ASCOM Myco 3 User manual

Quick Reference Guide
Ascom Myco™ 3
ascom

Introduction
Ascom Myco 3 supports streamlined workows, fast responses and fact-based
decisions. The enterprise-grade Ascom Myco 3 smartphone delivers actionable,
context-rich information to mobile personnel in healthcare, manufacturing, and
other demanding environments. The handset is based on AndroidTM 8.1 OreoTM and
includes several Ascom solutions complementing the Android standard oering.
This Quick Reference Guide (QRG) provides a brief overview of the most common
features of the Ascom Myco 3 handset.
The images in the QRG are taken from a handset with an English user interface.
Some functionalities described in this QRG may dier from your handset
depending on system conguration. Images of the screen can also dier from how
the screen looks on your handset.
Remember to read the Safety Instructions included in the product delivery before
using the handset.
The information in this document is subject to change without notice.
Ascom Myco is a trademark of Ascom (Sweden) AB.
Android, Google, Google play and other marks are trademarks of Google LLC; Oreo is a trademark of Mondelez International, Inc. group.
Table of Contents
Handset
Buttons
Handset Screens
Calling
Messaging
Notication Overview
Manage Notications
Notication Drawer
Quick Settings
1
2
3
4
4
Low Battery
True Hot Swap
Charging Methods
Battery Charging Rack
Desktop Charger
Handset Charging Rack
Micro USB Cable
7
Overview
Views
Communication
Notication
Settings
Charging
© 2019 Ascom. All rights reserved. TD93301EN / March 2019 / Ver. A
ascom © 2019 Ascom. All rights reserved. TD93301EN / March 2019 / Ver. A
ascom
8
8
9
9
10
11
11
5
5
6

© 2019 Ascom. All rights reserved. TD93301EN / March 2019 / Ver. A
ascom © 2019 Ascom. All rights reserved. TD93301EN / March 2019 / Ver. A
ascom
Top multifunction
button
Power
button
Volume
button
Main
display
Back
button
Overview
button
Home button
Back camera
Barcode
scanner
Exchangeable
color pad for
Clip
Battery
cover lock
Battery
pack
Multifunction
buttons
Multi-color
LED
Microphone
Microphone
Micro USB charging port
3.5 mm
Headset jack
Ascom IR location
Front
camera
Multifunction buttons
•Depending on the conguration this button can
be used for dierent purposes. For example, you
can scan a barcode or start an app.
Buttons
The handset is equipped with Back, Home, Overview, Power, Volume, and three
Multifunction buttons.
1
1
Power Button
•Press and hold to turn the handset on / o or
restart it.
• Press to lock and put the handset into sleep
mode.
Volume Button
•Press up (+) to increase or press down (-) to
decrease the volume level.
•Press and hold down (-) to mute all the sounds.
Press down (-) again to put the handset in silent
mode.
Back Button
•Press to navigate backwards, to the previous
screen.
Home Button
•Press to wake the screen from sleep mode.
•In unlocked mode, press to navigate to the
Home screen from any app.
Overview Button
•In unlocked mode, press to see a list of all active
apps.
2
3
2
3
4
5
6
1
46
5
Overview
12
Overview
Handset

© 2019 Ascom. All rights reserved. TD93301EN / March 2019 / Ver. A
ascom © 2019 Ascom. All rights reserved. TD93301EN / March 2019 / Ver. A
ascom
Handset Views
The interface of the handset is divided into two separate views:
The Home screen is the main view of the handset, where you can use such
features as shortcuts to get a quick access to dierent apps and functions.
The All apps screen is the view where you can nd all the installed apps on the
handset.
To get to the All apps screen, swipe up from the bottom of the Home screen or tap
the Up arrow icon .
To get back to the Home screen, swipe down in the All apps screen, or press the
Back or Home buttons.
Home screen
Navigate between Views
All apps screen
Back
button Home button
Communication
4
Calling
Messaging
1
Favorites
In the All apps screen, tap the Messages app
icon . You can also open the app from
the Shortcut panel of the Home screen.
Tap the Start chat icon at the
bottom of the screen to write a new message
or tap the conversation to read and reply to
it.
1
2
Manual
dialing
Contacts
Recent
calls
In the All apps screen, tap the
Phone app icon . You can also
open the app from the Shortcut
panel of the Home screen.
2Choose between manually dialing
the phone number, choosing the
contact from Favorites, Recent
calls, or the Contacts list .
NOTE:
Frequently used apps can be found in the shortcut panel of the Home screen.
If you can not nd the apps or want to change the shortcuts, contact your
system administrator for assistance.
Shortcut
panel
Views
3

