Audiovox PRO-9642a Pursuit Series User manual

128-8179
1 of 8
Page1
Model PRO-9642a
Owner's Manual
FEATURES:
2 Three Button Programmable RF Transmitters
Three Channel Receiver (capable of accepting 4 transmitters)
Code Hopping Technology
Remote Panic in all modes
Protected Valet
7 Function LED - Arm / Disarm / Zone 1 / Zone 2 / Zone 3 / Valet / Arming
Intrusion Alert with Memory
Audible Arm / Disarm / Defective Zone / Tamper Confirmation
Instant Siren Activation
Low Current Horn Output
Starter Disable
True Last Door Arming (hardwire only)
Defective Zone By-Pass
Hardwire or Voltage Sense Selectable
Active or Passive Arming Selectable
Programmable Auto Lock On / Off
Programmable Auto Unlock On / Off
Programmable Door Lock Pulse Duration 1 Second / 3.5 Seconds/1 Sec L/ Dbl. U/L
Programmable Active or Passive Door Locks
User Programmable Permanent Chirp Delete
On Command RF Chirp Delete from Transmitter
6 Tone Multi-Tone Siren
RF Inhibit with ignition on
Parking Light Flasher
OPTIONS:
Single or Dual Stage Shock Sensor
RemoteTrunk Release
Remote Keyless Entry
Multiple Vehicle Capable
Remote Starter
Remote Power Window Roll Up
Remote Garage Door Interface
3 Button Remote Security System
From 9642a with new transmitters & PBLED 5/07

128-8179
2 of 8
Page2
NOTE: Yoursystemhastheoptionof usinga siren,the vehiclehorn, orboth forthe sounding
device. Wherethesirenis referencedbelow, thehornor both mayinfact chirp, or
beep.
ARMINGTHE SYSTEM-ACTIVE
1.Turnoff theengine, exitthevehicle andcloseall doors,hood lid,andtrunk lid.
2.PressandreleasetheArm/ Lockbuttononthekeychain transmitter.
;ReddashmountedLEDbegins toflash slowly.
;ParkingLights flashone time.
;Sirenand/ orHornsounds onechirp.
If the siren/horn sounds 3 chirps, then you have left a door, trunk, or hood lid
ajar. Simplyclosetheopenedentry pointto providefullprotection. If thesiren
"chirped"three times,sometime afterarming,theexclusivedelayeddomelight
learncircuit hasbeenprogrammedandthesystemdetected aopenentrypoint
after the learned delay expired. Again, closing the hood, trunk, or doors will
correct the problem and you do not need to disarm the system to make the
correction.Ifthe siren/horn didnot sound whenarming,then thechirpshave
beenturnedoff,and youshould refertothesectiontitled“ELIMINATINGTHE
ARM/DISARMCHIRPS“inthismanual.
DoorsLock-Optional
SILENTARMING -ACTIVE
1.Turnoff theengine, exitthevehicle andcloseall doors,hood lidandtrunk lid.
2.Pressand holdtheArm/Lock buttononthe keychaintransmitter for2seconds.
;ReddashmountedLEDbegins toflash slowly.
;ParkingLights flashone time.
;Siren/Hornwillnot sound.
Ifthesiren/horn sounds3chirps, thenyouhave lefta door,trunk, or the
hoodlidajar.Simplyclosetheopenedentrypointtoprovidefullprotection.
DoorsLock-Optional
ARMINGTHE SYSTEM- PASSIVE(AUTOMATIC )
1.Turnoff theengine, exitthevehicle andcloseand lockall doors,hoodlid, andtrunklid.
;Red dash mounted LED begins to flash rapidly, indicating 30 second passive
arminghas begun.
2. Opening any protected entry point during the 30 second passive arming cycle will
immediately suspend automatic arming and the 30 second passive arming cycle will
re-start when all doors are closed.At the end of the passive arming cycle;
;ReddashmountedLEDbegins toflash slowly.
;ParkingLights flashone time.
;Sirenandor Hornsoundsone chirp
Ifthesiren/horn did notsoundwhen arming,thenthe chirpshavebeen
turnedoffandyou shouldreferto thesectiontitled "ELIMINATINGTHE
ARM/DISARMCHIRPS"inthismanual.
DoorsLock-Optional
Doorlocking duringpassivearmingisaselectablefeature.Thealarmcan
be programmed to allow the doors to lock only when arming using the
keychaintransmitter andtheywillnotautomaticallylockduringpassivearm-
ing.

