INSTRUCTION MANUAL
TEMPERATURE CONTROLLER
TC4 Series
※1: Thermocouple L (IC) type, RTD Cu50Ω
At room temperature (23℃±5℃): (PV ±0.5% or ±2℃, select the higher one) ±1digit
Out of room temperature range: (PV ±0.5% or ±3℃, select the higher one) ±1digit
In case of TC4SP Series, ±1℃will be added.
※2: The weight includes packaging. The weight in parentheses is for unit only.
※Environment resistance is rated at no freezing or condensation.
TC4S/SP (48 48mm) Series TC4Y (72 36mm) Series Other Series
※1: In case of the AC voltage model, SSR drive output method (standard ON/OFF control, cycle control,
phase control) is available to select.
※2: It is unavailable for TC4SP, TC4Y.
※3: Sockets for TC4SP (PG-11, PS-11(N)) are sold separately.
Ordering Information
Specications
Unit Description
Input Sensor and Temperature Range [IN-T]
Installation
Dimensions
Connections
T C 4 S 1 4 R
Item
Setting type
Digit
Size
Sub output
Power supply
Control output
NIndicator - Without control output
RRelay output+SSR drive output※1
224VAC 50/60Hz, 24-48VDC
4100-240VAC 50/60Hz
NNo alarm output
1Alarm1 output
2Alarm1 + Alarm2 output※2
SDIN W48 H48mm (terminal block type)
SP DIN W48 H48mm (11pin plug type)※3
YDIN W72 H36mm
MDIN W72 H72mm
HDIN W48 H96mm
WDIN W96 H48mm
LDIN W96 H96mm
49999 (4 Digit)
CSet by touch switch
TTemperature controller
1
3
2
6
4
1
2
3 5 4
6 7, 8
5
8
7
※
TC4 Series has selectable control output; Relay output, and SSR drive output.
AC/DC power type does not have SSRP function.
Series TC4 Series
TC4S TC4SP TC4Y TC4M TC4W TC4H TC4L
Power
supply
AC power 100-240VACᜠ50/60Hz
AC/DC Power 24VACᜠ50/60Hz, 24-48VDCᜡ
Allowable voltage range 90 to 110% of rated voltage
Power
consumption
AC power Max. 5VA (100-240VAC 50/60Hz)
AC/DC Power Max. 5VA (24VAC 50/60Hz), Max. 3W (24-48VDC)
Display method 7Segment (Red), Other display (Green, Yellow, Red LED)
Character size (W×H) 7.0×15.0mm 7.4×15.0mm 9.5×20.0mm 9.5×20.0mm 7.0×14.6mm 11.0×22.0mm
Input
type
RTD DPt100Ω, Cu50Ω (Allowable line resistance max.5Ω per a wire)
TC K (CA), J (IC), L (IC)
Display
accuracy
※1
RTD At room temperature (23℃±5℃): (PV ±0.5% or ±1℃, select the higher one) ±1digit
Out of room temperature range: (PV ±0.5% or ±2℃, select the higher one) ±1digit
※For TC4SP, add ±1℃ by accuracy standard. TC
Control
output
Relay 250VACᜠ3A 1a
SSR 12VDCᜡ± 2V 20mA Max.
Alarm output AL1, AL2 Relay: 250VACᜠ1A 1a (※TC4SP, TC4Y have AL1 only.)
Control method ON/OFF and P, PI, PD, PID control
Hysteresis 1 to100℃/℉(0.1 to 50.0℃/℉) variable
Proportional band (P) 0.1 to 999.9℃/℉
Integral time (I) 0 to 9999 sec.
Derivative time (D) 0 to 9999 sec.
Control period (T) 0.5 to 120.0 sec.
Manual reset 0.0 to 100.0%
Sampling period 100ms
Dielectric
strength
AC power 2,000VAC 50/60Hz for 1min. (between input terminal and power terminal)
AC/DC Power 1,000VAC 50/60Hz for 1min. (between input terminal and power terminal)
Vibration 0.75mm amplitude at frequency of 5 to 55Hz in each X, Y, Z direction for 2 hours
Relay
life cycle
Mechanical OUT: Min. 5,000,000 operations, AL1/2: Min. 5,000,000 operations
Electrical OUT: Min. 200,000 operations (250VAC 3A resistive load),
AL1/2: Min. 300,000 operations (250VAC 1A resistive load)
Insulation resistance Min. 100MΩ (at 500VDC megger)
Noise immunity Square-wave noise by noise simulator (pulse width 1㎲) ± 2KV R-phase and S-phase
Memory retention Approx. 10 years (When using non-volatile semiconductor memory type)
Environ
-ment
Ambient temp. -10 to 50℃, Storage: -20 to 60℃
Ambient humi. 35 to 85%RH, Storage: 35 to 85%RH
Insulation type Double insulation or reinforced insulation (mark: , Dielectric strength between the
measuring input part and the power part: AC power 2kV, AC/DC Power 1kV)
Approval
Weight
※2
Approx. 141g
(approx. 94g)
Approx. 123g
(approx. 76g)
Approx. 174g
(approx. 85g)
Approx. 204g
(approx. 133g)
Approx. 194g
(approx. 122g)
Approx. 194g
(approx. 122g)
Approx. 254g
(approx. 155g)
1. Present temperature (PV) display
RUN mode: Present temperature (PV) display.
