Armstrong Emech F5 Instruction manual

444-EN CPAC0027
Please read and save
these instructions
Emech®
Steam Water Mixing Valve
Model F5
Installation, Operation & Maintenance
Manual

Contents
Section / Description Page
INTRODUCTION................................................................................................................................................3
1.0 STEAM WATER MIXING VALVE -MODEL F5 - DATASHEET ...................................................................4
Parts and Materials....................................................................................................................................5,6
Dimensions ...............................................................................................................................................7,8
Technical Data .............................................................................................................................................8
Sizing Chart Instructions..............................................................................................................................9
Sizing Chart ...........................................................................................................................................10,11
2.0 INSTALLATION ..........................................................................................................................................12
2.1 Recommended Installation ..............................................................................................................13,14
3.0 MAINTENANCE - DISASSEMBLY .............................................................................................................15
4.0 MAINTENANCE - REASSEMBLY .........................................................................................................16,17
5.0 MOUNTING EMECH G1 ACTUATORS INSTRUCTIONS ................................................................18,19,20
6.0 COMMISSIONING GUIDE .........................................................................................................................21
6.1 Commissioning Overview .....................................................................................................................21
6.2 Commissioning Process .......................................................................................................................22
IMPORTANT NOTICE ......................................................................................................................................23
LEGAL DISCLAIMER .......................................................................................................................................24
Armstrong International
221
Armstrong Blvd., Three Rivers, Michigan, 49093 - USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
2

Introduction
Armstrong International
221
Armstrong Blvd., Three Rivers, Michigan, 49093 - USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
3
Introduction
Congratulations on selecting the Emech™ product from Armstrong. Armstrong devotes
considerable care and attention to the design of its products. To obtain the best performance
from them, the customer should read this manual from cover to cover. It contains important
installation and operating instructions.
The customer must strictly adhere to the safety tips, trouble shooting advice, cautions and
warnings appearing throughout this manual. Along with the warnings, instructions and
procedures in this manual, the customer should also observe such other procedures generally
applicable to equipment of the same type.
If the customer does not follow these and other such warnings, instructions and procedures,
the product may not perform as expected. More seriously, it may cause property damage,
personal injury, production down-time and other losses.
The customer should train its employees and contractors in the safe use of Armstrong products
in relation to the customer’s specific application. If the customer does not understand a point in
this manual, contact Armstrong or its authorized representative.

1.0 Steam Water Mixer - Model F5
Datasheet
F5 Valve General Features
Emech’s patented shear action disc design provides
precise control mixing of steam and water.
Fitted with the Emech G1 electronic actuator, and
integrated temperature sensor results in fast, accurate
and stable temperature control.
As a single compact assembly installation is simplified
The independence of this stand alone unit provides a
reliable solution for hot water supply.
Valve Features
•ISO 5211, 5210 actuator flange mounting
•Constructed of CF8M (316) stainless steel
•Hard coated stainless steel discs
•Standard end connections: NPT, (contact Armstrong
for other end connection options e.g. flanged)
•Top entry allows inline access to internal valve parts
•Size range: 1”, 1 1/2” and 2”
•Maximum opperating inlet steam temperature 363°F
(184°C)
•Rated pressure 145 psi (10 bar)
•Maximum dynamic pressure drop of 130 psi (9.6 bar)
•Manual handle option can be locked in both open and
the closed position
•Manual handle kit includes stroke limiting feature
to set the maximum opening of the steam port
•Design verification to ASME B16.34
•US Patent Approved
Emech Electronic Steam-Water Mixer
The Emech F5 3-port vavle can be fitted with the Emec
G1 electronic actuator, and Emech temperature probe.
The calibrated temperature probe fits the tapping in the
outlet port, and connects via cable to the G1 actuator.
With this temperature feedback signal, the G1 actuator
can provide temperature control accuracy of +/-1°F and
up to 200°F (95°C) control range.
Even with sudden changes of inlet pressure and
temperature to the F5 valve, the G1 controller
aggressively minimizes outlet temperature variations.
Contact Armstrong for this and other mix control
options.
(See CPAC0002 for details about the Emech G1
Electronic Actuator.)
• Analog (4-20mA input and output ports)
• Electrical stepper motor control
• Speed, position, and acceleration control
• User defined ‘2-speed stroke can eliminate water hammer
• Precise positioning achieving 0.03° valve seat placement
• Local closed loop control of temperature
• External RS232 connection (cable supplied)communication for
special mode configuration
• Local/remote control options
• Two operating modes: Stand alone control via onboard keypad
or Remote control via external 4-20mA
• Failsafe position feedback (non-contact absolute encoder)
• Keypad: 4 membrane switches with ‘dual touch’ safety features
• Display: 3.5 digit LCD display with back light
• Push button power switch providing soft start electronic control
The Emech Steam-Water Mixing system. Consisting of the F5
steam water mixer and G1 electronic actuator.
Armstrong International
221
Armstrong Blvd., Three Rivers, Michigan, 49093 - USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
4
1/8" NPSM port in the outlet for
fitting temperature sensor or guage
Low Torque 2300
stroke operation,
including all ports
closed' postion
Features of the Emech G1 Actuated Electronic Mixer

