Asus I01WD User manual

User Guide
15060-0pt10000
NA15096
NA15096_ZS630KL_UM.indb 1 2019/3/28 14:02:44

First Edition / March 2019
ASUS Phone (Mobile Phone)
Model: ASUS_I01WD (ZS630KL)
Before you start, ensure that you have read all the
safety information and operating instructions in this
User Guide to prevent injury or damage to your
device.
NOTE: For the complete E-Manual and more
detailed information, refer to https://www.asus.
com/support/.
Front features
Touch screen
display
Receiver
Proximity sensor
NA15096_ZS630KL_UM.indb 2 2019/3/28 14:02:45

Power key
Eject hole
Volume
key
Google
Assistant key
Nano SIM1, Nano SIM2, Micro SD card slot
Rear cameras Fingerprint sensor
Flash
NFC detection area
Side and rear features
Audio jack
Microphone
Speaker
USB Type-C port
Microphone
NA15096_ZS630KL_UM.indb 3 2019/3/28 14:02:50

Charging your ASUS Phone
To charge your ASUS Phone:
1. Connect the USB connector into the power
adapter’s USB port.
2. Connect the other end of the USB cable to your
ASUS Phone.
3. Plug the power adapter into a wall socket.
NOTES:
• Forsafetypurposes,useONLY the bundled
power adapter and cable to avoid damaging
your device and prevent the risk of injury.
• Forsafetypurposes,useONLY the bundled
power adapter and cable to charge your ASUS
Phone.
• Theinputvoltagerangebetweenthewall
outletandthisadapterisAC100V-240V.The
output voltage of the USB cable is +9V 2A,
18W.
IMPORTANT!
• WhenusingyourASUSPhonewhileitis
plugged to a power outlet, the grounded
power outlet must be near to the unit and
easily accessible.
• WhenchargingyourASUSPhonethrough
your computer, ensure that you plug the USB
cable to your computer’s USB port.
• AvoidchargingyourASUSPhoneinan
environment with ambient temperature of
above 35oC (95oF).
2
3
1
NA15096_ZS630KL_UM.indb 4 2019/3/28 14:02:50

Installing a nano SIM/ microSD card
To install a nano SIM/ microSD card:
3. Push the tray to close it.
1. Push the bundled eject pin into the hole on the
card slot to eject the tray out.
2. Insert the nano SIM or microSD card into the
appropriate slot.
NOTES:
• BothNanoSIMcardslotssupportGSM/GPRS/
EDGE,WCDMA/HSPA+/DC-HSPA+,FDD-LTE,
andTD-LTEDSDVnetworkbands.BothNano
SIMcardscanconnecttoVoLTE4Gcalling
service.ButonlyonecanconnecttoFDD-LTE,
andTD-LTEdataserviceatatime.
• ThemicroSDcardslotsupportsmicroSDand
microSDXC card formats.
NA15096_ZS630KL_UM.indb 5 2019/3/28 14:02:51

CAUTION!
• Donotusesharptoolsorsolventonyour
device to avoid scratches on it.
• UseonlyastandardNanoSIMcardonyour
ASUS Phone.
Using NFC
NOTE: NFC is only available in selected regions/
countries.
You can use NFC in the following three scenarios:
Reader mode: Your phone reads information from a
contactless card, NFC tag, or other NFC devices.
Place the NFC area of your phone on the contactless
card, NFC tag, or NFC device.
NA15096_ZS630KL_UM.indb 6 2019/3/28 14:02:51

Peer-to-Peer mode:Transfersphotos,contacts,or
other data between your phone and an NFC-enabled
smartphone.
Bring the NFC areas of both smartphones together,
without any space between them.
Card Emulation mode: Your phone can be used like
a contactless card.
Place the NFC area of your phone on the NFC area of
the NFC reader.
NA15096_ZS630KL_UM.indb 7 2019/3/28 14:02:51

