Armstrong Emech F2 Instruction manual

441-EN CPAC0014
Please read and save
these instructions
Emech®
Steam Water Mixing Valve
Model F2
Installation, Operation & Maintenance
Manual

Contents
Section / Description Page
FLOW CONTROL VALVE - MODEL F2 - INTRODUCTION.....................................................................................3
1.0 FLOW CONTROL - MODEL F2 - DATASHEET.................................................................................................4
Parts and Materials......................................................................................................................................... 5-6
Dimensions.......................................................................................................................................... ..............7
Speci ications ................................................................................................................................ ....................8
Operating Torque................................................................................................................................................9
Performance.................................................................................................................................................... 10
2.0 INSTALLATION ...............................................................................................................................................11
3.0 MAINTENANCE - DISASSEMBLY...................................................................................................................12
4.0 MAINTENANCE - REASSEMBLY ....................................................................................................... 13, 14, 15
5.0 EMECH VALVE to G1 ACTUATOR MOUNTING INSTRUCTIONS .................................................................16
IMPORTANT NOTICE.............................................................................................................................................17
Armstrong International
221
ArmstrongBlvd.,ThreeRivers,Michigan,49093-USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
2
LEGAL DISCLAIMER..............................................................................................................................................18
NOTES....................................................................................................................................................................19

Introduction
Armstrong International
221
ArmstrongBlvd.,ThreeRivers,Michigan,49093-USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
3
Introduction
Congratulations on selecting the Emech™ product from Armstrong. Armstrong devotes
considerable care and attention to the design of its products. To obtain the best performance
from them, the customer should read this manual from cover to cover. It contains important
installation and operating instructions.
The customer must strictly adhere to the safety tips, trouble shooting advice, cautions and
warnings appearing throughout this manual. Along with the warnings, instructions and
procedures in this manual, the customer should also observe such other procedures generally
applicable to equipment of the same type.
If the customer does not follow these and other such warnings, instructions and procedures,
the product may not perform as expected. More seriously, it may cause property damage,
personal injury, production down-time and other losses.
The customer should train its employees and contractors in the safe use of Armstrong products
in relation to the customer’s specific application. If the customer does not understand a point in
this manual, contact Armstrong or its authorized representative.

Manual override
handle
(not shown)
Push button
power switch
Graduated visual
indicator on shaft
coupling
Local keypad
and temperature
display with
hinged magnetic
latching
lockable cover
Epoxy powder
coated aluminum
enclosure designed
to Nema-4 (IP65)
Constructed of
CF8M (316)
stainless steel
Digital Control
The Emech 2 port valve can be tted with the Emech digital
actuator to provide modulating control. Closed loop control can
be achieved by connection of appropriate sensors to the actuator
e.g. temperature, ow, or pressure transducers.
F2050 with G1 Digital Actuator
Features of the Emech G1 Digital Actuator
•Analogue (4-20mA) and digital (Rs232) communication
•Speed, position, and acceleration control
• User dened ‘2-speed’ stroke can eliminate water hammer
•Very high resolution capability (0.03° rotational)
•Local closed loop control of Temperature
•External RS232 connection (cable supplied) for actuator
conguration
•Local / Remote control options
• Failsafe position feedback (non-contact absolute encoder)
• 4 membrane switches with ‘dual touch’ safety feature
• 3.5 digit LCD display with back light display
•Push button power switch
(See separate document for details about the Emech G1 Digital
Actuator.)
1.0 - Flow Control Valve - Model F2
Datasheet
F2 Valve General Features
The Emech 2 port valve utilizes ceramic shear action
disc technology to provide tight shut-o󰀨, high pressure
di󰀨erential capability and long life integrity.
Combined with the Emech digital actuator, high speed stand
alone closed loop control is possible. The Emech 2 port valve
utilizes ceramic shear actions discs as the dynamic seal.
The extremely hard nature of the ceramic produces outstanding
resistance to wear and cavitation damage compared with
conventional elastomer and plastic seated valves, minimizing
seal replacement and plant downtime.
Valve Features
•1/4 Turn Action
• ISO 5211, 5210 actuator ange mounting
•Constructed of 316 (CF8M) stainless steel
•Ceramic discs - durable, corrosion resistant
• End connections: NPT, ASME Cl. 150 Flanges, Socket
Weld, Sanitary Styled Flanges
•Elastomer seal options
•Top entry allows inline access to internal valve parts
•Size range: 3/4” (20 mm), 1” (25 mm), 1 1/2” (40 mm) and
2” (50 mm)
•Body temperature range: -13°F to 257°F (-25°C to 125°C)
•Rated pressure: 145 psi
•Maximum dynamic pressure drop of 130 psi
• BUBBLE TIGHT (zero leakage) shut-o󰀨*
• Manual handle option lock-able in both open and closed
position
•Liquid and gas capable
Handle can be padlocked
in the open or closed
position, and can be
'stroke limited'
Graduated scale
on the handle
Low torque °
stroke operation
90
Note: * Seat seal performs beyond the requirements of
ANSI B16.104 and FCI 70-2, Classes V and VI.
Armstrong International
221
ArmstrongBlvd.,ThreeRivers,Michigan,49093-USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
4