Steam Water Mixing Valve - Model F5
Parts and Materials
1
3
5
7
9
11
15
18
19
23
17
16
12
10
8
4
2
20
21
6
22
13
*
14
Note:
General assembly for model 025 shown.
Spindle and bottom wear ring details diffe
for 040 and 050 size.
Models 040
and 050 only *
Armstrong International
221
Armstrong Blvd., Three Rivers, Michigan, 49093 - USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
5
Continued....

Part Description Quantity Material Included in Seal and Bearing Kit
1 Locking screw 1 316 Stainless Steel
2 O-Ring Gland Internal 1 EPDM X
3 Gland Nut 1 316 Stainless Steel
4 O-Ring Gland External 1 EPDM X
5 Screw Body/Bonnet 8 304 Stainless Steel
7 Bonnet 1 316 Stainless Steel
8 Thrust washer 1 C-Cr Steel X
9 Needle Roller Bearing 1 C-Cr Steel X
10 Support Washer 1 316 Stainless Steel X
11 Cup Seals 2 Carbon PTFE X
12 Split Ring 1 316 Stainless Steel
13 Wear Ring 2 Carbon PTFE X
14 Spindle 1 316 Stainless Steel
15 Moving Disc 1 316 Stainless Steel O
16 Fixed Disc 1 316 Stainless Steel O
17 Spring * Stainless Spring Steel X
18 Pins 2 316 Stainless Steel
19 Face Seals 2 Carbon PTFE X
20 O-Ring Bonnet to Body` 1 Afla X
21 U Hammer Drive Screw 2 316 Stainless Steel
22 Name Plate 1 316 Stainless Steel
23 Body 1 316 Stainless Steel
* 025: 3, 040: 4, 050: 5
X Included in Seal and Bearing Spares Kits
O Included in Disc Set Spares Kits
Note: A2-80 grade high tensile strength stainless steel
fasteners used on the 050 valve size.
Spares
Seal and Bearing Spares Kits: 025 F5 040 F5 050 F5
Part Number: CPSK0071 CPSK0072 CPSK0073
Disc Set Spares Kits: 025 F5 040 F5 050 F5
Part Number: CPSK0074 CPSK0075 CPSK0076
Locating Pins
Part Number: CPME0059 CPME0081 CPME0088
Actuation options:
Electric actuators: F5 Valve Size Recommended Emech Actuator Model
025, 040 G12
050 G13
Emech® F5 Standard Valve Model Codes
Model Codes Description End Connection Steam Water Mixing Units Codes
F5025 F5 VALVE 1” (25mm) NPT Screwed NPT E25S
F5040 F5 VALVE 1-1/2” (40mm) NPT Screwed NPT E40S
F5050 F5 VALVE 2” (50mm) NPT Screwed NPT E50S
The Steam Water Mixing Units includes Valve, Actuator, Mounting Kit, Serial Cable, Temperature Sensor, Spanner and all
relevant IOM’s.
Armstrong International
221
Armstrong Blvd., Three Rivers, Michigan, 49093 - USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
6

