Aseptico AMC-20 Manual

AMC-20 Mo ile Dental System
OPERATION and MAINTENANCE
INSTRUCTION MANUAL

P.O. Box 1548 • Woodinville, WA 98072
8333 216 th Street S. . • Woodinville, WA 98072
International [phone] • Toll Free [phone]
www.aseptico.com • [email protected]
i.
This device has been tested and found to comply with the
emissions requirements of I C 60601-1-2:2001-09. These
requirements provide reasonable protection against harmful
electromagnetic interference in a typical medical installation.
However, high levels of radio-frequency (RF) emissions from
electrical devices, such as cellular phones, may disrupt the
performance of this device. To mitigate disruptive
electromagnetic interference, position this device away from
RF transmitters and other sources of electromagnetic energy.
Classifications in accordance with
UL-60601-1:
- Class II
- Type B Applied Parts
- Type BF quipment
- Ordinary Protection
- Not suitable for use in the presence of a
flammable anesthetic mixture with air, oxygen,
or nitrous oxide.
Note: For reliable grounding, connect to receptacle
marked “Hospital Grade”.
To prevent injury to people and damage to property,
please heed relevant warnings and remarks. They
are marked as follows:
WARNING: Serious injury or death may result if
ignored.
CAUTION: Damage to property or the
environment may result if ignored.
NOTE: Important additional information
and hints.
INDICATIONS FOR USE:
The AMC-20 is a mobile self-contained dental system that is
used for endodontic and general dentistry applications.
RX: FEDERAL LAW RESTRICTS THIS DEVICE TO
SALE BY OR ON THE ORDER OF A DENTIST
TABLE OF CONTENTS:
Introduction . . . . . . . . . . . . . . . . . . . . . . . . .1
Package Contents . . . . . . . . . . . . . . . . . . . .1
Safety Precautions . . . . . . . . . . . . . . . . . . .2
Setting Up the Unit . . . . . . . . . . . . . . . . . . .3
F gure 12 - Cart Front & S de V ew . . . . .5
F gure 13 - Cart Back V ew . . . . . . . . . . .6
F gure 14 - Cart Back V ew . . . . . . . . . . .7
Operation Functions . . . . . . . . . . . . . . . . . .8
Optional quipment Functions . . . . . . . . .10
Routine Adjustments . . . . . . . . . . . . . . . . .15
Sterilization & Maintenance . . . . . . . . .16-18
Packing/Unpacking Instructions . . . . . . . .19
Optional Case Packing Instructions . . . . .20
Troubleshooting . . . . . . . . . . . . . . . . . . . . .21
Specifications . . . . . . . . . . . . . . . . . . . . . .22
Symbol Definitions . . . . . . . . . . . . . . . . . . .23
Replacement Parts List . . . . . . . . . . . . . . .24
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . .25
CONFORMS TO UL STD 60601-1;
C RTIFI D TO CSA STD C22.2 NO. 601.1

1.
Congratulations!
Your new Aseptico AMC-20 Dental System is the finest mobile dental system available. The System
provides an array of standard and optional dental equipment features and functions designed to
serve a wide range of dental applications -- all conveniently packaged into a single self-contained
transportable cart.
This System is engineered to provide many years of reliable service. Please read the instructions
provided in this manual to receive the best and longest service from your Aseptico equipment.
Optional equipment and features are indicated in black and gray text blocks. Separate manuals
may be provided to cover the operation and maintenance of other accessories for your unit.
PACKAGE CONTENTS:
• Self Contained Mobile Cart
• HV and Saliva jector Hoses with Valves
• TA-90D 3-Way Air/Water Syringe with Tip
• Two 1-Liter Water Bottles, PN 730631-01
• AA-43W Wet/Dry Foot Control
• Power Cord – 120V Hospital Grade, PN 840101
• Waste Hose Assembly, PN 330673
PURCHASED SEPARATELY:
• AHP-72MBFO-XL 1:5 Increaser -Type Handpiece w/Fiber Optics
• AHP-77C 1:2 Increaser -Type Surgical Handpiece
• AHP-63MBFO-XL 1:1 -Type Handpiece w/Fiber Optics
• AHP-56MBFO-XL 5:1 Reduction -Type Handpiece w/Fiber Optics
• AHP-88MNP 8:1 Reduction -Type ndodontics Handpiece
STANDARD FEATURES:
• Automatic handpiece controls for two
pneumatic handpieces.
• ach pneumatic handpiece provides individually
controlled water and coolant air.
• 3-way air/water syringe with a self contained
water system.
• High Volume (HV ) and low volume
vacuum lines with adjustable suction valves and
a solids trap.
• 2 HP compressor with Aseptico pioneered
split head compression and vacuum.
• Aluminum tank for rust-free air supply.
• Rotating arms for positioning of the tubing in
the front of the unit.
OPTIONAL FEATURES:
• Optional 3rd pneumatic handpiece *.
• Optional Integrated electric motor with
control panel *. lectric handpiece provides
individually controlled water and coolant air.
• Optional ultrasonic scaler *.
• Optional curing light *.
• Optional fiber-optic illumination for handp'cs.
• Optional amalgam separator.
• Optional dual-voltage operation
(*) Only three of these four opt ons w th aster sks
can be added to each system conf gurat on.
OPTIONAL FEATURES:
OPTIONAL EQUIPMENT:
• A U-5000 Remote Mount Assembly
• AA-19L D-20CK5 Fiber-Optic 5-Hole Handpiece Illumination Kit
• AA-20CLM-CK Curing Light w/Module Kit
• ASC-10-20CK Ultrasonic Scaler with 3 Tips
• AA-20CL-CK Rapid Cure L. .D. Visible Curing Light
• AA-20AMAL-CK Amalgam Separator and By-Pass Filter
• Portable Case for Transporting Mobile Cart, PN 410195
• 110V or 220V Voltage Input, PN AA-20DV-CK
OPTIONAL EQUIPMENT:
NOTE: A L st of Replacement Parts s
Prov ded on Page 24.

