Atlas Copco Tensor STB User manual

User Guide
Tensor STB
Wireless tool for the Power Focus tightening controller
Atlas Copco Industrial Technique AB
9836 3043 01
Software version 10.11
Edition 7.0
2013-05

2 (36) 9836 3043 01
Copyright Atlas Copco Tools and Assembly Systems
Note! This manual can be altered without further notice.
For further information log in to Atlas Copco www.atlascopco.com

Contents
9836 3043 01 3 (36)
Contents
1Introduction...........................................................................................................4
1.1 Radio Frequency Exposure......................................................................................4
2System overview...................................................................................................5
2.1 Functionality.............................................................................................................6
2.1.1 System functionality...................................................................................................6
2.1.2 Tool functionality........................................................................................................6
2.2 Technical data..........................................................................................................7
2.2.1 Memory capacity .......................................................................................................7
2.2.2 Battery .......................................................................................................................7
2.2.3 IRC.............................................................................................................................8
3System setup.......................................................................................................10
3.1 Hardware setup...................................................................................................... 10
3.2 IRC hardware setup ............................................................................................... 10
3.2.1 Serial Port Adapter ..................................................................................................10
3.2.2 Antenna placement..................................................................................................11
3.3 Tool preparation..................................................................................................... 11
3.4 Setting up the Power Focus software..................................................................... 11
3.5 Setting up tool communication ............................................................................... 11
3.5.1 Getting started with IRC-B.......................................................................................12
3.5.2 Getting started with IRC-W –Infrastructure ............................................................12
3.5.3 Getting started with IRC-W –Ad hoc ......................................................................13
3.6 Connecting tool with Power Focus (Pairing)...........................................................14
3.6.1 Radio diagnostics ....................................................................................................15
3.7 Setting up standalone.............................................................................................16
3.7.1 Getting started with Standalone ..............................................................................16
3.7.2 Setting ST-selector in stand-alone mode ................................................................17
3.8 Connecting tool with ToolsTalk Service.................................................................. 18
3.9 Other settings in ToolsTalk Power Focus...............................................................21
3.9.1 Batch count..............................................................................................................21
4Parameters, relays and events...........................................................................22
4.1 Parameter list......................................................................................................... 22
4.2 Digital outputs (relays)............................................................................................23
4.3 Event codes........................................................................................................... 23
5FAQ ......................................................................................................................26
6Appendix..............................................................................................................27
6.1 Docking station setup............................................................................................. 27
6.1.1 Connecting to PC ....................................................................................................27
6.2 ToolsTalk Service with Serial port adapter .............................................................31
6.3 Cross-over Ethernet connection............................................................................. 32

Introduction
4 (36) 9836 3043 01
1 Introduction
This manual describes the Atlas Copco Tensor STB nutrunner.
For complete technical data, see Product Instructions for each tool.
For software and hardware compatibility between tool and controller, see Tensor STB release notes.
For an updated list of functionality, see Tensor STB release notes.
See also the Power Focus User guide, 9836 3123 01.
1.1 Radio Frequency Exposure
The Serial Port Adapter (or the IRC Focus front panel) and the Tensor STB contain a small radio
transmitter and receiver. During communication all IRC products receive and transmit radio frequency
(RF) electromagnetic fields in the frequency range for the ISM (Industrial, Scientific and Medical) band
(2.4GHz and 5.0 GHz).

System overview
9836 3043 01 5 (36)
2 System overview
Tensor STB is battery powered and communicates with the Power Focus tightening controller system
through wireless digital communication built on Industrial Radio Communication (IRC) technology.
Figure 1 System overview
A Tensor STB system includes the following parts.
Tool
Tensor STB tool
Tool battery
Battery charger
Docking station with power supply and USB cable, for configuration of IRC-W.
Controller options
IRC Focus for IRC-B
Power Focus 4000 or 3100
Serial Port Adapter for IRC-B or IRC-W
Serial cable for Power Focus
Power cable for Serial Port Adapter
RBU (Bronze, Silver or Gold)
Software
Tensor STB software
Power Focus software (W7.5 up to W10.10)
ToolsTalk Service, for configuration of IRC-W settings for infrastructure mode
For compatibility between software versions, see Tensor STB release notes.