Steam Water Mixing Valve - Model F5
Dimensions
Emech F5 Valve
Emech F5 Valve
(shown with Emech G1 Actuator)
Allow access for wiring
screw terminal and cable entry
(see installation instructions)
1/8" NPSM plugged port
1/8" NPSM sensor port
See Emech for other orientation
options when fitted with the G1 Actuator
C
D
B
PORT A (water) PORT B (steam)PORT C (outlet)
E
F
A
2.8"
(71 mm)
6.3”
(160 mm) 3.8"
(96.5 mm)
4.5”
(114 mm)
0.3”
(7.6 mm)
Armstrong International
221
Armstrong Blvd., Three Rivers, Michigan, 49093 - USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
7

Steam Water Mixing Valve - Model F5
Technical Data
Nominal Valve Size(1) 1” (25 mm) 1 1/2” (40 mm) 2” (50 mm)
A 4.25” (108 mm) 5.16” (131 mm) .01” (178 mm)
B 6.42” (163 mm) 7.83” (199 mm) 10.67” (271 mm)
C 4.72” (120 mm) 6.77” (172 mm) 8.66” (220 mm)
D 1.14” (29 mm) 1.30” (33 mm) 1.89” (48 mm)
E 4.78” (121.5 mm) 6.14” (156 mm) 7.40” (188 mm)
F 17.91” (455 mm) 19.06” (484 mm) 22.24” (503 mm)
Operational Stroke °rotational with Handle kit 230 230 230
with G1 Actuator 180 180 180
Thread size : Inlet NPT (inch) 1” 1 1/2” 2”
Thread size : Outlet NPT (inch) 1 1/4” 1 1/2” 2 1/2”
Cold water port flow characteristics ( 90° open
Cv: USgpm at dP=1 psi, 68°F (m3/h at dP=1 bar, 20°C) 8.0 (6.8) 13.3 (11.9) 26.6 (23.0)
U.S.Gpm (lpm) 44 (162) 74 (280) 146 (543)
Leakage is approximately 0.05% of rated valve capacity
As per the operating pressure
psi (g) (bar) 145 (10) 145 (10) 145 (10)
lb (kg) 5.5 (2.5) 11.0 (5.0) 22.0 (10.0)
Flow @ 30psi dP
Shutoff Leakage:
Body Pressure Rating, Designed to ASME B16.34
dPmax
Allowable Pressure @ <482°F
Physical Characteristics Weight (approx)
Valve only
Valve and Emech G1 Actuator lb (kg) 24.5 (11.0 30.0 (14.0) 49.0 (18.0)
Valve Topworks Dimensions For Actuator Mounting ( Spigot / bolts as per ISO 5210 / ISO 5211 )
Shaft / stem connection sq.std (mm) 0.39” (10 mm) 0.55” (14 mm) 0.55” (14 mm)
Topworks, 4 holes PCD (mm) 1.97” (50 mm) 2.76” (70 mm) 2.76” (70 mm)
Topworks, PCD hole Ø (mm) 0.26” (6.5 mm) 0.33” (8.5 mm) 0.33” (8.5 mm)
Topworks, Spigot diameter (mm) 1.38” (35.1 mm) 2.17” (55.1 mm) 2.17” (55.1 mm)
Valve mounting restrictions none none none
Notes:
(1) Note G12 actuator is recommended for 1” (25 mm), 1 1/2” (40 mm) F5 sizes. The G13 is recommended for the F5 size 2” (50 mm) valve.
• All specifications are for water and steam mixing
• Flows are without terminal fittings, restrictors, or non-return valves on the inlets
• If operating at more than one maximum rated condition, contact Armstrong to confirm the application is appropriate
Definitions
dP Differential pressure across the valve from inlet to outlet
dP max. Maximum allowable valve closed differential pressure across the valve from inlet to outlet
Operating pressure Valve body pressure rating.
Armstrong International
221
Armstrong Blvd., Three Rivers, Michigan, 49093 - USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
8

