ASROCK NUC BOX-1360P/D4 User manual

NUC BOX-1260P
NUC BOX-1240P
NUC BOX-1220P
User Manual
Version 1.0
Published May 2022

Version 1.0
Published January 2023
Copyright©2023 ASRock Industrial Inc. All rights reserved.
Copyright Notice:
No part of this documentation may be reproduced, transcribed, transmitted, or translated
in any language, in any form or by any means, except duplication of documentation by the
purchaser for backup purpose, without written consent of ASRock Industrial Inc.
Products and corporate names appearing in this documentation may or may not be
registered trademarks or copyrights of their respective companies, and are used only for
identication or explanation and to the owners’ benet, without intent to infringe.
Disclaimer:
Specifications and information contained in this documentation are furnished for
informationa l use only and subject to change without notice, and should not be
constructed as a commitment by ASRock Industrial. ASRock Industrial assumes no
responsibility for any errors or omissions that may appear in this documentation.
With respect to the contents of this documentation, ASRock Industrial does not provide
warranty of any kind, either expressed or implied, including but not limited to the implied
warranties or conditions of merchantability or tness for a particular purpose.
In no event shall ASRock Industrial, its directors, ocers, employees, or agents be liable for
any indirect, special, incidental, or consequential damages (including damages for loss of
prots, loss of business, loss of data, interruption of business and the like), even if ASRock
Industrial has been advised of the possibility of such damages arising from any defect or
error in the documentation or product.
is device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
CALIFORNIA, USA ONLY
e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance
controlled in Perchlorate Best Management Practices (BMP) regulations passed by the
California Legislature. When you discard the Lithium battery in California, USA, please
follow the related regulations in advance.
“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/
perchlorate”
ASRock Industrial’s Website: https://www.asrockind.com

Replaceable batteries
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS
Contact Information
If you need to contact ASRock Industrial or want to know more about ASRock
Industrial, you’re welcome to visit ASRock Industrial’s website at https://www.
asrockind.com; or you may contact your dealer for further information.
ASRock Industrial Incorporation
Email: [e-mail]
e terms HDMI®and HDMI High-Denition Multimedia Interface, and the HDMI
logo are trademarks or registered trademarks of HDMI Licensing LLC in the United
States and other countries.

4 5
English
Contents
Chapter 1 Introduction 1
1.1 Package Contents 1
1.2 Product Specications 2
1.3 Block Diagram 4
Chapter 2 Product Overview 5
2.1 Front View 5
2.2 Rear View 6
2.3 Inside View 7
Chapter 3 Hardware Installation 8
3.1 How to Remove the Bottom Case 8
3.2 How to Install the Memory Modules 9
3.3 How to Install the WiFi Module 10
3.4 How to Remove the M.2 SSD (Type 2280) and the Bracket 11
3.5 How to Install the M.2 SSD (Type 2260) 12
3.6 How to Install the Hard Drive 14
3.7 How to Install the VESA Bracket 16
Chapter 4 Motherboard 18
4.1 Motherboard Layout 18
4.2 Motherboard Specications 19
4.3 Onboard Headers and Connectors 21
4.4 Expansion Slots (M.2 Slots) 24
Chapter 5 UEFI SETUP UTILITY 25
5.1 Introduction 25
5.1.1 Entering BIOS Setup 25

NUC BOX-1360P/D4
NUC BOX-1340P/D4
4 5
English
5.1.2 UEFI Menu Bar 26
5.1.3 Navigation Keys 27
5.2 Main Screen (Advanced Mode) 28
5.3 Advanced Screen 29
5.3.2 Chipset Conguration 33
5.3.3 Storage Conguration 35
5.3.4 Super IO Conguration 37
5.3.5 AMT Conguration 38
5.3.6 ACPI Conguration 40
5.3.7 USB Conguration 41
5.3.8 Trusted Computing 42
5.4 Hardware Health Event Monitoring Screen 45
5.5 Security Screen 46
5.6 Boot Screen 47
5.7 Exit Screen 49
Chapter 6 Software Support 50
6.1 Install Operating System 50

