Aseptico ADC-02CF User manual

Foot Panel
Stabilizer
Backrest Strap
Selector Lever
Leveling Foot
Lift Lever
Backrest Latch
Backrest Cylinder
Leg Panel
Arm Sling
Pillow
Backrest Frame
Arm Post
Wheel
ADC-02CF • Setup Guide
Portable Hydraulic Dental Chair • NSN: 6520-01-652-8993
1. Using two people, lift the chair Afrom
the transport case and set it on the
oor.
A
2. Pull out the stabilizer Aand use it
as a handle to tilt the chair up on its
wheels B, then roll the chair to where
it will be used.
B
A
3. Set the chair back down on the oor
making sure the stabilizer
A
is fully
extended. Remove the backrest
strap
B
from the chair.
A
B
CONTINUED ON BACK . . .

4. Adjust the leveling foot A as needed
to compensate for an uneven oor.
A
5. Rotate the selector lever
A
to the
SEAT LIFT position as shown on the
label
B
on the chair base.
A
B
Pump the lift lever C to raise the chair
to the desired height.
C
Press and hold down the selector
lever Din the SEAT LOWER position to
lower the chair.
D
6. Lift the backrest A upright while
guiding the clevis pin B on the end of
the backrest cylinder, into the latch C
on the backrest frame, until they have
securely latched D.
A
C
B
D
7. Rotate the selector lever A to the
BACKREST LIFT position as shown on
the label B on the chair base.
A
B
Pump the lift lever C to raise the
backrest to the desired height.
C
Never attempt to raise the backrest by lifting up on the
backrest, as this may pull air
into the hydraulic system!
Always use the lift pump lever
to raise the backrest.
Press and hold down the selector lever
D
in the BACKREST LOWER position
to lower the backrest; if the seat is
unoccupied, it may be necessary to
push down on the backrest to help it
recline.
D
8. Unfold the leg Aand foot Bpanels of
the chair.
A
B
9. Fold out the hand grips A on the arm
posts and insert them into the ends of
the arm slings B.
AA
B B
10. Adjust the height of the pillow A as
needed.
A
Refer to the Operation and Maintenance Manual for
complete instructions.
P.O. Box 1548 • Woodinville, WA 98072-1548
[phone] • [phone]
www.aseptico.com • [email protected]
P/N: 421061 • Rev. C • ECO 13890 • 8/2016
Printed in USA