Parameter setting mode: Parameter or
parameter setting valuedisplay.
2. Deviation indicator, Auto-tuning indicator
It shows current temperature (PV) deviation
based on set temperature (SV) by LED.
The deviation indicators ( , , ) flash by
every 1 sec. when operating auto tuning.
3. Set temperature (SV) indicator
Press any front key once to check or change
current set temperature (SV), the set
temperature (SV) indicator is ON and preset set
value is flashed.
4. Temperature unit (℃/℉) indicator
It shows current temperature unit.
5. Control/alarm output indicator
OUT: It will turn ON when control output (Main Control
Output) is ON.
※
In case of CYCLE/PHASE control of SSR drive
output, it will turn ON when MV is over 3.0%.
(only for AC power type)
AL1/AL2: It will light up when alarm output Alarm1/
Alarm2 are on.
6. key
Used when entering into parameter group, returning
to RUN mode, moving parameter, and saving setting
values.
7. Adjustment
Used when entering into set value change mode, digit
moving and digit up/down.
8. FUNCTION key
Press + keys for 3 sec. to operate function (RUN/
STOP, alarm output cancel, auto-tunning) set in inner
parameter [DI-K].
※
Press + keys at the same time in set value
operation to move digit.
No. PV deviation temp. Deviation display
1 Over 2℃indicator ON
2 Below ±2℃indicator ON
3 Under -2℃indicator ON
Input sensor Display Temperature range (℃) Temperature range (℉)
Thermocouple
K (CA) KCA -50 to 1200 -58 to 2192
J (IC) JIC -30 to 500 -22 to 932
L (IC) LIC -40 to 800 -40 to 1472
RTD
DPt100Ω DPtH -100 to 400 -148 to 752
DPtL -100.0 to 400.0 -148.0 to 752.0
Cu50Ω CUsH -50 to 200 -58 to 392
CUsL -50.0 to 200.0 -58.0 to 392.0
※
Mount the product on the panel, fasten bracket by pushing with tools as shown above.
(In case of TC4Y, fasten bolts for bracket.)
TC4S Series
RSA-COVER (48×48mm) RMA-COVER (72×72mm)
RHA-COVER
(48×96mm, 96×48mm )
RLA-COVER (96×96mm )
TC4SP Series
TC4Y Series
TC4M Series
Bracket
TC4L SeriesTC4H Series
TC4W Series
Terminal cover (sold separately)
Panel cut-out
Size
Model
A B C D
TC4S Min. 65 Min. 65 45+0.6
0 45+0.6 0
TC4SP Min. 65 Min. 65 45+0.6
0 45+0.6 0
TC4Y Min. 91 Min. 40 68+0.7
0 31.5+0.5 0
TC4M Min. 90 Min. 90 68+0.7
0 68+0.7 0
TC4H Min. 65 Min. 115 45+0.6
0 92+0.8 0
TC4W Min. 115 Min. 65 92+0.8
0 45+0.6 0
TC4L Min. 115 Min. 115 92+0.8
0 92+0.8 0
TC4S/TC4SP Series TC4Y Series
TC4M, TC4W, TC4H, TC4L Series
48
45
64.56 48 58.5 45
72.2
6
64.5
67.5
72 6
30
60
104.4
3.5 10
12
46
23.9
12
37.5
40.5 3.34
A
C
D
B
48
44.7
64.596 6
91.5
64.5696
96
91.5
48 64.56
70
68.5
3
64
13
91.5
86
4
13
47.2
91.5
86
3
13
94
72 77
84
7
36 30
TC4S Series
TC4Y Series
TC4M Series
TC4SP Series
TC4H, TC4W, TC4L Series
※1: AC power: 100-240VAC 5VA 50/60Hz
AC/DC power: 24VAC 5VA 50/60Hz
24-48VDC 3W
AL1 OUT:
250VAC 1A 1a
SSR OUT:
12VDC ±2V
20mA Max
SOURCE
100-240VAC 5VA 50/60Hz
24VAC 5VA 50/60Hz
24-48VDC 3W
-
+
B'
※1
B
A
RTD
SENSOR
TC
-
+
AL2 OUT:
250VAC 1A 1a
Relay OUT:
250VAC 3A 1a
1 7
2 8
3 9
4 10
511
6 12
AL1 OUT:
250VAC 1A 1a
SSR OUT:
12VDC ±2V
20mA Max
SOURCE
100-240VAC 5VA 50/60Hz
24VAC 5VA 50/60Hz
24-48VDC 3W
※1
-
+
-
+
AL2 OUT:
250VAC 1A 1a
Relay OUT:
250VAC 3A 1a
B'
B
A
RTD
SENSOR
TC
1
10
13
22
2
11
14
23
3
12
15
24
4 16
5 17
6 18
7 19
8 20
9 21
AL1 OUT:
250VAC 1A 1a
SSR OUT:
12VDC ±2V
20mA Max
SOURCE
100-240VAC 5VA 50/60Hz
24VAC 5VA 50/60Hz
24-48VDC 3W
B'
※1
BA
- +
SENSOR
TC
RTD
Relay OUT:
250VAC 3A 1a
1 2 3 4 5 6 7 8 9 10 11
● SSRP function is selectable one of standard ON/OFF control, cycle control, phase control by utilizing
standard SSR drive output.