128-8179
3 of 8
Page3
PROTECTIONWHILETHESYSTEMISARMED
;Opening any protected door, hood, or trunk lid will cause the alarm to immediately
sound. The alarm will continue to sound for 30 seconds, then stop and continue to
monitorall protectedentrypoints.Ifthe thiefleftadooropened, thealarmwillsoundfor
six30second cycles,remain armedandignore thattriggered zone.
;Wheneverthesystemisarmed,thereddashmounted LEDindicator willslowly flash.
Thisservesas avisualdeterrent to thepotentialthief. TheLEDis averylow current
bulb and will not cause the vehicle’s battery to drain, even when left unattended for
extendedperiods.
;Wheneverthesystem istriggered,the vehicle’sparking lightswillflash forthefull 30
secondalarmcycle,attractingvisual attentionto thevehicle.
Optional - Whenever the system is armed, the vehicle’s starting circuit will be by-
passed. If the thief should choose to ignore the siren/horn, the vehicle can not be
started.
Optional-Anystrongimpactto thevehicle willcause thealarm totriggerforthefull30
secondalarmcycle.
Optional-Anymildimpacttothevehiclewillcausethealarmtosound ashort seriesof
warningtones.
DISARMINGTHESYSTEM
1. Asyou approachthevehicle,pressandreleasetheDisarm /Unlockbuttononthe keychain
transmitter.
;ReddashmountedLEDturnsoff.
Ifpassivearming wasselectedduring theinstallation,then theLED will
startflashingrapidly,indicating thatthesystemisre-armingautomatically.
Openanydoortosuspendtheautomaticarming.
;ParkingLightsflash twotimes.
Iftheparking lightsflashedthree times,thenthe alarmwastriggered in
your absence. Before turning the key on, examine the LED to identify
which zone was triggered.
;Siren / Horn sounds two chirps.
If the siren/horn sounds 4 chirps, then the alarm was triggered in your
absence. Before turning the key on, examine the LED and refer to the
INTRUSIONWARNINGSIGNALSsectionofthis manualtoidentifywhich
zone was triggered.
If the siren/horn did not sound when disarming, then the chirps have
beenturnedoff,and youshould referto thesection titled"ELIMINATING
THEARM/DISARMCHIRPS"inthismanual.
DoorsUnlock -Optional
SILENTDISARMING
1. Asyouapproach thevehicle,press andhold theDisarm/ Unlockbuttonon thekeychain
transmitterfor2 seconds.
;ReddashmountedLEDturnsoff.
Ifpassivearming wasselectedduring theinstallation,then theLED will
startflashingrapidly,indicating thatthesystemisre-armingautomatically.
Openanydoortosuspendtheautomaticarming.
;ParkingLightsflash twotimes.

128-8179
4 of 8
Page4
Iftheparking lights flashedthree times, thenthealarm wastriggeredin
your absence. Before turning the key on, examine the LED to identify
which zone was triggered.
;Siren/Horndoesnotsound.
Ifthesiren andorhorn sounds4chirps, thenthealarm was triggeredin
yourabsence.Before turning thekeyon, examinetheLED and referto
theINTRUSIONWARNING SIGNALSsectionof thismanual toidentify
which zone was triggered.
DoorsUnlock -Optional
WHILETHESYSTEMISSOUNDING
If during a triggered state, you wish to shut off the siren without disarming your security
system,simplypress and releaseany transmitter buttonotherthan thedisarmbutton. This
action will turn off the siren yet leave the vehicle fully armed and protected. This feature is
particularlyusefulif youareaware ofchildrenplaying nearyourvehicle thatmayaccidently
triggeryoursecurity system. Inthis caseyoucan cancelthe sirensoundingwithout disarm-
ingyoursecurity system.
INTRUSIONWARNINGSIGNALS
This system will inform you if an intrusion attempt has occurred while you were away from
the vehicle. If an intrusion attempt has occurred, the siren/horn will chirp 4 times and the
parkinglights willflash 3times whendisarming thesystem. Enterthevehicleandobservethe
reddashmounted LEDtoidentify whichzonewas triggered.
nIftheLED is flashingonetime...pause...one time...pause...etc.,thenan intrusion
attemptwasmade tothe optionalshocksensor,oran accessorytriggering device
thatmayhavebeenadded tothesystem.
oIftheLEDisflashing two times...pause...two times...pause...etc., then anintrusion
attemptwasmadetoahoodortrunkpinswitch that was added to the system, or to
a light activated entry point if the alarm was installed using the voltage sensing
feature.
pIftheLEDis flashing three times...pause...three times...pause...etc.,thenanintru-
sionattempt was made throughone of the vehicle’sdoors.
Theseintrusion warning indicators are stored in the system’s memory and will only be erased
whenthe ignition key isturned on.
PUSHBUTTONLED/VALET/OVERRIDE/PROGRAMMINGSWITCH:(PBLED)
ThePBLEDswitchallowsyoutotemporarilybypassallalarmfunctions,eliminatingtheneed
tohand your transmitterto parking attendantsor garage mechanics. When the system is in
valetmode,allalarm functions are bypassed, howevertheremotepanic feature and remote
doorlockswill remain operational. Tousethevalet mode, the systemmustfirst be disarmed
eitherbyusingyourkeychaintransmitter,orbyactivatingyourpersonalizedmanual override
code.
1. Enterthevehicle, and turn the ignition key totheonposition.
2. PressandholdthePBLEDswitchuntiltheLEDturnsonsolid. Thesystem willremainin the
valetmode.
3. Toreturn to normal operation, press and release the PBLED switch any time the ignition is
on.
NOTE: Alwaysremember to return the vehicle to the valet off position. This will ensure that
thevehicleremainsprotectedatalltimes.