2.
SAFETY PRECAUTIONS:
Aseptico accepts no liability for direct or consequential injury or damage resulting from improper
use, arising in particular through the non-observance of the operating instructions, or improper
preparation and maintenance.
WARNING: Clean, disinfect, and sterilize new or repaired handpieces and instruments before
first use and between each patient use. Only use sterilized handpieces and
instruments during treatment. Non-sterilized handpieces and instruments may cause
bacterial or viral infections. Always sterilize handpieces and instruments after
operation.
CAUTION: Always examine unit components for damage before commencing treatment.
Damaged components must not be used and must be replaced.
WARNING: Use for intended purposes only. Failure to observe the operating instructions may
result in the patient or user suffering serious injury or the product being damaged,
possibly beyond repair. Before using this product, make sure that you have studied
and understood the operating instructions.
WARNING: For use by qualified and trained personnel only.
WARNING: Do not install where there is a risk of an explosion. The Mobile Dental System is not
intended for operation in the presence of flammable anesthetics or gases.
WARNING: Always operate a high-speed handpiece with water coolant. Operating a high-speed
handpiece without water coolant can cause thermal injury to the patient.
CAUTION: Observe local regulations concerning disposal of amalgam waste.
WARNING: Never operate unit or work on patients when the top cover is open.
WARNING: Do not use this device for dental implant procedures.
CAUTION: Do not run saline solutions through the water system -- saline will corrode the water
filters.
WARNING: CONTRAINDICATIONS
Ultrasonic oscillations emitted by the optional Ultrasonic Scaler may prevent the
proper function of cardiac pacemakers. Therefore, Aseptico recommends that
patients with a cardiac pacemaker should not be treated with the Ultrasonic Scaler
component of the AMC-20 Cart.
WARNING: The optional Ultrasonic Scaler instrument tips oscillate at high frequency and can
fracture during operation. To help prevent the tips from fracturing and possibly
injuring the patient, always follow the scaler manufacturer's operating instructions
and recommended ultrasonic power settings.
WARNING: Do not use the optional Ultrasonic Scaler dry. If used dry, the Instrument Tip will heat
immediately. This may cause thermal injury to the tooth. nsure that adequate liquid
coolant is always available.
WARNING: Avoid looking directly into the optional Curing Light. Protect patient's eyes with
darkened eyewear when using the Curing Light Probe.
CAUTION: The lens for the optional electric motor L D is soft and can be damaged. If lens
needs to be cleaned, use a lint-free swab and isopropyl alcohol - do not use other
solvents as they might adversely react with the L D assembly.
CAUTION: The A U-5000 lectric Motor is not recommended for use with endodontic files that
have torque limit requirements less than 100 g-cm.
OPTIONAL EQUIPMENT SAFETY PRECAUTIONS:

1. Unpack the AMC-20
Dental System from
its cardboard crate
(Fig. 1) See page 19.
2. Attach the
appropriate air
handpieces to their
4-hole midwest style
connectors.
3. Place all handpiece and accessories tubes
in their appropriate holders (Fig. 2).
4. Attach the 'Waste-Full' sensor to the
connector on the top of the waste
compartment (see Fig. 3). nsure that all
tubes and the bungee tie-down cord are in
place on the waste container.
SETTING UP THE UNIT: 5. Fill the water
bottles with clean
water or other
suitable irrigation
fluid and attach to
the water bottle
caps (Fig. 4). The
water bottles
include floating
level indicators,
color coded to
identify different
fluids, e.g., sterile
water or distilled water.
6. Place the foot control on the floor.
7. Attach power cord to the back of the unit
(Fig. 5) and plug
into a grounded
electrical outlet.
Confirm that the
power cord is
correct for the
voltage source in
the country of use.
Turn main power
‘On’ (—).
8. Check system operating pressure on the
pressure gauge located under top cover
(Fig. 6). Use the system regulator to set
system operating pressure to optimum 80
PSI (5.51 bar). To adjust pressure, raise
knob on regulator, then turn clockwise to
increase pressure or counterclockwise to
decrease.
FIG. 3
WAST -FULL
S NSOR
3.
FIG. 2 INSTRUM NT HOLD RS
FIG. 5
MAIN
POW R
INL T
MAIN
POW R
ON/OFF
SWITCH
FIG. 6
RAIS KNOB
TH N ROTAT
TO ADJUST PR SSUR
FIG. 1 FIG. 4
L V L INDICATORS
WAT R BOTTL S
WAT R
BOTTL CAPS

4.
9. Unpack the AMC-
20 Dental System
from its optional
shipping case
(Fig. 7) per the
instructions
provided on page
20 or in the
Aseptico
"Packing Guide",
included in the case.
10. Attach the optional AEU-5000 Electric
Motor to the receptacle on the front panel.
Align the round dimple on the motor cord
connector with the mark on the receptacle
(see Fig. 8) and push cord straight into
receptacle until it snaps into position. To
remove motor/cord, pull motor cord
connector straight out of receptacle.
Attach the appropriate -Type handpiece
(sold separately) to the electric motor.
11. Optional Fiber-Optic Handpieces -
Attach the appropriate ISO Type-C (6-pin)
fiber optic air handpieces to their respective
connectors (see Fig. 9).
12. Optional Amalgam Separator - Open the
waste compartment door
on the back side of the
unit and place the
optional amalgam
separator into the
amalgam manifold.
Tighten the retaining
screw located under the top cover (Fig.
10). NOTE: Before installing the separator
into the manifold, remove the two caps
from the inlet and outlet ports of the
separator. nsure that the two O-rings that
seal the separator against the mani-fold
remain in place on the ends of the port
fittings and are not lodged inside the caps.
13. Optional Dual Voltage Option - Verify that
the optional voltage-selector switch is set
to the proper voltage before turning main
power On. To select the desired voltage,
use a long slender tool to toggle the switch
(see Fig. 11). IMPORTANT: When select-
ing voltage, align 110V/220V horizontal
markers on switch to the corresponding
markers on faceplate.
SETTING UP THE UNIT - Cont’d
FIG. 7
ALIGNMENT
MARKS
FIG. 8
FIG. 11
FIG. 10 OPTIONAL AMALGAM S PARATOR
R TAINING SCR W
OPTIONAL
S PARATOR
OPTIONAL EQUIPMENT SETUP:
IMPORTANT
WH N
S L CTING
VOLTAG S,
ALIGN
HORIZONTAL
MARK RS ON
SWITCH WITH
MARK RS ON
FAC PLAT
OPTIONAL
OPTIONAL
ISO-C 6-PIN
HANDPIECE
HANDPIECE
CONNECTOR
FIG. 9

