Aventics MSC Series Installation instructions

Aventics S.a.r.l. | AVTS/MKT5/F.Ö | cad_re-ass_msc-sh-2_r01.docx
1(4)
CAD Re-assembly instructions
for our neutral CAD file formats
Product: Guide cylinders, Series MSC
Parts assembled: 2 (5)
Consists of following parts: 6 pcs
Parts assembled: 2 (5)
All manuals and user guides at all-guides.com

Aventics S.a.r.l. | AVTS/MKT5/F.Ö | cad_re-ass_msc-sh-2_r01.docx
2(4)
Mate instructions, step by step for easy handling
Constraint 2(3) : Insert
Constraint 3(3) : Mate
Constraint 1(3): Insert
Constraint 2(3): Insert
Constraint 3(3): Align (1.9mm)
Constraint 2(2): Mate
Constraint 1(2): Insert
1 - Assemble A & B part. Parts assembled: 2 (6)
2 - Assemble C part. Parts assembled: 3 (6)
All manuals and user guides at all-guides.com

Aventics S.a.r.l. | AVTS/MKT5/F.Ö | cad_re-ass_msc-sh-2_r01.docx
3(4)
Mate instructions, step by step for easy handling
1. Assemble C part.
No of parts assembled: 4 (5)
Constraint 1(2): Insert
Constraint 2(2): Mate
3 - Assemble D part. Parts assembled: 4 (6)
Constraint 1(2): Insert
Constraint 2(2): Mate
4 - Assemble 1st Stopper part. Parts assembled: 5 (6)
All manuals and user guides at all-guides.com

Aventics S.a.r.l. | AVTS/MKT5/F.Ö | cad_re-ass_msc-sh-2_r01.docx
4(4)
Constraint 1(2): Insert
Constraint 2(2): Mate
5 - Assemble 2nd Stopper part. Parts assembled: 6 (6)
