Armstrong TVS 6000UD User manual

TVS 6000UD
Double Trap Isolation & Bleed Valve Station
Installation & Operations Manual
889-EN V1.6
Please read and save
these instructions

North America • Latin America • India • Europe / Middle East / Africa • China • Pacific Rim
armstronginternational.com
Designs, materials, weights and performance ratings are approximate and subject to change without notice. Visit armstronginternational.com for up-to-date information.
2
General Safety Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Operation (see exploded view on page 7). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Opening and Closing of the TVS Isolation Valves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Opening and Closing of the Bleed Valves. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Strainer Blowdown Valve and Depressurization of the TVS 6000UD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Testing the Operation of the Steam Trap Fitted onto the TVS 6000UD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Maintenance Operation and Replacement of Steam Trap Fitted on the TVS 6000UD. . . . . . . . . . . . . . . . . . 5
Closing Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Opening Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Troubleshooting TVS 6000UD Isolation Valves and Bleed, Test and Blowdown Valves . . . . . . . . . . . . . . 6
Removing Bonnet Assembly, Valve Sealing Rings, Lantern Bushings, & Valve Washers . . . . . . . . . . 7
Installing New Isolation Valve Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Repair Parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Limited Warranty and Remedy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Table of Contents

North America • Latin America • India • Europe / Middle East / Africa • China • Pacific Rim
armstronginternational.com
Designs, materials, weights and performance ratings are approximate and subject to change without notice. Visit armstronginternational.com for up-to-date information.
3
General Safety Information
This manual shall be used by experienced personnel only as a guide for installation and maintenance of the TVS 6000UD Trap
Valve Station Series. Selection or installation of equipment should always be accompanied by competent technical assistance. We
encourage you to contact Armstrong International or its local Representative if further information is required.
Equipment under pressure – operating at temperatures >212 °F/100 °C – make sure that all components (TVS and trap) are cold
before handling.
Operation (see exploded view on page 7)
In a double piston valve, the control of stem and seats leakage is obtained by tightness of valve sealing rings (3) to the body and
valve plugs (5). The bonnet compresses the valve sealing rings against the body and the valve plugs. Flexible disc springs (7)
automatically assure a tight seal by exerting pressure on the valve sealing rings, keeping them compressed.
Opening and Closing of the
TVS Isolation Valves
The arrows on the hand wheels clearly indicate the direction
to which the hand wheels must be operated (“+” to open and
“–“ to close)
The isolation valves A-A’ (upstream marked with red washer)
and G-G’ (downstream marked with green washer) begin
to stop the flow when the valve plugs enter the upper valve
sealing ring (3).
To play its role of double isolation valve, the plug must be
moved downward until it closes the lower valve sealing ring
(3) and valve stroke is achieved.
When the isolation valves are completely closed, the valve
plug is in full contact with the valve sealing rings, ensuring
the best possible seal. Since there is no metal to metal
seating, torquing the isolating valves closed is not required.
Armstrong recommends that after closing the isolation
valve completely, the hand wheel should be turned back
one-half turn. This makes it easy to re-open the valve after
prolonged periods of no use.
Icon Legend
CAUTION! Potential property damage, expensive repairs, and/or voiding the
equipment warranty may result.
BURN HAZARD! Contact with steam, hot water, or hot metal surfaces can cause
severe skin burns. Skin exposure to 140°F (60°C) water or metal
 foronlyve(5)secondsmaycauseaseconddegreeburn.
Model L/R

North America • Latin America • India • Europe / Middle East / Africa • China • Pacific Rim
armstronginternational.com
Designs, materials, weights and performance ratings are approximate and subject to change without notice. Visit armstronginternational.com for up-to-date information.
4
Opening and Closing of the Bleed Valves
The role of the bleed valves in the TVS 6000UD is to allow safe and quick replacement of the connected steam trap. When the 2 isolation
valves are closed, if there is any leakage from the isolation points it will be visible and divert to the atmosphere through the opened bleed
valves, i.e. upstream (A-A’) or downstream (G-G’) isolating valves.
This allows any leaks to be visualized and any potentially dangerous working conditions avoided during maintenance.
The 2 bleed valves will be opened and closed with a flat wrench (13 mm) with a torque of 55-68 N-m.
Strainer Blowdown Valve and
Depressurization of the TVS 6000UD
The TVS 6000UD is supplied with a built-in strainer designed to protect more sensitive steam traps against dirt normally present in
steam systems. The strainer is fitted with a blowdown valve (D) used to clean the screen on a regular basis. This blowdown valve can be
used at start-up to eliminate the larger amount of condensate generated into the atmosphere.
BURN HAZARD! Hot condensate and flash steam will be discharged from the test port. Use caution as burns could
occur to personnel. During this operation, the downstream isolation (G-G’) is normally closed. The same blowdown valve is
also used as a depressurizing valve when needed (during the replacement procedure of the steam trap). In this case, both
isolation valves (A-A’) and (G-G’) are to be closed and bleed valves (B and H) are to be open to atmosphere.
Testing the Operation of the Steam Trap
Fitted onto the TVS 6000UD
• Keep the upstream isolating valve (A-A’) open
• Close the downstream isolation valve (G-G’)
• Open test valve (F). Its location is indicated on the name plate
• Observe the steam trap operation at test port
BURN HAZARD! Hot condensate and flash steam will be discharged from the test port. Use caution as burns could
occur to personnel.
• Re-open the isolation valve (G-G’) and close the test valve (F) with a flat wrench (13 mm) with a torque of 55-68 N-m.