5.
FIG. 12 - AMC-20 w/Options (Front View)
OPTIONAL
ACC SSORY TRAY
HING D LID
ALLOWS
ACC SS TO
PLUMBING SYRING ,
HIGH & LOW
VACUUM
HOLD RS
R AR CAST R
w/BRAK
FOOT CONTROL
WITH WAT R VALV
BULKH AD CONN CTORS
COOLANT
AIR
TOGGL
COOLANT AIR
CONTROL
VALV
FLUSH
TOGGL
BOTTL
PR SSUR
R L AS
TOGGL
BOTTL
S L CTOR
TOGGL
AUXILIARY
WAT R
CONN CTION
AUXILIARY
AIR
CONN CTION
OPTIONAL
SCAL R
COOLANT
VALV
OPTIONAL
HANDPI C ,
SCAL R &
CURING
LIGHT
HOLD RS
L CTRIC
MOTOR
CONN CTOR
HANDPI C
PR SSUR
GAUG
SCAL R
CONTROL
KNOB
OPTIONAL
(COOLANT VALV
FOR 3RD AIR
HANDPC
OR
L CTRIC HAND-
PI C )
OPTIONAL
OPTIONAL
OPTIONAL
OPTIONAL
OPTIONAL
AIR HANDPI C
COOLANT VALV S
(2)
OPTIONAL-
L CTRIC
MOTOR
CONTROL
PAN L
OPTIONAL
Water
Bottle
Caps
(2)
Water
Bottles
(2)

6.
SETTING UP THE UNIT- Cont’d
FIG. 13 - AMC-20 w/Options
(Back View)
WAST
HOS
w/HANG R
WAST
COMPARTM NT
LATCH
WAST PUMP
ON/OFF SWITCH
OPTIONAL
DUAL
VOLTAG
S L CTOR
SWITCH
110V
OUTL T
AIR TANK
PURG
TOGGL
WAST
COMPARTM NT
ACC SS DOOR
OPTIONAL
220V OUTL T
QUICK DIS-
CONN CT
FOR WAST
HOS
1 AMP
CIRCUIT
BR AK RS (2)
TANK
DRAIN
OPTIONAL
10 AMP
CIRCUIT
BR AK RS (2)
FOR 220V
20 AMP
CIRCUIT
BR AK RS (2)
OPTIONAL
OPTIONAL
OPTIONAL
OPTIONAL
ACC SSORY TRAY
w/ADJUSTABL
HOLD R
OPTIONAL
XHAUST
FAN
MAIN POW R
ON/OFF
SWITCH
MAIN POW R
INL T
R TAIN R
CLIP

7.
FIG. 14 - AMC-20 w/Options
(Back View)
OPTIONAL
AMALGAM
S PARATOR
WAST
CONTAIN R
WAST FLOW
VALV
OPTIONAL
AMALGAM
BYPASS
FILT R
FILT R R GULATOR
OPTIONAL
FIB R OPTIC
CURING LIGHT MODUL
SYST M
PR SSUR
GAUG
PR SSUR
R GULATOR
C NTRAL VACUUM CANNIST R
W/ AMALGAM SOLIDS TRAP INSID
OPTIONAL
OPTIONAL
OPTIONAL OPTIONAL
AMALGAM
S PARATOR
R TAINING
SCR W
OPTIONAL
OPTIONAL
SCAL R
SHIPPING
FAST N RS
OPTIONAL
SYRING
SHIPPING
FAST N RS

8.
1. WET/DRY FOOT CONTROL (Fig. 15) – The
variable-speed foot control activates the
handpieces, optional scaler, optional curing
light, and water coolant on/off spray. Position
the foot control on the floor. For handpiece
operation, apply foot pressure to any part of
the center disk. The electric motor or
pneumatic turbine speed is proportional to
how far the pedal is depressed. Depress
gradually to increase speed; release to
decrease speed. The handpiece holder
toggle must be 'On' and the handpiece
removed from its holder before operation
can begin. To activate the water coolant,
move the wet/dry toggle switch on the foot
control to the right. Move switch to the left to
disable water.
2. INSTRUMENT CONTROLS (Figs. 16 & 17)
The Aseptico AMC-20 includes controls for
all handpiece and instrument holders. ach
holder includes an
On/Off toggle switch (see
Fig. 16) which when
turned 'Off' (toggle to the
left), keeps the
instrument off, even
when removed from its
holder. When the toggle
switch is turned 'On' (toggle toward the red
dot), the instrument will automatically start
when removed from its holder and the foot
control is pressed. The amount of air
pressure supplied to the pneumatic
handpieces may be adjusted by turning the
flow control screws on the control block
OPERATION FUNCTIONS:
APPLY
PRESSURE TO
ACTI ATE
HANDPIECE
WATER
OFF
WATER
ON
FIG. 15
under the upper cover (see Fig. 29, page 15).
The pressure to the handpiece can be read on
the pressure gauge located on the front panel
of the unit.
3. 3-WAY AIR/WATER SYRINGE (Fig. 18)
• Pressing the left button dispenses water.
• Pressing the right button dispenses air.
• Pressing both buttons simultaneously
dispenses an air/water mist. This mist can be
adjusted with the syringe control block
located under the top cover (see Fig. 28,
page 15).
4. WATER BOTTLES (Figs. 19 & 20) - The AMC-
20 incorporates a self-
contained pressurized
water system. This
system consists of two
1-liter clear water
bottles with a toggle
switch to direct the
flow from either one of
the two bottles. This
provides the ability to
use
FIG. 17 AIR
HANDPI C
CONTROLS
(2)
OPTIONAL
3RD AIR
HANDPI C
CONTROL
OR
OPTIONAL
L CTRIC
HANDPI C
CONTROL
OPTIONAL
OPTIONAL
OPTIONAL
CURING
LIGHT
OPTIONAL
OPTIONAL
SCAL R
OPTIONAL
FIG. 18
SYRING
SALIVA
J CTOR
HIGH VACUUM
(HV )
FIG. 16
ON
OFF
FIG. 19
L V L INDICATORS
WAT R BOTTL S
WAT R
BOTTL CAPS

