Aseptico ADC-01P-RED AseptiChair User manual

P.O. Box 1548 • Woodi ville, WA 98072-1548
1-800-426-5913 • 425-487-3157 • Fax: [phone]
Email: i [email protected] • I ter et: www.aseptico.com
OPERATION AND
MAINTENANCE MANUAL
AseptiChair
Item ADC-01P-RED

Page 2
TABLE OF CONTENTS
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Purpose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Performance Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Items Furnished . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Operation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Chair Set-Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Chair Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Collapsing the Chair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Cleaning & Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Parts Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
TABLE OF ILLUSTRATIONS
Figure 1 - eg Adjustment Pin ocation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Figure 2 - eg Adjustment Pin Placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Figure 3 - Folding Out Foot/ eg Rest . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Figure 4 - Arm Sling Pin Insertion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Figure 5 - Backrest adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Figure 6 - Positioning footrest to vertical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Figure 7 - Parts Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Page 3
PERFORMANCE CHARACTERISTICS:
Dimensions
Chair- Folded: 37” x 23” x 9.5”
Extended: 67” x 28” x 46”
Soft carrying case: 36” x 24” x 10”
Weight
Chair only: 30 lbs.
In soft carrying case: 34.5 lbs.
Maximum oad Capacity: Approx. 300 lbs.
Range of Positions
Minimum Seat Height: 11”
Maximum Seat Height: 22”
Backrest: Adjustable from upright (vertical) to supine (horizontal) positions
Footrest: Adjustable from upright (vertical) to supine (horizontal) positions
ITEMS FURNISHED
ADC-01P-RED Portable Dental Chair
Soft padded carrying case with handles
Operation and Maintenance Manual
PURPOSE:
The ADC-01P-RED Portable Dental Chair provides adolescent patient seating for field dentistry
and medical treatment. The ADC-01P-RED is fully adjustable from upright to supine positions.
The ADC-01P-RED is built with a high strength steel frame and rugged replaceable vinyl cover-
ings, allowing for long-term use.

Page 4
CHAIR SET-UP:
1. Remove the chair from its carrying
case and set it on the floor, legs
down, in its folded position.
2. Rotate the chair up onto one side
and remove the leg adjustment pins
from their storage pouch underneath
the chair seat. (Fig. 1)
Figure 1 - Leg Adjustment Pin L cati n
Figure 2 - Leg Adjustment Pin Placement
Figure 3 - F lding Out F t/Leg Rest
Figure 4 - Arm Sling Pin Inserti n
5. Insert right and left arm sling pins into holes
on the sides of the seat frame. (Fig. 4)
6. Complete set-up by positioning backrest and
placing headrest at the proper height on the
front side of backrest.
4. When the chair has been raised and
the height set, the foot and leg por-
tion should be folded forward, out
horizontally. It will stop in the hor-
izontal position. (Fig. 3)
3. Standing in front of the chair, put your toe
on one of the front chair legs and lift up on
the backrest and front seat portion. Raise
chair seat to desired height. ock in place
by inserting leg adjustment pins through
chair leg tube and into adjustment link on
the right and left side of the chair. (Fig. 2)
Leg
Adjustment
Pins
Insert
Leg
Adjustment
Pins
Insert Pins
Into Frame
Holes

Page 5
CHAIR ADJUSTMENTS:
1. Seat Height- The ADC-01P RED chair seat height can be set at
any of the five preset settings. Without a patient in the chair,
put your toe on one of the front chair legs and lift up slightly
on the chair seat. While lifting and holding seat, remove the
leg adjustment pin from the right and left side. Align link with
tube hole in any of the five positions and lock in place by
inserting the pin and chain assembly. (see Fig. 1)
2. Bac rest- The backrest may be set in any
position from upright to full supine. To
change the position of the backrest, simply lift
the chrome friction lever on the back side of
the backrest, lower backrest, then release
lever to lock.
3. Footrest- The footrest may be positioned
in the normal horizontal operating posi-
tion, or allowed to hang down vertically so
a patient can be seated in a sitting position.
To release footrest into the vertical posi-
tion, first fold toe section inward, then lift
slightly on footrest section. While lifting,
pull the black knobs on each side of the
chair frame to release and push footrest
down into the vertical position. ock in
the vertical position by snapping holding
strap around the chair leg frame.
To reposition footrest in the horizontal
position, unsnap holding strap from frame,
lift footrest to the horizontal position until
it locks, then unfold toe section out to hor-
izontal. (Fig. 6)
4. Headrest- The headrest slides freely on its mounting strap and
can be positioned at different heights for different size patients.
To return the backrest to an upright position,
lift backrest to desired position. Backrest will
automatically lock in place. (Fig. 5)
NEVER L WER THE BACK-
REST WHEN A PATIENT IS IN
THE CHAIR WITH UT C M-
PLETELY SUPP RTING
THEIR WEIGHT FIRST.
Figure 5 - Backrest adjustment
Figure 6 - P siti ning f trest t vertical
WARNING
Lift lever to position.
Release to lock.
Snap
Around
Frame
Pull Black
Knob to
Release

