Atlantic H-7312X User manual

ASSEMBLY INSTRUCTIONS
26 X 50
Before assembling your TV Table, please read through these
TV TABLE H-7312X
Page 1 of 7
TV TABLE H-7312X
Adult Assembly
WOODEN DOWEL - 16 pcs
JCB M8 X 65mm (2 1/2”) - 12 pcs
WOOD SCREW (1 1/2”) - 12 pcs
Spare - 1 pc
Spare - 1 pc
Spare - 1 pc
A
B
C
WOOD SCREW (3/4”) - 18 pcs
HINGE SCREW (5/8”) - 16 pcs
METAL KNOB - 4 pcs
KNOB SCREW 1 5/8” - 2 pcs
KNOB SCREW 1” - 2 pcs
Spare - 2 pcs
Spare - 2 pcs
D
E
I
WOOD KNOB - 2 pcs
+ 2 ASSEMBLE TO DRAWER
KNOB SCREW 1 3/8” - 2 pcs
H
FLAT WASHER - 12 pcs
SPLIT WASHER - 12 pcs
Spare - 2 pcs
F
SHELF CLIP - 16 pcs ALLEN WRENCH - 1 pc
Spare - 1 pc Spare - 1 pc
GJ
ATTENTION! If you receive a damaged or defective item,
please contact Atlantic Furniture at [email protected] or 1-800-955-3726 / M-F 9:00-5:00 EST
READY
ASSEMBLE
TO
instructions carefully and familiarize yourself with the different parts.
NOTE: WE INCLUDE SPARE HARDWARE IN CASE THE JCB, WASHER, WOODEN DOWEL, SHELF CLIP, ALLEN WRENCH
OR WOOD SCREW ARE DAMAGED DURING ASSEMBLY.
Phillips head
screwdriver
Customer supplied

PARTS LIST
01
02
03
04
05
06
07
08
09
10
11
HARDWARE
TOP PANEL
LEG
SIDE PANEL
DIVIDER
HINGE BLOCK
BOTTOM SHELF
BACK PANEL
DOOR
SIDE SHELF
MID SHELF
1 BOX + 1 BOX KNOB ENCLOSED
1 PC
4 PCS
2 PCS
2 PCS
4 PCS
1 PC
2 PCS
2 PCS
2 PCS
2 PCS
01
02
03
09
09
04
04
05
10
11
11
10
08
08
06
06
06
06
C
C
C
C
A
A
A
A
05
07
04
03
03
03
STEP 1 Install wooden dowels (A) to the locator holes as shown.
Attach the hinge block (06) to side panels (04).
Using wood screws (C) tighten with Phillips head screwdriver as shown below.
Page 2 of 7
Adult Assembly
A
C
WOODEN DOWEL
WOOD SCREW
1 1/2”
Phillips head
screwdriver
Customer supplied
TV TABLE H-7312X

Page 3 of 7
STEP 2
STEP 3
Remove drawers and attach legs pulling firmly (03) to the top panel (02). Using JCB (B), flat and split
washer (F) tighten with Allen wrench (J) as shown below.
.Do not tighten at this step
Adult Assembly
03
03
02
05
03
03
B
B
B
F
F
F
Install wooden dowels (A) to the locator holes as shown.
A
A
A
A
A
WOODEN DOWEL
Adult Assembly
B
JCB
F
J
FLAT, SPLIT
WASHER
ALLEN WRENCH
TV TABLE H-7312X

F
FLAT, SPLIT
WASHER
Page 4 of 7
STEP 4
STEP 5
Attach side panels (04) and dividers (05) to the top panel (02).
Attach bottom shelf (07). Using JCB (B), flat & split washer (F) tighten with Allen wrench (J). Using
wood screws (C) tighten with Phillips head screwdriver as shown below.
Tighten all JCB at this step.
Adult Assembly
04
05
07
05
02
04
B
B
C
C
C
C
F
F
B
C
JCB
WOOD SCREW
1 1/2”
Adult Assembly
Phillips head
screwdriver
Customer supplied
Phillips head
screwdriver
Customer supplied
J
ALLEN WRENCH
TV TABLE H-7312X

Page 5 of 7
STEP 6
Attach back panels (08). Using wood screws (D) tighten with Phillips head screwdriver as shown below.
Adult Assembly
D
WOOD SCREW
3/4”
Adult Assembly
G
SHELF CLIP
08
08
D
D
G
G
G
G
STEP 7 Install shelf clip (G) as shown below.
Phillips head
screwdriver
Customer supplied
TV TABLE H-7312X

Page 6 of 7
STEP 8 Install side shelf (10) and mid shelf (11) as shown below.
Adult Assembly
STEP 9 Install wood knob (H) or metal knob (I) to the door (09) using knob screws (1 3/8”) tighten with Phillips
head screwdriver as shown below.
Adult Assembly
H
I
WOOD KNOB
METAL KNOB
10
11
11 10
09
H
OR
I
Phillips head
screwdriver
Customer supplied
TV TABLE H-7312X

Congratulations!
Your TV Table is now ready for use.
To ensure lasting safety, we recommend that you periodically check
that all screws are tight and all parts are secure.
Page 7 of 7
STEP 10
STEP 11
Install the doors (09) to tv stand. Using wood screws (E) tighten with Phillips head screwdriver.
( Customer Supplied )
Adjust and tighten with Phillips head screwdriver.
Reinstall the drawers to TV stand as shown below.
ADJUSTER
LOOSEN AND TIGHTEN
Adult Assembly
Phillips head
screwdriver
Customer supplied
09
09
TV TABLE H-7312X
E
E
E
E
E
Adult Assembly
E
WOOD SCREW
5/8”