System overview
6 (36) 9836 3043 01
2.1 Functionality
2.1.1 System functionality
The Power Focus sends the Parameter set (Pset) and the batch size to the tool where it is stored and
executed, and the tightening result is sent back to the Power Focus. See schematic figure below.
The STB tool family has the same basic functionality as other ST tools, but due to the nature of the
wireless communication where the tightening data is stored in the tool, all features in the Power Focus SW
may not be available in STB. For a complete list, see Tensor STB release notes.
Remote start is not available, for safety reasons.
Figure 2 System functionality
2.1.2 Tool functionality
Figure 3 STB tool
1
Optional ST Scanner,
ST selector or GPIO
on bus connector
2
Buzzer
3
LEDs
4
Function button
5
Battery
6
Direction ring
7
Tool trigger
The Tensor STB tool is equipped with a buzzer and blue LEDs that can be configured as outputs to
indicate a series of events, as the event relays on Power Focus. In addition, STB has the following LEDs.
Pset
Result

System overview
9836 3043 01 7 (36)
Connection, blue LED: Indicates connection to Power Focus
Batch, green LED: Indicates Batch done
Battery, yellow LED: Indicates battery status (flashing light for low, and
fixed light for empty battery)
Alarm, red LED: A tool event is detected, for example Tool overheated
The function button, situated on the direction ring, can be configured as an input like the digital inputs on
Power Focus. It can generate different inputs depending on the position of the direction ring, clockwise
(CW) or counter clockwise (CCW).
External accessories can be mounted directly on the tool. Connected to the bus connector, the accessories
communicate with the Power Focus using the same data link as the tool. The tool accessory bus is
configurable to work in different modes depending on the connected device.
2.2 Technical data
For complete technical data, see Product Instructions for each tool.
2.2.1 Memory capacity
The results for up to 25 tightenings including traces can be stored together with 8 Jobs (or 8 Psets) in the
STB.
2.2.2 Battery
Tensor STB is equipped with a Lithium-Ion battery.
Figure 4 Number of tightenings
The capacity is dependent on the battery type and joint, softer joints gives less tightenings. See Figure 4
Number of tightenings illustrates the number of tightening between re-charge for different tools and
different types of joints (rundown angle in degrees) at the maximum torque for the tool. The same values
apply to the STB33 and STB63 tool models.

System overview
8 (36) 9836 3043 01
2.2.3 IRC
The Industrial Radio Communication (IRC) technology
operates on the free 2.4 GHz ISM band and also the
5.0GHz band (Uniband I and II).
The Tensor STB tool is available in two different versions
for the different IRC standards:
IRC-B
IRC-W
The table below gives an overview of the different standards.
Technique
Latency
Immunity
Multipath
Immunity
Interference
Immunity
Power
Consumption
IRC-B
High
High
High
Low
IRC-W
Moderate
Moderate
Moderate
High
The performance of IRC-W is highly dependent on the infrastructure at the site.
Latency defines the delay times of the communication link i.e. when transferring tightening results. The
multipath immunity indicates how well the reflections in the environment are handled, for example against
walls or equipment. The interference immunity indicates how well other radio sources are avoided.
IRC-B
79 (1 MHz) channels.
IRC-B features dynamic Adaptive Frequency Hopping (AFH).
No frequency planning needed.
Figure 5 IRC-B with AFH avoids collisions on the 2.4 GHz ISM band, for example Wi-Fi
More information at: www.bluetooth.com.

System overview
9836 3043 01 9 (36)
IRC-W (dualband)
13 (22 MHz) infrastructure channels in the 2.4 GHz band.
21 infrastructure channels in the 5.0 GHz band (Unii-band 1, Unii-band II, Unii-band-IIe and Unii-
band III)
11 ad-hoc channels in the 2.4 GHz band (channels 1-11)
4 ad-hoc channels in the 5.0 GHz band (Unii-band 1)
1 fixed channel used for communication.
Frequency planning needed.
Installation support from IT department needed.
Figure 6: IRC-W, three channels occupying the 2.4GHz ISM band with a channel bandwidth of 22 MHz.
Channel No.
Band (GHz)
Description
0
Automatic
2.4 GHz or 5.0 GHz band, where channel is chosen automatically to optimize performance.
1-14
2.412GHz-
2.484GHz
Channel distribution:
North America or FCC domain (1-11)
Europe or ETSI domain (1-13)
Japan (1-14) –not supported
36
5.15-5.25 GHz
Unii-band 1
40
44
48
52
5.25-5.35 GHz
Unii-band II (restrictions for ad-hoc usage –please contact Atlas Copco representative)
56
60
64
100
5.5 GHz
Uniband IIe (restrictions for ad-hoc usage –please contact Atlas Copco representative)
104
108
112
116
132
5.6-5.7 GHz
136
140
149
5.745-5.825 GHz
153
157
161
165
More information at www.wi-fi.org.