Flow Control Valve - Model F2
Parts and Materials
Armstrong International
221
ArmstrongBlvd.,ThreeRivers,Michigan,49093-USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
5

Flow Control Valve-Model F2
Parts and Materials
Part Description Quantity Material Code:
Inlet Size:
F2020
3/4” (20 mm)
F2025
1” (25 mm)
F2040
1-1/2” (40 mm)
F2050
2” (50mm)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Name Plate
U Hammer Drive Screw
Pin
Top Wear Ring
Bottom Wear Ring
Bonnet
Body
Spindle
Gland Nut
Top Disc
Bottom Disc
Energizers O-ring
Needle Roller Bearing
Screw Body/Bonnet
Screw Locking (M4 x 6)
O-Ring Gland Internal
O-Ring Gland External
O-Ring Spindle
O-Ring Body/Bonnet
Thrust Washer
1
2
2
1
1
1
1
1
1
1
1
2
1
4
1
1
1
2
1
2
316 stainless steel
316 stainless steel
316 stainless steel
trim dependent
trim dependent
CF8M (316) stainless steel
CF8M (316) stainless steel
316 stainless steel
316 stainless steel
trim dependent
trim dependent
trim dependent
C-Cr steel
304 stainless steel
304 stainless steel
trim dependent
trim dependent
trim dependent
trim dependent
C-Cr steel
1) 1) 1) 1)
1) 1) 1) 1)
2) 2) 2) 2)
2) 2) 2) 2)
1) 1) 1) 1)
1) 1) 1) 1)
1) 1) 1) 1)
1) 1) 1) 1)
1) 1) 1) 1)
1) 1) 1) 1)
1) 1) 1) 1)
Spare Kits:
1) Included in Valve Trim
2) Included in Valve Trim
F2 - Seal Kits
F2 - Ceramic Disc Sets
CPSK0001
CPSK0005
CPSK0002
CPSK0006
CPSK0017
CPSK0007
CPSK0018
CPSK0008
3) Locating Pins CPME0059 CPME0059 CPME0081 CPME0088
Emech F2 - Actuation Options:
Electric Actuators
Handle Kits
F2 Valve Size
020, 025 and 040
050
020 and 025
040 and 050
Recommended Emech Actuator Model
G12
G13
CPSK0013
CPSK0014
Trim selection
The following table is Armstrong’s recommendation for trim selection.
Compound Maximum recommended fluid
temperature in Emech valves
Application Compound Compatibility
recommendations
EPDM -13 to +257°F All water and Glycol
applications.
Water, steam, hydroxides, solvents,
alchols, several acids, ketone & silicone oils.
F2020 F2025 F2040 F2050
Armstrong International
221
ArmstrongBlvd.,ThreeRivers,Michigan,49093-USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
6