● Realizing high accuracy and cost effective temperature control as linear output(cycle control and
phase control).
● Select one of standard ON/OFF control [STND], cycle control [CYCL] , phase control [PHAS] at [SSrM]
parameter of Parameter group 2. For cycle control, connect zero cross turn-on SSR or random
turn-on SSR. For phase control, connect random turn-on SSR.
SSR Drive Output Selection Function (SSRP Function)[SSrM]
※
When selecting cycle or phase control mode, the power supply for a load and a temperature
controller must be the same.
※
In case of selecting cycle [CYCL] or phase [PHAS] control mode for PID control, control cycle [T] is
not allowed to set.
※
For AC/DC power model (TC4 - 2R), this parameter [SSrM] is not displayed and it is available only
standard control by relay or SSR.
1)Standard ON/OFF control [STND]
A mode to control the load in the
same way as Relay output type.
(ON: output level 100%,
OFF: output level 0%)
2)Cycle control [CYCL]
A mode to control the load by
repeating output ON / OFF
according to the rate of output
within setting cycle.
Having improved ON / OFF noise
feature by Zero Cross type.
3)Phase control [PHAS]
A mode to control the load by
controlling the phase within
AC half cycle. Serial control is
available.
Random turn-on SSR must be
used for this mode.
50Cycle 50Cycle
50% 80%
AC
OUT
ON ONOFF OFF
AC
OUT
10% 50%
AC
OUT
SSR voltage output
(12VDC) Load
Power
100-240VAC
50/60Hz
Temperature controller
(TC4Series) SSR module
※ The above specications are subject to change and some models may be discontinued
without notice.
※
Be sure to follow cautions written in the instruction manual and the technical descriptions
(catalog, homepage).
Thank you for choosing our Autonics product.
Please read the following safety considerations before use.
Safety Considerations
※Please observe all safety considerations for safe and proper product operation to avoid hazards.
※Safety considerations are categorized as follows.
Warning Failure to follow these instructions may result in serious injury or death.
Caution
Failure to follow these instructions may result in personal injury or product damage.
※The symbols used on the product and instruction manual represent the following
symbol represents caution due to special circumstances in which hazards may occur.
31
55
56
20
15
21
5
45
16
48.6
44.9
36
48.4
9.8
41.5
18 22
22.5
1. Fail-safe device must be installed when using the unit with machinery that may cause serious injury
or substantial economic loss. (e.g. nuclear power control, medical equipment, ships, vehicles,
railways, aircraft, combustion apparatus, safety equipment, crime/disaster prevention devices, etc.)
Failure to follow this instruction may result in re, personal injury, or economic loss.
2. Install on a device panel to use.
Failure to follow this instruction may result in electric shock or re.
3. Do not connect, repair, or inspect the unit while connected to a power source.
Failure to follow this instruction may result in electric shock or re.
4. Check 'Connections' before wiring.
Failure to follow this instruction may result in re.
5. Do not disassemble or modify the unit.
Failure to follow this instruction may result in electric shock or re.
1. When connecting the power input and relay output, use AWG 20(0.50mm2) cable or over and tighten
the terminal screw with a tightening torque of 0.74~0.90N.m.
When connecting the sensor input and communication cable without dedicated cable, use AWG
28~16 cable and tighten the terminal screw with a tightening torque of 0.74~0.90N.m.
Failure to follow this instruction may result in re or malfunction due to contact failure.
2. Use the unit within the rated specications.
Failure to follow this instruction may result in re or product damage.
3. Use dry cloth to clean the unit, and do not use water or organic solvent.
Failure to follow this instruction may result in electric shock or re.
4. Do not use the unit in the place where ammable/explosive/corrosive gas, humidity, direct sunlight,
radiant heat, vibration, impact, or salinity may be present.
Failure to follow this instruction may result in re or explosion.
5. Keep metal chip, dust, and wire residue from owing into the unit.
Failure to follow this instruction may result in re or product damage.