9.
different solutions (NOTE: The yellow and
blue floating level indicators can be used
to identify bottle contents when two
different types of fluids are used. Always
flush lines before changing solutions). A
pressure relief valve allows both bottles to
be replaced without draining the air tank.
(NOTE: This valve releases pressure from
both bottles; you cannot remove one bottle
while using the other). To refill the water
bottles:
a.) Toggle the bottle pressure relief valve
to 'Off' (see Fig. 20) to remove
pressure from both bottles.
b.) Unscrew bottles and remove from their
caps.
c.) Fill bottles with water or other solution.
d.) Screw bottles back into their caps.
e.) Toggle the pressure relief valve to 'On'
to pressurize both bottles.
f.) Select bottle to be used via the Bottle
Selector Toggle Switch (Fig. 20).
5. COOLANT AIR TOGGLE VALVE (Fig. 20)
When turned on, this valve allows coolant
air to flow to the working handpiece or
motor when the foot pedal is depressed.
6. COOLANT AIR CONTROL VALVE (Fig. 20)
Adjusts the volume of coolant air to the
working handpiece or motor.
7. FLUSH TOGGLE (Fig. 20) – Allows user to
flush the handpiece or motor with water,
washing away contaminants which may
have accumulated in the handpiece and
tubing. User should flush the handpiece for
about 5 seconds after every patient, and
about 20 seconds at the beginning of each
day. To flush a handpiece, remove it from its
holder and point the spray nozzle away from
you, i.e., into a basin. Flip the flush toggle
and hold the desired number of seconds.
Release the toggle when done. NOTE: If
water bottles drain empty when flushing, air
will be flushed through the lines.
8. BOTTLE PRESSURE RELEASE
TOGGLE (Fig. 20) – Allows pressure to be
released from both bottles while
maintaining system pressure.
9. WATER BOTTLE TOGGLE VALVE (Fig.
20) – Allows user to direct the water flow
from either one of the two bottles (toggle
points to the bottle in use).
10. HIGH AND LOW VOLUME VACUUMS
(Fig. 18) – The unit is equipped with a 5-
liter waste tank, a high volume evacuator
(HV ) hose, and a low volume saliva
ejector hose. Both high and low volume
systems operate simultaneously from the
same vacuum source. To gain vacuum on
the HV , fully open the HV valve and
close the low volume valve. To gain
vacuum on the low volume valve, close the
HV and open the low volume to full open.
11. CENTRAL VACUUM KIT – Used with the
vacuum system and contains a disposable
solids collector. The system is located
under the top cover (see Fig. 14, page 7).
FIG. 20 COOLANT AIR TOGGL
COOLANT AIR CONTROL VALV
FLUSH TOGGL
BOTTL PR SSUR
R L AS TOGGL
BOTTL S L CTOR TOGGL
COOLANT FOR AIR HANDPC #3
OR
COOLANT FOR
AIR HANDPCS #1 & #2
OPTIONAL
SCAL R
COOLANT
OPTIONAL
OPTIONAL L CTRIC HANDPC
OPTIONAL

10.
OPERATION FUNCTIONS - Cont'd:
15. OPTIONAL AEU-5000 ELECTRIC
MOTOR & CONTROL PANEL (Fig. 22) -
There are two different control modes that
can be used to operate the electric motor:
Manual Mode using the console buttons, or
Preset Mode using the preprogrammed
Presets:
A. MANUAL OPERATION - At any time,
the user can adjust the ratio, speed, torque,
motor direction, and electric motor L D
settings using the control panel keypad (The
Preset indicator in upper left of LCD will
blink on and off, indicating the change):
1) Depress the Standby
button to turn electric motor
control panel on or off. If the
console was turned off using
the Standby button, the Display will
darken and all the buttons, except the
Standby button, will become inoperative.
Press the Standby button again to turn on
the control panel and return the motor to
its last used settings.
2) Press the RATIO
button repeatedly to
select the ratio that
matches the handpiece being used. Available
ratios are: 1:5, 1:2, 1:1, 5:1, and 8:1.
NOTE: The user can reprogram the unit to
display only a preferred set of ratio(s) from
the five available options. Refer to page 12
for complete instructions on Customizing
Ratios.
3) Press
the SPEED
Up/Down
buttons to
select the desired operating speed for the
handpiece being used. See Figure 23 for
handpiece speed ranges.
OPTIONAL EQUIPMENT FUNCTIONS:
12. WASTE PUMP SWITCH & WASTE DISCHARGE
QUICK DISCONNECT (Fig. 21) – A waste pump
switch is provided on the back of the unit to purge
the waste system. A quick disconnect is provided
next to the switch, to attach the drain hose. NOTE:
The hose must be attached before waste will
discharge.
13. AIR TANK DRAIN VALVE (Fig. 21) – Allows air
pressure and any condensation to be drained from
air tank. Turn "On" to open drain or "Off" to close
drain.
14. EXTERIOR OUTLET (Fig. 21) – A 110V outlet is
provided on the back of the unit for powering
accessories. A 220V ( uro Style) outlet is provided
as an option. NOTE: The system uses a step down
transformer to apply the proper voltage to the unit
when plugged into the optional 220V. When 110V is
used for the primary voltage entering the unit, the
optional 220V socket will provide 220V output.
FIG. 21
110V OUTL T
WAST DISCHARG
QUICK-DISCONN CT
WAST PUMP
ON/OFF SWITCH
AIR TANK DRAIN
ON/OFF TOGGL
XHAUST FAN
AIR TANK DRAIN
OPTIONAL 220V OUTL T
OPTIONAL