6 1
English
Chapter 1 Introduction
1.1 Package Contents
• NUC BOX-1360P/D4 / NUC BOX-1340P/D4
• 1 x Screw for M.2 slot
• 1 x 19V/90W Power Adapter
• 1 x Screw Package
• 1 x VESA mounting bracket
• 1 x Bracket for M.2 2280 support
• Quick Installation Guide

NUC BOX-1360P/D4
NUC BOX-1340P/D4
6 1
English
Chapter 1 Introduction
1.1 Package Contents
• NUC BOX-1360P/D4 / NUC BOX-1340P/D4
• 1 x Screw for M.2 slot
• 1 x 19V/90W Power Adapter
• 1 x Screw Package
• 1 x VESA mounting bracket
• 1 x Bracket for M.2 2280 support
• Quick Installation Guide
Because the hardware specications might be updated, the content of this documentation
will be subject to change without notice.
If any items are missing or appear damaged, contact your authorized dealer.

2 3
English
1.2 Product Specications
NUC BOX-1360P/D4
NUC BOX-1340P/D4 Barebone
CPU
Intel® 13th Gen (Raptor Lake-P) Core™ Processors
NUC BOX-1360P/D4 (i7-1360P, 4P+8E)
NUC BOX-1340P/D4 (i5-1340P, 4P+8E)
Chipset MCP
BIOS AMI SPI 256 Mbit
Memory Supports Dual Channel DDR4 3200 MHz
Storage 1 x M.2 (KEY M, 2242/2260/2280)
with PCIe Gen4 x4 for SSD
*M.2 Key M 2280(Supported by bracket)
1 x SATA3.0 (6.0 Gb/s)
LAN Intel® I226LM with 10/100/1000/2500 Mbps
WiFi 1 x Wi-Fi 6E 802.11ax (2.4Gbps) + BT 5.2
(M.2 Key E, 2230 PCIe x1, USB 2.0 for Wireless)
Audio Realtek ALC233, High Denition Audio
Front I/O 1 x USB 3.2 Gen2 (Type A)
1 x USB4 (Supports DP1.4a display output)
1 x USB 3.2 Gen2 (Type-C, Support DP1.4a display
output)
1 (headphone & microphone jack)
Rear I/O 1 x HDMI 2.0b, 1 x DP1.4a, 2 x 2.5 Gigabit LAN, 2 x USB
3.2 Gen2 (Type-A), DC-IN
M.2 slot
SATA

NUC BOX-1360P/D4
NUC BOX-1340P/D4
2 3
English
Power Unit 19V/90W Power Adapter
Dimension 110.mm (W)x 117.5mm (D) x 47.85mm (H)
VESA Bracket included , supports 75 x 75 and 100 x 100 mm
Weight 1Kg
Operating Tem-
perature 0°C~40°C

4 5
English
1.3 Block Diagram
M.2 M Key
2242/2280
PCIe x4 Gen4
3.5mm
Combo Conn.
Transformer
DDR4 SO-DIMM 3200 (32GB)
M.2 KEY-E (2230)
DDR4 - CH1
LAN1
I226LM
Raptor Lake P
PCIe*1+CNVi+USB2*1
Intel
DDR4 - CH0
DDR4 SO-DIMM 3200 (32GB)
PCIe#9
PCIe#6+USB2#10
2.5G LAN
RJ45
OIDMOIDM
CPU_PCIEX4_A_[3:1]
SATA#0
SATA
Header
SPI0 CS0#
SPI ROM 32MB
Flash Box
TPM2.0
CS2#
TCP0+USB2#5
TCP1+USB2#6
TCP2
TCP3
HDMI
Conn.
AUX/DDC
Switch
ITE
Retimer
DP++
Conn.
BB
Retimer
TypeC Conn.
(USB+DP)
HDA
Codec
ALC233
Line_Out
MIC_In
USB2#7#8
USB2
Pin Header
USB3#1+USB#1
USB3#2+USB#2
USB3.2 Rear IO
TypeA
USB3#3+USB2#3
USB3.2 Front IO
TypeA
eSPI BUS
eSPI
Heder
CPU
FAN(4pin)
SIO
NCT5525D
PWM
Hardware
Monitor(+Vcore,+DC in)
Thermal Resistor
(SYS,CPU)
ADC
GPIO
USB
PWR Ctrl
UART(PortA)
3in1
COM transceiver
WDT
(28W)
LAN2
I226LM
PCIe#5(vPro)
2.5G LAN
RJ45
MDIO
Transformer
MDIO
RS-232/422/485
COM
Header
USB3#4+USB2#4
TypeC Conn.
(TBT)
USB4/USB3/DP
TMDS
NUC BOX-1360P/D4
NUC BOX-1340P/D4