SSR OUT:
12VDC ±2V
20mA Max
SOURCE
100-240VAC 5VA 50/60Hz
24VAC 5VA 50/60Hz
24-48VDC 3W
B'
※1
B
A
RTD
SENSOR
TC
-
+-
+
-
+
Relay OUT
250VAC 3A 1a
1
2
3
4
5
6
7
8
9
10
11
AL1 OUT:
250VAC 1A 1a
SSR OUT:
12VDC ±2V
20mA Max
SOURCE
100-240VAC 5VA 50/60Hz
24VAC 5VA 50/60Hz
24-48VDC 3W
-
+
B'
B
A
RTD
SENSOR
TC
AL1 OUT:
250VAC 1A 1a
AL2 OUT:
250VAC 1A 1a
Relay OUT:
250VAC 3A 1a
1 10
211
3 12
4 13
5 14
6 15
7 16
8 17
9 18
DRW170775AA
(unit: mm)
<Crimp terminal>
a
b
c
Terminal number a b c
1 to N 6 Max. 1.9 Max. 4.0
(unit: mm)
※Use crimp terminals or teminals of size specied below.
ab
<Round>
ab
<Forked>
a Min. 3.0mm Min. 3.0mm
b Max.5.8mm Max.5.8mm
Warning
Caution

Parameter Groups
● Parameter Group 1
● Parameter Group 2 Alarm [
AL-1/ AL-2
] Input Correction [IN-B]
Input Digital Filter [MAvF]
Hysteresis [HYS]
Manual Reset [REST]
Digital Input Key ( + 3sec.) [ DI-K]
Control Output MV When Input Sensor Line Is Broken [ErMV]
Parameter Lock [LOC]
Error
Cautions during Use
Controller itself does not have errors but there may be error by external input temperature sensor. This function
is for correcting this error.
E.g.) If actual temperature is 80℃but controller displays 78℃, set input correction value [IN-B] as '002' and
controller displays 80℃.
※As the result of input correction, if current temperature value (PV) is over each temperature range of input
sensor, it displays 'HHHH' or 'LLLL'.
If current temperature (PV) is uctuating repeatedly by rapid change of input signal, it re ects to MV and stable
control is impossible. Therefore, digital lter function stabilizes current temperature value.
For example, set input digital lter value as 0.4 sec, and it applies digital lter to input values during 0.4 sec and
displays this values. Current temperature may be different by actual input value.
The function to set control output MV in case of open error. Users are able to set by ON/OFF setting or MV
setting. It executes control output by set MV regardless of ON/OFF or PID control output.
●If Hysteresis is too narrow, hunting (oscillation,
chattering) could occur due to external noise.
●In case of ON / OFF control mode, even if PV reaches
stable status, there still occurs hunting. It could be due
to Hysteresis [HYS] SV, load’s response characteristics
or sensor’s location. In order to reduce hunting to a
minimum, it is required to take into following factors
consideration when designing temp. controlling;
proper Hysteresis [HYS], heater’s capacity, thermal
characteristics, sensor’s response and location.
When selecting P/PD control mode, certain temperature difference
exists even after PV reaches stable status because heater's rising
and falling time is inconsistent due to thermal characteristics of
controlled objects, such as heat capacity, heater capacity. This
temperature difference is called offset and manual reset [REST]
function is to set/correct offset.
When PV and SV are equal, reset value is 50.0%. After control
is stable, PV is lower than SV, reset value is over 50.0% or PV is
higher than SV, reset value is below 50.0%.
Set below 50.0 as reset value
Set over 50.0 as reset value
Offset
Offset
SV
●Manual reset [REST] by control result
Heating operation
Hysteresis
[HYS]
ON OFF
SV
Control
output
Temp.
AM!A
Alarm
operation Alarm option
3)Sensor break alarm
The function that alarm output will be ON when sensor is not connected or when sensor's disconnection is
detected during temperature controlling. You can check whether the sensor is connected with buzzer or other
units using alarm output contact. It is selectable between standard alarm [SBaA] or alarm latch [SBaB].
4)Loop break alarm (LBA)
It checks control loop and outputs alarm by temperature change of the subject. For heating control (cooling
control), when control output MV is 100% (0% for cooling control) and PV is not increased over than LBA
detection band [LBaB] during LBA monitoring time [LBaT], or when control output MV is 0% (100% for cooling
control) and PV is not decreased below than LBA detection band
[LBaB] during LBA monitoring time [LBaT], alarm output turns ON.
