Asoni CAM668F User manual

20M-IR 1080P Full-HD
H.264 CMOS Network Camera
CAM668F / CAM668F-PoE
User’s Manual
Date: 7/20/2012
Firmware Version: VB1.0.26

1
Content
Content .......................................................................................................................................1
1. Preface.................................................................................................................................3
2. Product Specifications.......................................................................................................3
3. Product Installation ............................................................................................................6
A. Hardware Installation......................................................................................................6
Cable Connections................................................................................................................6
I/O Connections....................................................................................................................7
B. Monitor Setting................................................................................................................9
C. IP Assignment.................................................................................錯誤! 尚未定義書籤。
4. Live Video..........................................................................................................................12
5. Configuration ....................................................................................................................17
A. System ...........................................................................................................................17
System Information.............................................................................................................17
User Management..............................................................................................................21
System Upgrade.................................................................................................................23
System Logs.......................................................................................................................24
B. Video/Audio Setting ......................................................................................................25
Video Format ......................................................................................................................25
Image Setting......................................................................................................................30
Audio Setting ......................................................................................................................33
C. Network Setting.............................................................................................................35
Network Setting ..................................................................................................................35
Mail / FTP / Samba Setting.................................................................................................39
PPPoE / DDNS Setting.......................................................................................................43
D. Network (Advance) Setting...........................................................................................46
HTTPS Setting....................................................................................................................46
SNMP Setting .....................................................................................................................48
IP Filter Setting ...................................................................................................................50
QoS/ DSCP Setting.............................................................................................................52
IEEE 802.1x Setting............................................................................................................53
E. Event Handling..............................................................................................................54

2
Event Setting ......................................................................................................................54
I/O Setting...........................................................................................................................59
Schedule.............................................................................................................................61
6. Network Configuration .....................................................................................................63
A. Intranet Only..................................................................................................................63
Connects to PC Directly......................................................................................................63
Connects to an Exist LAN...................................................................................................64
B. Internet Only..................................................................................................................65
Connects to ADSL with Fixed Public IPAddress.................................................................65
Connects to ADSL with Floating Public IPAddress (PPPoE)..............................................66
C. Intranet + Internet..........................................................................................................68
Connects to Internet with Fixed Public IPAddress..............................................................68
Connects to Internet with Floating Public IPAddress..........................................................70
7. Factory Default..................................................................................................................71

3
1. Preface
This camera is a 1080P Full-HD 2 Mega-Pixel CMOS network camera which builds in web
server. User views real-time video via IE browser. It supports H.264, MJPEG and MPEG4
video compression which provides smooth and high quality video.
The IR model equips infrared illuminator to provide good image quality, even in darkness.
The PoE model built-in support for Power over Ethernet allows the camera to receive both
data and power over a single Ethernet cable.
This camera is an easy-to-use IP camera which is designed for security application.
2. Product Specifications
2 Mega-Pixel CMOS Sensor
H.264 / MJPEG / MPEG4 compression formats and triple streaming
Supports resolution up to 1920x1080, 1080P@30FPS real time
Self-Contained HTTP Web Server providing Internet capability for remote access
Day & Night functionality for 24-hours surveillance, auto activate IR illuminator in low
illumination
Infrared radiant distance up to 20 meters
Outdoor housing with IP66 waterproof standard
Digital Wide Dynamic Range
Shutter Speed adjustment
Sense Up adjustment
Day&Night Switch time control manually
Built-in PoE splitter, support for Power over Ethernet (PoE model)
2-way audio
Online firmware upgrade
Recorded files compatible with Microsoft Windows Media Player
Hardware
CPU / RAM / ROM ARM 9, 32 bit RISC / 256MB / 16MB
Image Sensor 1/2.7” CMOS, 2 Mega-Pixel
Lens Adjustable Vari-focal 3.3 ~ 12 mm, F1.4, Mega-Pixel lens