NUC BOX-1360P/D4
NUC BOX-1340P/D4
4 5
English
Chapter 2 Product Overview
is chapter provides diagrams showing the location of important components of
the NUC BOX-1360/D4 / NUC BOX-1340P/D4.
2.1 Front View
No. Description
1Audio (Mic-in, Line-out)
2 USB4 (Supports DP1.4a display output)
3 USB 3.2 Gen2 (Type C, supports DP1.4a display output)
4 USB 3.2 Gen2 (Type A)
1 2
4
3

6 7
English
2.2 Rear View
No. Description
1DC-IN
2 1 x HDMI
3 RJ-45 (2.5G)*
4DisplayPort**
5 USB 3.2 Gen2
* ere are two LEDs on the LAN port. Please refer to the table below for the LAN port LED indications.
Activity / Link LED Speed LED
Status Description Status Description
O No Link O 10Mbps connection
Blinking Data Activity Orange 100Mbps/1Gbps
connection
On Link Green 2.5Gbps connection
**To use DisplayPort as a display output, please connect your monitor/display to HDMI Port when
installing OS system.
is DisplayPort only supports DP to HDMI dongle and DP to DVI dongle, and does not support DP to
D-Sub dongle.
ACT/LINK LED
SPEED LED
LAN Port
12 3
45

NUC BOX-1360P/D4
NUC BOX-1340P/D4
6 7
English
2.3 Inside View
No. Description
1SO-DIMM Slots
2 SATA 3.0 Connector
3 M.2 Slot (2242/2260/2280)
4Wi Module Slot
5 Hard disk drive tray (compatible with 2.5" SATA HDD/SSD)
SO-DIMM memory, Wi module and M.2 are not included with this system.
1
3
2
4
5

8 9
English
Chapter 3 Hardware Installation
is chapter helps you install or remove important components.
3.1 How to Remove the Bottom Case
1. Remove the four screws on the bottom case.
2. en li up and remove the bottom panel.
2
1

NUC BOX-1360P/D4
NUC BOX-1340P/D4
8 9
English
3.2 How to Install the Memory Modules
1. Carefully insert the SO-DIMM memory modules into the slot at a 30-degree angle.
2. Push down until the modules snap into place.
1. e NUC BOX-1360P/D4 / NUC BOX-1340P/D4 requires DDR4 SO-DIMM.
2. For dual channel conguration, you always need to install identical (the same brand,
speed, size and chip-type) Memory Module SO-DIMM pairs.
e SO-DIMM only ts in one correct orientation. It will cause permanent damage to the
motherboard and the DIMM if you force the DIMM into the slot at incorrect orientation.

10 11
English
3.3 How to Install the WiFi Module
1. Locate the WiFi Module slot on the motherboard.
2. Carefully insert the WiFi Module into the slot.
3. Tighten the screw to secure the WiFi Module to the motherboard.

NUC BOX-1360P/D4
NUC BOX-1340P/D4
10 11
English
3.4 How to Remove the M.2 SSD (Type 2280) and the Bracket
1. Release the screw and carefully remove the M.2 SSD (Type 2280).
2. Release the screw and remove the bracket from the motherboard.

12 13
English
3.5 How to Install the M.2 SSD (Type 2260)
1. Locate the M.2 slot on the motherboard. Install the stando.
2. Carefully insert the M.2 SSD into the slot.

NUC BOX-1360P/D4
NUC BOX-1340P/D4
12 13
English
3. Tighten the screw to secure the M.2 SSD to the motherboard.

14 15
English
3.6 How to Install the Hard Drive
1. Carefully insert the M.2 SSD (Type 2280) into the slot.
2. Carefully insert the M.2 SSD (Type 2280) into the slot.