Start control
to
When control output MV is 100%, PV is increased over than LBA detection band [LBaB] during
LBA monitoring time [LBaT].
to The status of changing control output MV (LBA monitoring time is reset.)
to When control output MV is 0% and PV is not decreased below than LBA detection band [LBaB]
during LBA monitoring time [LBaT], loop break alarm (LBA) turns ON after LBA monitoring time.
to Control output MV is 0% and loop break alarm (LBA) turns and maintains ON.
to The status of changing control output MV (LBA monitoring time is reset.)
to When control output MV is 100% and PV is not increased over than LBA detection band [LBaB]
during LBA monitoring time [LBaT], loop break alarm (LBA) turns ON after LBA monitoring time.
to When control output MV is 100% and PV is increased over than LBA detection band [LBaB]
during LBA monitoring time [LBaT], loop break alarm (LBA) turns OFF after LBA monitoring time.
to The status of changing control output MV (LBA monitoring time is reset.)
2)Alarm opetion
Option Name Description
ㅁㅁㅁㅁㅁㅁAM .A Standard
alarm
If it is an alarm condition, alarm output is ON. If it is a clear alarm condition, alarm output
is OFF.
AM ㅁ.ㅁㅁㅁㅁㅁㅁㅁㅁㅁㅁB Alarm latch If it is an alarm condition, alarm output is ON and maintains ON status.
(Alarm output HOLD)
AM .C Standby
sequence 1
First alarm condition is ignored and from second alarm condition, standard alarm
operates. When power is supplied and it is an alarm condition, this rst alarm condition
is ignored and from the second alarm condition, standard alarm operates.
AM .D
Alarm latch
and standby
sequence 1
If it is an alarm condition, it operates both alarm latch and standby sequence. When
power is supplied and it is an alarm condition, this rst alarm condition is ignored and
from the second alarm condition, alarm latch operates.
AM .E Standby
sequence 2
First alarm condition is ignored and from second alarm condition, standard alarm
operates. When re-applied standby sequence and if it is alarm condition, alarm output
does not turn ON. After clearing alarm condition, standard alarm operates.
AM .F
Alarm latch
and standby
sequence 2
Basic operation is same as alarm latch and standby sequence1. It operates not only by
power ON/OFF, but also alarm setting value, or alarm option changing. When re-applied
standby sequence and if it is alarm condition, alarm output does not turn ON. After
clearing alarm condition, alarm latch operates.
1)Alarm operation
When executing auto-tuning, LBA detection band[LBaB] and LBA monitoring time are automatically set based
on auto tuning value. When alarm operation mode [AL-1, AL-2] is set as loop break alarm (LBA)[LBa ], LBA
detection band [LBaB] and LBA monitoring time [LBaT] parameter is displayed.
Condition of re-applied standby sequence for standby sequence 1, alarm latch and standby sequence 1: Power ON
Condition of re-applied standby sequence for standby sequence 2, alarm latch and standby sequence 2: Power ON,
changing set temperature, alarm temperature [AL1, AL2] or alarm operation [AL-1,AL-2], switching STOP mode
to RUN mode.
Mode Name Alarm operation Description
AM)_
- - No alarm output
AM!
Deviation
high-limit
alarm
SV
100℃
PV
110℃
OFF ONH
PV
90℃
SV
100℃
OFF ONHIf deviation between PV and SV
as high-limit is higher than set
value of deviation temperature,
the alarm output will be ON.
High deviation: Set as 10℃High deviation: Set as -10℃
AM@
Deviation
low-limit
alarm
PV
90℃
SV
100℃
OFFON H
SV
100℃
PV
110℃
OFFON HIf deviation between PV and SV
as low-limit is higher than set
value of deviation temperature,
the alarm output will be ON.
Lower deviation: Set as
10℃
Lower deviation: Set as
-10℃
AM#
Deviation
high/low-
limit
alarm
PV
90℃
PV
110℃
SV
100℃
OFFON ONH H If deviation between PV and SV
as high/low-limit is higher than set
value of deviation temperature,
the alarm output will be ON.
High/Lower deviation: Set as 10℃
AM$
Deviation
high/low-
limit
reserve
alarm
If deviation between PV and SV
as high/low-limit is higher than set
value of deviation temperature,
the alarm output will be OFF.
PV
90℃
PV
110℃
SV
100℃
OFF OFFONH H
High/Lower deviation: Set as 10℃
AM%
Absolute
value high
limit alarm
PV
90℃
SV
100℃
OFF ONH
SV
100℃
PV
110℃
OFF ONH
If PV is higher than the absolute
value, the output will be ON.
Absolute-value Alarm:
Set as 90℃
Absolute-value Alarm:
Set as 110℃
AM^
Absolute
value low
limit alarm
PV
90℃
SV
100℃
OFFON H
SV
100℃
PV
110℃
OFFON H
If PV is lower than the absolute
value, the output will be ON.
Absolute-value Alarm:
Set as 90℃Absolute-value Alarm: Set as 110℃
SBa Sensor
break alarm
-
It will be ON when it detects
sensor disconnection.
LBa Loop break
alarm
-
It will be ON when it detects loop
break.
