AWM-BT Page 1 of 3
Installation Guide
AWM-BT
AWM Tilt Bracket
COMPONENT CHECKLIST
REQUIRED TOOLS
WEIGHT RANGE
Flat Monitor
4.5 - 25kg (10 - 55lb)
Curved Monitor
4.5 - 18kg (10 - 40lb)
Display Size
24” - 55”
• Phillips Head Screwdriver
IMPORTANT INFORMATION
! Please ensure this product is installed as per these installation instructions.
! EachTiltBracketsupportsamaximumweightasperabovecapacityspecication.
! Thisproductisnotsuitableforoutdooruse.
! Donotusethisproductformobileapplications.
! The manufacturer accepts no responsibility for incorrect installation.
! This product is compatible with Atdec AWM Series products.
! VESAmountedaccessories(suchasminiPCbracketsandmounts),andoffsetVESAlocationsexertadditional
leveragethatcanexceedthecapacityofthemounteventhoughthemonitorweightmaybewithinthestatedrange.
PleasecontactAtdecifyouwouldlikefurtherinformation.
B
Bracket
(x1)
A
VESA Plate
(x1)
C
M4x10
Screw
(x4)
D
M4x20
Screw
(x4)
E
10mm
Spacer
(4x)
F
4mm
Hex Key
(x1)
300mm (12”) max
overall display depth

AWM-BT Page 2 of 3
2. Slide bracket onto post and set height
2.2Lineuptheinnerguideon
rearofbracketwithrearchannel
onpost.Slideinnerguideinto
channelandlowerbracket.
2.1 Directionoftiltbracketon
post:
WhendeskxingisCClamp
(AWM-FC)orHeavyDutyF
Clamp(AWM-FH)TiltBracket
must only be attached with
displayfacingthefrontofthe
mountingsurface.
WhenusingGrommetClamp
(AC-GC)TiltBracketcanbe
positionedwithdisplayfacing
forwardsorbackwardsonthe
post.
2.3Firmlytighten
handknobat
chosenheight.
1.1 VESA compatibility 1.2 Attach VESA plate with
M4x10 Screws.
1.2 For recessed VESA use
10mmSpacersandM4x20
Screws.
1. Attach VESA plate to display
75mm
100mm
75mm
100mm
For 75mm VESA
unscrew 5mm to
access top holes.
NOTE:
SomedisplaysrequiretheuseofaVESAadapter
beforeattachingtheVESAplate.ThisVESA
adaptermayshipintheboxwiththedisplay.
Consultyourdisplay’sinstallationguidefor
furtherinformation.
OR
A
C
TOP
A
D
E
TIGHTEN
B
AWM POST
(not supplied)
Arrow side
towards user
B
AWM POST
(not supplied)
Arrow side
towards user
WORK SURFACE
WORK SURFACE
OR
OR
WORK SURFACE
WORK SURFACE
OR
OR

AWM-BT Page 3 of 3
No portion of this document or any artwork contained herein should be reproduced in any way without
the express written consent of Atdec Pty Ltd. Due to continuing product development, the manufacturer
reserves the right to alter specications without notice. ©20221124
4. Fine adjustment
3. Attach display
3.1 Set VESA plate to
open position.
WARNING:
Use two people to
install display
3.2 LiftdisplayuntilVESA
plateisabovetheheightof
the bracket.
3.3 Withpostcenteredslowly
lowerdisplayuntilbaronVESA
platesitsinsaddleinbracket.
3.4 Set VESA plate
to closed position by
sliding clips on both
sides inwards.
3.5 Adjust display tilt
angle by gripping edges
of screen and rolling up or
down to desired position.
3.6 Tighten tilt knobs
to set display angle.
4.1 Tocorrecthorizontalangle
ofdisplay+/-3°:
Turnasingleneadjustment
knobtoadjustangleofdisplay.
4.2 Toclosesmallgapbetween
displays+/-6mm(1/4”):
Turnbothneadjustment
knobs-alternatingsidesafew
rotationsatatime.
OPEN
WARNING:
Do not loosen
hand knob once
display mounted�
OPEN
CLOSED
Clockwise = More friction
Anti-clockwise = Less friction
OPTIONAL ADJUSTMENT
- TILT FRICTION
4mm Hex key can be used
to reduce tilt friction (for
light screen) or increase tilt
friction (for heavy screen).
F
TILT
KNOBS
CLOSED
Clockwise=Higher
Anti-clockwise=Lower
FINE HEIGHT ADJUST
FINE ADJUSTMENT
KNOBS
NOTE:
Ensure slide clips in
CLOSED position