4.53”
(115 mm)
3.82”
(97 mm)
6.30”
(160 mm)
2.76”
(70 mm)
0.31”
(8 mm)
Contact Armstrong for other orientation
options when fitted with the G1 Actuator.
Allow access for wiring screw
terminal and cable entry
(See installation instructions)
1/2” NPT Cable entry - 1
each side. Supplied with
plugs shown.
K (2 Auxiliary Ports)
Emech F2 Valve
(one view shown with handle kit)
Emech F2 Valve
(shown with Emech G1.2 Actuator)
Preferred Flow Direction
Flow Control Valve - Model F2
Dimensions
Armstrong International
221
ArmstrongBlvd.,ThreeRivers,Michigan,49093-USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
7

Nominal Valve Size(1) 3/4” (20 mm) 1” (25 mm) 1 1/2” (40 mm) 2” (50 mm)
NPT 0.75” 1.00” 1.50” 2.00”
A 1.30” (33 mm) 1.38” (35 mm) 2.00” (50 mm) 2.32” (59 mm)
B 2.50” (64 mm) 3.35” (85 mm) 4.25” (108 mm) 5.50” (140 mm)
C 2.72” (120 mm) 5.85” (149 mm) 7.85” (199 mm) 9.84” (250 mm)
D 0.71” (18 mm) 0.87” (22 mm) 1.26” (32 mm) 1.54” (39 mm)
E 4.92” (125 mm) 5.35” (136 mm) 6.81” (173 mm) 7.64” (194 mm)
F 6.58” (167 mm) 6.58” (167 mm) 8.07” (205 mm) 8.07” (205 mm)
G 3.03” (77 mm) 3.90” (99 mm) 5.12” (130 mm) 6.42” (163 mm)
H 4.02” (102 mm) 4.49” (114 mm) 5.87” (149 mm) 6.77” (172 mm)
I 17.52” (445 mm) 17.95” (456 mm) 18.90” (480 mm) 19.57” (497 mm)
Auxiliary Port Thread Size: K 0.25” 0.25” 0.50” 0.50”
Operational Stroke °rotational with Handle kit 90 90 90 90
Flow characteristics (90° open, 100% open Cv (Kv))
Cv (Kv): USgpm at dP=1 psi, 68°F (m3/h at dP=1 bar, 20°C) 16.2 (14.1) 27.9 (24.3) 48.9 (42.5) 82.8 (72)
Flow @ 29psi dP U.S.Gpm (lpm) 88 (332) 150 (573) 264 (1002) 449 (1697)
Leakage Characteristics
The F2 Emech ceramic shear action valves have bubble tight (zero leakage) shut-o󰀨. The Emech seat seal performs beyond the re-
quirements of ANSI B16.104 and FCI 70-2 Classes V and VI.
Body Pressure Rating - Designed to ASME B16.34
Operating Pressure @ <257°F (125°C) psi (bar) 145 (10) 145 (10) 145 (10) 145 (10)
Physical Characteristics Weight (approx)
Valve only lb (kg) 3.0 (1.5) 5.0 (2.5) 12.0 (5.5) 21.0 (9.5)
Valve and Emech G12 Actuator lb (kg) 220 (10.0) 24.5 (11.0) 31.0 (14.0) 50.0 (23.0)
Valve Topworks Dimensions For Actuator Mounting (Spigot/bolts as per ISO 5210/ISO 5211)
Shaft/Stem Connection sw.std (mm) 0.39” (10) 0.39” (10) 0.55” (14) 0.55” (14)
Topworks 4 holes PCD (mm) 1.97” (50) 1.97” (50) 2.76” (70) 2.76” (70)
Topworks, PCD hole Ø inch (mm) 0.26” (6.5) 0.26” (6.5) 0.33” (8.5) 0.33” (8.5)
Topworks, Spigot diameter inch (mm) 1.38” (35.1) 1.38” (35.1) 2.17” (55.1) 2.17” (55.1)
Valve mounting restrictions None None None None
Notes:
(1) Note G12 actuator is recommended for 3/4” (20 mm), 1” (25 mm), and 1 1/2” (40 mm) F2 sizes. The G1.3 is recommended for the F2
size 2” (50 mm) valve.
• All specications are for water.
• Flows are quoted without terminal ttings, restrictors, or non-return valves on the inlets. (Non-return valves are recommended.)
• If operating at more than one maximum rated condition, contact Armstrong to conrm the application is appropriate.
Denitions:
dP max. Maximum allowable valve closed di󰀨erential pressure across the valve from inlet to outlet.
Operating Pressure Valve body pressure rating.
Flow Control Valve - Model F2
Specifications
Armstrong International
221
ArmstrongBlvd.,ThreeRivers,Michigan,49093-USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
8