※H: Alarm output hysteresis[AHYS]
Setting range: Deviation alarm (-[F.S] to [F.S],
Absolute value alarm (temperature range)
※In case alarm operation mode [AL-1, AL-2], AM)_/SBa
/ LBa of Parameter group 2 is set to [AL-1, AL-2], no
parameters is displayed.
Setting range: 0.1 to 999.9℃/℉
ON/OFFcontrol
hysteresis
Manual reset
Derivation time
Integral time
Proportional band
Auto-tuning
※1
AL1 alarm temperature
AL2 alarm temperature
Setting range: 0 to 9999 sec.
※Integral operation will be OFF when set value is "0".
Setting range: 0 to 9999 sec.
※Derivative operation will be OFF when set value is "0".
Setting range: 0.0 to 100.0%
※It is displayed in P/PD control.
Setting range: 1 to 100℃/℉ (For DPtL/CUsL: 0.1 to 50.0℃/℉)
※
It is displayed when control type parameter [C-MD] of Parameter
group 2 is set ONOF.
※
It starts to operate auto-tuning when it is ON and
set as OFF automatically after finish the operation.
※
Deviation indicators (▲, , ▼) flash (cycle:1
sec.) during auto tuning function.
AL1
AL2
AT
P
I
PAR1
D
REST
ONOFF
01)0
0000
0000
05)0
002
HYS
3 sec.
2 sec.
Run mode
※2
※3
1250
1250
※
AC/DC power type has no SSR drive output method [SSrM] and
supports only ON/OFF output when selecting SSR in control output
[OUT].
Parameter Factory default Parameter Factory default
IN-T ㅁKCA T 02)0
UNIT ?C AL-1 AM!A
IN-B 0000
MAvF 00)1 AL-2 AM@A
L-SV -050 AHYS 0001
H-SV 1200 LBaT 0000
O-FT HEAT LBaB 002
C-MD PID DI-K STOP
OUT RLY ErMV 00)0
SSrM STND LOC OFF
● SV setting
● Parameter Group 1
● Parameter Group 2
Parameter Factory default
-
0
Parameter Factory default
AL1 1250
AL2
AT OFF
P 01)0
I0000
D
REST 05)0
HYS 002
Factory Default
Display Description
OFF Unlock
LOC1 Lock parameter group 2
LOC2 Lock parameter group 1, 2
LOC3 Lock parameter group 1, 2, SV setting
A function to prevent changing SV and parameters of
each setting group. Parameter setting values are still
possible to check when parameter lock is set.
※OFF, LOC1 are available only for indicator (TC4 -N N).
Display Description Troubleshooting
OPEN Flashes if input sensor is disconnected or sensor
is not connected. Check input sensor state.
HHHH Flashes if measured sensor input is higher than
temperature range. When input is within the rated temperature
range, this display disappears.
LLLL Flashes if measured sensor input is lower than
temperature range.
Major Products
Press any key among
, , , .
※1: It is not displayed for AC/DC power model (TC4 - 2R).
※
If no key entered for 30 sec., it returns to RUN mode
automatically and the set value of parameter is not be saved.
※This parameter might not be displayed depending on
other parameter settings.
SV setting Parameter group 1[PAR1] Parameter group 2[PAR2]
4sec. 2sec.
3sec.
3sec.
②①
④
③
⑤
RUN mode
AL1
AL2
AT
Pㅁㅁ
I
D
REST
HYS
AL1 alarm temperature
AL2 alarm temperature
Auto tuning
Proportional band
Integral time
Derivative time
Manual reset (Normal
deviation correction)
ON/OFFcontrol hysteresis
IN-Tㅁㅁ
UNITㅁㅁ
IN-Bㅁㅁ
MAvFㅁㅁ
L-SV
H-SV
O-FTㅁㅁ
C-MD
OUTㅁㅁ
SSrMㅁㅁ
T
AL-1ㅁㅁ
AL-2ㅁㅁ
AHYSㅁㅁ
LBaTㅁㅁ
LBaBㅁㅁ
DI-Kㅁㅁ
ErMVㅁㅁ
LOCㅁㅁ
Input type
Temperature unit
Input correction
Input digital lter
SV low-limit value
SV high-limit value
Control output operation
Control type
Control output
SSR drive output method※1
Control cycle
AL1 alarm operation mode
AL2 alarm operation mode
Alarm output hysteresis
LBA monitoring time
LBA detection range
Digital input key
Control output MV in case
of input break error
Parameter lock
①
Press any key once in RUN mode, it advances to set value
setting group.
②
Press key over 2sec. in RUN mode, it advances to
parameter group 1.
③
Press key over 4sec. in RUN mode, it advances to
Parameter group 2.
④
First parameter will be displayed on viewer when it
advances to the setting group.
⑤
Press key over 3sec. in the setting group, it returns
to RUN mode.
※
Exception: Press key once in SV setting group it
returns to RUN mode.
※
Press key again within a sec after return to RUN mode by press key over 3sec., it
advances to the first parameter of previous setting group.