11.
button repeatedly until the word "ENDO"
appears in the Motor Direction window.
Next, select the desired Torque level using
the UP/Down Torque buttons. The unit is
then ready to operate in NDO mode - the
rotation of the handpiece will automatically
alternate between forward and reverse
when the selected torque is reached (in
order to free the instrument).
7) Press and release the
ILLUMINATION button to
turn the handpiece L D
On/Off. To activate the
handpiece and L D, remove the
handpiece from its holder, turn the
Illumination button 'On', and press the foot
pedal to operate the motor. When the foot
pedal is released and the motor has
stopped, the light will turn off after
approximately 20 seconds.
Press and hold the Illumination button for
three seconds to enter the L D intensity
adjustment mode. When in this mode, press
the Torque Up/Down buttons to select the
desired illumination in 10% increments, from
10% to 100%. The handpiece L D will
automatically turn on and change intensity
4) Press the TORQUE Up/Down buttons to
select the
desired
operating
torque
percentage.
5) Press MOTOR DIRECTION button
repeatedly to cycle
through and select the
Forward (FWD) or
Reverse (R V) settings. An audible tone
indicates reverse direction.
6) To switch the electric
motor to ndodontic
operating mode, first
select the 8:1 handpiece
ratio, then press the MOTOR DIRECTION
Fig. 22 - Optional Electric Motor Control Panel
ILLUMINATION
AD USTMENT
w/DISPLAY
SPEED (RPM)
SELECTOR
w/DISPLAY
MOTOR DIRECTION
(FWD/REV) SELECTOR
w/DISPLAY
TORQUE
SELECTOR
w/DISPLAY
PRESET SELECTOR
w/DISPLAY HANDPIECE RATIO
SELECTOR
w/DISPLAY
CONTROL PANEL
STANDBY
BUTTON
ENDODONTIC MODE
(ENDO) SELECTOR
w/DISPLAY
Fig. 23 - Electric Motor Speed Ranges
1:5 10,000 - 200,000 RPM
1:2 4,000 - 80,000 RPM
1:1 2,000 - 40,000 RPM
5:1 400 - 8,000 RPM
8:1* 280 - 5,000 RPM
*280 - 1250 RPM in ENDO Mode

12.
OPTIONAL EQUIPMENT FUNCTIONS - Cont’d:
the Preset button to toggle the ratio to either
enabled or disabled status. The word "On" will
appear in the Preset display window when
enabled, and two dashes "_ _" will appear
when disabled (see Figs. 24a & 24b).
4) Repeat Step 3 above for the remaining four
ratio options until only the desired ratio(s) are
enabled.
5) Press and hold the Ratio button to exit the
Ratio Customization Mode. Only the enabled
ratios will be displayed when selecting Ratio
options; any ratio that has been disabled will
not be displayed (unless you re-enable it).
NOTE: The system must always have at least
one ratio option enabled. If the user attempts
to disable the last operational ratio, the system
will emit a beep sound and ignore the user's
command to disable this remaining option.
NOTE: If the factory defaults are restored, all
customized Ratio option settings will be
overwritten.
D. CUSTOMIZING PRESETS - ach Preset
can be customized by the user with its own
unique set of operating parameters:
1) First select the Ratio, then select the Preset
number of the Preset you wish to customize.
2) Adjust the Preset's speed, torque,
handpiece illumination, and motor direction as
desired. NOTE: The NDO Mode feature can
only be enabled when an 8:1 ratio is selected.
The Preset indicator will blink on and off,
indicating a change is in process.
3) Press and hold the Preset button to save
its new settings (a beep will sound).
4) Press the foot pedal to activate the motor
and begin operation.
as the adjustments are made. The display
icon will blink as the adjustments are
made. To exit the adjustment mode, press
and release the Illumination button.
B. PRESET OPERATION - The optional
lectric Motor module is shipped with five
preprogrammed factory Presets for each
ratio (see Fig. 25). This allows the user to
instantly access a wide range of settings.
After the handpiece ratio has been
selected, press the
Preset Button repeatedly
to cycle through five
different Presets (P1 - P5). When the
desired Preset is displayed, its operating
parameters are automatically activated.
ach Preset can store the following
parameters:
- Bur/Drill Speed
- Motor Direction
- Torque Setting
- L D Light 'On' or 'Off'
- ndo Mode Activation (8:1
handpiece ratio only)
NOTE: The lectric Motor is programmed at
the factory to initially start up with Ratio 1:5
and Preset No.1 active. Subsequently, when
the System power is turned on, the last
settings used will be activated.
C. CUSTOMIZING RATIOS - The user can
enable or disable individual handpiece ratio
options, so that only preferred or commonly
used ratios are displayed during the ratio
selection process. Follow these steps to
reprogram the unit with customized ratio
options:
1) Press and hold the Ratio button to enter
the Ratio Customization Mode.
2) Press the Ratio button repeatedly to
switch between the available ratio options.
ach Ratio displays in the Ratio window as
the user cycles through the five options.
3) When the desired ratio is displayed, press
Fig. 24a -Enabled
Fig. 24b -Disabled