Flow Control Valve - Model F2
Operating Torque
Emech F2-Standard Model Codes:
Model Code Description End Connection Flow Control Unit Codes
F2020 F2 VALVE 3/4” (20mm) NPT Screwed NPT E20F
F2025 F2 VALVE 1” (25mm) NPT Screwed NPT E25F
F2040 F2 VALVE 1-1/2” (40mm) NPT Screwed NPT E40F
F2050 F2 VALVE 2” (50mm) NPT Screwed NPT E50F
Emech F2- Model Codes on request:
Model Code Description End Connection Flow Control Unit
Codes
D48916 F2 Valve 1”(25mm) SW Socket Weld ASME B16.34
F2040R F2 VALVE 1-1/2”(40mm) FLG Flanged ASME CL.150 E40FR
F2050R F2 VALVE 2”(50mm) FLG Flanged ASME CL.150 E50FR
F2050RH F2 VALVE 2”(50mm)SANITARY FLG Flanged ASME CL.150
The Flow Control Units includes Valve, Actuator, Mounting Kit, Serial Cable, Temperature Sensor, Spanner and
all relevant IOM's.
Note:
1. The charted seating and unseating torques are the sum of all friction and resistance for opening
and closing of the disc against the indicated pressure differential for normal service.
2. The relationship between values are linear, and can therefore be interpolated between nominated values.
3. The effect of dynamic torque is not considered in the table.
4. In sizing operators it is not necessary to include safety factors.
5. Break-open torques are approximately equal to the shut-off torques.
The charted values are based on clean liquid service at temperatures between 32°F to 212°F with no internal
deposition or chemical attack, operated a minimum of once a day.*
For conditions that vary from those noted above, apply the following application factors.
Note: The above factors are cumulative but never more than 2x the value shown in the Break Open Torque tables above.
*Frequency of operation
< once per day +15%
< once per week +25%
< once per month +40%
< once per year +80%
Service conditions
Dry service
Light slurry semi-solids
Heavy slurry and some solids
Temperature: -13°F to 14°F
14°F to 32°F
Over 212°F to 257°F
+30%
+40%
+70%
+30%
+15%
+30%
F2 Break Open Torques
Break Open Torque (lb.in)
Valve
Size
Shut off Pressure (psi)
020 F2
025 F2
040 F2
050 F2
17
27
89
124
31
40
185
230
0 145
F2 Break Open Torque
Closed Pressure (psi)
270
225
180
135
90
45
0
0 35 70 105 140
Armstrong International
221
ArmstrongBlvd.,ThreeRivers,Michigan,49093-USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
9

F2 Valve Performance
Representation of typical flow characteristic of the F2 valve through 90° of rotation.
CLOSED OPEN OPEN
Spindle Position (° rotational)
Flow Control Valve - Model F2
Performance
Armstrong International
221
ArmstrongBlvd.,ThreeRivers,Michigan,49093-USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
10

