AUMA AUMATIC AC 01.2 Manual

Actuator controls
AUMATIC AC 01.2
Profibus DP
To be used in combination with the operation instructions only!
●The present short instructions do NOT replace the operation instructions!
●They are only intended for persons already familiar with the operation instructions
wheresafety instructions,assembly,operation and commissioning are already described
in detail!
●The operation instructions must always be available.
FO connectionShort instructions

Table of contents Page
31. Short description...................................................................................................................
42. FO connection........................................................................................................................ 42.1. Basic information 52.2. FO terminal compartment: open 52.3. FO cables: connect 72.4. FO terminal compartment: close
83. Network topologies................................................................................................................ 83.1. Line topology 93.2. Star topology 103.3. Loop topology (two-fibre loop)
124. Corrective action.................................................................................................................... 124.1. LED indications
135. Technical data......................................................................................................................... 135.1. FO connection board:
156. Appendix................................................................................................................................. 156.1. Measuring methods 156.2. Reference addresses 156.3. Literature
2
Table of contents

1. Short description
AUMA actuator controls with FO connection are intended for use in optical fieldbus
networks.
The FO connection integrated in the electrical connection enables the conversion
from electrical RS-485 signals into optical signals and vice versa.
FO connection behaviour is passive at the bus, i.e.control of AUMA actuators is via
bus is made in the same way as for a connection via copper cables (RS-485).
Contrary to RS-485 based systems, different topologies are possible:
●Line topology
●Star topology
●Redundant loop topology
Apart from the large distances, FO cables offer further advantages:
●In environments with electromagnetic interference
●Lightning arrester or overvoltage protection
●Equipotential earth bonding and earthing
●Galvanic separation of the actuator
●Use of common cable trenches for power and signal cables
●Prevention of interference emissions along the transmission line
This allows for customised solutions for various applications such as water/waste
water industries, tunnelling, power plants, thermal industry or telecontrol engineering.
3
Short description

2. FO connection
2.1 Basic information
Hazardous voltage!
Risk of electric shock.Failure to observe this warning can result in death or serious
injury.
→The connection must be carried out exclusively by suitably qualified personnel.
→Prior to opening: Disconnect both system and device from the mains.
→Observe basic information contained in this chapter.
→Observe safety instructions contained in the operation instructions pertaining
to the actuator.
Eye damage caused by open fibre optic cable ends!
→NEVER look directly into open cable ends or FO cable connections.
Connection or receive problems when ignoring the installation instructions!
→Only using FO cable connection (connector types) with the wiring techniques
indicated in these instructions.
→Only mount connector types with locking mechanisms in the defined position.
→Protect unused FO cable connections against contamination or dust with protec-
tive caps/plugs supplied by the factory.
→Connect incoming FO cable with the optical receiver, the outgoing FO cable
with the optical sender. NOT vice versa!
→Do NOT kink FO cables! Observe bending radius of cable manufacturer.
Cable and wire types
Table 1: Cables and wires according DINVDE 0888 part 3:
Multi-mode 62.5 (50)/125 μm
Single-mode 9/125 μm
Fibre
62.5 (50)/125 μm glass fibre (multi-mode): 2,500 m
9/125 μm glass fibre (single-mode): 15 km
Range
Recommendation: <2.0 dB/km (multi-mode) or <0.4 dB/km
(single-mode)
Damping coefficient
Remove outer sheathing of FO cable at a length of approx. 42 cm to enable loop
wiring in the terminal compartment.
Figure 1: Plug types: ST or SC (depending on version)
Controls mounted to wall bracket
In the event of heavy vibration of the valve, we recommend mounting the actuator
controls separately from the actuator on a wall bracket. For information about the
wall bracket, refer to operation instructions for the actuator.
4
FO connection

2.2 FO terminal compartment: open
The AUMA plug/socket connector (SDE bus) is equipped with a connection board
for connecting the fibre optic cables.When removing the cover [1], the connection
board is easily accessible.
Figure 2: AUMA plug/socket connector SDE bus
[1] Cover (FO terminal compartment)
[2] Screws for cover
[3] O-ring
[4] Cable entries for fibre optic cables
[5] Blanking plugs
1. Loosen screws [2] and remove cover [1].
2. Insert cable glands suitable for FO cables.
➥The enclosure protection IP…stated on the name plate is only ensured if suita-
ble cable glands are used.
➥Example: Name plate for enclosure protection IP 68.
3. Seal unused cable entries [4] with suitable blanking plugs [5].
4. Insert the wires into the cable glands.
2.3 FO cables: connect
Figure 4: Connection board with connector types SC (left), ST (right)
[1] Channel 1
[2] Channel 2 (for loop or line topology)
[3] Protective cap/plug
TX Optical output
RX Optical input
5
FO connection

