AVLink HX-RUW2 User manual

HDMI
EXTENDER
HX-RUW2
(Remote)
USER MANUAL V1.0
HX-RUW2
Packa e Contents-
 1x HX-RUW2 Remote Unit
 1 user manual
 1x Power adapter DC 12V with lock
 1x R Blaster Cable
 1x R Receiver Cable
 2x screws
 4x foot pads
Any thing missed, please contact with your vendor.
-1-
Features
 Through the HDM Extender, you can use one source
device (HDBaseT output port) to display.
 Extension of HDM signal up to 100/70 meter on
HDTV
 HDCP Compliant
 Supports 3D pass-through
 Supports all frequency band R control
 One CAT.5e/ CAT.6 cable extension
 Supports resolution up to 4Kx2K
 HDBaseT technology
 Use CAT.5e/ CAT.6 cable to install easily
Specifications
Function HX-RUW2
HDM Out Connector HDM A-Type Female x 1
RJ-45 Connector 1
R N 3.5ψ Stereo Jack x 1
R OUT 3.5ψ Stereo Jack x 1
Max. Resolution 4Kx2K
Cable Distance 100 m
Power Adapter (Min.) DC 12V with lock
Housing Metal
Weight 315g
Dimensions (LxWxH) 150x80x35 mm
-2-
REMOTE FRONT VIEW
1. R N
2. R OUT
3. 2P N D P Switch
4. 4- N-1 LED
(MODE LED、L NK LED、HDCP LED、POWER LED)
DIP SWITCH SETTING
Select RS-232 or F/W upgrade mode:
1 2 Mode
OFF NC RS-232
ON NC F/W upgrade
REMOTE REAR VIEW
1. Power jack (12V DC)
2. L NK (RJ-45 Connector)
3. HDM OUT
4. F/W UPGRADE
Installation
1. Turn off the source device and HDTV.
2. Connect the HDM extension cable between the HDTV
and the “HDM OUT” port of HX-RUW2.
3. Connect the CAT.5e/ CAT.6 cables between the source
device and the HX-RUW2 “L NK” port of extender.
4. Connect the power cord and turn on the extender.
5. Turn on the source device (equipment) and HDTV.
-3-

IR Receiver Cable Directions:
Put it into the HX-RUW2 “ R N” port and place the R
Receiver Cable, so that you can point to it easily with your
R remote controller.
IR Blaster Cable Directions:
Plug R blaster cable plug into HX-RUW2 “ R OUT” port, t
sits in front of the device (equipment) receiver’s R sensor,
which is located on the front-panel.
Additional Options
Select any additional options you may require.
1. R Receiver Cable
GND
+V
Sig
2. R Blaster Cable
NC
P+
N-
-4-
Technical Specifications Output Si nal
Pin #
Si nal
Pin #
Si nal
1 TMDS Data 2+ 11 TMDS Clock Shield
2 TMDS Data 2 Shield 12 TMDS Clock -
3 TMDS Data 2- 13 CEC
4 TMDS Data 1+ 14 Reserved
(N.C. on device)
5 TMDS Data 1 Shield 15 SCL
6 TMDS Data 1- 16 SDA
7 TMDS Data 0+ 17 DDC/CEC Ground
8 TMDS Data 0 Shield 18 +5V Power
9 TMDS Data 0- 19 Hot Plug Detect
10 TMDS Clock+
Wirin Information & Codin
Conductor
Identification
RJ45 Pin
Assi nment
Color Code for
Conductor
Pair 1 5 White-Blue
4 Blue
Pair 2 1 White-Orange
2 Orange
Pair 3 3 White-Green
6 Green
Pair 4 7 White-Brown
8 Brown
-5-
Note
However sometimes, especially in demonstrations or in a
lab environment, the cable is rolled randomly in small turns
for convenience. The randomly rolled UTP cable suffers
additional signal impairments (compared to a straight cable)
and therefore the maximal operating reach might be
reduced.
Rolling a CAT5E/CAT6 cable around a 70cm fixed
diameter plastic drum has just a minor effect on the FEXT
(Far End Cross Talk) when compared to a fully stretched
cable.
© C&C TECHN C TA WAN CO., LTD. All rights reserved.
Trademarks:
All the companies, brand names, and product names
referred to this manual are the trademarks or registered
trademarks belonging to their respective companies.