System setup
10 (36) 9836 3043 01
3 System setup
This section describes how to connect the Power Focus and STB.
The STB tool is compatible with standard Power Focus 4000 and 3100 as well as the IRC
Focus for both Graph and Compact controllers and all available RBU-types (except for DS).
3.1 Hardware setup
Setup the Power Focus system according to the local network recommendation.
If using a Serial Port Adapter, the connection with ToolsTalk Power Focus must go through Ethernet as
the serial port 2 is required for the adapter. In case there is no network available, the connection between
Power Focus and the PC running ToolsTalk Power Focus is made with a cross-over Ethernet cable
according to the instructions in section 6.2 ToolsTalk Service with Serial port adapter.
In case an IRC Focus is used, it is possible to connect to the Power Focus with a serial connection.
In both cases, it is also possible to access the Power Focus 4000 with a USB connection.
3.2 IRC hardware setup
Tools using IRC-W infrastructure proceed to section 3.5.2 Getting started with IRC-W –Infrastructure.
Tools using IRC-B or IRC-W with an IRC Focus proceed directly to section 3.2.2 Antenna placement. For
tool running IRC-W ad-hoc or IRC-B using a Serial Port Adapter process as described below.
3.2.1 Serial Port Adapter
When using a Serial Port Adapter, connect it according to the following instructions.
1. Turn off the Power Focus.
2. Connect an Atlas Copco crossover cable between
the Serial Port Adapter and the Power Focus serial
port 2, called RS232 (2). Recommended maximum
cable length: 2 metres.
3. Connect the power cable between the Serial Port
Adapter and the mains circuit in the premises.
4. Turn on the Power Focus.
Figure 7 Serial Port
Adapter connection
Figure 8 Serial Port
connection

System setup
9836 3043 01 11 (36)
3.2.2 Antenna placement
The antenna must be located with free line of sight to
the tool, for example above pallets and other
equipment.
The antenna on the serial port adapter can be
adjusted to optimize performance.
In IRC Focus, the antenna is built-in behind the front
panel.
Since the IRC Focus has a smaller antenna, it is
especially important to ensure proximity and
obstruction-free placement.
Place the controller in free line of sight to the tool.
Figure 9 Antenna placement of the controller
3.3 Tool preparation
The battery must be charged before proceeding.
3.4 Setting up the Power Focus software
The Power Focus can be programmed from ToolsTalk Power Focus or directly on Power Focus Graph.
ToolsTalk Power Focus:
1. Establish a connection with program control from ToolsTalk.
2. Open Power Focus Map > Tool > Configuration > Connection to access the radio and connection
parameters.
3. Proceed to section 3.5 Setting up tool communication and select connection type.
Power Focus Graph:
1. Press PROG > Tool > Configuration > Connection to access the radio and connection parameters.
2. Proceed to section 3.5 Setting up tool communication and select connection type.
3.5 Setting up tool communication
You need to set up how to communicate with the tool, i.e., type of connection.

System setup
12 (36) 9836 3043 01
Figure 10 Tool configuration
3.5.1 Getting started with IRC-B
In ToolsTalk Power Focus do the following settings:
1. Set parameter T290 Primary tool to IRC-B.
2. Set T294 Serial port to Serial 2 if a Serial Port Adapter is used or Internal for IRC Focus.
3. Reboot the Power Focus.
4. Continue to section 3.6 Connecting tool with Power Focus (Pairing).
NOTE: It is possible to use a Serial Port Adapter on an IRC Focus, but the Serial Port Adapter will have
precedence and will disable the Internal radio module. Only a reboot will re-enable it.
3.5.2 Getting started with IRC-W –Infrastructure
IRC-W connection requires the following settings.
Network settings: The network administrator must open the network for UDP traffic for the MAC
address of the STB tool.
Supports IEEE 802.11 a/b/g/n
Thorough frequency planning is needed for the premises
Network settings from the administrator must be entered in ToolsTalk Service.
See section 3.8 Connecting tool with ToolsTalk Service.0
Autentication/encryption standards supported:
WEP: 64 (Open or shared)
WEP 128 (Open or shared)
WPA-PSK, TKIP
WPA2-PSK, AES/CCMP
LEAP,WEP128
LEAP, TKIP
LEAP, AES/CCMP
PEAP, WEP128

