5000 series strike
Installation Instructions
4019006.001 rev F
©HES 2005

An ASSA ABLOY Group company
Raising the Standards
1
What do I have?
What do I need?
1 5000 series strike body
1 Trim enhancer
2 Trim enhancer screws
5-11 Blue wire connectors
quantity description item
What tools would you recommend I use?
quantity description item
1 5000 series faceplate
2 Faceplate screws
2 Mounting screws
1 Pig tail connector
You will need 1 faceplate option kit (not included, see page 3) which contains:
*
*tool may differ for different applications
#4-40 x 1/8
#8-32 x 5/8
1
2
3
4
5
6
#12-24 x 1/2
2
1
2
3
4
5
6
What item are you looking for?
5000 series strike body
Faceplate option kit
Trim enhancer
Mounting screws
Faceplate screws
Trim enhancer screws
1
2
3
4
5
6
!
Caution
Before connecting electric strike at the installation site verify input
voltage using a multimeter. Any input voltage exceeding 10% of the
solenoid rating may cause severe damage to the unit.
(sold separately)
(sold with faceplate option kit)
(sold with faceplate option kit)

Raising the Standards
An ASSA ABLOY Group company
3
Electrical ratings for the 5000:
What faceplate will you be using?
501
501A
503
502
504
501B
503B
metal
metal
flat aluminum
flat aluminum/wood
wood
aluminum door
aluminum door
501
501A
503 502
504
501B
503B
option door/frame
pg 24 pg 24
pg 18
pg 26
pg 21
pg 16 pg 14
Step 1
Step 2
Minimum Wire
Gauge Requirements
Solenoid Voltage
12V - 16V 24V
200 feet or less 18 gauge 20 gauge
200 to 300 feet 16 gauge 18 gauge
300 to 400 feet 14 gauge 16 gauge
Refer to pages 13-26 for faceplate dimensions.
strike wiring
configuration
continuous duty
intermittent duty
12V - 16V 24V
resistance 50 Ohms 200 Ohms
10.8 VDC - 17.6 VDC
12 VAC - 17.6 VAC
10% max duty cycle. (2 minute max on time).
10.8VDC - 13.2VDC
.22 Amps - .27 Amps
.22 Amps - .35 Amps
24 VAC - 26.4 VAC
.12 Amps - .13 Amps
21.6 VDC - 26.4 VDC
.1 Amps - .13 Amps
21.6 VDC - 26.4 VDC
.1 Amps - .13 Amps
.24 Amps - .35 Amps
4
Installer Hint
The wires do not need to be stripped, insert wires into the blue wire
connector, crimp with pliers, and you are finished.
Is your frame already prepared?
If the answer is yes continue to step 4.
If the answer is no see frame prep example pages 11-12.
Is a pigtail already attached?
Step 3
Step 4
If the answer is yes continue to step 5.
If the answer is no please follow the instructions below.
Retrieve wires from inside the frame.
a
Connect the pigtail to the wires inside the frame by using the
blue wire connectors.
b
Crimp connectors with pliers.
c
a
b
c

Raising the Standards
An ASSA ABLOY Group company
5
If the answer is 12 - 16* Volt continue to step 6.
If the answer is 24 Volt please follow the instructions below.
Step 5
Cut the violet and black wires.
a
Insert violet and black wires coming from the strike into one
blue wire connector, crimp with pliers.
b
crimp one blue wire connector on each black and violet wire coming
from the connector to prevent a short circuit.
c
black
violet
black
violet
red/green
red
a
c
b
violet
black
*For 16 Volt AC/DC operations,
maintain the solenoid wiring
configured for 12 - 16 V. Be advised
that with a 16 Volt source, the Model
5000 is capable of a 10% Intermittent
Duty Cycle (e.g. “On” for 2 seconds
followed by “Off” for 20 seconds)
with an “On” time not to exceed
2 minutes continuous.
16 Volt AC/DC Capable
(10% Intermittent Duty Cycle)
What does the strike wiring configuration need to be?
6
Installer Hint
When adjusting the screws for field selectability, veteran
installers suggest adding a drop of Loctite to the screws before
tightening them into their final position for added durability.
Do you use Standard or LBM?
If the answer is standard continue to step 7.
If the answer is LBM follow the instructions below.
What is LBM?
Step 6
Step 6a
LBM stands for Latch Bolt Monitoring. The LBM option detects that
the Latch is captured in the Strike.
white
orange
green
common
normally open
normally closed
wiring diagram
LBM
®