050 F2
040 F2
025 F2
020 F2
4248 lbf.in (480 Nm)
2124 lbf.in (240 Nm)
920 lbf.in (105 Nm)
496 lbf.in (55 Nm)
1150 lbf.in (130 Nm)
1150 lbf.in (130 Nm)
1150 lbf.in (130 Nm)
620 lbf.in (70 Nm)
360 lbf. (1600 N)
144 lbf. (640 N)
72 lbf. (320 N)
45 lbf. (200 N)
450 lbf. (2000 N)
180 lbf. (800 N)
90 lbf. (400 N)
56 lbf. (250 N)
TABLE 2.1: Maximum Nozzle Forces and Moments for Flanged and Screw end F2 valves
Nozzle Load Orientations
2.0 Flow Control Valve - Model F2
Installation
When installing the valve in line, be sure
to follow good practice using either
sealing tape or thread adhesive in the
joints.
The valve may be attached straight to the
pipework.
NOTE: Be sure to consider the ease of
removing the valve should this become
necessary in the future. See images 3 and
4 below for typical installation methods.
NOTE: For valve maintenance, the bonnet
screws can be removed and full access to the
internal components is possible.
The valve may be connected to the pipe
work with a union style of tting.
The valve may be connected to the pipe
work with a thread adapter and a clamp
style tting. e.g. Tri-Clover™.
CAUTION:
WARNING:
WARNING:
WARNING:
WARNING:
Prior to installation ensure that the pipes leading to the valve are clear from debris which may block or
damage the valve on commissioning.
Only trained personnel familiar with pipe work and pressure systems should install and maintain
Emech equipment. Failure to do so may result in serious personal injury!
Depressurize pipe work to atmospheric pressure and drain all uids from the pipe work before working
on the valve. Failure to do so may result in serious personal injury!
Ensure that the intended maximum operating pressure of the line does not exceed the pressure rating
of the valve. Failure to do so may result in serious personal injury!
The valve must be supported adequately so as not over stress the pipe work and or the valve body.
See Figure 5 and Table 2.1 below for the maximum nozzle loads on the valves. Application of loads above
these values may result in serious personal injury and or equipment damage!
Armstrong International
221
ArmstrongBlvd.,ThreeRivers,Michigan,49093-USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
11

3.0 - Flow Control Valve - Model F2
Maintenance- Dismantling
CAUTION!
Before dismantling the valve,ensure all
upstream and downstream pressurised pipe
work is isolated appropriately.
Ensure the pressure and uids are drained
from the valve and pipe work.
After removing the gland nut locking screw,
unwind the gland nut counterclockwise using
the spanner provided. (Image 1)
Using a hex wrench, remove the four cap
screws around the bonnet. (Image 2)
Carefully remove the bonnet from the body
particularly if the valve is mounted in a
vertical position.
The spindle may detach from the rotating
disc and remain in the bonnet.(Image 3).
Remove the spindle and ensure that the two
thrust washers and needle bearing is on the
spindle. You may have to remove these from
the bonnet.
Alternately the spindle may stay attached to
the rotating disc in which case it should be
carefully removed. (Image 4)
In either situation, the spindle will need
to have two O-rings and two wear rings
removed (Image 5).
Remove the discs from the valve body.
Remove two energizers and check the pins
for any damage. If the pins are damaged
they need to be ordered separately (Image
7).
Finally remove the O-ring around the ange
of the bonnet (Image 8).
Armstrong International
221
ArmstrongBlvd.,ThreeRivers,Michigan,49093-USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
12