Information Required to Size the Valve:
• Running water pressure drop*(psi)
• Steam pressure drop** (psi)
• Water temperature rise required (dT) °Fahrenheit.
• Required flow (U.S. gpm
NOTES:
* The ‘Water Pressure Drop’ is the difference between the running water pressure at the wate
inlet port and the outlet port.
** The ‘Steam Pressure Drop’ is the difference between the running steam pressure at the steam
inlet port and the pressure at the outlet port.
To Size the Valve:
1. Determine the cold water capacity of the valve using the “Cold Water Capacity” column with the ‘Water Pressure
Drop’ column.
2. Using the ‘Steam Pressure Drop’ column, locate the steam pressure available at the valve steam inlet port.
Determine the ‘Temperature Rise’ required by subtracting the inlet water temperature from the desired water
temperature desired. Go across the columns to locate the temperature rise required to find the flow (U.S. gp
the F5 can heat to the required temperature..
3. Compare the capacities found in steps 1 and 2. The LOWER of these two capacities is the maximum amount of
hot water that size valve can produce to the desired temperature.
NOTE: A minimum flow rate must be established for there to be effective mixing, and temperature contro
The approximate minimum flows for effective stream water mixing ar
F5025 4 (15) U.S. gpm (lpm)
F5040 6 (23) U.S. gpm (lpm)
F5050 20 (100) U.S. gpm (lpm)
EXAMPLE:
Using the 1” size valve (F5025).
Assume the running water pressure drop is 60 psi (4.0 bar), and the steam pressure drop is 40 psi (2.5 bar). The 1”
(25 mm) valve can pass 72 U.S. gpm (268 lpm) of cold water, but can only heat 14 U.S. gpm (54 lpm) with a 100°F
(50°C) temperature rise.
Therefore the capacity of the mixer for this case is only 14 U.S. gpm (54 lpm).
If the steam pressure could be raised to 100 psi, the capacity of the same unit would be 35 U.S. gpm (152 lpm),
100°F (50°C) temperature rise.
Safety features of the F5 valve when coupled with the Emech® G1 actuator:
• If the cold water supply fails the valve will be closed within approximately two seconds.
• If the temperature sensor fails the valve will be closed within approximately two seconds.
• The G1 has a manual override handle enabling operation of the valve when there is no power supply.
Checklist for sizing the F5 steam water mixer
Steam Water Mixing Valve - Model F5
Sizing Chart Instructions
Armstrong International
221
Armstrong Blvd., Three Rivers, Michigan, 49093 - USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
9

Steam Water Mixing Valve - Model F5
Sizing Chart (Gal/PSI)
NOTES: • Contact Armstrong (or an authorized Rep) for operation in the shaded conditions indicated above.
• Armstrong recommends hard facing on the bonnet and spindle assembly for extended duty in high pressure drop
applications. See the F5 valve model code descriptions on page 3 for valve selection.
Armstrong International
221
Armstrong Blvd., Three Rivers, Michigan, 49093 - USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
10

NOTES: • Contact Armstrong (or an authorized Rep) for operation in the shaded conditions indicated above.
• Armstrong recommends hard facing on the bonnet and spindle assembly for extended duty in high pressure drop
applications. See the F5 valve model code descriptions on page 3 for valve selection.
Armstrong International
221
Armstrong Blvd., Three Rivers, Michigan, 49093 - USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
11
Steam Water Mixing Valve - Model F5
Sizing Chart (Bar/Lpm)

CAUTION: Prior to installation ensure that the pipes leading to the valve are clear from debris which may block or damage
the valve on commissioning.
WARNING: Only trained personnel familiar with pipe work and pressure systems should install and maintain
Emech equipment. Failure to do so may result in serious personal injury!
WARNING: Depressurize pipe work to atmospheric pressure and drain all fluids from the pipe work before working on the
valve. Failure to do so may result in serious personal injury!
WARNING: Ensure that the intended maximum operating pressure of the line does not exceed the pressure rating of the
valve. Failure to do so may result in serious personal injury!
WARNING: Non return valves are strongly recommended upstream of the valve inlets. Failure to install them may cause
undesirable back-flow and may result in serious personal injury and or equipment damage
WARNING: The valve must be supported adequately so as not to over stress the pipe work and or the valve body. See
Figure 5 and Table 1 below for the maximum nozzle loads on the valves. Application of loads above these
values may result in serious personal injury and or equipment damage!
2.0 - Steam Water Mixing Valve - Model F5
Installation
When installing the valve in line, be
sure to follow good practice using
either sealing tape or thread adhesive
in the joints.
The valve may be attached straight to
the pipe work.
Note: Be sure to consider the ease
of removing the valve should this
become necessary in the future. See
images 3 and 4 for typical installation
methods.
Note: For valve maintenance, the
bonnet screws can be removed and
full access to the internal components
is possible.
The valve my be connected to the
pipe work with a union style of fittin
(image 3).
Table 2.1: Maximum Nozzle Forces and Moments
Valve Size Force - FxFyFzMoment - MxMyMz
025
040
050
90 lbf.
180 lbf.
450 lbf.
1150 lbf.in
2655 lbf.in
5310 lbf.in
Armstrong International
221
Armstrong Blvd., Three Rivers, Michigan, 49093 - USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
12

