Argos Devon 532/7623 User manual

Width-45.5cm
Depth -30cm
Height -42.7cm
Issue1-15/03/16
Important - Please read these instructions fullybefore starting assembly
Dimensions
Ifyouneedhelporhavedamagedormissingparts,call the CustomerHelpline:03456400800.
Forfurtherassistancepleasevisit http://www.argos-support.co.uk/.
Assembly Instructions - Please keep for future reference
Devon End Table
532/7623

Checkyouhaveall the
componentsand toolslisted on
pages 2and3.
Removeall fittingsfromthe
plasticbagsand separatethem
intotheir groups.
Keepchildrenandanimals
awayfrom the workarea,small
partscouldchokeifswallowed.
Makesureyouhaveenough
spacetolayoutthepartsbefore
starting.
Donot standorput weighton
theproduct,thiscouldcause
damage.
Assembletheitem ascloseto
itsfinalposition(inthe same
room)aspossible.
Assembleonasoftlevel
surfacetoavoiddamagingthe
unitoryourfloor.
Partsoftheassemblywillbe
easierwith2people.
1
SafetyandCareAdvice
Important -Pleaseread theseinstructionsfully before starting assembly
Fromtimetotimecheckthat
therearenoloosescrewson
thisunit.
Thisproductshouldnotbe
discardedwithhouseholdwaste.
Taketoyourlocalauthority
wastedisposalcentre.
Onlycleanusingadampcloth
andmilddetergent,donouse
bleachorabrasivecleaners.
Careandmaintenance
Assembleall partsand bolts
looselyduring assembly, only
oncethe product iscomplete
shouldyou fullytighten the bolts
HandyHints
Regularlycheck and ensure
that all boltsand fittingsare
tightend properly.
Toreduce
the likelihood of
damaging your
product please
ensurethat your
power drill isset on alow torgue
setting.

Top panel1 (45.5 30cm)
Components-Panels
2
Pleasecheckyouhaveallthepanelslistedbelow
1
2
3
Sideframe 2 (40.9 28cm)
Rail 2 (38.7 4.5cm)
Bottom panel 1 (42.5 27cm)
4
If youhavedamaged ormissing componets,call the
Customer Helpline:03456 400800.For further
assistance please visit http://www.argos-support.co.uk/

Components-Fittings
0101520253035404550556065707580859095100 110115120125130135140145150155160165170
105
5
Note: The quantitiesbelow arethecorrectamounttocompletetheassembly. Insomecasesmorefittings
may be supplied thanarerequired.
Phillipsscrewdriver
(medium &large)
Flatbladescrewdriver
(medium)
Pleasecheckyouhaveallthefittingslistedbelow
Ruler -Usethisrulertohelpcorrectlyidentifythescrews
Toolsrequired
3
Rubber
mallet
B
A
Ø8 30mmWooden dowel 4
C
Locking pin 4
DØ3.5 45mm
Screw 12
Locking nut 4

Step1
4
Step2
AssemblyInstructions
a. Insert2 Locking pin
to Side frame .
b. Insert2 Wooden dowel
to Side frame .
Repeat Step a& b forthe
otherSide frame.
2
a. Attach Rails and
Bottompanelto the
Side frames .
b. Insert Locking nut
to the Bottompaneland
use screwdriver turn
Locking nutclock
wise to lock as showon
picture.
C
2
B
B
A
A
C
C
C
C
C
C
B
2
A2
2
3
4
C

Step3
Step4
5
AssemblyInstructions
Fix the unitto Top panel
by 8 Screwas
showon picture.
Assembly is completed.
1
1
Fixing railsto Side
frameby 4 Screw
as showon picture.Use
screw driverturn Screw
clock wise to fix.
D
2
3
D
D
Dx4
Dx8