System setup
9836 3043 01 13 (36)
PEAP, TKIP
PEAP, AES/CCMP
EAP/TLS, WEP128
EAP/TLS, TKIP
EAP/TLS, AES/CCMP
To setup the controller use ToolsTalk Power Focus or Graph interface and do the following settings:
1. Set parameter T290 Primary tool to IRC-W.
2. Set parameter T296 IRC-W operational mode to Infrastructure.
3. T293 Power Focus IP port is default 6677, and must be the same as in the tool.
Reboot Power Focus.
NOTE: It is possible to run IRC-W infrastructure on an IRC Focus.
3.5.3 Getting started with IRC-W –Ad hoc
This is the default Operation mode for the IRC-W tool. If this setting has been changed, tool must be re-
programmed to ad-hoc, see 3.8Connecting tool with ToolsTalk Service. The Ad hoc mode makes it
possible to set up on which channel to communicate.
In ToolsTalk Power Focus do the following settings:
1. Set parameter T290 Primary tool to IRC-W.
2. Set parameter T296 IRC-W operational mode to Ad-Hoc.
3. Set T294 Serial port to Serial 2 if a Serial Port Adapter is used or Internal for IRC Focus.
4. Set parameter T297 IRC-W channel to the correct channel number. If Auto is selected the PF and the
tool will select the best available channel.
5. Reboot Power Focus.
6. Continue to section 3.6 Connecting tool with Power Focus (Pairing).

System setup
14 (36) 9836 3043 01
3.6 Connecting tool with Power Focus (Pairing)
The Power Focus and the tool need to be paired together in order to establish the IRC-B or IRC-W ad hoc
connection. This is not needed when running in infrastructure mode.
Do not start the Power Focus pairing procedure before both LEDs on tool are flashing.
Initiate pairing within 30s or the tool might time out.
Power Focus Compact or IRC Compact:
1. Press the F-button 10 times (F10).
2. Press the return-key to confirm the selection.
Power Focus Graph or IRC Graph:
1. Press PROG > Tool > Configuration > Connection > IRC Pairing > right arrow
2. Press the soft key marked Start to confirm the selection.
3. Press OK to exit setup.
ToolsTalk Power Focus:
Select Power Focus Map > Tool > Configuration > Radio > IRC pairing
Wait a few seconds until the blue connection LEDs on the
tool and the Serial Port Adapter (if used) are on.
The pairing is consistent until the tool or the
Serial Port Adapter is replaced.
Figure 12
Connection LED on
tool
Figure 13
Connection LED on,
Serial Port Adapter
Event E559 indicates a successful pairing completed and event E550 indicates connection with the tool.
The connection to Power Focus is established within one minute.
1. Disconnect the (charged) battery from the tool.
2. Press the tool trigger while reattaching the battery.
3. When the tool LEDs are off, release the tool trigger.
4. When the tool LEDs are on again, press the tool trigger.
5. When the tool LEDs are off again, release the tool trigger. Both LEDs start
to flash (after approximately 10 seconds).
Figure 11 LED on

System setup
9836 3043 01 15 (36)
3.6.1 Radio diagnostics
It is possible to see some radio diagnostics in ToolsTalk Power Focus:
Select Power Focus Map > Tool > Diagnostics > Radio
Figure 14 Radio diagnostics window
If you press the button Radio diagnostic you can get the actual reading for response time, RSSI value
(Received Signal Strength Indication) channel used and MAC address for the accesspoint (BSSID).
Figure 15 Active response time and RSSI value
NOTE: If IRC-B is used it is only possible to see the Active response time.

