Autel MaxiTPMS TS608 User manual

COMPLETE TPMS SOLUTION IN 4 SIMPLE STEPS
TPMS WORK HAS NEVER BEEN SO EASY.
MaxiTPMS®TS608
First of all, choose the vehicle.
Note: For vehicles with Indirect TPMS, on-screen relearn procedure helps you to
reset TPMS system.
Main Menu Vehicle Make
Vehicle Mode Vehicle Year
Indirect TPMS Relearn Procedure
www.autel.com
www.maxitpms.com
TPMS QUICK GUIDE

STEP 1. Check Sensor
Check Sensor Menu
Sensor Status Sensor Activation Result
Pair the tablet with the VCI mini
by Bluetooth.
Plug VCI mini into the vehicle
OBD port.
Hold the tablet close to the tire sidewall
right above the sensor. Press Trigger to
activate the sensor.
STEP 2. TPMS Diagnose
One click for complete TPMS health diagnose: read sensor ID from ECU, check
sensor ID matching condition, read DTCs from TPMS ECU and clear DTCs.
Trigger sensors to check sensor status: sensor IDs, temperature, pressure,
battery condition.

OBD Diagnose Result
1. If the marks before the IDs are red, it indicates that the ID retrieved by activation
is inconsistent with the ID saved in the ECU. If the IDs are the same, the
marks will become green.
2. If DTCs are detected from the TPMS ECU, a yellow hazard icon displays in the
DTC column and the details button is available. If no DTC is detected, a green
“No DTC” message will display on the DTC screen.
OBD Diagnosing
TPMS Status
Click details View DTCs Description

Note: When reading sensor IDs from ECU is not supported by the vehicle,
ECU ID cannot be displayed in the TPMS diagnose status.
Click Special Function
Click Live Data
OBD Diagnosing
View Live Data
View Special Function
TPMS Status (read ECU ID
not available)
STEP 3. Sensor Programming
Four ways to program MX-Sensors: Copy by Activation, Copy by OBD, Copy by
Manual Input, Auto Create

Sensor Program Menu Click Copy by Activation
MX-Sensor Programming Program Success (MX-sensor ID is
copied from the activated sensor ID)
Sensor Program menu Click Copy by OBD
MX-Sensor Programming Program Success (MX-sensor ID is
copied from the sensor ID saved in ECU)
Copy by OBD (Copy the sensor ID read from ECU into a MX-Sensor.)
Copy by Activation (Copy the activated sensor ID into a MX-Sensor.)

Note: No Relearn is needed when the MX-Sensor ID is copied from the
original ID by Activation, OBD or Manual Input. Ensure the
new-programmed MX-Sensor has been put in the same position.
Select the sensor position Click Copy by Input
Input the original sensor ID into a
MX-Sensor (Red mark indicates
OE sensor ID location)
Click OK to program
MX-Sensor Programming Program Success
(the original sensor ID is copied
to the new MX-Sensor)
Copy by Manual Input
(Manually input the original sensor ID to program the new MX-Sensor.)

Note: When the new sensor ID is created randomly, position relearn is
necessary.
Select sensor position Click Auto Create
MX-Sensor Programming Program Success
Position Relearn Menu Check Relearn Procedure First
Auto Create
(Randomly create ID for the MX-Sensor.)
STEP 4. Position Relearn
(Three ways for Position Relearn: Stationary Relearn, Active Relearn, OBD Relearn.)

Trigger all sensors one by one
Trigger all sensors one by one
OBD II relearn processing
Drive the car according
to Relearn Procedure
Click OBD Relearn
OBD II relearn success
Keep the vehicle in relearn mode
and trigger all sensors one by one
Follow Relearn Procedure
for Stationary Relearn
Active Relearn
OBD Relearn
(When available, OBD Relearn is highly recommended to save time and energy.)
Stationary Relearn