128-8179
5 of 8
Page5
MANUALLYOVERRIDINGYOURSYSTEM:
USINGTHEPBLEDOVERRIDESWITCH
Your Security System can be disarmed without the use of the keychain transmitter. This is
necessary,since youwillneedthe ability to operate your vehicleifthetransmitteris lost or its
batteryfails.If your system hasbeen selected for ValetSwitch manual override asindicated
onthelast page of thismanual, to bypass thealarmsystem;
1. Openthe vehicle door. Thealarm will sound.
2. Turntheignitionkeyto the on position.
3. Within5seconds, press andreleasethe PBLED overrideswitch.
Thealarmsystemwillstopsounding and enter the (bypassed)mode. Youcan now start and
operatethe vehicle normally.
Typically this override modeisusedonlyif the transmitter has become inoperative.
Programming Your Custom Override Code:
Unlike override switches easily found, and defeated, this security system allows the con-
sumer to program a personal override code, offering a higher level of security. To take
advantageofthis option, programmable feature #10must be selected fortheCustom Code
Option. Consultyour installation center forprogrammingdetails.Thesystem comesfromthe
factorywithapre-programmed override code of11.Tochange thisdefaultoverride code, do
thefollowing:
1. Disarm the system by use of the transmitter, or by use of the emergency override
sequence.Turntheignition switch to theon position.
2. Within10seconds, press and release thePBLEDswitch, 3 times.
3. Within 10 seconds turn the ignition switch off, on, off, on, off, on.
(Thesiren or hornwill beep andthe lights willflash one time.)
4. Within10 seconds, begin toenter your chosen10ths digit by pressingand releasing the
PBLEDswitchfrom1upto 9 times.
5. Within10 seconds ofthe last entered 10ths digit, turn the ignitionswitch off thenon.
6. Within10 seconds, begin to enteryour chosen units digit bypressing and releasing the
PBLEDswitchfrom1upto 9 times.
7. Finishby turning the ignition switch to theoff position.
If the new code was accepted, the unit will report back the newly entered code, by flashing
theLED,first indicating the 10thsdigit,pause and then theunitsdigit. The unit willreportthe
new code three times with a one second pause between each code, then the system will
beginarming.If the LEDflash pattern reports thepreviously stored code, thenew code was
notentered correctly. Please repeatsteps1 through 7 aboveconsidering the following.
NOTE: Acceptabledigits10thsorunits are 1 through 9.Theunitwillnot recognize a 0 (Zero),
ornodigit entered inany place, units ortenths.
NOTE: If 15 seconds of inactivity expire, or if the ignition switch is turned off for more then
5 seconds during any of the above steps, the unit will revert back to the last
successfully stored code.
Custom Code Programming Example:
To Change the code from the factory pre-assigned code of 11 to “52” you would do the
following:
1. Disarm the system by use of the transmitter, or by use of the emergency override se-
quence.
2. Turnthe ignition switch totheon position.
3. Within10seconds, press and release thePBLEDswitch, 3 times.
4. Within 10 seconds turn the ignition switch off, on, off, on, off, on.
(Thesiren or hornwill beep andthe lights willflash one time.)