© 2019 Ascom. All rights reserved. TD93301EN / March 2019 / Ver. A
ascom © 2019 Ascom. All rights reserved. TD93301EN / March 2019 / Ver. A
ascom
Swipe left or right to
clean the notication (if
allowed).
Manage Notications
Tap the Down arrow
icon or swipe down
on the notication to
see the details.
Double tap the
notication to open the
app that sent it.
Notication Overview
Notications appear in dierent places and formats, such as icons in the Status
bar or as detailed texts in the Notication drawer. In unlocked mode, notications
appear at the top of the screen.
1. App icon
2. App name
3. Timestamp
4. Expand indicator
5. Title / Headline
6. Supporting text
7. Actions
8. Icon, for example "Contact icon"
123
4
5
6
7
There are three ways to manage notications on the lock screen:
8
Notications
5
To open the Notication drawer, swipe
down from the top of your screen.
You can open the Notication drawer in
unlocked mode and on the lock screen.
Notication Drawer
The Notication drawer shows a
list of notications, such as missed
calls, conversations, system and app
messages.
Incoming notications rst appear as
icons in the Status bar at the top of
the screen to show that there is new
information in the Notication drawer.
Back
button
Home
button
To hide the Notication drawer,
swipe upwards, tap outside the
drawer, or press the Back or
Home buttons.
Notications
6

© 2019 Ascom. All rights reserved. TD93301EN / March 2019 / Ver. A
ascom © 2019 Ascom. All rights reserved. TD93301EN / March 2019 / Ver. A
ascom
Quick Settings
To see a selection of settings, swipe
down from the top of the screen.
To open the whole Quick Settings
panel, swipe down again.
To turn the setting on / o , tap
the corresponding icon.
The Quick Settings panel can be used to make some fast changes in your Ascom
Myco 3, such as alter the brightness of the screen or put the handset in battery
save mode.
You can open the Quick Settings panel both in unlocked mode and on the lock
screen.
Settings
7
Charging
8
Low Battery
If the battery level is low, charge the battery or change it to a fully charged one as
soon as possible.
-Low battery icon
-"Battery is low" notication
A battery level of 5 % or less is
indicated by:
-Battery alert icon
-"Battery is low" notication
-Sound signal from the handset
A battery level of 15 % or less is
indicated by:
True Hot-Swap
Ascom Myco 3 has an easily replaceable battery that can be changed without
powering down the handset or exiting your active apps. With hot-swap
functionality you can continue working and using your apps even when the battery
is being exchanged.
-When removing the battery, your handset is operational for another 60
seconds.
-If the battery is not replaced within 60 seconds, the handset switches o.

© 2019 Ascom. All rights reserved. TD93301EN / March 2019 / Ver. A
ascom © 2019 Ascom. All rights reserved. TD93301EN / March 2019 / Ver. A
ascom
Remove the battery pack from the handset and place it in the charging slot
for batteries. Push the battery in until it clicks into the locked position. If the
battery has been correctly inserted, the LED turns orange to show that the
battery is charging.
When the LED turns green, the battery is fully charged.
Charging
Slide the battery cover lock to the right to release the battery.
Remove the battery pack from the handset and place it in the charging slot.
If the battery has been correctly inserted, the LED turns red to show that the
battery is charging.
When the LED turns green, the battery is fully charged.
The handset has a rechargeable battery that can be charged separately from the
handset. To charge it, use the Battery Charging Rack or the Desktop Charger.
If you want to charge the handset, do it either with a Handset Charging Rack,
Desktop Charger or a Micro USB cable.
Battery Charging Rack
2
1
3
9
Charging Methods
Charging
10
NOTE: With the Desktop Charger you can charge the handset together with one
extra battery.
Desktop Charger
Place the handset in the charging slot for handsets. If the handset is correctly
inserted, the charging screen appears showing the battery charge level and
the owner name.
When the green check mark icon appears on the screen and the LED turns
green, the battery is fully charged.
1
2
Use the Desktop Charger to charge only the handset or the handset together with one
extra battery.
3
4

© 2019 Ascom. All rights reserved. TD93301EN / March 2019 / Ver. A
ascom © 2019 Ascom. All rights reserved. TD93301EN / March 2019 / Ver. A
ascom
Charging
11
Place the handset in a charging slot. If the handset as been correctly inserted,
the charging screen appears showing the battery charge level and the owner
name.
When the green check mark icon appears on the screen and the LED turns
green, the battery is fully charged.
1
2
Handset Charging Rack
Open the charging port at the bottom of the handset.
Attach the Micro USB cable to the charging port and connect USB Power
supply to a power outlet.
When the LED turns green, the battery is fully charged.
Close the charging port to prevent liquid and dust damage.
Micro USB Cable
2
1
3
4

Ascom (Sweden) AB
Grimbodalen 2
SE-417 49 Gothenburg
Sweden
Phone: [phone]
www.ascom.com