Page 6
COLLAPSING THE CHAIR:
1. Fold toe and then leg sections onto seat as it was originally stored.
2. Pull arm slings out of the holes in the chair frame.
3. Put your toe onto one of the front chair legs and lift up slightly on
the seat, then remove height adjustment pins. While supporting
chair weight, let the chair fold down toward the floor.
4. As the chair folds down, release the backrest adjustment lever
until the chair collapses completely. Rotate the chair up onto one
side and insert the leg adjustment pins into their storage pouch
underneath the chair seat.
5. Fold the arm slings and headrest onto the chair and place folded
chair into carrying case.
CLEANING AND MAINTENANCE:
Although bleach, when diluted to <10% and wiped clean immediately
could be used, it is not recommended. The use of barrier covers and
mild cleaning solutions is recommended as the primary asepsis
approach on chair and stool upholstery instead of relying on
chemicals. The use of barriers greatly extends the life of chair and
stool upholstery and can be replaced between patients.
NEVER F RCE THE CHAIR INT THE C LLAPSED P SITI N.
F RCING THE CHAIR D WN WITH UT RELEASING THE
BACKREST ADJUSTMENT LEVER MAY BEND THE ADJUST-
MENT ASSEMBLY AND WILL V ID THE WARRANTY.
WARNING
NEVER SIT ON THE EDGE OF THE SIT-
TING SURFACE. ALWAYS SIT IN THE
CENTER OF THE SEAT.
WARNING

Page 7
NOTES

Page 8
PARTS LIST
Item Part Number Quantity
1Seat Cover Assembly, ADC-01P-RED 460451-01 1
2Armrest Right/ eft, ADC-01P-RED 460447-01 1
3Armrest Right/ eft, ADC-01P-RED 460447-01 1
4Cover, backrest, ADC-01P-RED 461845 1
5Strap, headrest, ADC-01P-RED 461847 1
6Screw, #8x5/8" Chrome SEMS 510239 8
7Headrest, pillow assembly, ADC-01P-RED 461846 1
8Armrest support rod assembly 460444-08 2
9Tie Wrap, 30" 510135 6
10 Tie Wrap, 13" 510134 3
11 Strap, leg, ADC-01P-RED 461848 1
12 C/S, 1/4-20x1" BtnSoc S/S 510294 1
13 Hinge, back support 460382-08 1
14 Nut, 1/4-20 Nyloc S/S 510296 8
15 Back Support Assembly 330088 1
16 eg adjustment link 460097-08 2
17 Hole plug, 1/4" black 510201 2
18 Endcap, 1" domed 850026 4
19 eg Assembly, inside 330099 1
20 eg Assembly, outside 330101 1
21 Bolt, 5/16-18 Grade 5 carriage 510242 2
22 Washer, 5/16 Flat S/S 510266 4
23 Nut, 5/16-18 Nyloc S/S 510126 2
24 Endcap, 1" insert 510204 2
25 C/S, 1/4-20x1-1/4" BtnSoc S/S 510295 3
26 Toe Frame Assembly 330091 1
27 Nut, 5/16-18 hex S/S 510103 2
28 Foam, seat pad 460576 1
29 Spring Pin, 1/4x3/4" S/S 510251 2
30 eg Frame Assembly, cmpl 330093-08 1
31 Knob, 5/16-18 insert cornet 850025 2
32 Spring, .420Dx.038Wx.875 comp. 510233 2
33 C/S, 5/16-18x1-1/4" S/S 510050 2
34 C/S, 5/16-18x1" S/S 510048 4
35 SMS, PanPhl #6 x 5/8“ Tapping 510362 2
36 Washer, 5/16 SAE S/S 510107 8
37 Seat Frame Assembly, cmpl 330097-08 1
38 Pin, leg adjustment assembly 460445-08 2
39 C/S, 1/4-20x1-3/4" BtnSoc S/S 510027 4
40 Hole plug, 3/4" black 510263 2
41 Backrest Frame Assembly, ADC-01P-RED 330561-01 1
42 Spacer, 1/4ID x 3/4OD Coved 510261-01 2
43 Spacer, 1/4ID x 3/4OD x .250 thick 510379 2
Not Shown Case, grey carrying, w/Handles 410193 1
Not Shown Backrest Assembly, ADC-01P-RED, compl 330562 1

PARTS DIAGRAM
Aseptic ADC-01P-RED
P rtable Dental Chair
Figure 7 - Parts Diagram

NOTES

NOTES

P.O. Box 1548 • Woodi ville, WA 98072-1548
1-800-426-5913 • 425-487-3157 • Fax: [phone]
email: i [email protected] • I ter et: www.aseptico.com
P/N: 420821
Rev. G
EC 14684
03/2019 PRINTED IN THE USA
WARRANTY
Aseptico warrants its products against defects in material or workmanship for a
period of two (2) years, from date of original invoice. Some handpieces are
warranted for one year under the same conditions. ther handpieces and
expendable components, such as air turbines and light bulbs, are covered by shorter
warranty periods, or have no warranty. Aseptico's sole obligation under product
warranty is (at its sole option and discretion) to repair or replace any defective
component or product in part or whole. Aseptico shall be the sole arbiter of such
action.
In the event of alleged defect under warranty, the purchaser is to notify Aseptico's
Customer Service Department promptly. Customer Service will provide instructions,
usually directing that the product be returned for service. Shipment to Aseptico and
the cost thereof is always the responsibility of the purchaser.
Accidental misuse, inappropriate installation, or failure to perform directed
maintenance voids the warranty. Deliberately defacing, modifying, or removing the
serial number voids the warranty.
Aseptico does not assume, under this warranty, any risks or liabilities arising from the
clinical use of its products, whether or not such use involves coincidental utilization of
products manufactured by others.
