Avlite Airfield lighting system Supplement

Version 3.0
AIRFIELD LIGHTING SYSTEM
including Radio Controller
& AV-70-RF Solar Aviation Lights
Installation & Service Manual

AV-70-RF
Solar Aviation Light
Dual internal
high-performance
solar modules
Automatic
night activation
Tough UV-stabilised
LEXAN® polycarbonate
lens and light base
LED aviation lens
with 0 to +7° vertical
divergence
User-replaceable
battery in sealed
compartment
Global 2.4GHz
RF Radio
Control
Figure 1 Leading Dimensions of AV-70-RF

Latest products and information available at www.avlite.com
3
AV-70-RF Solar Aviation Light
with Radio Control
Table of Contents
Introduction.................................................................................................................. 4
Operating Principle ..................................................................................................... 4
Technology................................................................................................................... 4
AV-70-RF Model ........................................................................................................... 5
Optional Congurations ............................................................................................. 7
Assembly & Installation.............................................................................................. 8
Unpacking Instructions .....................................................................................................................................8
Initial Inspection................................................................................................................................................8
Assembling the Light & Conguration of Settings ............................................................................................8
Installing the Light Assembly to the Frangible Stake Mount .............................................................................9
Installing the Light Assembly to the Frangible Concrete Mount......................................................................10
How Does the System Work?................................................................................... 11
Standard Operating Procedure ................................................................................ 11
Best Practice.............................................................................................................. 11
Manual Light Activation via External Momentary Button (where tted) .............. 12
Avlite Radio Controller.............................................................................................. 13
Assembly & Installation of Radio Controller .......................................................... 14
Unpacking Instructions ...................................................................................................................................14
Initial Inspection..............................................................................................................................................14
Assembling & Charging..................................................................................................................................14
Turning the Unit On ........................................................................................................................................14
Charging the Radio Controller........................................................................................................................14
Radio Controller Menu.............................................................................................. 15
Modes of Operation........................................................................................................................................15
Light Group.....................................................................................................................................................15
LED Intensity ..................................................................................................................................................15
Timeout Mode.................................................................................................................................................15
Timeout Duration ............................................................................................................................................15
LED Bank Setup.............................................................................................................................................16
Battery Diagnostic ..........................................................................................................................................16
Controller Battery Voltage...............................................................................................................................16
Sending Commands.......................................................................................................................................16
Using the Radio Control to Activate the Aireld Lighting System (ALS)............. 17
Turn All the Lights ON ....................................................................................................................................17
Setup the Lights to Operate in DUSK till DAWN Mode. .................................................................................17
Runway B Only is to be HIGH Intensity, but Runway A will remain in Current Conguration.........................17
Runway B Only is to be HIGH Intensity, with a Timeout of 8 Minutes &
Runway A will be I/R Low Intensity High Intensity. ...........................................................................17
Flash Codes ............................................................................................................... 19
Maintenance & Servicing.......................................................................................... 24
Trouble Shooting....................................................................................................... 25
Avlite Light Warranty................................................................................................. 26
Version No. Description Date Approved
1.0 Manual Launch July 2010 K. Paton
1.1 Trouble Shooting Update December 2010 A. Burns
2.0 Update: Quality Logo May 2011 P. Rainey
2.1 Update to mounting section November 2011 M. Henry
2.2 General update June 2012 J. Dore
3.0 Updated codes January 2013 J. Dore

Latest products and information available at www.avlite.com
4
AV-70-RF Solar Aviation Light
with Radio Control
Introduction
Congratulations! By choosing to purchase an Avlite light, you have become the
owner of one of the most advanced solar LED aireld lights in the world.
Avlite Systems draws on more than 25 years experience in the design and manufacture of navigation
aids, and particular care has been taken to ensure your light gives years of trouble free service.
As a commitment to producing the highest quality products for our customers, Avlite has been
independently certied as complying with the requirements of ISO 9001:2008 quality management
system.
By taking a few moments to browse through this booklet, you will become familiar with the versatility of
your light, and be able to maximise its operating function.
Please remember to complete the Avlite warranty registration card accompanying your light.
Operating Principle
The solar module of the light converts sunlight to an electrical current that is used to charge the
battery. The battery provides power to operate the light at night.
The asher unit has very low current requirements. A microprocessor drives an array of ultra bright
LED’s through a DC/DC converter, which enables the LED’s to operate within the manufacturer’s
specications. The battery is protected from over-charging within the circuit to ensure maximum
battery life.
On darkness, the microprocessor will initiate a program check and after approximately 1 minute will
turn on.
Technology
Avlite Systems is a world-class solar lighting systems manufacturer with a proven
reputation for rapid, innovative, and agile technology solutions designed specically
for defense, government, civil and humanitarian aid operations in the most remote,
toughest environments.
Electronics
Avlite employs leading in-house electronic engineers in the design and development of software and
related circuitry. All individual electronic components are sourced directly by Avlite procurement staff
ensuring that only the highest quality components are used in our products.
LED Technology
All aviation lights use the latest advancements in LED (Light Emitting Diode) technology as a light
source. The major advantage of LED’s over traditional light sources is well established in that they
typically have an operational life in excess of 100,000 hours, resulting in substantial savings to
maintenance and servicing costs.
Precision Construction
Commitment to investing in the design and construction of injection-moulded parts including optic
lenses, light bases and a range of other components ensures that all Avlite products are of a
consistent and superior quality.
Optical Performance
Avlite manufactures a range of aviation LED lenses moulded from multi-cavity dies. Complex shapes
such as the AV70 and 16-segment multi-focus lenses are a testament to the company’s superior in-
house lens manufacturing capabilities and outstanding optical performance.
Award-winning, Patented Technology
Several United States and Australian patent registrations are held on Avlite’s range of innovative
designs, with other regional patents pending in Canada, United Kingdom and Europe.