13.
Figure 25 - Optional Electric Motor Factory Default Presets
RATIO PRESET
NO.
SPEED
(RPM) DIRECTION TORQUE ENDO MODE
(8:1 Ratio Only)
HANDPC
LED
1:5
1 200,000 FWD 100 % —On
2 150,000 FWD 100 % —On
3 150,000 FWD 50 % Torque Limit —On
4 100,000 FWD 100 % —On
5 100,000 FWD 50 % Torque Limit —On
1:2
1 80,000 FWD 100 % —Off
2 60,000 FWD 100 % —Off
3 60,000 FWD 50 % Torque Limit —Off
4 40,000 FWD 100 % —Off
5 40,000 FWD 50 % Torque Limit —Off
5:1
1 2,000 FWD 100 % —On
2 1,500 FWD 100 % —On
3 1,200 FWD 100 % —On
4 800 FWD 100 % —On
5 400 FWD 100 % —On
8:1
( NDO
MOD )
1 300 FWD 100% Y S Off
2 300 FWD 70% Y S Off
3 300 FWD 50% Y S Off
4 300 FWD 30% Y S Off
5 300 FWD 10% Y S Off
1:1
1 40,000 FWD 100 % —On
2 40,000 FWD 50 % Torque Limit —On
3 20,000 FWD 100 % —On
4 10,000 FWD 100 % —On
5 8,000 FWD 100 % —On
FACTORY DEFAULTS: The optional lectric
Motor Module will retain the factory default
settings (Fig. 25) in memory until changed by
the user. To recall the original factory
defaults, press and hold the PR S T and
RATIO buttons simultaneously for
approximately 3 seconds. IMPORTANT:
When factory defaults are recalled, all user-
customized Ratio and Preset settings will be
overwritten.
SLEEP MODE: After 20 minutes of motor
inactivity, the optional lectric Motor Module
automatically enables an energy-saving
Sleep Mode which turns off the Display.
When in this mode, three square symbols
will blink consecutively across the darkened
LCD.
To turn the unit on again and light up the
Display, the user can either press the
Standby button on the Control Panel or
remove the handpiece from its holder and
then press on the foot pedal. The last used
settings will be restored.
16. OPTIONAL SCALER (Fig. 26, page 14) –
The AMC-20 offers an optional piezo-

14.
OPTIONAL EQUIPMENT FUNCTIONS - Cont’d:
the foot pedal will turn the light Off. The
light is cooled with drive air from the AMC-
20 manifold at 20 psi. An audible tone will
sound every 10 seconds while the light is
active.
18. OPTIONAL AMALGAM SEPARATOR
(Fig. 14, page 7) – The amalgam separator
is located in the rear waste compartment.
The separator allows for particulate from the
waste compartment to be trapped prior to
being pumped out of the unit. The separator
can be replaced by unscrewing the knob
located under the top cover, and removing
the filter from the waste compartment.
CAUTION: Observe local regulations
concerning disposal of amalgam waste.
19. OPTIONAL WASTE FLOW CONTROL (Figs.
14 & 30, pages 7 & 15) The waste flow control
is located in the rear waste compartment. This
valve allows for the adjustment of the waste
pump flow rate, to meet a State’s or Country’s
regulatory requirements for wastewater filtering
and collection (refer to para. 5, page 15).
20. OPTIONAL ACCESSORY TRAY (Fig. 27)
The height of the optional accessory tray
can be adjusted: remove the tray and arm
from the pivot block, then use the 3/16"
Allen wrench (supplied) to loosen the hex
screw and reposition the block to the
desired height. The tray and arm also pivot
horizontally.
electric scaler system that provides
adjustable ultrasonic levels and a water
coolant system. The scaler includes 3
instrument tips: The #37 instrument is
specially developed for subgingival scaling,
furcations, supragingival fine scaling and
spot removal. The #38 tip is used for
lingual and buccal subgingival scaling and
furcations. The #39 tip is used for universal
lingual and buccal supragingival scaling.
The scaler is controlled by the scaler
ultrasonic setting adjustment knob which is
located on the left side of the front panel
(see Fig. 26). The ultrasonic intensity can
be adjusted by turning the control knob
clockwise to maximum or counterclockwise
to minimum. When scaling, follow the tip
manufacturer's recommended ultrasonic
settings for each tip.
The coolant level is controlled by the
scaler coolant flow adjustment knob (see
Fig. 28, page 15). Turn knob
counterclockwise to increase coolant flow;
turn clockwise to decrease coolant flow.
17. OPTIONAL CURING LIGHT (Fig. 17, page
8) - The AMC-20 offers an optional L D
curing light. When the light is removed
from the holder and the foot pedal is
depressed, the light turns On. Releasing
FIG. 26 SCAL R ULTRASONIC CONTROL
SWITCH
erify that scaler coolant flow
of no less than 20ml/min is
available at the tip.
SEE ACCOMPANYING SCALER
DOCUMENTS
WARNING:
Avoid looking directly into Curing Light. Protect
patient with darkened eyewear when using light
probe near patient's eyes.
FIG. 27 PIVOT
BLOCK