A label on the connector indicates the wiring (fibre type, connector type).
Table 2: Markings on the label
FO cable connector typeFO cable fibre type
ST = Straight tip (BNC connector)SM = Single-mode SC = Subscriber connector (Snap-in connector)MM = Multi-mode
FO cables: connect
1. Install cables within the terminal compartment in a loop to achieve the highest
possible bending radius.
Figure 5: Wiring within in the terminal compartment
2. Measure and record the damping of the FO cables before connection.
3. Link connectors crosswise:
Output TX of actuator 1 to input RX of actuator 2
Input RX of actuator 1 to input TX of actuator 2
Figure 6: Example of ST BNC connector
➥Make sure that:
- the bayonet-type connection of connector type ST is properly engaged
- the straight tip of connector type SC fully mates the FO cable socket.
4. Protect unused FO cable connections against contamination or dust with pro-
tective caps/plugs supplied by the factory.
6
FO connection

2.4 FO terminal compartment: close
Figure 7: AUMA plug/socket connector SDE bus
[1] Cover
[2] Screws for cover
[3] O-ring
[4] Cable entries for fibre optic cables
[5] Blanking plugs
1. Clean sealing faces of cover [1] and housing.
2. Apply a thin film of non-acidic grease (e.g.petroleum jelly) to the sealing faces.
3. Check whether O-ring [3] is in good condition, correctly insert O-ring.
4. Fit cover [1] and fasten screws [2] evenly crosswise.
5. Fasten cable glands with the specified torque to ensure the required enclosure
protection.
7
FO connection

3. Network topologies
When connecting several terminal devices (actuators) in a network, the structure is
called network topology.AUMA offers 3 different network topologies.
3.1 Line topology
Figure 8: Structure for line topology
Max. FO cable range in km (observe technical data!)
[1] Channel 1
[2] Channel 2
[3] Any Profibus DP device
[4] FO coupler at DCS (mandatory)
[5] FO coupler for any Profibus field device
Special features of line topology
The optical signal is converted into an electrical signal at each device. Prior to
transmission to the next device, the electrical signal is converted into an optical
signal.
Interruption of an FO cable (case A) or failure of an FO connection board (case B)
results in a loss of control for the subsequent actuators:
Case A
(standard)
As soon as the electrical connection is removed from the , the FO connection of this
actuator is no longer available. As a consequence, communication with the
subsequent actuators is lost.To prevent this, the FO connection used in the can also
be externally supplied with 24 V DC.
Case B
(option)
As soon as the actuator is switched off (motor voltage), the FO connection board of
this actuator is no longer available. As a consequence, communication with the
subsequentactuatorsislost.Topreventthis,thecompletecanbeexternallysupplied
with 24 V DC.
8
Network topologies

Information ●Communication of the following devices is monitored by channel 2.In the event
of loss of communication (i.e.no response from the next device), the shows
the following indication: Wrn FOC.
●If the actuator is the last device of the line topology, the monitoring function
should be deactivated (parameter FO cable monitoring M0709 = Off (final devi-
ce).
●Ensure proper termination for RS-485 connection of FO coupler.
3.2 Star topology
Figure 9: Structure for star topology
Max. FO cable range in km (observe technical data!)
[1] Channel 1
[2] Channel 2
[3] Any Profibus DP field device
[4] FO coupler at DCS (mandatory)
[5] FO coupler for any Profibus field device
Special features of star topology
Failure of an FO cable section or of an actuator's FO connection board has no effect
on the operability of the remaining actuators.
Information ●As all AUMA actuators are operated at the end of the FO cable section and
controlled via channel 1, the parameter FO cable monitoring M0709 should be
set to Off (final device).
●Ensure proper termination for RS-485 connection of FO coupler.
9
Network topologies