Latest products and information available at www.avlite.com
5
AV-70-RF Solar Aviation Light
with Radio Control
AV-70-RF Model
The AV-70-RF solar aviation light is a radio controlled version of the popular AV70 which can be
used in conjunction with a PALC or simple handheld controller. Users can wirelessly control ON/
OFF functions, adjust light intensities, switch between visual and IR (tactical) operational modes.
The solar modules of the light convert sunlight to an electrical current that is used to charge the
battery. The battery provides power to operate the light at night.
The LED driving circuitry has very low current requirements. A microprocessor drives an array
of ultra bright LED’s through a DC/DC converter, which enables the LED’s to operate within the
manufacturer’s specications. The battery is protected from over-charging within the circuit to
ensure maximum battery life.
The Avlite AV-70-RF solar aireld light is exceptional in its unique ability to ‘track the sun’,
operating reliably in low sunlight conditions. Made from tough, durable polycarbonate and using
the latest high-intensity LED’s, the AV-70-RF light boasts dual high-performance solar modules
incorporated into Avlite’s world-rst Solar Collection Lens.
Multiple Radio Controllers can be used to operate the lights at the same time.

•Specications subject to change or variation without notice *Subject to standard terms and conditions †Intensity setting subject to solar availability
SPECIFICATIONS•* AV-70-RF
Light Characteristics
Light Source 12 ultra-high intensity LEDs
Available colors Red, Green,White,Yellow,Amber, Blue, Sectored Combinations
Peak Intensity (cd)† Steady-on: Blue - 2.8 Red - 6.8 Green - 9.0 White - 7.0 Yellow - 6.5
Flashing: Blue - 5.5 Red - 18.2 Green - 21.9 White - 19.1 Yellow - 15.1
Horizontal Output (degrees) 360
Vertical Divergence (degrees) 0 to +7
Reector Type Omnidirectional 360° LED Reector (US Pat. No. 6,667,582.
AU Pat. No. 778,918)
Available Flash Characteristics >250 including steady-on (user-adjustable)
Intensity Adjustments Adjustable in 25% increments
LED Life Expectancy (hours) >100,000
Electrical Characteristics
Operating Voltage (V) 3.6
Temperature Range -40 to 80°C
Solar Characteristics
Solar Module Type Multicrystalline
Output (watts) 2.5 (2 x 1.25watt)
Solar Module Efciency (%) 14
Charging Regulation Microprocessor controlled
Power Supply
Battery Type High grade NiMH – Environmentally friendly
Battery Capacity (Ah) 8
Nominal Voltage (V) 3.6
Autonomy (nights) Steady-on: >14
Flashing: >38 (14 hour darkness, 12.5% duty cycle)
Physical Characteristics
Body Material LEXAN® Polycarbonate – UV stabilized
Lens Material LEXAN® Polycarbonate – UV stabilized
Lens Diameter (mm/inches) 140 / 5½
Lens Design External optics with interior ute design
Mounting 6 x 17mm holes on 200mm PCD
Height (mm/inches) 240 / 9½
Width (mm/inches) 231 / 91/8
Mass (kg/lbs) 1.1 / 23/8
Product Life Expectancy Up to 12 years
Environmental Factors
Humidity 0 to 100%, MIL-STD-810F
Icing 22kg per square inch
Wind Speed Up to 160kph
Shock MIL-STD-202G,Test Condition G, Method 213B
Vibration MIL-STD202G,Test Condition B, Method 204
Certications
CE EN61000-6-3:1997. EN61000-6-1:1997
Quality Assurance ISO9001:2008
Waterproof IP68
Intellectual Property
Patents US Pat. No. 6,667,582.
AU Pat. No. 778,918
Trademarks AVLITE® is a registered trademark of Avlite Systems
Warranty * 3 year warranty
Options Available • Avlite Pilot Activated Lighting Control
• IR LEDs
• External ON/OFF Switch
• External Battery Charging Port
• Manual Operation