Federal Communications
Commission Statement
Thisdevicecomplieswithpart15oftheFCCRules.
Operation is subject to the following two conditions:
(1)Thisdevicemaynotcauseharmfulinterference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
Changes or modications not expressly approved by
the party responsible for compliance could void the
user‘s authority to operate the equipment.
Thisequipmenthasbeentestedandfoundto
comply with the limits for a Class B digital device,
pursuanttopart15oftheFCCRules.Theselimitsare
designed to provide reasonable protection against
harmfulinterferenceinaresidentialinstallation.This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interferencetoradiocommunications.However,
there is no guarantee that interference will not occur
in a particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment o and on, the user is encouraged to try
to correct the interference by one or more of the
following measures:
- Reorientorrelocatethereceivingantenna.
- Increase the separation between the
equipment and receiver.
- Connect the equipment into an outlet on a
circuit dierent from that to which the receiver
is connected.
- Consultthedealeroranexperiencedradio/TV
technician for help.
Theantenna(s)usedforthistransmittermustnotbe
co-located or operated in conjunction with any other
antenna or transmitter.
NA15096_ZS630KL_UM.indb 8 2019/3/28 14:02:51

Thecountrycodeselectionisfornon-USmodels
only and is not available to all US models. Per FCC
regulation, all WiFi products that are marketed in US
must be xed to US-operated channels only.
TheresponsiblepartywithintheUSAper47CFRPart
2.1077(a)(3):
ASUS COMPUTER INTERNATIONAL (America)
Address: 48720KatoRd.,Fremont,CA94538,USA
Telephone:[phone]
RF Exposure Information (SAR)
Thisdevicehasbeentestedandmeetsapplicable
limitsforRadioFrequency(RF)exposure.
SpecicAbsorptionRate(SAR)referstotherateat
whichthebodyabsorbsRFenergy.SARlimitsare
1.6 Watts per kilogram (over a volume containing
a mass of 1 gram of tissue) in countries that follow
the United States FCC limit and 2.0 W/kg (averaged
over 10 grams of tissue) in countries that follow the
CounciloftheEuropeanUnionlimit.TestsforSARare
conducted using standard operating positions with
the device transmitting at its highest certied power
level in all tested frequency bands.
ToreduceexposuretoRFenergy,useahands-free
accessory or other similar option to keep this device
away from your head and body. Carry this device
at least 10 mm away from your body to ensure
exposure levels remain at or below the as-tested
levels. Choose the belt clips, holsters, or other
similar body-worn accessories which do not contain
metallic components to support operation in this
manner.CaseswithmetalpartsmaychangetheRF
performance of the device, including its compliance
withRFexposureguidelines,inamannerthathas
not been tested or certied, and use such accessories
should be avoided.
ThehighestFCCSARvaluesforthedevice(ASUS_
NA15096_ZS630KL_UM.indb 9 2019/3/28 14:02:51

I01WD) are as follows:
• 1.18W/Kg@1g(Head)
• 0.93W/Kg@1g(Body)
• 1.18W/Kg@1g(Hotspot)
TheFCChasgrantedanEquipmentAuthorization
forthisdevice(ASUS_I01WD)withallreportedSAR
levelsevaluatedasincompliancewiththeFCCRF
exposureguidelines.SARinformationonthisdevice
is on le with the FCC and can be found under the
DisplayGrantsectionofwww.fcc.gov/oet/ea/fccid
after searching on FCC ID: MSQI01WD.
FCC Statement (HAC)
Thisphonehasbeentestedandratedforusewith
hearing aids for some of the wireless technologies
thatituses.However,theremaybesomenewer
wireless technologies used in this phone that have
not been tested yet for use with hearing aids. It is
important to try the dierent features of this phone
thoroughly and in dierent locations, using your
hearing aid or cochlear implant, to determine if
you hear any interfering noise. Consult your service
provider or the manufacturer of this phone for
information on hearing aid compatibility. If you have
questions about return or exchange policies, consult
your service provider or phone retailer.
TheFederalCommunicationsCommissionhas
implemented rules and a rating system designed
to enable people who wear hearing aids to more
eectively use these wireless telecommunications
devices.Thestandardforcompatibilityofdigital
wireless phones with hearing aids is set forth in
American National Standard Institute (ANSI) standard
C63.19-2011.TherearetwosetsofANSIstandards
with ratings from one to four (four being the best
rating): an“M”rating for reduced interference
making it easier to hear conversations
on the phone when using the hearing aid
microphone,anda“T”ratingthatenablesthephone
to be used with hearing aids operating in the telecoil
NA15096_ZS630KL_UM.indb 10 2019/3/28 14:02:51