15.
ROUTINE ADJUSTMENTS:
controlled by turning the flow adjustment
screws on the control block and monitoring
the pressure gauge on the front of the
system cabinet. The control block is located
under the top cover, behind the barrier wall
(Fig. 29). Turn screws clockwise to decrease
pressure or counterclockwise to increase
pressure. IMPORTANT: Always adjust the
HP1 and HP2 handpieces' pressures to the
manufacturer's recommended settings. The
pressure settings for the optional scaler,
curing light and electric motor are preset at
the factory and do not require any further
adjustments.
FIG. 29
1. WATER COOLANT FLOW AD USTMENT
(Fig. 20, page 9)
ach handpiece has an individual
water control valve that regulates the
water coolant flow to the handpiece and
motor. Install and run a handpiece at a mid-
ange speed. Make sure the wet/dry toggle is
in the "ON" position on the foot control. Turn
the appropriate water coolant flow control
clockwise, until it seats softly. Begin turning
counterclockwise until a fine mist is visible.
This will provide excellent cooling while the
bur is cutting. (Note that each water coolant
control valve on the control panel controls its
respective handpiece located on the rotating
arm.)
2. COOLANT AIR CONTROL AD USTMENT
(Fig. 20, page 9)
A coolant air toggle valve and
control valve are provided to turn
coolant to the handpiece and motor
On and Off, and to control the flow. Turn the
coolant air control valve clockwise until it
seats softly. Begin turning counterclockwise
until the desired amount of air is achieved.
3. SYRINGE AIR/WATER FLOW
AD USTMENT (Fig. 28) – The syringe flow
adjustment block is located under the top
cover, behind the arm barrier wall. There are
two slotted adjustment screws: the left screw
adjusts the air flow and the right screw
adjusts the water flow. Turning the
adjustment screws clockwise will decrease
the pressure, while turning them
counterclockwise will increase the pressure.
4. HANDPIECE PRESSURE AD USTMENT
The amount of air pressure supplied to the
HP1 & HP2 pneumatic handpieces may be
FIG. 28
WAT R FLOW
ADJUSTM NT
SCR W
AIR FLOW
ADJUSTM NT
SCR W
FLOW ADJUSTM NT SCR WS (5)
5. OPTIONAL WASTE FLOW AD USTMENT
(Fig. 30) The optional
waste flow valve controls
the waste water flow rate.
The valve is located in the
rear waste compartment.
Turn the lever as shown to adjust the flow
rate as specified by your State or County
laws regarding disposal of dental
wastewater. The small circle on the flow
indicator represents a 1-liter per minute flow
setting for the specific amalgam separator
provided with this AMC-20 Cart. An optional
bypass filter is available for areas where
amalgam separators are not required.
WAST FLOW
ADJUSTM NT
VALV
OPTIONAL
BYPASS
FILT R
FIG. 30
OPTIONAL EQUIPMENT AD USTMENTS:
OPTIONAL

16.
HANDPIECES:
Flush the pneumatic handpieces for about 5 seconds
after every patient and about 20 seconds at the
beginning of each day. NOTE: The flush valve is
located on the control panel, on the right side of the
unit (see Fig. 20, page 9). When
sterilizing optional -type handpieces,
follow the instructions provided by the
handpiece manufacturer.
IMPORTANT! Protect motor from
excess oil draining from optional -
Type handpieces. After lubricating and
before autoclaving, stand hand-piece
by its base on a paper towel and
allow excess oil to drain (see Fig. 31).
3-WAY AIR/WATER SYRINGE:
The syringe features quick-change
autoclavable tips: To remove a tip, press on the
locking collar surrounding the tip socket and
pull the used tip straight out of the socket.
To insert a new tip, press locking collar and
push tip into socket as far as it will go. Release
ring and gently tug on tip before using to
ensure that tip is securely locked into socket.
Syringe Tip Sterilization:
1) Remove contaminated syringe tip.
2) Remove all visible signs of contamination before
autoclaving.
3) Autoclave tip at 132° C (270° F) for ten minutes.
4) Sterilize between each patient use.
NOTE: Since only the tips can be autoclaved, it
is recommended that the air/water syringe be
bagged with a disposable, single-use plastic
sleeve between each patient use.
A
A
STERILIZATION AND MAINTENANCE:
WATER LINES:
Disinfect the water lines weekly. Prepare a 1:10
bleach solution (1 part household bleach to 9 parts
water). Purge all water lines (see page 17, Purg ng
Water From the System). Fill water bottles with
bleach solution. Run bleach solution through all
lines. Allow bleach solution to stand in lines for 10
minutes but no longer: Immediately remove water
bottles and discard the bleach, then flush water
bottles and all lines thoroughly with clean water.
Purge all water lines with air and leave dry until next
clinical use.
VACUUM LINES:
The HV and low volume saliva ejector valves are
fully autoclavable. Remove the valves from their
hoses before autoclaving. The vacuum hoses should
not be autoclaved. Clean hoses with a disinfectant
solution using standard vacuum hose cleaning
procedures. CAUTION: Use only NON-foaming
cleansers in the vaccum lines.
AMALGAM SOLIDS TRAP:
Replace the disposable
amalgam solids trap
routinely. The
performance of the
vacuum system will
decrease significantly as
the trap fills up with solids.
The trap sits inside the
central vacuum canister located under the top lid.
Keep spare traps in stock. The AMC-20 uses
standard 1 7/8” traps (open or closed type):
Check w th state laws regard ng the recycl ng of
amalgam sol ds waste.
CAUTION:
Do not run saline solutions through the water
system -- saline will corrode the water filters.
A
PART NO. QUANTITY PART NO. QUANTITY
AA-29 1 AA-290VS 1
AA-29-100 100 AA-290VS-100 100
OP N TYP CLOS D TYP
Fig. 31
CAUTION FOR ALL STERILIZATION:
• Do not exceed 135° C or 275° F
• Do not submerge in any solutions
• Do not use ultrasonic cleaners
A

