Asoni CAM661H User manual

720P HD H.264
CMOS Network Fixed Dome Camera
CAM661H / CAM661H-PoE
User’s Manual
Date: 7/20/2012
Firmware Version: VB1.0.26

1
Content
Content .......................................................................................................................................1
1. Preface.................................................................................................................................3
2. Product Specifications.......................................................................................................3
3. Product Installation ............................................................................................................5
A. Hardware Installation......................................................................................................5
Cable Connections................................................................................................................5
B. Monitor Setting................................................................................................................7
C. IP Assignment.................................................................................錯誤! 尚未定義書籤。
4. Live Video..........................................................................................................................10
5. Configuration ....................................................................................................................14
A. System ...........................................................................................................................14
System Information.............................................................................................................14
User Management..............................................................................................................18
System Upgrade.................................................................................................................20
System Logs.......................................................................................................................21
B. Video/Audio Setting ......................................................................................................22
Video Format ......................................................................................................................22
Image Setting......................................................................................................................27
C. Network Setting.............................................................................................................29
Network Setting ..................................................................................................................29
Mail / FTP / Samba Setting.................................................................................................33
PPPoE / DDNS Setting.......................................................................................................37
D. Network (Advance) Setting...........................................................................................40
HTTPS Setting....................................................................................................................40
SNMP Setting .....................................................................................................................42
IP Filter Setting ...................................................................................................................44
QoS/ DSCP Setting.............................................................................................................46
IEEE 802.1x Setting............................................................................................................47
E. Event Handling..............................................................................................................48
Event Setting ......................................................................................................................48
Schedule.............................................................................................................................54

2
Micro-SD Card....................................................................................................................56
6. Network Configuration.....................................................................................................59
A. Intranet Only..................................................................................................................59
Connects to PC Directly......................................................................................................59
Connects to an Exist LAN...................................................................................................60
B. Internet Only..................................................................................................................61
Connects toADSL with Fixed Public IPAddress.................................................................61
Connects toADSL with Floating Public IPAddress (PPPoE)..............................................62
C. Intranet + Internet..........................................................................................................64
Connects to Internet with Fixed Public IPAddress..............................................................64
Connects to Internet with Floating Public IPAddress..........................................................66
7. Factory Default..................................................................................................................67
Compatible List of SD Card.....................................................................................................68

3
1. Preface
This camera is a 720P HD CMOS network camera which builds in web server. User views
real-time video via IE browser. It supports H.264, MJPEG and MPEG4 video compression
which provides smooth and high quality video. The event video can be stored in the
Micro-SD card, and can be playback remotely.
The PoE model built-in support for Power over Ethernet allows the camera to receive both
data and power over a single Ethernet cable.
This camera is an easy-to-use IP camera which is designed for security application.
2. Product Specifications
Mega-Pixel CMOS Sensor
H.264 / MJPEG / MPEG4 compression formats and triple streaming
Supports resolution up to 1280x800, 720P@30FPS real time
Self-Contained HTTP Web Server providing Internet capability for remote access
Built-in PoE splitter, support for Power over Ethernet (PoE model)
Supports Micro-SD card for local event recording
2-way audio
Online firmware upgrade
Recorded files compatible with Microsoft Windows Media Player
Hardware
CPU / RAM / ROM ARM 9, 32 bit RISC / 256MB / 16MB
Image Sensor 1/4” Mega-Pixel CMOS
Lens Fixed 4.2mm, Mega-Pixel Lens, F1.6
Illumination 1 lux
Power Supply Normal model: DC 12V, 1A
PoE model (built-in PoE Splitter):
Use PoE: PoE Injector (IEEE 802.3af)
Or, use Power Adaptor: DC 12V, 1A
Power Consumption Max. 4 Watt
Dimensions Φ131.2 x H94.3 mm
Network