4.0 - Flow Control Valve - Model F2
Maintenance - Reassembly
Replace the pins if they are damaged.
Before assembling/re-assembling the valve,
make sure hands are free of dirt and grease
and the valve is clean.
Fit the energizers into the body. Apply a light
even coast of grease to all seals. All Emech
seal kits are provided with recommended
lubricant. (See table 4.2 on page 15).
Place the bottom disc onto the valve body.
Apply a light even coat of grease to the top
surface of the bottom disc. (Image 3)
Place the top disc on the bottom disc and bed
it down by rotating one on the other.
Ensuring the disc slots are clear of dust or
dirt, check the spindle ts neatly into the slots
on the top disc.
NOTE: The spindle should be tight tting. If
the spindle does not sit at on top of the disc,
clean lugs. If the spindle still does not sit at,
le the lugs.
Fit the two O-rings and d the top and bottom
wear rings to the spindle.
Continued....
Armstrong International
221
ArmstrongBlvd.,ThreeRivers,Michigan,49093-USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
13

Align the discs with the spindle on top before
gently lowering the bonnet over the spindle
down to the body (Image 11).
Secure down the bonnet with the allen head
cap screws using an allen wrench (Image
12).
Check the torque of the bolts to the range
indicated in table 4.1. (See table 4.2 page
15).
Apply a light even coat of grease to the
spindle bearing surfaces and the O-rings
(Image 7).
Check the t of the spindle in the bonnet
(Image 8). If the spindle ts, proceed to
Image 9.
Lightly grease both sides of the thrust washer
and place on the spindle. Place on the
needle roller bearing (Image 9) and apply
grease (approx 60% of the void space).
Lightly grease both sides of the second thrust
washer and place on the bearing.
Apply a light even coat of grease to the body/
bonnet seal O-ring and bonnet bore. Place
the O-ring around the perimeter of the bonnet
(Image 1).
Rotate the spindle one full rotation. The
movement should be smooth and even with
no variation in torque (Image 13).
Lubricate inside and outside of the gland
nut, paying particular attention to the thread.
Insert the O-ring in the gland nut and then the
external O-ring (Image 114).
Armstrong International
221
ArmstrongBlvd.,ThreeRivers,Michigan,49093-USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
14
Continued.....

15
16
17
Table 4.1: Nominal Tightening Torques for Lubricated Stainless Steel Socket Head Cap
Metric Cap Screw UNC Cap Screw
Size Torque (Nm) Torque (inlb) Size Torque (Nm) Torque (inlb)
Table 4.2: Recommended Lubricants and Thread Adhesives
M3
M4
M5
M6
M8
M10
M12
1.3
2.9
5.7
10
25
47
82
12
26
50
89
221
416
726
3.3
5.5
11
22
39
95
27
49
97
195
345
841
#8-32
#10-24
1/4”
5/16”
3/8”
1/2”
Description Manufacturer/Model Code Used for:
Food Safe Teflon Lubricant* Klubersynth UH1 14-151 Ceramic discs; o-rings; wear rings; bonnet bore
lubrication; roller thrust bearing lubricant
All Stainless Steel Fasteners
Thread Locking Adhesive Loctite 262
*Sachets of this lubricant are included in the Seal Kits.
“Zero” Notch
With the gland wench provided, screw
the gland nut down until it bottoms out.
Do not over-tighten! (Image 15).
Back the gland nut o󰀨 3 notches (70
degrees). If the notch does not align with
the locking screw head, back the gland
nut o󰀨 further to align (Image 16).
Insert the locking screw after applying a thread locking adhesive (Image 17). Tighten the
locking screw as per the torque values given in table 4.1.
NOTE: Rotate the spindle 1-2 times to ensure the operating torque is constant, and the
rotating action is smooth.
Reassemble and connect the handle kit or actuator to the valve. When connecting to
an actuator, ensure that the valve and actuator are both in the “zero” or starting position
before mounting together.
NOTE: The valve is CLOSED when the spindle notch points to the “0” mark stamped on
the valve top (see Image 17).
Armstrong International
221
ArmstrongBlvd.,ThreeRivers,Michigan,49093-USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
15