17.
WASTE REMOVAL:
Routinely empty
the waste contain-
er daily. To empty
the waste system,
connect the waste
hose elbow to
the waste dis-
charge on the
back of the unit by
inserting the elbow
until it locks into
place. Switch on
the waste purge pump to empty the waste system.
To disconnect the waste hose, depress the button on
top of the waste discharge to release the waste hose
elbow. IMPORTANT: The waste hose must be connect-
ed to the waste discharge to enable pump switch oper-
ation. NOTE: Amalgam separators (optional equipment)
require no settlement time before draining the waste
tank. Replace the amalgam separator annually or soon-
er if it becomes full of particulate and impedes waste
tank discharge. Replacement amalgam separators (PN
730595) are available through Aseptico. Refer to the
label on the amalgam separator for the address of an
approved amalgam recycler.
AIR TANK PURGE:
Routinely purge the air tank once a day to remove
condensation from the air storage tank.
PURGING WATER FROM THE SYSTEM:
Purge all water from the system if the unit will be
unused for more than a week or exposed to freezing
temperatures. mpty both water bottles, then reinstall
them into their caps. Rotate open (counter-clockwise)
all water coolant knobs (open knobs fully for fastest
purging). Toggle on all instrument holder switches.
Switch on the main power. Toggle on the bottle
pressure switch. Purge all water lines simultaneously
or one at a time: Hold handpieces and scaler over a
basin while holding the flush toggle switch in the on
position until all water is purged from the lines with air.
Finally, hold the water syringe over the basin and hold
down the water button until all water is purged from
the line with air.
GENERAL CLEANING:
The external surfaces of the chassis should be
cleaned using a soft cloth moistened with a mild
detergent solution. Any external surfaces of the unit
that are contacted during use should be wiped down
with a soft cloth moistened with a disinfectant at the
beginning of each day and between each patient use.
D
C
A
B
OPTIONAL EQUIPMENT MAINTENANCE:
OPTIONAL ELECTRIC MOTOR &
CORD ASSEMBLY:
The entire optional A U-5000 lectric
Motor and Cord Assembly is fully
autoclavable (Fig. 32). Steam autoclave
motor/cord assembly at 132° C (270° F)
for ten minutes. Loosely coil the motor
cord when autoclaving. Avoid sharply
bending the cord when autoclaving.
Alternatively, wipe down the motor cord
with disinfecting solution, and/or sleeve
the cord between each patient.
OPTIONAL ELECTRIC MOTOR O-RINGS:
Replace electric motor O-rings when worn
or damaged (Fig. 33). Gently peel old O-
rings out of grooves and replace with new
rings (PN 520069). Occasionally apply
non-toxic lubricant (preferably containing
PTF ) to O-rings to maintain flexibility.
The entire optional
motor & cord assembly
is steam autoclavable.
Fig. 32 - Optional Motor & Cord Sterilization
• Do not attempt to disassemble the optional motor
or motor connector.
• Do not oil or lubricate the optional motor.
• Do not attach a handpiece to the optional motor
while the motor is running.
• Do not bend optional motor cord sharply.
WARNING
Failure to comply with any of the above instructions
may void your warranty.
CAUTION:
The optional electric motor is sensitive to shock.
Do not drop or impact it against a hard surface.
C
A
B
D

18.
OPTIONAL MOTOR LED LENS CLEANING:
The lens of the L D light on the optional electric
motor (Fig. 33) is soft and can be damaged. It
should not be exposed to dust and debris.
xcessive dust and debris may cause a drastic
decrease in optical output. In the event that the
light requires cleaning, first try a gentle
swabbing, using a lint-free swab. If needed,
use a lint-free swab and isopropyl alcohol to
gently remove dirt from the lens. Do not use
other solvents as they may adversely react
with the L D assembly.
OPTIONAL ULTRASONIC SCALER:
(Refer to ultrason c scaler nstruct ons for
use, suppl ed separately.)
The scaler handpiece cover and scaler tips are
fully autoclavable. Disinfect and clean the cover
and tips before autoclaving. Autoclave at a
maximum temperature of 135º C (275º F) for
10 minutes or 120º C (248º F) for 20 minutes.
Wipe off the scaler handpiece and its silicone
hose with a soft cloth. Use a 45% isopropyl and
detergent solution. DO NOT IMMERSE the
handpiece in any fluid or spray any fluid directly
on the handpiece.
OPTIONAL CURING LIGHT:
(Refer to cur ng l ght nstruct ons for use,
Sunl te Lazer model, suppl ed separately.
Sunl te Lazer s a product of K net c Instruments, Inc.)
The curing probe is fully autoclavable. Detach
probe by pressing quick disconnect button on
side of handle. Clean probe with disinfectant
then autoclave at 135°C (275°F) for 20 minutes
minimum. Clean and sterilize probe between
each patient use. NOTE: The lamp module
(the section that seats into the tubing
connector) is NOT autoclavable.
OPTIONAL ELECTRIC MOTOR/CORD
RECEPTACLE O-RINGS
The O-rings for the three water/air ports in the
optional electric motor/cord receptacle should
be replaced if damaged or worn. Use the
provided O-ring installer pin and sleeve to
replace the O-rings:
1. Remove old O-ring from water or air port
fitting.
2. Slide new O-ring over pointed end of
installer pin, onto the pin’s shank (see
Figure 34).
3. Insert pointed end of installer pin into open
end of installer sleeve until O-ring stops
against end of tool.
4. Position concave end of installer pin against
end of water/air port fitting (see Figure 35).
5. Push installer sleeve inward, until new O-
WARNING:
Avoid looking directly into optional curing light.
Protect patient with darkened eyewear when
using light probe near patient's eyes.
OPTIONAL EQUIPMENT STERILIZATION AND MAINTENANCE - Cont'd:
O-RING
INSTALLER
SLEEVE
FIG. 35
INSTALLER
PIN
O-RING
INSTALLER
PIN
FIG. 34
O-RING
FIG. 36
WATER/AIR
FITTING
Fig. 33 O-Rings
(3)
L D