mode thus reducing unwanted background noise.
TheHearingAidCompatibilityratingisdisplayedon
the wireless phone box.
AphoneisconsideredHearingAidCompatible
for acoustic coupling (microphone mode) if it has
an“M3”or“M4”rating. A digital wireless phone is
consideredHearingAidCompatibleforinductive
coupling(telecoilmode)ifithasa“T3”or“T4”rating.
ThetestedM-RatingandT-Ratingforthisdevice
(ASUS_I01WD)areM4andT4.
You’ll want to try a number of wireless phones so
that you can decide which works the best with your
hearing aids. You may also want to talk with your
hearing aid professional about the extent to which
your hearing aids are immune to interference, if they
have wireless phone shielding, and whether your
hearingaidhasaHACrating.
Canada, Industry Canada (IC)
Notices
ThisdevicecomplieswithIndustryCanada’slicence-
exemptRSSstandard(s).Operationissubjecttothe
following two conditions:
(1) Thisdevicemaynotcauseinterference;and
(2) Thisdevicemustacceptanyinterference,
including interference that may cause
undesired operation of the device.
LeprésentappareilestconformeauxnormesCNR
d’Industrie Canada applicables aux appareils radio
exempts de licence. Son utilisation est sujette aux
deux conditions suivantes :
(1) Cet appareil ne doit pas créer d’interférences
nuisibles, et
(2) Cet appareil doit tolérer tout type
d’interférences, y compris celles susceptibles de
provoquer un fonctionnement non souhaité de
l’appareil.
NA15096_ZS630KL_UM.indb 11 2019/3/28 14:02:51

Radio Frequency (RF) Exposure Information
TheradiatedoutputpoweroftheWirelessDevice
is below the Industry Canada (IC) radio frequency
exposurelimits.TheWirelessDeviceshouldbeused
in such a manner such that the potential for human
contactduringnormaloperationisminimized.This
device (ASUS_I01WD) has been evaluated for and
shown compliant with the IC Specic Absorption
Rate(“SAR”)limitswheninstalledinspecichost
products operated in portable exposure conditions.
Canada’sREL(RadioEquipmentList)canbefoundat
the following web address: http://www.ic.gc.ca/app/
sitt/reltel/srch/nwRdSrch.do?lang=eng.
AdditionalCanadianinformationonRFexposure
also can be found at the following web address:
http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/
sf08792.html.
Thisequipmentshouldbeinstalledandoperated
with minimum distance 1.0 cm between the radiator
and your body.
Cet appareil doit être installé et utilisé avec une
distance minimale de 1.0 cm entre l’émetteur et
votre corps.
Informations concernant l’exposition aux
fréquences radio (RF)
La puissance de sortie émise par cet appareil sans l
est inférieure à la limite d’exposition aux fréquences
radiod’IndustrieCanada(IC).Utilisezl’appareilsans
l de façon à minimiser les contacts humains lors
d’un fonctionnement normal.
Cet appareil été évalué et démontré conforme
aux limites de DAS (Débit d’absorption spécique)
d’IC lorsqu’il est installé dans des produits hôtes
particuliers qui fonctionnent dans des conditions
d’exposition à des appareils portables.
Ce périphérique est homologué pour l’utilisation
au Canada. Pour consulter l’entrée correspondant
àl’appareildanslalisted’équipementradio(REL
-RadioEquipmentList)d’IndustrieCanadarendez-
NA15096_ZS630KL_UM.indb 12 2019/3/28 14:02:51

vous sur :
http://www.ic.gc.ca/app/sitt/reltel/srch/nwRdSrch.
do?lang=eng.
Pour des informations supplémentaires concernant
l’expositionauxondesradioauCanada,rendez-vous
sur :
http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/
sf08792.html.
CAN ICES-3(B)/NMB-3(B)
ThisClassBdigitalapparatuscomplieswith
Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à
la norme NMB-003 du Canada.
Thisdeviceanditsantenna(s)mustnotbeco-
located or operated in conjunction with any other
antenna or transmitter, except tested built-in radios.
TheCountyCodeSelectionfeatureisdisabledfor
products that are marketed in the US/ Canada.
Cet appareil et son ou ses antenne(s) ne doivent pas
être situés près de ou utilisés conjointement avec
une autre antenne ou un autre émetteur, exception
faite des radios intégrées qui ont été testées.
La fonction de sélection de l’indicatif du pays est
désactivée pour les produits commercialisés aux
États-Unis et au Canada.
TheICIDforthisdevice(ASUS_I01WD)is
3568A-I01WD.
L’identiant Industrie Canada de cet appareil (ASUS_
I01WD) est: 3568A-I01WD.
NA15096_ZS630KL_UM.indb 13 2019/3/28 14:02:51