4
IR Distance 20 Meters
IR LED Built-in 35 IR LEDs
Illumination Normal: 0.5 lux IR On: 0 lux
Day / Night Built-in Mechanism IR Cut Filter (ICR)
Shutter Time 1/5 ~ 1/10000 sec
Audio In 1 Microphone in (3.5mm phone jack for connecting external passive-type of
microphone)
Audio Out 1 Line out (3.5mm phone jack for connecting external amplified speaker)
Digital I/O 1 Digital in / 1 Relay out
Power Supply Normal & Wireless model: DC 12V, 1A
PoE model (built-in PoE Splitter):
Use PoE: PoE Injector (IEEE 802.3af)
Or, use Power Adaptor: DC 12V, 1A
Power Consumption Max. 9 Watt
Dimensions W83 x H79.5 x L182.5 mm
Network
Ethernet 10/ 100 Base-T
Network Protocol HTTP, HTTPS, TCP/IP, RTP/RTSP, UDP, 3GPP, SMTP, FTP, Samba, PPPoE,
DHCP, DDNS, NTP, UPnP, SNMP, QoS/DSCP, IP Filter, IEEE 802.1x
System
Video Resolution 1920x1080, 1280x720, 640x480, 320x240, 176x144
Compression Format H.264 / MJPEG / MPEG4
Frame Rate Up to 30FPS
Triple Streaming Yes (2 for live view, 1 for 3GPP)
3GPP Yes, Live view with 3G mobile phone
Video Bitrate Adjustment CBR, VBR
Video Adjustment Brightness, Contrast, Hue, Saturation, Sharpness, Gain control, Shutter time,
Sense Up, Digital WDR, Gamma, Exposure, Digital Noise Reduction,
Day/Night color mode, Video orientation
Image Snapshot Yes
Privacy Mask Yes, 3 different areas
Motion Detection Yes, 3 different areas
Event Trigger Motion Detection, Digital In
Triggered Action Send Email, Send to FTP, Save to Samba HDD, Relay Out
Pre/ Post Alarm Yes, configurable
Security Password protection, IP address filtering, HTTPS encrypted data
transmission, IEEE 802.1x port-based authentication, QoS/DSCP

5
Firmware Upgrade HTTP mode, can be upgraded remotely
Connection Up to 10 clients simultaneously
Audio Yes, 2-way
Web browsing requirement
OS Windows 2000, XP, Vista, Windows 7
Web Browser Microsoft IE V7.0 (32-bit) or above, Mozilla Firefox V6.0 or above, Opera
V11.5 or above, Safari V5.1 or above, Google Chrome V13.0 or above
Suggested Hardware Intel Core 2 Duo 2.53GHz, RAM: 1GB
Graphic card: 128MB onboard RAM
* Specifications are subject to change without notice

6
3. Product Installation
A. Hardware Installation
Cable Connections
Power Jack:
To connect the DC 12V power adapter.
Digital I/O:
Digital In and Relay Out.
Microphone Input (Red): The 3.5mm phone jack allows connect to a passive-type of
microphone, the audio will be heard at the remote site.

Audio Output (Green): The 3.5mm phone jack allows connect to an amplified
speaker, you can hear the voice of the remote site from the
speaker.
Network Connector:
The RJ-45 connector allows connect the Ethernet cable.
Zoom Adjustment:
This screw is for zooming in and zooming out.
Focus Adjustment:
This screw is for adjusting the focus.
Factory Default Wire: This wire is for restore the camera to factory default, please
refer to Factory Default chapter.
1. Connect the cable of Digital I/O, Video output,Audio output and Microphone input if
you want to use these functionalities.
2. Connect Ethernet cable for network connection.
3. Connect power adapter to turn on the camera.




Digital I/O
(
Red) Microphone Input
(
Green) Audio Output
Ethernet
Connector


Zoom
Focus


Power Jack (DC 12V)

7
4. If the camera is PoE model, the power adapter is not necessary. The camera will get
the power from the PoE injector or PoE switch.
PoE (Power over Ethernet) is a technology that integrates power into a standard LAN
infrastructure. It enables power to be provided to the network device, such as an IP
phone or a network camera, using the same cable as that used for network connection.
It eliminates the need for power outlets at the camera locations. Please follow the
below figure for the connection.
5. Set up the network configurations according to the network environment. For further
explanation, please refer to Network Configuration chapter.
I/O Connections
I/O connector – used in application, for e.g., motion detection, event triggering, alarm
notifications. It provides the interface to:
1 set of Digital Input (Alarm + GND) – The digital inputs for connecting devices
that can toggle between an open and closed circuit, such as PIRs, door/window
contacts, glass break detectors, etc. When a signal is received the status changes
and the input becomes active.
1 set of Relay Output (N.O. + COM or N.C + COM) – The output to Relay switch of
the alarm device such as LEDs, Sirens, etc.
GND
ALARM
N.C.
COM
N.O.
Digital In
Relay Out
PoE Switch or PoE Injector
Ethernet Cable
Data only
Ethernet Cable
Mixed data and power
PoE Network Camera
To Network

8
Digital Input (Alarm Input)
GND (Ground): Initial status is LOW.
Alarm: Max. 50mA, 12VDC.
Relay Output
COM: Common pin.
N.O. (Normally Open): Max. 1A/ 24VDC or 0.5A / 125VAC.
N.C. (Normally Close): Max. 1A / 24VDC or 0.5A / 125VAC.
GND
ALARM
N.C.
COM
N.O.
Door/Window
Contacts
GND
ALARM
N.C.
COM
N.O.

9
B. Monitor Setting
1. Right-Click on the desktop. Select “Properties”
2. Change color quality to “Highest (32bit)”.
