wall)

Assembly Instructions
4
Step 1
Assembling side panel
NOTE:It would be useful to ask
someone to help you at this stage.
C
C
C
C
C
I
I
I
I
I
I
I
I
I
A
A
A
A
A
A
A
A
Attach corner pieces to side
panel and insert locking nuts
into side panel,tighten the
locking nuts to secure.
Stretch runner as shown,use 2 pcs
screw to fix it on side panel,then
stretch runner in opposite
direction,use 1 pc screw to fix.
1
1
1
a:
b:
Front
Front
Screw
Slide part
Fix part
Fix part
Fix part
B
B
B
B
12
12
12
C
B
a:
Screw locking pins into corner
pieces as shown.
b:
12

Assembly Instructions
Step 2
5
a: b:
4
Assembling legs
NOTE:It would be useful to ask
someone to help you at this stage.
by hand
by hand
J1
J2
J3
A
A
A
AJ1
J1
J1
J1
1
34
Assembling the unit
NOTE:It would be useful to ask
someone to help you at this stage.
Carefully attach side panels to
top panel and bottom panel ,
insert locking nuts into it,tighten
locking nuts to secure the unit.
C
Step 3
1
1
3
4
C
C
C
C
C
C
C
c:
4
J2
J2
J2
J2
d:
4
J3
J3
J3
J3
J
J1
b:
Use Φ4 x 12mm screw to fix leg
plate on bottom panel .
4
A
J
a:
Unlock metal leg by using screw
driver as shown.
J1J2
J3
c:
Screw bolt on the leg plate
by hand.
d:
Screw the leg body clockwise
to lock.
C
Note:
Not use screwdriver to tighten for
this step,to avoid overtighten.

Assembly Instructions
Step 4
Step 5
6
Assembling drawer
NOTE:It would be useful to ask
someone to help you at this stage.
3
3
2
D
A
E
Assembling back panel
NOTE:It would be useful to ask
someone to help you at this stage.
a:
b:
8
9
10
F
F
11
5
C
C
B
B
6 7
a:
Use 30mm screw to fix drawer
side panel onto drawer back
panel .
89
10
F
b:
Carefully slide bottom panel into
grooves.
Screw locking pins into upper
drawer front ,insert locking nuts
into drawer side panels,tighten it
closkwise to secure.
Repeat Step bto assemble middle
drawer and under drawer.
11
5
C
B
D
3
Use Φ3 x 12mm screw to fix
back panel to the unit,please
make sure the bracket hole on back
panel match top panel as shown.
Use Φ4 x 12mm screw to fix
hanger bracket on top panel .
2
3
A
E
C

A
7
NOTE:If you have damaged or missing components,
call the Customer Helpline:08456 400800
Argos LTD,489-499 Avebury Boulevard,
Central Milton Keynes, MK9 2NW
Assembly Instructions
Step 8
NOTE:It would be useful to ask
someone to help you at this stage.
NOTE:It would be useful to ask
someone to help you at this stage.
Fixing to the wall
Use screw and wall plug to
fix the unit on the wall via wall
bracket .
Step 6
FG
c:
Screw bolt into holes as shown,
try if drawer stopper function well.
b:
Carefully pull drawer out.
a:
Pull out the runner, alignment to
the groove on the drawer, then
insert the drawer to close first.
Repeat same step to input other
drawers.
H
Assembling drawer
Step 8
Step 7
5
8
F
I
I
I I
G
H
H
I
a: b:
c:
G
F
D
D
After above assembly, please
double check and make sure all
screws are tightened before us.
Warning!
Please make sure the unit is
secured to the wall before use.
Please refer to next page the Guide
for Wall Mounting & Fixings.

A Guide to - Wall Mounting & Fixings
Revision 2 - 7/10/09
Important note:
Types of walls
Care &
Maintenance
No.1 “General Purpose” wall plug
No.6 “Shield Anchor” wall plug
Heavy loads
No.3 “Cavity Fixing” wall plug
No.4 “Cavity Fixing-Heavy Duty”
wall plug
No.5 “Hammer Fixing” wall plug
No.2 “Plasterboard” wall plug
Generally aerated blocks should not
be used to support heavy loads, use
a specialist tting in this case. For light
loads, general purpose wall plugs can
be used.
For use with heavier loads such as TV
& HiFi speakers and satelite dishes etc.
For use with plasterboard partitions or
hollow wooden doors.
For use when tting or supporting
heavy loads such as shelving, wall
cabinets and coat racks.
For use with walls stuck with
plasterboard. The hammer xing allows
it to be xed to the wall rather than the
plasterboard. Always check the xing
is secure to the retaining wall.
For use when attaching light loads on
to plasterboard partitions.
Safety: Always check the fitting
and location to ensure your safety
in and around the home.
Fitting: From time to time check
the fitting to ensure the wall plugs
or screws do not become loose.
You can use one of the following types of wall plug if your walls are made
of brick, breeze block, concrete, stone or wood.
Important: When drilling into walls always
check that there are no hidden wires or pipes etc.
Hints:
1: General rule: Always use a larger screw and wall plug
if you are not sure.
2: Ensure you use the recommended drill bit to match the wall
plug and hole size.
3: Ensure you drill the hole horizontally, do not force the drill or
enlarge the hole.
4: Take extra care when drilling high walls, ceilings and ceramic
tiles. Ensure wall plugs are inserted beyond the thickness of
the ceramic tiles to avoid the tiles splitting or cracking.
5: Ensure wall plugs are well tted and are a tight t in the
drilled hole.
If plastic wall plugs
are supplied with your
product:
Make sure that the screws and wall plugs being used
are suitable for supporting your unit. Consult a qualified
tradesperson if you are unsure.
- these are only suitable for
use in masonry walls.
If you are in any doubt about
the correct wall plugs for
your wall, seek professional
advice.
Failure of the product due to
using incorrect xings is the
responsibility of the installer.