2.1 Recommended Installation
2.1 - Steam Water Mixing Valve - Model F5
Recommended Installation
Step 1: Location Considerations
For F5 valves mounted with an Emech G1 electronic actuator ensure the installation
locations offers suitable access to the electrical connection terminals, the manual
override handle, actuator power switch, display and keypad.
Do not install the actuator near or in high pressure wash down areas. The units must
NOT be installed upside down. For manually operated F5 valves ensure suitable
access to the handle for safe operation.
Step 2: Recommended Installation
See Figure 2.6 (page 14) for a recommended F5 valve installation schematic.
MUST HAVE
• Check valves (poppet style) MUST be fitted upstream of the valve inlet port
and as close as practicable to the inlets.
• Pipe work adequately supported.
• A 24Vdc regulated power supply.
RECOMMENDED
• Isolation valves are RECOMMENDED on the supply lines.
• A failsafe solenoid operated spring to close isolation valve is highly RECOMMENDED for over
temperature
• failure modes (see item 2 on figure 2.6)
• Ensure mechanical protection of the wiring (e.g. use armour conduit).
• It is RECOMMENDED to place wiring in screened condui or cables.
• Ensure pipe works are straight for as long as practicable to the Emech valve inlets and any cable condit
is fully sealed on both ends against water ingress.
• Use appropriate inlet pipe diameters and supply pressure to cope with required application flows
CONSIDERATIONS
• Consider strainers if water supply carries pipe scale or other particulates that may damage valve seat and
seals.
• Consider gauge points for temperature and pressure on inlets and outlets.
All Emech valves and actuators are shipped fully assembled and factory set to Factory Default Settings
as a standard. Any requirement for customised Settings or Software settings will need to be
communicated at the time of order placement on the Factory.
Armstrong International
221
Armstrong Blvd., Three Rivers, Michigan, 49093 - USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
13
Continued.....

Note: Also Refer to
Quick Start Guide
provided with all
Actuated Systems.
Armstrong International
221
Armstrong Blvd., Three Rivers, Michigan, 49093 - USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
14

3.0 Steam Water Mixing Valve - Model F5
Maintenance Disassembly
CAUTION!
Before dismantling the valve, ensure all
upstream and downstream pressurized pipe
work is isolated appropriately. Ensure the
pressure and fluids are drained from the valve
and pipework.
Remove the gland nut locking screw (image
1). Fit the gland nut wrench into the two holes
provided in the top of the gland nut (image 2)
and unwind counterclockwise to remove the
gland nut from the bonnet.
Use an allen wrench to remove the bonnet
bolts that fasten the bonnet to the body (image
3).
Carefully remove the bonnet from the body
particularly if the valve is mounted in a vertical
position.
Note that the moving disc is not fastened to the
spindle. Take care that the moving disc is not
dropped as the bonnet assembly is removed.
Set the rotating disc aside.
Remove the fixed disc being careful not to lose
any of the springs from the back face.
Remove the bonnet/body seal and 2 face
seals. Inspect the pins and check for wear.
Replace if worn. See page 6 Item 3 for
replacement pins (image 6).
Remove the spindle from the bonnet by
pushing down on the spindle end.
Check that the secondary cup seal and thrust
bearing assembly is on the spindle. You may
have to remove these from the bonnet store.
Remove the thrust bearing assembly, wear
rings, cup seals and split ring from the spindle.
Clean all grease and dirt from parts not being
replaced.
Ensure that the spindle seal surfaces are
protected from damage while the valve is
disassembled.
Armstrong International
221
Armstrong Blvd., Three Rivers, Michigan, 49093 - USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
15