128-8179
6 of 8
Page6
5. Within10seconds,begintopress andreleasethePBLED switchtosetthe tenthsdigit.(As
perthe example, press andrelease 5 times toset the tenths digitto 5)
6. Within10 seconds of the last pressofthepushbutton, turn the ignition switchoffthenon.
7. Within10seconds, begintopressandreleasethe PBLED switchtosettheunits digit.
(Asper the example,press and release 2 times to set the units digit to 2).
8. Turntheignitionswitch to the off position. Immediatelyobservethe LED flash pattern.
YouwillnotetheLEDflashingfivetimes,pause,andthenflashtwotimes,pause.Thispatternwillbe
repeatedthreetimesindicatingthenewcode(52)hasbeenacceptedandstoredinmemory.
NOTE: Ifafterstep 7, the LED flashesa code other than whatwasjust entered, this indicates
thatthe code has notbeen changed. You will have torepeat steps 1 through7 above
beingcertainto note the following:
Acceptabledigits 10ths orunits are 1 through 9. The unit will not recognize a 0 (Zero), or no
digitenteredin any place, unitsortenths.
NOTE: If15secondsofinactivityexpire,oriftheignitionswitchisturnedoffformorethen5seconds
duringanyoftheabovesteps,theunitwillrevertbacktothelast successfullystoredcode.
MANUALLYOVERRIDINGYOURSYSTEM:
USINGTHECUSTOMCODEOVERRIDE
Assuming the override code programmed has not been changed, and the default override
codeof 11 is inthe system's memory.
1) Enterthe vehicleand turn the ignitionswitchto the on position.
NOTE:The siren will sound.
2) Within5 seconds,pressand release the PBLED switch 1time.
3) Within5 seconds, turn theignition switch off then on.
4) Within5 seconds,pressand release the PBLED switch 1time.
5) Turnthe ignition switch off then onand start the vehicle.
NOTE: If you have changed the programmed override code then substitute your new code
tenths for step 2 above, and units for step 5 above.
ELIMINATINGTHE NORMAL ARM/DISARMCHIRPS
Youcanselectivelyeliminatethenormalarm & disarm chirpsbyholdingthe transmitter button
slightly longer when arming or disarming. This will prevent the siren chirps for one arm or
disarmcycle. Ifyou find this inconvenientand wish to eliminatethese chirps permanently,
1.Turn the ignition switch 'on"then 'off".
3.Within10seconds of turning offtheignition, press and release thePBLEDswitch 3 times.
4.Ifthechirps were on before youstarted,thesiren will emit 2 shortchirpsindicatingthat the
chirps are now off. If the chirps were off before you started, the siren will emit one short
chirpindicating that thechirps are now on.
NOTE: Ifthe vehicle battery is disconnected then reconnected, the unit will return to the
defaultsettingofchirpson. Repeattheaboveproceduretoeliminatethearm/disarm
chirps.
NOTE: Whenever the chirps are by - passed, the 4 chirp intrusion indicator and 3 chirp
defective zone indicator will always operate. Since these are important warnings to
you that something has happened, they cannot be eliminated.
REMOTEPANICOPERATION
TheLock or Unlockbutton on yourkeychain transmitter alsofunctions as a panic switch for
useinemergencysituations.To use remotepanic,
1.PressandholdtheLockorUnlockbuttononthekeychaintransmitterfor3ormore seconds.
Thealarmwillimmediatelysound.

128-8179
7 of 8
Page7
2.To stop the alarm, press and hold the Lock or Unlock button on the transmitter againfor
3seconds. If the button is notpressed,thealarmwillautomaticallystopafter30seconds.
Alsoif anytransmitterbuttonotherthan the LockorUnlockbuttonis pressed andreleased,
thePanicmodewillbeturnedoffimmediately. Thenormalfunctionof thistransmitterbutton
willbesuspendedduringthePanic sounding period.
NOTE: WhileinthePanicmode,pressingandreleasingtheLockortheUnlockbuttonswill, if
theoption is installed,lockandunlock the doors respectively. Whileinthepanicmode,
anytime the unlock button is pressed, the panic feature will continue for the allotted
30 seconds, however, the security system will be disarmed allowing the vehicle to
start.
ADDITIONALREMOTEFUNCTION(CHANNEL3 )
Thissecuritysystemhas an additional feature that canbeconnectedto a number of different
optionalaccessories.Some of the more commonusesfor this channel are:
Remote Trunk Release
Remote Car Starter
Remote Window Closure
Remote Garage Door Interface
To activate the optional accessory, press and hold the option button 2 on the keychain
transmitter for 3 seconds.

128-8179
8 of 8
Page8
DASHLED INDICATORS
RAPIDFLASHING = PASSIVEARMING
SLOWFLASHING = ARMED
OFF = DISARMED
ONSOLID = VALETMODE
3FLASH...PAUSE = INTRUSIONZONE3
2FLASH...PAUSE = INTRUSIONZONE2
1FLASH...PAUSE = INTRUSIONZONE1
SIRENCHIRPINDICATORS
1CHIRP* = ARM
2CHIRPS* = DISARM
3CHIRPS = ARM/DOOROPENED
4CHIRPS = DISARM/INTRUSION
* These chirps are optional, and can be de - activated.
PARKING LAMPS 1 FLASH = ARM
2FLASHES = DISARM
3FLASHES = DISARM/INTRUSION
Your System Has These Features Activated
Single Stage Shock Sensor
Dual Stage Shock Sensor
Remote Keyless Entry
Starter Disable when armed
Auto Lock with ignition key
Auto Unlock with ignition key
Passive Arming
No Lock in passive mode
Hardwire doors, hood, and trunk
Siren Activation
Horn Activation
PRO-9642a
SYSTEM FUNCTIONSATA GLANCE
© 2007 Audiovox Electronics Corporation, Hauppauge N.Y. 11788 128-8179