Raising the Standards
An ASSA ABLOY Group company
7
Do you need fail secure or fail safe?
If the answer is fail secure follow the instructions under step 7a.
If the answer is fail safe follow the instructions under step 7b.
What is fail safe?
Step 7
Step 7b
Fail safe means if the strike loses power it remains unlocked.
If you need to convert the strike to fail safe
What is fail secure?
Step 7a
a
Move screws into fail safe position
as shown.
b
Tighten screws.
c
a
Move screws into fail secure position as shown.
b
Tighten screws.
c
Fail secure means if the strike loses power it remains locked.
All HES strikes come standard as fail secure.
If you need to convert the strike to fail secure
Loosen screws, but do not remove them. b
Loosen screws, but do not remove them. b
a
a
Installer Hint
When using the trim enhancer you will need to make the cutout
slightly larger than the actual dimensions given for the strike. This
will allow space for the trim enhancer.
8
Do you want to use a trim enhancer?
If the answer is no continue to step 10.
If the answer is yes please follow the instructions below.
Step 9
Place trim enhancer on
electric strike body.
a
b
The trim enhancer allows the installer to cover up a rough or
incorrect sized frame cut.
a
b
How do I attach the faceplate?
Step 8
Place faceplate on electric strike body.
a
Attach the faceplate to electric
strike body using the faceplate
screws provided with the
faceplate option kit.
Attach the trim enhancer to electric
strike body using the provided
trim enhancer screws .
b
a
b

Raising the Standards
An ASSA ABLOY Group company
9
What are the final steps?
Step 10
ba
Connect the electric strike to the pigtail.
a
Insert strike into frame.
b
Tighten both mounting screws securely.
c
10
Installer Hint
When using a combination of lip extensions always stack the smallest size
to the outside.
Do you require a stackable lip extension?
Accessory
Stackable lip extensions are press fit and can easily be
combined to meet the needs of any jamb width, while retaining
the security and finish appearance of the electric strike. To order
stackable lip extensions please contact our customer support
department at 800.626.7590
1/2” - Part Number: 5104-1/2
a
a
b
c
d
1” - Part Number: 5104-1
b
1-1/4” - Part Number: 5104-1-1/4
c
3” - Part Number: 5104-3
d

An ASSA ABLOY Group company
Raising the Standards
11
Frame preparation example*
Want to simplify the process?
c
bMask off the section of the frame
to be cut by using masking tape.
Find the cutout dimensions on
pages 13-26. Draw your guide
lines on the masking tape to
show where you will make the
needed cuts.
a
c
b
Remove the exisiting strike plate from
the frame by removing the screws.
a
*Note: Frame example with ANSI 4 7/8” x 1 1/4” strike preparation
HES offers a universal Metal Template Kit to simplify
the installation procedure. Order the model 154-MTK
by calling customer support at 800.626.7590.
12
Installer Hint
ALWAYS use eye and ear protection.
Veteran Installers recommend cutting inside the lines and
finishing the cutout with a metal file.
eFile the frame to remove rough edges
and ensure the strike fits properly.
d
e
Using your guide lines cut the frame to
the dimensions you have measured.
d
Frame preparation example*
*Note: Frame example with ANSI 4 7/8” x 1 1/4” strike preparation
return to page 4 and
continue with Step 4

Raising the Standards
13 14
An ASSA ABLOY Group company
Installer Hint
To obtain the best results, always cut well inside the lines and
use a metal file to finish off the cutout.
3 3/8"
85.7
1 1/4"
31.8
4 7/8"
124
11/16"
17.5
[2.3]
3/32"
What should the cutout be?
Cut frame according to the dimensions in the drawing.
a
a
501 faceplate option
What are the faceplate dimensions?
501 faceplate option
[mm]
Inches [mm]
Inches

An ASSA ABLOY Group company
Raising the Standards
15
1 1/4"
31.8
4 7/8"
124
3 3/8"
85.7
3/32"
[2.3]
11/16"
17.5
What should the cutout be?
a
Cut frame according to the dimensions in the drawing.
a
Install the mounting tabs to the frame, but do not fully tighten mounting
tab screws.*
b
After you install the strike, securely tighten the mounting tab screws.
c
b
501A faceplate option
c
*Note: To make it easier to mark the locations for the
mounting tabs, attach the mounting tabs to the faceplate,
turn the faceplate backwards and insert it into the cutout.
Mark the hole locations using the template. Remove the
assembly and drill holes.
[mm]
Inches
16
Installer Hint
It is often beneficial to first put masking tape on the door frame where
you will be installing the electric strike. The masking tape protects the
frame surface from being scratched during the installation process.
What are the faceplate dimensions?
501A faceplate option
[mm]
Inches