4.0- Steam Water Mixing Valve - Model F5
Reassembly
PREPARATION: Ensure the assembly
area is completely dirt free. Ensure also
that the valve parts are clean and ready
to be re assembled. Check all valve parts
for damage or wear and insert pins image 1.
In the valve body fit the 2 face seals an
the bonnet/body seal. Check the disc
locating pins are in and secure (Image 2).
Take the fixed disc and check the seal
surface is clean and that all springs are
in place. Add grease to the springs to
retain them in the disc (image 3) and
assemble onto the valve body and locating
pins (image 4).
Take the rotating disc, check the seal
surface is clean, smooth and undamaged.
Apply a light layer of Kluber grease
supplied in the Seal Kit. Place the
moving disc onto the fixed disc as show
(image 5), then rotate several times to
bed discs together.
Push on the primary cup seal to the
spindle. Ensure the orientation is correct!
(See image 7). Fit the split washer and
thick wear ring before fitting the
secondary cup seal.
Smear on a liberal quantity of the Kluber
grease to the bearing support washer
and needle roller bearing making sure all
surfaces are coated and approximately
60% of the bearing void is filled
Fit the bearing support washer, thin
washer and then the needle roller bearing
onto the spindle.
Slide on the thin top washer.
Smear a liberal amount of grease onto
the spindle seal and wear ring surfaces.
Locate the spindle assembly onto the top
disc (image 8).
Armstrong International
221
Armstrong Blvd., Three Rivers, Michigan, 49093 - USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
16
Continued.......

Fit the internal and external o-rings into the gland
nut (image 9). Apply a coating of grease to the
o-ring surfaces and thread. Wind the gland nut into
the body 2 or 3 revolutions by hand (image 10).
Apply a coat of grease inside the bonnet bores.
Check the lightly greased bonnet/body seal is in
it’s groove, and place the bonnet over the spindle.
Push down gently so that the spindle seals slide
into the bore.
The bonnet should be able to be pushed all the
way so that the flange contacts the bod . Use 4
fasteners (2 front and 2 rear) to hold the bonnet in
place against
the spring and o-ring pressure. Insert the
remaining fasteners and tighten evenly (image 11).
Rotate the gland nut all the way down so that the
spindle and disc assembly are clamped (image 12).
The spindle should be difficult to rotate or eve
locked.
Back off the gland nut 1-2 notched and
rotate the spindle clockwise and counter-clockwise
several times to evenly spread the applied
lubricants.
Insert the locking screw after applying a thread
locking adhesive and tighten (see image 13).
Note: Rotate the spindle 1-2 times to ensure the
operating torque is constant and the rotating action
is smooth.
See section 5.0 for Emech G1 actuator mounting.
Note: handle kits are supplied with separate
assembly instructions.
Note: Rotate the spindle 1-2 times to ensure the
operating torque is constant, and the rotating action
is smooth.
NOTE: The valve MUST be in the CLOSED
position before mounting the actuator or handle kit
(image 14).
Steel discs; o-rings; wear rings; bonnet
bore lubrication; roller thrust bearing lubricant
All Stainless Steel Fasteners
Klubersynth UH1 14-151
Armstrong International
221
Armstrong Blvd., Three Rivers, Michigan, 49093 - USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
17