Using GPS (Global Positioning
System) on your ASUS Phone
TousetheGPSpositioningfeatureonyourASUS
Phone:
• Ensure that your device is connected to the
InternetbeforeusingGoogleMaporany
GPS-enabledapps.
• Forrst-timeuseofaGPS-enabledappon
your device, ensure that you are outdoors to
get the best positioning data.
• WhenusingaGPS-enabledapponyour
device inside a vehicle, the metallic
component of the car window and other
electronicdevicesmightaecttheGPS
performance.
Safety information
CAUTION! Use of controls or adjustments or
performance of procedures other than those
speciedhereinmayresultinhazardousradiation
exposure.
Laser safety information
CLASS 1 LASER PRODUCT
Complieswith21CFR1040.10and1040.11except
for deviations pursuant to Laser Notice No. 50, dated
June24,2007
NA15096_ZS630KL_UM.indb 14 2019/3/28 14:02:51

ASUS Phone care
• UseyourASUSPhoneinanenvironmentwith
ambient temperatures between 0 °C (32 °F) and
35 °C (95 °F).
The battery
WARNING: Disassembling the battery by yourself
will void its warranty and may cause serious harm.
Your ASUS Phone is equipped with a high
performance non-detachable Li-polymer battery.
Observe the maintenance guidelines for a longer
battery life.
• Donotremovethenon-detachableli-polymer
battery as this will void the warranty.
• Avoidcharginginextremelyhighorlow
temperature.Thebatteryperformsoptimallyin
an ambient temperature of +5 °C to +35 °C.
• Donotremoveandreplacethebatterywitha
non-approved battery.
• UseonlyASUSbattery.Usingadierentbattery
may cause physical harm/injury and may
damage your device.
• Donotremoveandsoakthebatteryinwateror
any other liquid.
• Nevertrytoopenthebatteryasitcontains
substances that might be harmful if swallowed
or allowed to come into contact with
unprotected skin.
• Donotremoveandshort-circuitthebattery,as
it may overheat and cause a re. Keep it away
from jewelry or metal objects.
• Donotremoveanddisposeofthebattery
in re. It could explode and release harmful
substances into the environment.
• Donotremoveanddisposeofthebattery
withyourregularhouseholdwaste.Takeittoa
hazardousmaterialcollectionpoint.
• Donottouchthebatteryterminals.
NA15096_ZS630KL_UM.indb 15 2019/3/28 14:02:51

• Toavoidreorburns,donotdisassemble,
bend, crush, or puncture the battery.
NOTES:
• Riskofexplosionifbatteryisreplacedbyan
incorrect type.
• Disposeofusedbatteryaccordingtothe
instructions.
The charger
• UseonlythechargersuppliedwithyourASUS
Phone.
• Neverpullthechargercordtodisconnectit
from the power socket. Pull the charger itself.
Caution
Your ASUS Phone is a high quality piece of
equipment. Before operating, read all instructions
and cautionary markings on the (1) AC Adapter.
• DonotusetheASUSPhoneinanextreme
environment where high temperature or high
humidityexists.TheASUSPhoneperforms
optimally in an ambient temperature between
0 °C (32°F) and 35 °C (95 °F).
• DonotdisassembletheASUSPhoneorits
accessories. If service or repair is required,
returntheunittoanauthorizedservicecenter.
If the unit is disassembled, a risk of electric
shock or re may result.
• Donotshort-circuitthebatteryterminalswith
metal items.
Operator access with a tool
IfaTOOLisnecessarytogainaccesstoanOPERATOR
ACCESSAREA,eitherallothercompartmentswithin
thatareacontainingahazardshallbeinaccessible
totheOPERATORbytheuseofthesameTOOL,or
such compartments shall be marked to discourage
OPERATORaccess.
NA15096_ZS630KL_UM.indb 16 2019/3/28 14:02:51

Proper disposal
Risk of explosion if battery is replaced
by an incorrect type. Dispose of used
batteries according to the instructions.
DONOTthrowthebatteryinmunicipal
waste.Thesymbolofthecrossedout
wheeled bin indicates that the battery
should not be placed in municipal waste.
DONOTthrowthisproductinmunicipal
waste.Thisproducthasbeendesigned
to enable proper reuse of parts and
recycling.Thesymbolofthecrossedout
wheeled bin indicates that the product
(electrical, electronic equipment and
mercury-containing button cell battery)
should not be placed in municipal waste.
Check local regulations for disposal of
electronic products.
DONOTthrowthisproductinre.DO
NOTshortcircuitthecontacts.DONOT
disassemble this product.
WARNING
CancerandReproductiveHarm-
www.P65Warnings.ca.gov
NOTE: For more legal and e-labelling information,
check on your device from Settings > About >
Legal information / Regulatory labels.
ASUS Recycling/Takeback Services
ASUS recycling and takeback programs come
from our commitment to the highest standards for
protecting our environment. We believe in providing
solutions for you to be able to responsibly recycle
our products, batteries, other components as well as
the packaging materials. Please go to http://csr.asus.
com/english/Takeback.htm for detailed recycling
information in dierent regions.
NA15096_ZS630KL_UM.indb 17 2019/3/28 14:02:52