※Parameter setup Parameter group 2 → Parameter group 1 → SV setting
• Set parameter as the above considering parameter relation of each setting group.
• Check parameter set value after change parameter of Parameter group 2.
※Indicator model (TC4 -N N)displays shaded parameter ( ) of Parameter group 2.
※
AL-1,AL-2 parameters of Parameter group 2 is decided whether to display according by alarm output type.
※
If alarm operation mode[AL-1,AL-2] of Parameter group 2 is set to AM)_/SBa /LBa , AHYS
parameter is not displayed.
● Flow Chart For SV Setting Group
Change set value
by , , keys.
Press any key among , , , .
①RUN mode (display current temperature)
②Set value change mode
③Finish the setup.
④Check SV
※In case of changing set temperature from 210℃to 250℃
※1: S: Press any key among , , .
※2: After checking/changing set value at each parameter, and press
key, set value flashes twice and it moves to next parameter
automatically.
※3: It is displayed when control type parameter [C-MD] of parameter
group 2 is set PID.
※Press key for 3 sec. to return RUN mode at any parameter.
※This parameter might not be displayed depending on other
parameter settings.
※1: S: Press any key among , , .
※2: After checking/changing set value at each parameter, and press
key, set value flashes twice and it moves to next parameter
automatically.
※Press key for 3 sec. to return RUN mode at any parameter.
※This parameter might not be displayed depending on other
parameter settings.
Parameter lock
Control output MV in case
of input break error
Digital input key
LBA detection band
LBA monitoring time
Alarm output hysteresis
AL2 alarm operation
AL1 alarm operation
Control cycle
※Alarm operation mode ※Alarm option
SSR drive
output method
Control output
Control type
Control output operation
SV low-limit value
SV high-limit value
Input digital lter
Input correction
Temperature unit
Input type
3 sec.
4 sec.
Run mode
※
Front temperature unit indicator will flash when
selecting the unit.
※
When changing temperature unit, SV, IN-B, H-SV,
L-SV, AL1, AL2, LBaT, LBaB, AHYS parameters
are initialized.
※
When changing input type, SV, IN-B, H-SV, L-SV, AL1, AL2, LBaT,
LBaB, AHYS parameters are initialized.
Setting range: -999 to 999 (DPtL / CUsL: -199.9 to 999.9)
※Operates only selected output between Relay or SSR.
※
When changing control output operation, ErMU is
initialized.
※When changing control type, ErMU is initialized
(control output MV is below 100%) and DI-K turns
OFF automatically.
※Same with the above [AL-1].
※
When changing alarm operation AL1, AL2, alarm temperature of
AL1, AL2 is initialized.
※
Press key to
convert alarm
operation mode
into alarm option.
Setting range: 0.1 to 120.0 sec.
※
Set input digital filter time for average input value affected control,
and display value.
Setting range: Within the rated temperature
range by input sensor [L-SV ≤ ( H-SV-1digit)]
When changing SV low-limit value,
if SV < L-SV, SV is initialized as L-SV.
Setting range: Within the rated temperature
range by input sensor [H-SV ≥ ( L-SV+1digit)]
When changing SV high-limit value,
if SV > H-SV, SV is initialized as H-SV.
Setting range:0.5 to 120.0 sec.
※
If control output [OUT] is set as RLY, factory default is 20.0 sec, or
set as SSR, factory default is 2.0 sec.
※
This Twill not be displayed when SSR drive output method [SSrM]
is set as CYCL, PHAS.
Setting range: 1 to 100℃/℉ (DPtL/CYsL: 0.1 to 50.0℃)
※
If alarm operation mode [AL-1,AL-2] is set to AM)_, SBa ,
LBA , AHYS parameter is not displayed.
Setting range: 0 to 9999sec. (Automatically setting with Auto-tunning)
※
LBaT parameter is displayed when alarm operation mode [AL-1,
AL-2] is set as LBA .
Setting range: 0.0 to 100.0%
※
0.0/100.0% is displayed when control type parameter [C-MD] is
set ONOF.
※
When changing PID control to ON/OFF control, if MV is below
100.0%, it is initialized as 0.0%. ※
For indicator model
(TC4 -N N), only OFF,
LOC1 are available.
※
AlRE is not displayed for not alarm output model.
※
AT is not displayed when control type parameter [C-MD] is set ONOF.
Setting range: 0 to 999℃/℉ (DPtL/ CUs: 0.0 to 999.9℃/℉)
(Automatically setting with Auto-tunning)
※
When alarm operation mode [AL-1, AL-2] is set as loop break
alarm (LBA) [LBA ], and LBaT parameter does not set as 0,
LBaB parameter is displayed.
※
It is displayed when selecting control
output [OUT] as SSR. For AC/
DC power type (TC4 - 2R), this
parameter [SSrM] is not displayed.