3.3 Loop topology (two-fibre loop)
Figure 10: Structure for loop topology
Max. FO cable range in km (observe technical data!)
[1] Channel 1
[2] Channel 2
[3] Integration of any Profibus DP device (option)
[4] FO coupler at DCS (mandatory)
[5] FO coupler for any Profibus field device
Special features of loop topology
●The interruption of an FO cable between two actuators is recognised by the
redundancymodules(viaparameterFO cable monitoring =On (not final device)).
Both display and the bus indicate Wrn FOC.The network is then operated as
an optical line and all actuators remain available.
●If one module fails (i.e.when the voltage supply is interrupted), only the actuator
connected to this module is disconnected from the loop, the remaining network
stays operative as a line. All other actuators remain available.
●The actuators have a redundant FO cable connection with a standard Profibus
DP interface (not redundant).
Cable routing and PLC fault evaluation
●To increase service safety, install cables for go-and-return in the loop on sepa-
rate lines.
●To achieve complete monitoring of the redundant optical loop, all FO fault signals
(including the fault output of the FO coupler) at the master must be evaluated
by the PLC controls.
Setting response and slot time
The following settings should performed at the master:
10
Network topologies

●The minimum response time of all slaves (min TSDR) has to be set to a value
of 11 bit times (basic setting) or more.In the event of continuous communication
faults, this value has to be verified.
●The Profibus slot time (TSL) must be set as to ensure that on request of the
master, the response of the slaves arrives at the master within the slot time -
even in the event of a fault in the fibre optic cable.The minimum slot time in bit
times depends on the data rate, the total length of the fibre optic cable and the
number of actuators used within the loop.
Calculation of slot time:
TSL ≥max_TSDR + LFO * tFO + nDL * tDL
TSL Slot time
max_TSDR Maximum response time of the slowest slave in bit times.In the table below, the
values of the AC 01.2 have been entered.
LFO Overall cable length of the FO cable used within the loop in km.
If bus segments start from the loop couplers, which have been extended beyond the
maximum electrical cable lengths using FO couplers or repeaters, the two longest
bus segments should be added to the FO cable length within the loop.
tFO Constant that accounts for the bit times per FO cable (refer to table)
nDL Number of actuators used within a loop
tDL Constant that accounts for the running time of an FO module in bit times (refer to
table)
max_TSDR tDL [bit times]tFO [bit times/km]Data rate [kbit/s]
2010301,500 15410500 1533.75187.5 1531.87593.75 1530.90945.45 1520.38419.2 1520.1929.6
11
Network topologies

4. Corrective action
4.1 LED indications
Figure 11: LEDs on connection board
[1] Channel 1
[2] Channel 2
FunctionColourDesignationLED
Device ready for operation (power supply available)greenPWR1 FO collective fault:Will be activated if either LED 5, 6 or LED 8
or 9 are illuminated or if the internal RS-485 connection is defec-
tive.
redERROR2
Byte with incorrect bit(s) received on RS-485redSTATUS3 Byte received on RS-485greenRX4 Optical receiving signal (channel 1) incorrect (no or insufficient
RX receive level). Both display and Profibus DP indicate: Wrn
FOC
redFail5
Is illuminated with LED 7 (green):
System reserve (channel 1) reached (critical or permissible recei-
ve level).
The display shows the following indication:Diagnostic > FO cables
> FOC level channel 1 = Level critical, no Rx or Level critical, Rx
Furthermore, boththe AUMATIC display andProfibusDPindicate:
Wrn FO cable budget
yellowLimit6
Is illuminated and LED 6 (yellow) is not illuminated:
Good RX receive level (channel 1).
Is blinking:Data is being received on RX (channel 1).
The display shows the following indication:Diagnostic > FO cables
> FOC level channel 1 = Level good, no Rx or Level good, Rx
greenLink/Act7
Optical receiving signal (channel 2) incorrect (no or insufficient
RX receive level). Both display and Profibus DP indicate: Wrn
FOC
redFail8
Is illuminated with LED 10 (green):
System reserve (channel 2) reached (critical or permissible recei-
ve level).
The display shows the following indication:Diagnostic > FO cables
> FOC level channel 2 = Level critical, no Rx or Level critical, Rx
Furthermore, boththe AUMATIC display andProfibusDPindicate:
Wrn FO cable budget
yellowLimit9
Is illuminated and LED 9 (yellow) is not illuminated:
Good RX receive level (channel 2).
Is blinking:Data is being received on RX (channel 2).
The display shows the following indication:Diagnostic > FO cables
> FOC level channel 2 = Level good, no Rx or Level good, Rx
greenLink/Act10
12
Corrective action

