Atdec AD-WM-9080 User manual

AD-WM-9080 Page 1 of 4
Installation Guide
AD-WM-9080
Full Motion Wall Mount 9080
COMPONENT CHECKLIST
W
Full Motion Wall Mount
Assembly
X
Display Bracket
(x2)
Y
Security Clip
(x4)
Z
Drilling Template
C
M6x16
Screw
(x4)
G
M8x45
Screw
(x4)
A
M4x16
Screw
(x4)
E
Washer
(x4)
B
M5x16
Screw
(x4)
F
D
M8x25
Screw
(x4)
H
Spanner
M5x8
Security Screw
(x4)
IMPORTANT INFORMATION
! Please ensure this product is installed as per these installation instructions.
! The manufacturer accepts no responsibility for incorrect installation.
! Failure to mount this product correctly may cause serious injury/death during or following installation.
! This product is not suitable for outdoor use.
! Do not use this product for mobile applications.
! This product supports a maximum load of 90.7kg (200lb).
! Wall Plate only achieves maximum weight rating when appropriately fastened to a wall of adequate structural capacity.
! Professional installer to ensure adequate structural capacity of wall (including appropriate safety factor) to support total
weight of all equipment being mounted.
! Drilling into electrical wires can cause death - use appropriate equipment and caution when drilling holes in walls to avoid
electrical cables, water pipes and gas pipes. Do not drill into structures unless you have established it’s safe to do so.
! Suits displays with mounting hole patterns from 100mm to 800mm wide by 100mm to 600mm high.
REQUIRED TOOLS
• Stud nder
• Spirit level
• Power drill
• Suitable drill bits
• Driver bit for selected
wall fasteners
• Phillips head screwdriver
• Socket wrench set
NOTE:
! Wall Plate Mounting Fasteners are NOT supplied with Wall Mounts.
Professional installer to ensure correct Mounting Fastener type, location &
quantity to suit structure where Wall Mount is installed.
! ALWAYS use a washer between the chosen fastener and the wall plate.
! Mounting fasteners to be used as per manufacturers instructions, including
minimum engagement to achieve necessary performance. 0 - 90.7kg
(0 - 200lb)
WEIGHT CAPACITY

AD-WM-9080 Page 2 of 4
2. Adjust the horizontal alignment of the display arms (OPTIONAL)
1. Mount the Wall Mount Assembly to the wall
12 3
2.1. Prior to mounting the display,
you may choose to adjust its nal
horizontal alignment.
Use a Phillips head screwdriver
to remove the four Phillips head
screws from the arm assembly and
remove the security plates.
2.2. Support the arm assembly and
horizontally slide it left or right
along the wall plate within the
allowable range - where the holes
on the arm assembly align with
those on the wall plate.
2.3. Replace the security plates and
the four Phillips head screws,
ensuring the proper alignment
of the holes on the display arm
assembly, the wall plate and the
security plates.
NOTE:
• Lifting and securing of the wall mount should
be perfomed by two people.
• Use supplied drilling template Zto mark and
drill holes as required.
• Choice and supply of appropriate wall mount
fasteners is the responsibility of the installer.
• Consult a preferred fastener supplier or a
structural engineer to select fasteners which
are most appropriate for the weight of the
display and wall construction method.
• Wall mount must be level. Verify using a
quality spirit level tool.
• On a Stud Wall or Drywall use a good quality
Stud Finder to position mounting fasteners in
the centre of studs.
• On a Masonry Wall avoid positioning Wall
mount mounting fasteners in a mortar join.
Z
Slot Dimension
Ø8 x 34mm
*Fasteners shown for example only
A - FOR DISPLAYS WITH 100x100 TO 200x200 VESA SPACING
A3. Remove the horizontal VESA rails from the Wall Mount Assembly
A3.2. Slide the rails out of the display mount assembly.
Save these for future display upgrades.
A3.1. Use a Phillips head screwdriver to remove
the safety screws from the centre and at
least one side of each rail.

AD-WM-9080 Page 3 of 4
B3. Attach the Display Brackets to the Display B4. Hook the Display onto the Arm Assembly
A4. Remove the Display Plate A5. Attach the Display Plate to the Display
B - FOR DISPLAYS WITH 300x100 TO 800x600 VESA SPACING
A6. Hook the Display onto the Arm Assembly
A+E
B+E
C+E
D
G
A+E
B+E
C+E
D
G
A4.1. Use supplied spanner H or a socket wrench to
remove the two security nuts from the display plate.
A4.2. Unhook the display plate from the display arms.
A6.1. Angle the display and hook the slot on the
Display Plate to the hook on the Arm Assembly.
This should be completed by two people.
WARNING: Ensure the round protrusion on
the display plate sits inside the slot on the arm
assembly before proceeding.
B4.1. Angle the display and hook the Display
Brackets on to the horizontal rails of the Arm
Assembly.
This should be completed by two people.
A6.2. Use supplied spanner H or a socket wrench to replace
the two security nuts removed in Step A4.
Tighten to the desired level of friction for level
correction/rotation adjustment
NOTE:
• When selecting screws, ensure the display is not loose
and screws are not forced too deep into the display.
NOTE:
• When selecting screws, ensure the display is not loose
and screws are not forced too deep into the display.

AD-WM-9080 Page 4 of 4
Display Tilt Display Rotation/Level Correction
No portion of this document or any artwork contained herein should be reproduced in any way without
the express written consent of Atdec Pty Ltd. Due to continuing product development, the manufacturer
reserves the right to alter specications without notice. ©20220112
MAINTENANCE
ADJUSTMENTS
CABLE MANAGEMENTB5. Secure the Display
• Tighten fasteners and check if the mount is secure and safe to use at regular intervals (at least every three months.)
• Please contact your distributor if you have any questions.
• Use the pre-installed cable management clips to route
cables along the arms of the mount.
• Ensure that cables will not become tangled in the arms
during motion.
B5.1. Position the four Security Clips Ybehind the Display
brackets as shown, ensuring that the ange on each
Security Clip is aligned with the rectangular slot on
each Display Bracket.
B5.2. Secure each Security Clip Y using Security Screw F.
-5° / +10°
+/- 5°
Y
F
Align Security Clip to Slot
To adjust rotation friction, loosen or tighten
the two nuts below the Display Arms using
supplied spanner H or a socket wrench tool.
WARNING:
Only loosen, do not remove the two nuts.
NOTE:
• Pulling and holding the spring-loaded levers
outward will allow the lever handles to rotate
without adjusting the tilt tension. This will allow
for additional adjustment range.
• Alternatively, use a suitable hex key tool to
adjust the tilt tension.