Copyright©2019ASUSTeKCOMPUTERINC.
AllRightsReserved.
You acknowledge that all rights of this Manual remain with ASUS.
Any and all rights, including without limitation, in the Manual or
website, and shall remain the exclusive property of ASUS and/or its
licensors. Nothing in this Manual intends to transfer any such rights,
or to vest any such rights to you.
ASUSPROVIDESTHISMANUAL“ASIS”WITHOUTWARRANTYOF
ANYKIND.SPECIFICATIONSANDINFORMATIONCONTAINEDINTHIS
MANUALAREFURNISHEDFORINFORMATIONALUSEONLY,ANDARE
SUBJECTTOCHANGEATANYTIMEWITHOUTNOTICE,ANDSHOULD
NOTBECONSTRUEDASACOMMITMENTBYASUS.
ASUS
Address: 4F, No.150 Li-Te Rd., Peitou, Taipei,
Taiwan
Tel: [phone]
Fax: [phone]
Declaration
We declare that the IMEI codes for this product, ASUS
Phone, are unique to each unit and only assigned to
thismodel.TheIMEIofeachunitisfactorysetand
cannot be altered by the user and that it complies
with the relevant IMEI integrity related requirements
expressedintheGSMstandards.
Should you have any questions or comments regarding
this matter, please contact us.
Sincerely yours,
ASUSTeK COMPUTER INC.
Tel:886228943447
Fax:886228907698
Support: https://www.asus.com/support/
ZenTalk Fans Forum
(http://www.asus.com/zentalk/global_forward.php)
NA15096_ZS630KL_UM.indb 18 2019/3/28 14:02:52

Première Édition / Mars 2019
ASUS Phone (Téléphone portable)
Modèle : ASUS_I01WD (ZS630KL)
Avant de commencer, assurez-vous de lire le Manuel de
l'utilisateur accompagnant ce produit et contenant des
informations relatives à la sécurité et à l'utilisation, et ce
an d'éviter de vous blesser ou d'endommager l'appareil.
REMARQUE : Pour le manuel d'utilisation complet
et des informations plus détaillées, consultez le site
https://www.asus.com/support/.
Face avant
Écran tactile
Écouteur
Capteur de
proximité
NA15096_ZS630KL_UM.indb 19 2019/3/28 14:02:52

REMARQUES :
• Pourdesraisonsdesécurité,utilisezUNIQUEMENT
l'adaptateur secteur et le câble fournis pour éviter
d'endommager votre appareil et de vous blesser.
• Pourdesraisonsdesécurité,utilisezUNIQUEMENT
l'adaptateur secteur et le câble fournis pour recharger
votre appareil.
• Laplagedetensiond'entréeentrelaprisemuraleetcet
adaptateur est de 100Vca - 240Vca.Tension de sortie du
câble USB : +9V 2A, 18W.
IMPORTANT !
• Sivousutilisezletéléphonelorsquecelui-ciestreliéà
unepriseélectrique,cettedernièredoitêtrereliéeàla
terre, à proximité et aisément accessible.
• Lorsduchargementdutéléphoneparlebiaisd'un
ordinateur, branchez le câble USB sur l'un des ports USB
de votre ordinateur.
• Évitezdechargervotretéléphonedansun
environnement dont la température ambiante est
supérieure à 35°C (95°F).
Face arrière et faces latérales
Prise casque
Bouton
d’alimentation
Fente pour carte nano SIM1, nano SIM2, microSD
Touche de
réglage du
volume
Haut-parleur
Microphone
Microphone
Caméras arrières Lecteur d'empreintes
digitales
Orice d'éjection
Flash
Touche
Assistant
Google
Zone de détection NFC
Port USB Type C
NA15096_ZS630KL_UM.indb 20 2019/3/28 14:02:53