1.0 Preparing the actuator for assembly onto Emech™ valves
Before fitting the actuator to the valve assembly, ensure the actuator is in the zero position. All new or replacement
Emech actuators are shipped in the zero position. To check the actuator position or to re-zero an actuator follow
section 1.1 if a power supply is available or section 1.2 for manual re-zeroing.
1.1 Automatically zeroing the actuator (24Vdc power supply required)
Power on the actuator (a 24Vdc regulated power supply is required). Refer Section 3
of the G1 actuator installation, operation and maintenance manual for electrical installation.
With a temperature sensor connected to Port 1 of the actuator ensure the actuator is in
Temperature Controller mode (hold mode and press down (-) on the actuator keypad
to toggle between Positioner or Temperature mode). Now disconnect the temperature
probe from the actuator. The actuator will move automatically to the ‘zero’ position and
display “E2” on the keypad display.
G1 actuator keypad
1.2 Manually zeroing the actuator
If there is no power available to
‘zero’ the actuator it is possible to
use the actuator’s manual override
handle to adjust the actuator shaft
position.
The actuator ‘zero‘ is achieved
when the coupling keyway is at 45°
to the reference plane as indicated
in images 1 and 2.
2.0 Actuator mounting orientation
To accommodate installation space restrictions the actuator may be mounted to an Emech valve in any one of four
positions. The instructions provided in this document explain how to mount the actuator in the standard orientation for
each type of Emech valve. To mount the actuator in one of the other three off-set orientations (see figure 2.1) follow
the directions outlined in section 2.1.
2.1 Nonstandard mounting orientations
Ensure the valve is in the “0” position by following the
standard mounting instructions for the valve in the
relevant chapter of this document. When it comes to
placing the graduated coupling onto the valve spindle
orientate the coupling so the “0” mark aligns with the
desired off set direction as indicated in figure 2.1.
Continue with the standard mounting instructions.
Ensure the notch (zero indication on bracket) in the
actuator bracket aligns with the coupling “0” when the
actuator is fitted to the valve.
The valve and actuator will operate as per a standard mounting assembly
Actuator ‘zero ‘position
Coupling keyway
Reference plane 45°
Coupling keyway
45°
180° off set 90° off set
270° off set
Emech valve mounting flange
Standard
(Refer relevant
valve chapter)
Figure 2.1 Actuator mounting orientation
2
Armstrong International
221
ArmstrongBlvd.,ThreeRivers,Michigan,49093-USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
5.0-Emech Valve to G1 Actuator
Mounting Instructions
16

Important Notice
Armstrong’s products are capable of being used in many di󰀨erent types of industrial applications and
operating environments. Consequently, Armstrong is only able to provide general guidelines concerning
the suitability and use of its products. It is not possible for Armstrong to provide specic guidelines for
specic applications and operating environments simply because there are too many of them. Therefore,
proper selection of a specic product for a specic application and operating environment, and its
compatibility with other equipment to which it is attached, is the customer’s responsibility. The customer
must assume the ultimate responsibility for the proper sizing, selection, compatibility, installation and
operation of Armstrong products. All operating parameters should be validated for the customer’s
application by a professional engineer, qualied installer or by another technical expert. Armstrong does
not warrant the performance of its products or their suitability for a particular purpose.
Although the information is believed to be accurate, Armstrong accepts no liability for any errors or
omissions. Armstrong has endeavored to provide timely information but it cannot represent that the
information is complete. The information shall not be deemed a warranty, representation or guarantee
concerning a product’s suitability or tness for a customer’s specic purpose. Armstrong does not warrant
the information or any particular benets that the customer will derive. It is the customer’s responsibility to
determine the suitability for its own use of the products described herein.
The customer must make its own independent judgment and assessment and should not rely upon any
opinions, interpretations, statements, assurances or representations given.
Because Armstrong is continually improving and upgrading its products, the specications, dimensions
and information contained herein are subject to change without notice. This information is intended to
provide general guidance to the customer. For specic guidance or support, contact Armstrong or its
authorized representative.
Installation is entirely at the customer’s risk. Armstrong accepts no liability for direct, indirect, incidental,
special, or consequential damages resulting from the customer’s failure to follow Armstrong’s warnings,
instructions and procedures or such other procedures generally applicable to equipment of the same
type. The foregoing limitation extends to damages to person or property as well as loss of prots, loss of
products, loss of operations, the cost of alternative arrangements and loss of time, whether incurred by
the customer, its employees or a third party.
Armstrong products should be installed by qualied technicians only. Do not attempt installation unless
you are a qualied technician. Armstrong accepts no liability for damages resulting from faulty installation.
Nothing in this document is intended to cancel, modify or supersede the terms of the Armstrong Limited
Warranty and Remedy.
Armstrong International
221
ArmstrongBlvd.,ThreeRivers,Michigan,49093-USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
17