North America • Latin America • India • Europe / Middle East / Africa • China • Pacific Rim
armstronginternational.com
Designs, materials, weights and performance ratings are approximate and subject to change without notice. Visit armstronginternational.com for up-to-date information.
5
Maintenance Operation and Replacement
of Steam Trap Fitted on the TVS 6000UD
In case the steam trap must be replaced for any reason, please apply the safety procedure as follows:
Closing Procedure
BURN HAZARD! Use caution as burns could occur to personnel.
Close A-A’, G-G’
Open B, H, F, D
• After pressure has been relieved, remove bolts and the trap
• Clean the connector block sealing surfaces
• Apply “Never seize” to the new trap bolts (2), insert bolts through connector block making sure the trap is properly positioned
(per ex: inverted bucket in the vertical position). Tighten bolts evenly with a torque of 55-80 N-m
• Resume normal (steam) operation. Please apply the safety procedure as follows:
Opening Procedure
• Close B, D
• Open A-A’
• Check that the steam trap is working properly
• Close F, H
-Check for leaks around the connector block

North America • Latin America • India • Europe / Middle East / Africa • China • Pacific Rim
armstronginternational.com
Designs, materials, weights and performance ratings are approximate and subject to change without notice. Visit armstronginternational.com for up-to-date information.
6
Troubleshooting TVS 6000UD
Isolation Valves and Bleed, Test and
Blowdown Valves
A piston valve will retain its leak tightness for several years without maintenance. In severe service such as rapid heating and cooling,
some field maintenance may be required. Depending on the problem, these simple steps may help:
• Isolation valve(s) (A-A' and/or G-G') leak when the valve(s) is(are) closed.
-First, check to make sure the isolation valves are completely closed. Then, check to see if the bonnet is seated on the body of
the connector block. If not, tighten the bonnet bolts until the bonnet seats. This will allow the bonnet bolts to compress the
valve sealing rings against the body and the valve plug. If the valve(s) continue to leak, replace the isolation valve assembly.
• Valve stem leaks.
-See above instructions.
• Maintain the isolation valves as soon as leakage starts. Internal leakage can wear the valve plug or valve sealing rings and
they will have to be replaced if leakage continues.
CAUTION! Before tightening the bonnet bolts, ensure the isolation valve is in the closed position.
• Bleed (B&H), test (F) and blowdown (D) valves leak. Reseat with 55-80 N-m torque.

North America • Latin America • India • Europe / Middle East / Africa • China • Pacific Rim
armstronginternational.com
Designs, materials, weights and performance ratings are approximate and subject to change without notice. Visit armstronginternational.com for up-to-date information.
7
Removing Bonnet Assembly, Valve Sealing
Rings, Lantern Bushings, & Valve Washers
Description Quantity
1BONNET TVS CS A105N/LF2 (D8563) 1
2Handwheel TVS/Manif DI (D126073) 1
3RING VAL TVS4000 GPH + SS (B5028)* 3
4Bushing Lantern SS T303 (B5019)* 1
5Stem Val TVS6000 SS 17-4PH
(D125134) 1
6Bolt Hex M8 X 1.25 x 25mm CS (B5035) 2
7Washer Flat ID SS T304 (B5033) 2
8Nut Hex M6XI SS 17-4PH (B5022) 1
9Spring Disc (B5031)* 7
10 WASHER FLAT 10.5MM ID SS T304
(B5029) 4
11 Bushing Lantern TVS6000 SS T303
(D125140)* 1
12
DISC TVS 6000UD OD 26 X ID 8 X
THICK 0.5 MM:
RED (D125703)
or
GREEN (D125702)
1
(*) part of Seal ad Mech Assembly (D125704)
• This can be done with the TVS 6000UD remaining in the steam line.
• Be sure to isolate the TVS 6000UD trap valve station both up and downstream by using separate shut-off valves before
performing any maintenance
• Open isolation valves (A-A’) and (G-G’)
• Open bleed valve (B&H) to atmosphere
• Open the blowdown/depressurizing (D) to atmosphere
• Loosen and remove the bonnet bolts and pull the bonnet assembly out of the valve body
• Remove the valve sealing rings, valve washers and lantern bushings using Armstrong extracting tool. Check to see if all
components have been removed. Inspect and clean any debris that might have remained in the valve body
CAUTION! This applies to all points above: equipment under pressure – operating at temperature >212 °F/100 °C
– ensure all components (TVS and trap) are cold before handling.
Installing New Isolation Valve Assembly
• Place Armstrong spare part # D125139 isolation valve assembly in the valve body
• Lightly tap the isolation valve assembly to the bottom of the valve body
• Coat the threads of the bonnet bolts with “Never Seize”, insert bolts through bonnet holes and tighten evenly until the bonnet seats
on the valve body
• Check the TVS 6000UD isolation valve for proper operation by opening and closing the valve one or two times
• Open shut-off valves up and downstream from the trap valve station with its isolation valve in the closed position and check for
leaks with trap installed
• Follow the opening and closing sequences as explained on page 5
Repair Parts
• Packing assembly TVS6000 SST303 (D125139)
• Seal and Mech TVS 6000UD (D125704)
• Valve NBD assembly ¼ MNPT TVS6000SST303 3.1 (D125135)
