Argos HOME LARGE TRESTLE TABLE DESK User manual

LARGE TRESTLE TABLE DESK
Dimensions
Width - 140cm
Depth - 60cm
Height - 75cm
Issue 3 - 20/07
/2016
Important – Please read these instructions fully before starting assembly
Assembly Instructions - Please keep for future reference 616/9639
If you need help or have damaged or missing parts, call the Argos Aftersales
Helpline: 0345 640 0800

1
Note: if required the next
page can be cut out and used
as reference throughout the
assembly. Keep this page with
these instructions for future
reference.
To reduce the likelihood
of damaging your product,
please ensure that your
power drill is set on a low
torque setting.

Tabletop
(140X60CM)
1Bottom board x 2
(54.5X29.5CM)
2
Cross bar x 2
(55X2CM)
4
Supporting bar x 4
(74 XØ0.6CM)
7
Cross bar x 4
(55X1.8CM)
5
Frame x 4
(33X73.5CM)
3
Cross bar
(102X2CM)
6

A
E
B C
Spanner x 1
Bolt (Ø6mm x 12 mm ) x 10
Bolt (Ø6mm x 60 mm ) x 2
Bolt (Ø6mm x 28 mm ) x 8 Bolt (Ø6mm x 32 mm ) x 21
Nut x 2
G
Allen key (68 x 25mm) x 1
FD

Assembly Instructions
4
4 x screw
Attach supporting bar 7
to the assembled
section by using
A.
Step 1
a: Attach cross bar 4 & 5
Please do not tighten
all the screws until
step b is completed.
to frame 3 by using
screw4 x Cfor each.
b:
c:
d:
a:
b:
c:
d:
3
3
4
5
5
C
G
2
BG
G
A
7
E
F
Attach the shelf 2 to the
assembled section by
B.using 4 x screw
Repeat the above for
the other one.
Repeat the above for
the other one.
Secure the supporting
bar 7 by using screw A
and Nut E . Tighten
with supplied
spanner F .
Assembly Instructions
x 2
x 2
x 2
x 2
A
A

Assembly Instructions
Step 2
Step 3
Assembly Instructions
6
G
D
C
G
1
Attach crossbar 6 to the
assembled section by
.
Attached table top 1 to
the assembled section
C.
Assembly is complete.
5
using 2 x screw D
by using 5 x screw