Limited Warranty and Remedy
Armstrong International, Inc. or the Armstrong division that sold the product (“Armstrong”) warrants to the original
user of those products supplied by it and used in the service and in the manner for which they are intended, that
such products shall be free from defects in material and workmanship for a period of one (1) year from the date
of installation, but not longer than 15 months from the date of shipment from the factory, [unless a Special
Warranty Period applies, as listed below]. This warranty does not extend to any product that has been subject to
misuse, neglect or alteration after shipment from the Armstrong factory. Except as may be expressly provided in
a written agreement between Armstrong and the user, which is signed by both parties, Armstrong DOES NOT
MAKE ANY OTHER REPRESENTATIONS OR WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT
NOT LIMITED TO, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR ANY IMPLIED WARRANTY OF
FITNESS FOR A PARTICULAR PURPOSE.
The sole and exclusive remedy with respect to the above limited warranty or with respect to any other claim
relating to the products or to defects or any condition or use of the products supplied by Armstrong, however
caused, and whether such claim is based upon warranty, contract, negligence, strict liability, or any other basis or
theory, is limited to Armstrong’s repair or replacement of the part or product, excluding any labor or any other
cost to remove or install said part or product, or at Armstrong’s option, to repayment of the purchase price.
As a condition of enforcing any rights or remedies relating to Armstrong products, notice of any warranty or other
claim relating to the products must be given in writing to Armstrong: (i) within 30 days of last day of the applicable
warranty period, or (ii) within 30 days of the date of the manifestation of the condition or occurrence giving rise to
the claim, whichever is earlier. IN NO EVENT SHALL ARMSTRONG BE LIABLE FOR SPECIAL, DIRECT,
INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING, BUT NOT LIMITED TO, LOSS OF
USE OR PROFITS OR INTERRUPTION OF BUSINESS. The Limited Warranty and Remedy terms herein apply
notwithstanding any contrary terms in any purchase order or form submitted or issued by any user, purchaser, or
third party and all such contrary terms shall be deemed rejected by Armstrong.
Armstrong International
221
ArmstrongBlvd.,ThreeRivers,Michigan,49093-USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.
18

Notes:
19
Armstrong International
221
ArmstrongBlvd.,ThreeRivers,Michigan,49093-USA
Phone [phone] Toll Free (888) HOT-HOSE (468-4673)
Designs, materials, weights and performance ratings are
approximate and subject to change without notice. Visit
armstrong international.com/emech for up-to-date information.

Armstrong International
North America • Latin America • India • Europe / Middle East / Africa • China • Pacific Rim
armstronginternational.com
441-EN
Printed in U.S.A. - 8/10/2016
© 2016 Armstrong International, Inc.
Designs, materials, weights and performance ratings are approximate and subject to change without notice.
Visit armstronginternational.com for up-to-date information.
Emech®
Steam Water Mixing Valve
Model F2
Installation, Operation & Maintenance
Manual