4
Ethernet 10/ 100 Base-T
Network Protocol HTTP, HTTPS, TCP/IP, RTP/RTSP, UDP, 3GPP, SMTP, FTP, Samba, PPPoE,
DHCP, DDNS, NTP, UPnP, SNMP, QoS/DSCP, IP Filter, IEEE 802.1x
System
Video Resolution 1280x800, 1280x720, 640x480, 320x240, 176x144
Compression Format H.264 / MJPEG / MPEG4
Frame Rate Up to 30FPS
Triple Streaming Yes (2 for live view, 1 for 3GPP)
3GPP Yes, Live view with 3G mobile phone
Video Bitrate Adjustment CBR, VBR
Video Adjustment Brightness, Contrast, Hue, Saturation, Sharpness, Gain control, Shutter time,
Sense Up, Digital WDR, Gamma, Exposure, Digital Noise Reduction, Video
orientation
Image Snapshot Yes
Privacy Mask Yes, 3 different areas
Motion Detection Yes, 3 different areas
Event Trigger Motion Detection
Triggered Action Send Email, Send to FTP, Save to SD Card, Save to Samba HDD
Pre/ Post Alarm Yes, configurable
Security Password protection, IP address filtering, HTTPS encrypted data
transmission, IEEE 802.1x port-based authentication, QoS/DSCP
Firmware Upgrade HTTP mode, can be upgraded remotely
Connection Up to 10 clients simultaneously
SD card management
Recording Trigger Motion Detection, IP Check, Network Disconnect
Schedule Snapshot with schedule
Video Format Video (AVI), Snapshot (JPEG)
Video Playback Yes
Web browsing requirement
OS Windows 2000, XP, Vista, Windows 7
Web Browser Microsoft IE V7.0 (32-bit) or above, Mozilla Firefox V6.0 or above, Opera
V11.5 or above, Safari V5.1 or above, Google Chrome V13.0 or above
Suggested Hardware Intel Core 2 Duo 2.53GHz, RAM: 1GB
Graphic card: 128MB onboard RAM
* Specifications are subject to change without notice

5
3. Product Installation
A. Hardware Installation
Cable Connections
Power Jack:
To connect the DC 12V power adapter.
Network Connector:
The RJ-45 connector allows connect to the Ethernet network.
Micro-SD Card Slot
(inside of the camera):
Insert a Micro-SD card if you want to do the event recording in
the camera.
1. Connect Ethernet cable for network connection.
2. Connect power adapter to turn on the camera.
3. If the camera is PoE model, the power adapter is not necessary. The camera will get
the power from the PoE injector or PoE switch.
PoE (Power over Ethernet) is a technology that integrates power into a standard LAN
infrastructure. It enables power to be provided to the network device, such as an IP
phone or a network camera, using the same cable as that used for network connection.
It eliminates the need for power outlets at the camera locations. Please follow the
below figure for the connection.
PoE Switch or PoE Injector
Ethernet Cable
Data only
Ethernet Cable
Mixed data and power
PoE Network Camera
To Network


Power Jack
Network Connector

Micro
-SD Card Slot (Inside of camera)

6
4. Set up the network configurations according to the network environment. For further
explanation, please refer to Network Configuration chapter.

7
B. Monitor Setting
1. Right-Click on the desktop. Select “Properties”
2. Change color quality to “Highest (32bit)”.

8
C. IP Assignment
Always consult your network administrator before assigning an IP address to your
camera in order to avoid using a previously assigned IP address.
MAC Address: Each network camera has a unique Ethernet address (MAC address)
shown on the sticker of the device.
One final note, although the IP Search is able to find and configure any network
device on the LAN except those that are behind a router, it is a good idea to set the
host PC to the same subnet. In order to connect to the Web-based user interface of
the network camera, the host PC must be in the same subnet. For more information
about subnets, please consult your network administrator.
“Asoni IP Search” is a utility that provides an easier, more efficient way to configure the IP
address and network settings of the network camera in Local Network (LAN).
The software can be installed from the attached software CD.
1. Once “Asoni IP Search” has been successfully installed on the computer, double
click the “Search CAM4_CAM6_NVR6LX” icon on the desktop.






9
2. IP Search searches all the network devices which connect to the intranet and lists
on the window. Click [Search] button to search again.
3. From the list, click and select the device with the MACAddress that corresponds to
the device that is to be configured.
4. The network configuration of the selected device will show on the bottom, filling in
the Device Name, IP Address, Subnet Mask, Gateway and the others.
5. Click [Modify]button to save the settings into the device.
6. Wait for few seconds to let the device update the settings, and then click [Search]
button again to re-search the network devices.
7. Double-click the network device listed on the window, It will open an IE browser and
connect to this device directly.
