Arkon SM410 User manual

Package Contents:
(1) GN014-SBH - Deluxe mini windshield suction pedestal
(1) GN047-SBH - Swivel air vent mount
(1) SM040-2 - Universal phone cradle with adjustable feet
(1) AP013 - Optional adhesive circular disc for dash / console
(1) Alcohol cleaning pad
!Safety Precautions
Do not install Arkon products over an air bag cover or within the air
bag deployment zone. Arkon Resources, Inc. assumes no responsi-
bility of liability for injury or death as a result of car crashes and / or
air bag deployment.
Arkon is not responsible for any damages caused to your car, your
device, or yourself due to the installation or use of this pedestal mount.
The Mobile Mounting Specialists™
Consumer Hotline:
USA [phone]
INT’L [phone]
Monday - Friday 9 am - 5 pm, PST
Do not place mount in or near an air bag deployment
zone or where it will obstruct view of the road.
!
SM410
|Mini Windshield Suction and Air Vent Mount Kit with Universal Cradle
www.arkon.com
Arcadia, CA 91006 USA
Designed in USA | Made in China and Taiwan
© Copyright 2010 Arkon Resources, Inc.
No tools required for installation.
Dash or Console Mounting (Optional)
Step 1.
Step 2.
Find a safe location on the dash or console. Use the inclu-
ded alcohol pad to clean the mounting surface if necessary.
Remove the paper backing on the adhesive disc and rmly
press in place.
Place the pedestal’s suction base (J) over the center of the
circular disc. While rmly holding the pedestal on top of
the disc, ip the base lever down (K) to the locked position.
K
J
Windshield Mounting
Step 1.
A
B
D
C
Step 3. Adjust the angle and rotation of the pedestal head by
loosening the swivel-tightening ring (D).
Universal Cradle Attachment
Step 1. Attach the universal cradle to the dual-T head by inserting
the dual T-tabs (E) into the dual T-slots (F) on the cradle back.
Place the phone or device into the cradle with the device
sitting on the adjustable support legs (G). Clamp the
grip arms (H) inward to rmly grasp the device. Press the
release button (I) to open the arms.
Device Insertion and Removal from Cradle
Step 1.
Step 2.
Find a safe location on the interior of the vehicle’s wind-
shield to mount the pedestal. Firmly push the suction base
(A) against the windshield and ip the base lever down (B)
to the locked position. See diagram below.
Adjust the angle of the pedestal arm by tightening the
angle adjustment knob (C) at the base to the desired angle.
AP013
Adhesive
Disc
SM040-2
Universal
Phone Cradle
GN014-SBH
Mini Windshield
Suction Mount
GN047-SBH
Air Vent Mount
S
M
0
4
Uni
ve
Pho
ne
I
H
G
F
E

!Safety Precautions
Do not install Arkon products over an air bag cover or within the air
bag deployment zone. Arkon Resources, Inc. assumes no responsi-
bility of liability for injury or death as a result of car crashes and / or
air bag deployment.
Arkon is not responsible for any damages caused to your car, your
device, or yourself due to the installation or use of this pedestal mount.
The Mobile Mounting Specialists™
Consumer Hotline:
USA [phone]
INT’L [phone]
Monday - Friday 9 am - 5 pm, PST
www.arkon.com
Arcadia, CA 91006 USA
Designed in USA | Made in China and Taiwan
© Copyright 2010 Arkon Resources, Inc.
SM410
|Windshield Suction and Air Vent Mount Kit with Universal Cradle - Cont.
Flat side face up
Attach the universal cradle to the dual-T head by inserting the
dual-T tabs (Q) into the dual T-slots (R) on the back of the
cradle or device.
Attach the vent mounting clips (L) to the back of the pedestal
(M) with the vent clips positioned with the at sides facing up.
Step 1.
Air Vent Mount Assembly
L
M
Step 1.
Step 1.
Swivel Ball Head Assembly Attachment
Attach Universal Cradle to Air Vent Mount
Slip the tightening ring (N) over the air vent mount ball.
Snap the dual-T head adapter plate (O) on to the mounting
ball (P). Screw the tightening ring over the adapter plate
until securely holding the plate. Swivel to adjust the angle
of the dual-T head.
N
O
P
Pinch the vent mounting clips (L) so that the teeth open and
gently insert vent pedestal into vent louvres until the mount-
ing clips are attached to the n/blade of the vent. Adjust the
support leg (S) vertically until it rests rmly along the bottom
of the vent or dashboard surface below the vent.
Step 1.
Air Vent Mounting
!Use caution when adjusting the swivel head. Use caution when
inserting or removing the pedestal or the phone from the cradle.
Make sure that the teeth of the vent clips are open wide enough
to not damage the vent ns/blades.
L
S
Place the phone or device into the cradle with the device
sitting on the support legs (G). Clamp the grip arms (H)
inward to rmly grasp the device. Press the release button
(I) to open the arms.
Device Insertion and Removal from Cradle
Step 1.
I
H
G
If necessary, adjust the removable support legs by sliding
them laterally on top or bottom of the cradle. These will
provide added support and stability for your device.
Universal Cradle Adjustments
Step 1.
R
Q
