Aseptico ADU-03 Manual

OPERATION and MAINTENANCE
INSTRUCTION MANUAL
ADU-03 Single Handpiece Manual Con rol Sys em

The Aseptico ADU-03 is one of the finest pneumatic handpiece control systems available to the
professional. Offering manual activation and easily mounted on a wall or post, the ADU-03
provides an economic control system for a dental operatory, hygienist's room, or satellite office.
Congratulations!
This system is engineered to provide many years of reliable service. Please read the instructions
provided in this manual to receive the best and longest service from your Aseptico equipment.
Separate manuals may be provided to cover the operation and maintenance of handpieces or
other accessories for your unit. Handpieces are purchased separately.
PACKAGE CONTENTS
•ADU-03 Pneumatic Control Unit
•TA-90D 3-Way Air/Water Syringe with Tip
•AA-42 Foot Control and Tubing
1. Use the WALL MOU TI G HOLES to
secure cabinet back to a flat vertical surface
(see Fig. 1)
2. Attach the front of the unit to the CABI ET
MOU TI G TABS using the 8 screws
provided (see Fig. 1).
3. Connect the braided airline to a clean
regulated 70-100 PSI compressed air supply.
4. Connect the blue water line to 35psi max city
water supply -OR- if using the Optional
NWS-7 Water System, fill the white plastic
water-supply bottle with clean water and
attach the bottle to the white fitting on the
underside of the unit (see Fig. 2).
WALL MOUNTING HOLES
CABINET MOUNTING TABS
Figure 1
OPTIONS
•WS-7 Self-Contained Clean Water System
with AA-61 Water Connector for scalers
SETUP:
OPTIONAL NWS-7
WATER S STEM
WATER FLOW
CONTROL
WATER ON/OFF
TOGGLE
PRESSURE
GUAGE
3-WA
S RINGE
HANDPIECE
CONNECTOR
DRIVE AIR
PRESSURE CONTROL
(UNDERNEATH
CONSOLE)
Figure 2
AA-61
WATER CONNECTOR

Water On/Off Toggle:
Controls the on/off flow of water coolant to
the handpiece.
Water Flow Control:
Adjusts the water coolant flow to the
handpiece.
Pressure Gauge:
Gives a visual indication of the drive air
pressure to the handpiece.
Drive Air Pressure Control:
Adjusts the drive air pressure to the
handpiece.
Foot Control:
Controls the drive air pressure to the
Figure 3 DEPRESS
LOCKING COLLAR
handpiece. Apply light foot pressure to
any part of the foot control cover.
3-Way Air /Water Syringe:
Delivers air, water, or a combination mist.
Supplied with autoclavable tip.
NWS-7 Water System (Optional):
White 1-liter bottle dispenses water
through the 3-Way Air/Water Syringe and
handpiece.
AA-61 Water Connector:
Provides water via standard 1/4” quick
disconnect to independent Cavitron or
scaler units requiring a water supply.
OPERATION FUNCTIONS: (Refer to Fig. 2)
UNIT OPERATION:
Handpiece - Connect either a high-speed or
low-speed handpiece to the handpiece
connector. Depress foot control for operation.
3-Way Air/Water Syringe - Depress the right
button for air operation, and the left button for
water operation. Depressing both buttons will
create a mist. The syringe features quick-
change autoclavable tips: To remove a tip,
press on the locking collar surrounding the tip
socket and pull the used tip straight out of the
socket (see Fig 3). To insert a new tip, press
locking collar and push tip into socket as far
as it will go. Release collar and gently tug on
tip before using to ensure that tip is securely
locked into socket.
CLEANING
Syringe Tip Sterilization:
1) Remove contaminated syringe tip.
2) Remove all visible signs of contamination
before autoclaving.
3) Autoclave tip at 132° C (270° F) for ten minutes.
4) Sterilize between each patient use.
NOTE: Since only the tips can be autoclaved,
it is recommended that the air/water syringe
be bagged with a disposable, single-use
plastic sleeve between each patient use.
Water Lines: Disinfect the water lines weekly.
Prepare a 1:10 bleach solution (1 part
household bleach to 10 parts water). Remove
water reservoir and discard residual water.
Replace empty water supply tank and air
purge all waterlines. Fill water supply tank with
bleach solution. Run bleach solution through
all lines. Allow bleach solution to stand in lines
for 10 minutes. Remove water supply tank and
discard bleach. Flush water supply tank and
all lines thoroughly with clean water. Air purge
and leave lines dry until next clinical use.

P/ 420284
Rev. G
ECO 14684
03/2019
Printed In The USA
P.O. Box 1548, Woodinville, WA 98072
8333 216 th Street S.E. Woodinville, WA 98072
[phone] • [phone]
www.aseptico.com • [email protected]
WARRANTY
Aseptico warrants its products against defects in material or workmanship for a period of two (2)
years, from date of original invoice. Some handpieces are warranted for one year under the
same conditions. Other handpieces and expendable components, such as air turbines and light
bulbs, are covered by shorter warranty periods, or have no warranty. Aseptico's sole obligation
under product warranty is (at its sole option and discretion) to repair or replace any defective
component or product in part or whole. Aseptico shall be the sole arbiter of such action.
In the event of alleged defect under warranty, the purchaser is to notify Aseptico's Customer
Service Department promptly. Customer Service will provide instructions, usually directing that
the product be returned for service. Shipment to Aseptico and the cost thereof is always the
responsibility of the purchaser.
Accidental misuse, inappropriate installation, or failure to perform directed maintenance voids the
warranty. Deliberately defacing, modifying, or removing the serial number voids the warranty.
Aseptico does not assume, under this warranty, any risks or liabilities arising from the clinical use
of its products, whether or not such use involves coincidental utilization of products manufactured
by others.