PAR2
IN-T
UNIT
IN-Bㅁㅁ
MAvF
L-SV
H-SV
O-FT
C-MD
OUT
SSrM
T
AL-1
AL-2
AHYS
LBaT
LBaB
DI-K
ErMV
LOC
LBaA AM!Aㅁ AM!B
?F?C
000
)1
-050
1200
HEAT
PID
RLY
STND
02)0
AM!A
AM@A
001
0
002
00)0
SSR
ONOF
COOL
CYCL PHAS
※2
※1
KCA JIC LIC DPtH DPtL CU%H CU%L
STOP AlRE ATOFF
LOC1 LOC2 LOC3
OFF
Ti
me
※In case of [IN-T]
input sensor type,
low/high-limit setting
temperature (SV) is
also set as max./min.
temperature range of
input sensor.
Set both alarm operation and alarm option by combining.
Each alarm operates individually in two alarm output models.
When the current temperature is out of alarm range, alarm
clears automatically. If alarm option is alarm latch or alarm latch
and standby sequence 1/2, press digital input key( + 3 sec.,
digital input key[DI-K] of Parameter group 2 set as AlRE), or
turn OFF the power and turn ON to clear alarm.
Parameter Operation
OFF OFF It does not use digital input key function.
RUN/STOP STOP
Pauses control output. Auxiliary output (except loop break alarm, sensor break alarm)
except Control output operates as setting. Hold the digital input keys for 3 sec. to restart.
RUN RUN
t t tt
STOP STOP RUN
Digital input key
(t: over 3 sec.)
Clear alarm AlRE
Clears alarm output by force.
(only when alarm option is alarm latch, or alarm latch and standby sequence 1/2 .)
This function is applied when present value is out of alarm operation range but alarm
output is ON. Alarm operates normally right after clearing alarm.
Auto-tuning AT
Starts/Stops auto-tuning. This function is same as auto-tuning[AT] of parameter group 1.
(You can start auto-tuning [AT] of parameter group 1 and stop it by digital input key.)
※
This parameter AT appears only when control method [C-MD] Parameter group 2
is set as PID. When control method [C-MD] Parameter group 2 is set as ONOF, this
parameter is changed as OFF.
Reset all parameters as factory default. Hold the front ++ keys for 5 sec., to enter parameter reset [INIT]
parameter. Select 'YES' and all parameters are reset as factory default. Select ‘NO’ and previous settings are
maintained. If setting parameter lock [LOC] or processing auto-tuning, parameter reset is unavailable.
● Parameter Reset
http://www.autonics.com
HEADQUARTERS:
18, Bansong-ro 513beon-gil, Haeundae-gu, Busan,
South Korea, 48002
TEL: [phone]
E-mail: [email protected]
DRW170775A A
Photoelectric Sensors Temperature Controllers
Fiber Optic Sensors Temperature/Humidity Transducers
Door Sensors SSRs/Power Controllers
Door Side Sensors Counters
Area Sensors Timers
Proximity Sensors Panel Meters
Pressure Sensors Tachometer/Pulse (Rate) Meters
Rotary Encoders Display Units
Connector/Sockets Sensor Controllers
Switching Mode Power Supplies
Control Switches/Lamps/Buzzers
I/O Terminal Blocks & Cables
Stepper Motors/Drivers/Motion Controllers
Graphic/Logic Panels
Field Network Devices
Laser Marking System (Fiber, Co₂, Nd: YAG)
Laser Welding/Cutting System
1. Follow instructions in 'Cautions during Use'. Otherwise, It may cause unexpected accidents.
2. Check the polarity of the terminals before wiring the temperature sensor.
For RTD temperature sensor, wire it as 3-wire type, using cables in same thickness and length.
For thermocouple (CT) temperature sensor, use the designated compensation wire for extending wire.
3. Keep away from high voltage lines or power lines to prevent inductive noise.
In case installing power line and input signal line closely, use line lter or varistor at power line and shielded
wire at input signal line.
Do not use near the equipment which generates strong magnetic force or high frequency noise.
4. Install a power switch or circuit breaker in the easily accessible place for supplying or disconnecting the power.
5. Do not use the unit for other purpose (e.g. voltmeter, ammeter), but temperature controller.
6. When changing the input sensor, turn off the power rst before changing.
After changing the input sensor, modify the value of the corresponding parameter.
7. 24VAC, 24-48VDC power supply should be insulated and limited voltage/current or Class 2, SELV power
supply device.
8. Make a required space around the unit for radiation of heat.
For accurate temperature measurement, warm up the unit over 20 min after turning on the power.
9. Make sure that power supply voltage reaches to the rated voltage within 2 sec after supplying power.
10. Do not wire to terminals which are not used.
11. This unit may be used in the following environments.
①Indoors (in the environment condition rated in 'Specications') ②Altitude max. 2,000m
③Pollution degree 2 ④Installation category II