5. Technical data
Information The following technical data includes standard and optional features. For detailed
information on the customer-specific version, refer to the order-relevant data sheet.
This data sheet can be downloaded from the Internet at http://www.auma.com in
German and English (indication of commission number required).
5.1 FO connection board:
ST (BNC connector) or SC (Snap-in connector)FO connection For line topology: 2 x IN/OUT
For star topology: 1 x IN/OUT
For loop topology: 2 x IN/OUT
Channels (optical)
Maximum 1.5 Mbit/s
Automatic recognition of the following baud rates:
9,6KBit/s, 19,2KBit/s, 45,45KBit/s, 93,75KBit/s, 187,5KBit/s, 500KBit/s, 1,5 MBit/s
Data rate:
Half-duplexTransmission type RS-485 ↔Fiber optic cable:< 3TBit
Tx ↔Rx: 11 TBit
Propagation delay
Multi-mode 62.5 (50)/125 μm
Single-mode 9/125 μm
Fibre
For multi-mode fibre: 13 dB
For single-mode fibre: 17 dB
Optical budget
62.5/125 μm glass fibre (multi-mode):
2,500 m (FO cable damping max.2.0 dB/km, without additional damping)
Network range max.
50/125 μm glass fibre (multi-mode):
2,500 m (FO cable damping max.2.0 dB/km, without additional damping)
9/125 μm glass fibre (single-mode):
15 km (FO cable damping max.0.4 dB/km, without additional damping)
1,310 nmWave length –25 °C to +50 °COperation temperature 24 V DC/70 mA, internally supplied via power supply unit of the AUMATIC.External voltage
supply of the AUMATIC 24 V DC/500 mA possible.Only once the AUMATIC is operated on
external voltage supply will the bus remain uninterrupted in case of a loss of supply voltage.
Power supply
13
Technical data

2 LEDs for general diagnostics:
●LED PWR (green) = Device ready for operation (power supply available)
●LED ERROR (red) = Fault
2 status LEDs for the RS-485 interface:
●LED RX (green) = Byte received on RS-485
●LED STATUS (red) = Byte with incorrect bit(s) received on RS-485
3 status LEDs for each channel:
●LED FAIL (red) = No or insufficient signal on RX
●LED LIMIT (yellow) = Critical but still permissible receive level
●LED Link/Act (green) = Good RX receive level. Data is received via the RS485 channel
Indications (LEDs)
Profibus DPSuitable bus systems d-Light RS485 by eks Engel GmbH & Co. KG, www.eks-engel.de
Versions: 13-MM-ST, 13-MM-SC, 13-SM-ST, 13-SM-SC
●FO coupler for line or star topology:
-RS485/PBD-1KANAL-MM-ST-AC2 (AUMA article no.:
K007.920) / (EKS order no.: 01000 6221-FV)
-RS485/PBD-1KANAL-MM-SC-AC2 (AUMA article no.:
K007.921) / (EKS order no.: 01000 6223-FV)
-RS485/PBD-1KANAL-SM-ST-AC2 (AUMA article no.:
K007.922) / (EKS order no.: 01000 6231-L-FV)
-RS485/PBD-1KANAL-SM-SC-AC2 (AUMA article-no.:
K007.923) / (EKS order no.: 01000 6233-L-FV)
●FO coupler for loop topology:
-RS485/PBD-RING-MM-ST-AC2 (AUMA article-no.:
K007.924) / (EKS order no.: 01000 6371-FV)
-RS485/PBD-RING-MM-SC-AC2 (AUMA article no.:
K007.925) / (EKS order no.: 01000 6373-FV)
-RS485/PBD-RING-SM-ST-AC2 (AUMA article no.:
K007.926) / (EKS order no.: 01000 6381-L-FV)
-RS485/PBD-RING-SM-SC-AC2 (AUMA article no.:
K007.927) / (EKS order no.: 01000 6383-L-FV)
Required FO modules for the
master
14
Technical data

6. Appendix
6.1 Measuring methods
Figure 12: Damping measurement
6.2 Reference addresses
●Required FO module for the master:
eks Engel GmbH & Co. KG
Schützenstr. 2, 57482 Wenden-Hillmicke,
Tel.: + 49-2762 - 9313 - 60,
www.eks-engel.de
6.3 Literature
●Christoph P.Wrobel
Optische Übertragungstechnik in der Praxis
Grundlagen, Komponenten, Installation, Anwendungen
Hüthig Verlag
ISBN 3-7785-2638-3
15
Appendix

AUMA Riester GmbH & Co. KG
P.O.Box 1362
D 79373 Muellheim
Tel [phone] - 0
Fax [phone] - 1250
[email protected]
www.auma.com
Y005.170/003/en/4.12
For detailed information on AUMA products refer to the Internet: www.auma.com