System setup
16 (36) 9836 3043 01
3.7 Setting up standalone
This can be done after setting up the tool communication according to section 3.5 Setting up tool
communication and performing a pairing. Standalone mode can be configured preferably when working
with IRC-B or IRC-W ad-hoc mode.
3.7.1 Getting started with Standalone
The STB power tool can be used in standalone mode, i.e., without being connected to the controller.
To setup the tool in standalone mode follow this instruction:
1. Start by pairing the tool and controller.
2. In the PF Map Tool branch, double-click on Maintenance and then click Standalone to view the
Standalone settings.
´
Figure 16 Standalone parameter settings
3. To edit the standalone parameters click Set
stand alone parameters.
4. In the Set Stand Alone Parameters dialog
box select the Use standalone check box,
and then select type of accessory.
None: Only one Pset can be used.
ST Selector: Up to four Psets are
available. The ST Selector must be
set to mode 1. To set up the ST
Selector, please refer to section
3.7.2 Setting ST-selector in stand-
alone modeFel! Hittar inte
referenskälla..
GPIO: Up to four Psets are
available.
5. Select a Pset for each position.
6. Click OK when finished to store the
standalone configuration to tool.
Figure 17 Standalone parameter settings

System setup
9836 3043 01 17 (36)
The ST selector functions can be programmed in ToolsTalk by selecting the item “ST selector” in T472
Accessory.
Figure 18 ST selector programming
Standalone mode is indicated by the flashing blue Connection LED on the tool. It will take
some time (up to 15 seconds) for this to occur.
7. To the left in the Tool Maintenance dialog box, click Disconnect tool.
8. To disconnect the tool, click Disconnect tool, and then click OK in the Disconnect tool dialog box.
Pair the tool to upload results and/or change standalone configuration.
If running in IRC-W infrastructure mode the tool will automatically reconnect to the Power
Focus when it is recycled.
NOTE: When reconnecting tool to controller: to upload the results after re-pairing the Pset Id:s used must
exist in the PF.
3.7.2 Setting ST-selector in stand-alone mode
If an ST selector is used, the ST selector must be pre-programmed to work in stand-alone mode. This is
done by following this procedure:
1. When powering up the STB tool, keep the left button on the selector is pressed in, and the
selector will enter the configuration mode. (Requirement : The Accessory Bus parameter
T210 Mode must be configured to ST Bus).
2. By pressing the right button it is then possible to toggle between the different available
modes. Ensure that mode 1 is chosen and stored by pressing the left button again.
3. If full functionality mode(Mode 2) is chosen the selector is now ready to be used, but if stand
alone mode (Mode 1) is chosen the operator must enter number of Psets that should be used.
Figure 19 Disconnect tool

System setup
18 (36) 9836 3043 01
This is done by pressing the right button again until the right number is shown on the display.
Mode 3 works exactly the same way as Mode 1.
4. When the right number is displayed, it is stored by pressing the left button again. The selector
is now ready to be used.
The mode will be stored in the selectors memory even after power off.
3.8 Connecting tool with ToolsTalk Service
The docking station is useful when configuring the tool to operate in an infrastructure W-LAN
environment. It is also useful for service operation on the tool software or tool parameters.
:
1. Connect the tool to
the docking
station. For
instructions on
how to connect the
tool, see section
6.1 Docking
station setup.
2. In ToolsTalk
Service, open
Options > Settings.
3. Select Port and
USB device.
4. Click OK.
Figure 20 TTS settings
5. Click the Connect icon
when the tool is
connected to the
Tensor STB docking
station.
The tool stays connected
during the session with
ToolsTalk Service.
Figure 21 Connect icon
6. Open Configuration > IRC-W. Set parameters 106402 Remote IP Address to the IP address of the
Power Focus, and 106403 Remote Port to the port number same as the controller parameter T293
Power Focus IP port, default 6677..

System setup
9836 3043 01 19 (36)
Figure 22 IRC Hardware settings
7. Enter the settings for the IRC-W parameters. The data for Authentication/Encryption type and key
is submitted by the network administrator.
Figure 23 IRC-W settings

System setup
20 (36) 9836 3043 01
8. Store the settings in the Authentication/Encryption window and then also on the previous window.
Finally, click on the Disconnect icon.
Remove the tool from the docking station and attach the battery. The tool is automatically connected to
Power Focus.
Figure 24 Authentication/Encryption Key dialog