An ASSA ABLOY Group company
Raising the Standards
17
3 3/8"
85.7
4 7/8"
124
1 1/4"
31.8
11/16"
17.5
What should the cutout be?
Cut frame according to the dimensions in the drawing.
beveled aluminum door
a
Install the mounting tabs to the frame, but do not fully tighten mounting
tab screws.*
b
After you install the strike, securely tighten the mounting tab screws.
c
a
b
c
501B faceplate option
*Note: To make it easier to mark the
locations for the mounting tabs, attach
the mounting tabs to the faceplate, turn
the faceplate backwards and insert it
into the cutout. Mark the hole locations
using the template. Remove the
assembly and drill holes.
[mm]
Inches
18
Installer Hint
Veteran installers suggest removing all dust and debris before final
installation of the electric strike.
What are the faceplate dimensions?
501B faceplate option
[mm]
Inches

An ASSA ABLOY Group company
Raising the Standards
19
What should the cutout be?
Cut frame according to the dimensions in the drawing.
a
Install the mounting tabs to the frame, but do not fully tighten mounting
tab screws.*
b
After you install the strike, securely tighten the mounting tab screws.
c
a
b
c
502 faceplate option
*Note: To make it easier to mark the
locations for the mounting tabs,
attach the mounting tabs to the f
aceplate, turn the faceplate back-
wards and insert it into the cutout.
Mark the hole locations using the
template. Remove the assembly and
drill holes.
[mm]
Inches
20
Installer Hint
To obtain the best results when preparing a wood frame for an
electric strike installation; cut a 1/4" area around the inside of the template
dimensions first with a wood chisel or router for a clean finished edge.
What should the cutout be?
Cut frame according to the dimensions in the drawing.
a
Chisel out the recess dimensions within the frame.
b
a
b
502 faceplate option
For wood applications pre-drill pilot hole for mounting points
with a #30 drill bit.
c
[mm]
Inches

An ASSA ABLOY Group company
Raising the Standards
21
What are the faceplate dimensions?
502 faceplate option
[mm]
Inches
22
Installer Hint
Cutting an aluminum frame with a router or a jigsaw can be very messy
and noisy. Spread out a drop cloth in front of your work area to capture the
aluminum chips and bring a vacuum to clean up after your installation.
What should the cutout be?
Cut frame according to the dimensions in the drawing.
a
Install the mounting tabs to the frame, but do not fully tighten mounting
tab screws.*
b
After you install the strike, securely tighten the mounting tab screws.
c
a
b
c
503 faceplate option
*Note: To make it easier to mark the
locations for the mounting tabs, attach
the mounting tabs to the faceplate, turn
the faceplate backwards and insert it into
the cutout. Mark the hole locations using
the template. Remove the assembly and
drill holes.
[mm]
Inches

An ASSA ABLOY Group company
Raising the Standards
23
What should the cutout be?
Cut frame according to the dimensions in the drawing.
a
Install the mounting tabs to the frame, but do not fully tighten mounting
tab screws.*
b
After you install the strike, securely tighten the mounting tab screws.
c
a
b
c
503B faceplate option
*Note: To make it easier to mark the
locations for the mounting tabs,
attach the mounting tabs to the face-
plate, turn the faceplate backwards
and insert it into the cutout. Mark the
hole locations using the template.
Remove the assembly and drill holes.
[mm]
Inches
beveled aluminum door
24
Installer Hint
Veteran installers suggest masking the frame off with tape.This allows
you to mark your guides on the tape instead of the frame. Then after
you cut the frame you simply need to remove the tape for a clean finish.
What are the faceplate dimensions?
503/503B* faceplate option
* 503B bevel face R 1/8”
503B*
503
[mm]
Inches

Raising the Standards
An ASSA ABLOY Group company
25
What should the cutout be?
Cut frame according to the dimensions in the drawing.
a
Chisel out the recess dimensions within the frame.
b
a
b
504 faceplate option
For wood applications pre-drill pilot hole for mounting points
with a #30 drill bit.
c
[mm]
Inches
[34.9]
1 3/8”
26
Installer Hint
To obtain the best results when preparing a wood frame for an electric strike
installation; cut a 1/4" area around the inside of the template dimensions first
with a wood chisel or router for a clean finished edge.
What are the faceplate dimensions?
504 faceplate option
[mm]
Inches
