ASROCK iBOX 6000 Series User manual

iBOX 6000 Series
User Manual
Version 1.0
Published June 2022

Version 1.0
Published April 2023
Copyright©2023 ASRock Industrial Inc. All rights reserved.
Copyright Notice:
No part of this documentation may be reproduced, transcribed, transmitted, or translated
in any language, in any form or by any means, except duplication of documentation by the
purchaser for backup purpose, without written consent of ASRock Industrial Inc.
Products and corporate names appearing in this documentation may or may not be
registered trademarks or copyrights of their respective companies, and are used only for
identication or explanation and to the owners’ benet, without intent to infringe.
Disclaimer:
Specifications and information contained in this documentation are furnished for
informational use only and subject to change without notice, and shou ld not be
constructed as a commitment by ASRock Industrial. ASRock Industrial assumes no
responsibility for any errors or omissions that may appear in this documentation.
With respect to the contents of this documentation, ASRock Industrial does not provide
warranty of any kind, either expressed or implied, including but not limited to the implied
warranties or conditions of merchantability or tness for a particular purpose.
In no event shall ASRock Industrial, its directors, ocers, employees, or agents be liable for
any indirect, special, incidental, or consequential damages (including damages for loss of
prots, loss of business, loss of data, interruption of business and the like), even if ASRock
Industrial has been advised of the possibility of such damages arising from any defect or
error in the documentation or product.
is device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
CALIFORNIA, USA ONLY
e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance
controlled in Perchlorate Best Management Practices (BMP) regulations passed by the
California Legislature. When you discard the Lithium battery in California, USA, please
follow the related regulations in advance.
“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/
perchlorate”
ASRock Industrial’s Website: https://www.asrockind.com

Replaceable batteries
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS
CAUTION (or Warning)
Hot surface
Do not touch
e equipment intended only for use in a Restricted Access Area.
DIN Rail/Wall Mount: M3x5mm Screws (for securing the mounting bracket(s) to the chassis)
VESA Mount: M4x6mm Screws (for securing the VESA bracket to the monitor)
is product should be connected by means of a power cord to a socket-outlet
with earthing connection.
e terms HDMI®and HDMI High-Denition Multimedia Interface, and the HDMI logo are
trademarks or registered trademarks of HDMI Licensing LLC in the United States and other
countries.

Contact Information
If you need to contact ASRock Industrial or want to know more about ASRock Industrial,
you’re welcome to visit ASRock Industrial’s website at https://www.asrockind.com; or you
may contact your dealer for further information.
ASRock Industrial Incorporation
Email: [email protected]m

Contents
Chapter 1 Introduction 1
1.1 Package Contents 1
1.2 Product Specications 2
1.3 Block Diagram 4
Chapter 2 Product Overview 5
2.1 Front View 5
2.2 Rear View 6
2.3 Inside View 7
Chapter 3 Hardware Installation 8
3.1 How to Remove the Bottom Case 8
3.2 How to Install the WiFi Module 9
3.3 How to Install the M.2 SSD 10
3.4 How to Install the 2.5-inch Hard Drive 11
3.5 How to Install the Memory Modules (DDR4) 13
3.6 How to Install the VESA Bracket (Optional) 14
3.7 How to Install the Wall Mounting Brackets 16
3.8 How to Install the Din Rail Mounting Bracket (Optional) 18
3.9 Positions of the iBOX 6000 Series 19
Chapter 4 Motherboard 20
4.1 Motherboard Layout 20
4.2 Jumpers Setup 22
4.3 Onboard Headers and Connectors 23

4.4 Installation of ROM Socket 26
4.5 Expansion Slots (M.2 Slots) 27
Chapter 5 UEFI Setup Utility 28
5.1 Introduction 28
5.1.1 UEFI Menu Bar 28
5.1.2 Navigation Keys 29
5.2 Main Screen 29
5.3 Advanced Screen 30
5.3.1 CPU Conguration 31
5.3.2 Chipset Conguration 33
5.3.3 Storage Conguration 34
5.3.4 Super IO Conguration 35
5.3.5 ACPI Conguration 36
5.3.6 USB Conguration 37
5.3.7 Trusted Computing 38
5.4 Hardware Health Event Monitoring Screen 39
5.5 Security Screen 40
5.6 Boot Screen 41
5.7 Exit Screen 42
Chapter 6 Software Support 43
6.1 Install Operating System 43

iBOX 6000 Series
8 1
English
Chapter 1 Introduction
1.1 Package Contents
• 1 x iBOX-6000 Series
• 1 x 19V/65W Power Adapter
• 1 x Wall Mount Kit & Screw Package
• 1 x Quick Installation Guide
Because the hardware specications might be updated, the content of this documentation
will be subject to change without notice.
If any items are missing or appear damaged, contact your authorized dealer.

2 3
English
1.2 Product Specications
Memory
Technology
Capacity
Socket
Dual Channel DDR4 3200 MHz
32GB (16 GB per DIMM)
2 x 260-pin SO-DIMM
Graphics
Controller
HDMI
DisplayPort
MultiDisplay
Intel®Gen 11 Graphics
HDMI 2.0b
Max resolution up to 4096x2160@60Hz
DisplayPort 1.2, DP++
Max resolution up to 4096x2160@60Hz
Dual-Display
Processor System
CPU
Chipset
BIOS
Intel®ElkHart Lake SoC Processors
iBOX-J6412 (J6412, QC, Max Speed upto 2.6GHz, 10W)
SoC
AMI SPI 256 Mbit
Audio
Interface Realtek ALC233, High Definition Audio.
Ethernet
Controller/ Speed
Connector
Realtek RTL8111G-CG/RTL8111H-CG with 10/100/1000 Mbps
2 x RJ-45
Expansion Slot
M.21 x M.2 (KeyE, 2230) with PCIe x1, USB 2.0
Storage
M.2
SATA
1 x M.2 (KEYM, 2242/2260/2280) with PCIe x1 and SATA3 for SSD
*M.2 Key M2280(Supported by bracket)
1 x SATA3.0 (6.0 Gb/s)
Rear I/O
HDMI
DisplayPort
Ethernet
USB
DC Jack
1 x HDMI 2.0b
1 x DP1.2
2 x 1 Gigabit LAN
1 x USB 2.0
1 x USB 3.2 Gen2 (Type-A)
1
Front I/O
USB
Audio
1 x USB 3.2 Gen2 (Type-A)
2 x USB 3.2 Gen2 (Type-C , 5V/3A)
1 x USB 2.0
1 (headphone & microphone jack)

iBOX 6000 Series
2 3
English
Environment
Operating Temp
Storage Temp
Operating Humidity
Storage Humidity
-20ºC ~ 50ºC
-40°C–85° C
5% ~ 90%
5% ~ 90%
Internal Connector
TPMInfineon SLB9670VQ2.0
Watchdog Timer
Output
Interval
From Super I/O to drag RESETCON#
256 Segments,0, 1, 2, ...255sec
Power Requirements
Input PWR
Power On
1 x 19V/65W Power Adapter
AT/ATX Supported
- AT : Directly PWR on as power input ready
- ATX : Press button to PWR on afterpower input ready
Others
OS Support
Certifications
Packing List
Windows 10/11
CE, FCC
1 x 19V/65W Power Adapter
1 x Screw Package
1 x Wall mount kit
Mechanical
Construction
Mounting
Dimensions (L x W x H)
Weight
Aluminum housing
Wall mounting kit
VESA mounting kit(optional)
Din rail kit (optional)
135 x 110 x 44.5mm (5.31" x 4.33" x 1.75")
Net Weight: 0.7kg