1.0 Preparing the actuator for assembly onto Emech™ valves
Before fitting the actuator to the valve assembly, ensure the actuator is in the zero position. All new or replacement
Emech actuators are shipped in the zero position. To check the actuator position or to re-zero an actuator follow
section 1.1 if a power supply is available or section 1.2 for manual re-zeroing.
1.1 Automatically zeroing the actuator (24Vdc power supply required)
Power on the actuator (a 24Vdc regulated power supply is required). Refer Section 3
of the G1 actuator installation, operation and maintenance manual for electrical installation.
With a temperature sensor connected to Port 1 of the actuator ensure the actuator is in
Temperature Controller mode (hold mode and press down (-) on the actuator keypad
to toggle between Positioner or Temperature mode). Now disconnect the temperature
probe from the actuator. The actuator will move automatically to the ‘zero’ position and
display “E2” on the keypad display.
G1 actuator keypad
1.2 Manually zeroing the actuator
If there is no power available to
‘zero’ the actuator it is possible to
use the actuator’s manual override
handle to adjust the actuator shaft
position.
The actuator ‘zero‘ is achieved
when the coupling keyway is at 45°
to the reference plane as indicated
in images 1 and 2.
2.0 Actuator mounting orientation
To accommodate installation space restrictions the actuator may be mounted to an Emech valve in any one of four
positions. The instructions provided in this document explain how to mount the actuator in the standard orientation for
each type of Emech valve. To mount the actuator in one of the other three off-set orientations (see figure 2.1) follow
the directions outlined in section 2.1.
2.1 Nonstandard mounting orientations
Ensure the valve is in the “0” position by following the
standard mounting instructions for the valve in the
relevant chapter of this document. When it comes to
placing the graduated coupling onto the valve spindle
orientate the coupling so the “0” mark aligns with the
desired off set direction as indicated in figure 2.1.
Continue with the standard mounting instructions.
Ensure the notch (zero indication on bracket) in the
actuator bracket aligns with the coupling “0” when the
actuator is fitted to the valve.
The valve and actuator will operate as per a standard mounting assembly
Actuator ‘zero ‘position
Coupling keyway
Reference plane 45°
Coupling keyway
45°
180° off set 90° off set
270° off set
Emech valve mounting flange
Standard
(Refer relevant
valve chapter)
Figure 2.1 Actuator mounting orientation
2
Armstrong International
221
Armstrong Blvd., Three Rivers, Michigan, 49093 - USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
5.0-Emech Valve to G1 Actuator
Mou nting Instructions
18
Continued......

Cold Port
Zero
Outlet Port
Center
Coupling
Note: The actuator may be mounted in any
one of four positions.
The instructions below explain how to
mount the actuator facing the outlet port as
per image on page 7.
To ensure the actuator is in the ‘zero’
position, power on the actuator (a 24V DC
regulated power supply is required). Ensure
the actuator is in Temperature Controller
mode - hold mode and press down (-) on
the actuator keypad to toggle between
Temperature and Positioner mode.
Once in temperature mode, disconnect the
temperature probe from the actuator. The
actuator will move automatically to the ‘zero’
position and the keypad display will show
“E2”.
Set the Valve position to closed. Ensure
the notch on the spindle (image 1) points
towards the valve “0” mark and the cold port
(image 2) which is the fully closed position
for the valve seats and the default cold port
(image 2).
Place the graduated coupling (image 3)
on the spindle & ensure the zero points
to the outlet port (image 4).
If the actuator is to be mounted in one
of the other three positions, rotate the graduated
coupling so that the “ZERO”
mark will line up with the notch in the
bracket (image 8) of the actuator,
when valve is fully coupled to actuator.
DO NOT MOVE THE SPINDLE FROM ITS
ZERO POSITION WHEN USING ONE OF THE
OTHER POSITIONS FOR THE ACTUATOR.
Place the center coupling (image 5) on
the graduated coupling (image 6).
Continued...
Armstrong International
221
Armstrong Blvd., Three Rivers, Michigan, 49093 - USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
19

Place the actuator on the valve in the
desired position (image 7). The zero mark on
the coupling (image 4) should align with the
notch on the bracket (image B).
Insert one M8 X 25 socket cap screw
into one of the mounting holes with
M8 Spring Washer and Nut. Insert the
remaining three cap screws and fasten.
Ensure the bonded washer (image 0) is on
the sensor (image 10).
Screw the sensor into the outlet port of
the valve (image 11) and tighten before
connecting the the sensor to the actuator.
Plug the sensor connector into the actuator
input port labelled “1” and hand tighten . The
actuator is now assembled
correctly (image 12).
WARNING!! DO NOT USE A WRENCH
TO SCREW THE SENSOR INTO THE
ACTUATOR.
See section 5.0 of the actuator
Installation, Operation and Maintenance
manual for software configuration
Armstrong International
221
Armstrong Blvd., Three Rivers, Michigan, 49093 - USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
20
