Aries B35-2004 User manual

PAGE 1 • B35-2004-RC • 877.287.8634 • NEED ASSISTANCE? • ARIESAUTOMOTIVE.COM
Product Image
Notes and Maintenance
Before you begin installation, read all instructions thoroughly.
Proper tools will improve the quality of installation and reduce the time required.
Before installing this bull bar, we recommend installing a license plate relocation
bracket, sold separately (ARIES part# 35-0000).
To protect the product, wax after installing. Regular waxing is recommended to
add a protective layer over the finish. Do not use any type of polish or wax that may
contain abrasives that could damage the finish.
For gloss black finishes, mild soap may be used to clean the product.
Refer to the table to the left when securing hardware during the
installation process to help prevent damage to the product or vehicle.
Level of Difficulty
Easy
Scan
for helpful
install tips
INSTALLATION MANUAL B35-2004
Parts List
1Bull bar
1Mounting bracket,
driver side
1Mounting bracket,
passenger side
4Hex bolt, M12
8Flat washer, M12
4Lock washer, M12
4Hex nut, M12
Tools Required
Ratchet Socket, 18mm
Level Wrench, 19mm
Torque Specifications
METRIC
M6 bolt 3 ft.-lbs.
M8 bolt 7 ft.-lbs.
M10 bolt 16 ft.-lbs.
M12 bolt 28 ft.-lbs.
SAE
1/4" bolt 3 ft.-lbs.
5/16" bolt 7 ft.-lbs.
3/8" bolt 16 ft.-lbs.
7/16" bolt 20 ft.-lbs.
1/2" bolt 28 ft.-lbs.

ARIESAUTOMOTIVE.COM • NEED ASSISTANCE? • 877.287.8634 • B35-2004-RC• PAGE 2
Step 1
Starting underneath the vehicle,
remove the factory tow hooks.
Set the hardware aside for later use.
Step 2
Select the driver-side bracket. Check
the fit between the tow hook and the
bracket.
Lift the tow hook and bracket to the
underside of the frame channel and
reinstall using the factory hardware.
Step 3
Snug the hardware, but do not fully
tighten. Some factory tow hooks may
not clear the bracket and cannot be
reinstalled.
Repeat this step on the passenger side.
Step 4
With help, lift the bull bar into place and
align the mounting tabs of the bull bar on
the outside of the installed brackets.

PAGE 3 • B35-2004-RC• 877.287.8634 • NEED ASSISTANCE? • ARIESAUTOMOTIVE.COM
Step 5
Insert a M12 hex bolt with a flat washer
from the outside and secure with another
flat washer and a nylock nut.
Snug the hardware,
but do not fully tighten.
Repeat this on the passenger side
Step 6
At this time, level and adjust the
bull bar to the desired location.
With the bull bar in position, it is
recommended to tighten all brackets
to the vehicle first, followed by the
bull bar connections.
Step 7
Congratulations on the installation
of your new ARIES 3" bull bar.
With the bull bar installed, periodic
inspections should be performed to ensure
all mounting hardware remains tight.
To protect your investment, see the
'Notes and Maintenance' section on
the first page of this instruction manual.