Latest products and information available at www.avlite.com
7
AV-70-RF Solar Aviation Light
with Radio Control
•
Specications subject to change or variation without notice
* Subject to standard terms and conditions
SPECIFICATIONS•* AV-ALS-RC-2.4-AVMESH
Electrical Characteristics
Range Up to 1.4km,AvMesh®
Temperature Range -40 to 80°C
Frequency (GHz) 2.4
Nominal Voltage (V DC) 7.2
Power Supply
Battery Type High grade NiMH - Environmentally friendly
Battery Capacity (Ah) 4
Battery Voltage (V DC) 7.2
Physical Characteristics
Case Material Anodised aluminium
Screen Backlit
Product Life Expectancy Up to 12 years
Certications
FCC Approved M100103
CE EN61000-6-3:1997. EN61000-6-1:1997
Quality Assurance ISO9001:2008
Intellectual Property
Trademarks AVLITE® is a registered trademark of Avlite Systems
Warranty * 1 year warranty
Optional Congurations
Optional External ON/OFF Switch
The AV-70-RF can be tted with an external ON/OFF switch below the solar panel at the base of the
unit. The ON/OFF switch may be useful if the unit is only required for short periods and is often being
moved or needs to be stored often, and disconnecting the battery is not viable.
External Battery Charging Port
The AV-70-RF can be tted with an external DC charging port. The external charging port can be used
to charge the battery while the light is stored for extended periods, ensuring the battery is fully charged
when the light is ready for use.
Optional Manual Operation
An external momentary button can be incorporated into the AV-70-RF for emergency use. If the radio
controller is lost or damaged this button allows users to turn the light on manually and step through the
different intensity levels.
Avlite Pilot Activated Lighting Control
The Avlite wireless network of the AV-70-RF can be integrated to a third party Pilot Activated Lighting
Controller (AV-PALC), to allow approaching aircraft to activate lighting on unmanned aerodromes.
Handheld
controller
and charger in
protective case

Latest products and information available at www.avlite.com
8
AV-70-RF Solar Aviation Light
with Radio Control
Assembly & Installation
The installation of the AV-70-RF Solar Aireld Light includes the following steps:-
• Unpacking
• Initial Inspection
• Assembling the light & conguration of settings
• Installing the light assembly
Tools required for assembly & installation:-
• Large at blade screwdriver (to suit “Flash Adjustment” Plug)
• Hammer or Sledge Hammer
• 6mm Allen Key
Unpacking Instructions
Unpack all hardware and verify container contents in accordance with Fig. 2 or Fig. 3. Please contact
your Avlite ofce if there is any hardware missing.
Initial Inspection
Inspect all hardware for damage. If there is any damage, please contact your Avlite Ofce. Retain
original packing material for possible future use in shipping the AV-70-RF.
Assembling the Light & Conguration of Settings
a. Use a large at-blade screwdriver to remove the Flash Adjustment Plug from the base of the light
(see Figure 1).
A sealed vent on the base allows air transfer without moisture intake and should not be disturbed.
b. Setting the Light Group: Adjust Rotary Switches, A & B.
Determine, to which group, each individual light belongs. E.g., taxiway edge lights = 0, runway
edge lights = 1, obstruction lights = 2, threshold lights = 3, etc...
Adjust Rotary Switch A to the appropriate light group. E.g. 0, 1, or 2
c. Set the toggle switch to the “ON” position. This will activate the AV-70-RF.
d. To test operation of the light, the Radio Controller will need to be used (see “Using the Radio
Control to activate the ALS System” section of manual for information).
e. Replace the Flash Adjustment Plug.
f. Bolt the light into location.
1. Before activating the lights, the lights must be layed out on the runway in the
location they will be installed.
2. RF lights should always be installed on mounting plates and stakes. Avlite does
not recommend installation on rubber tiles.

Latest products and information available at www.avlite.com
9
AV-70-RF Solar Aviation Light
with Radio Control
Installing the Light Assembly to the Frangible Stake Mount
The completed AV-70-RF mount plate assembly is to be mounted on the Stake (Fig 3) in rm soil (not
loose sand, screenings or other unbound material).
a. Fit the AV-70-RF light on the top of the mounting plate. Insert bolts through the four holes in
the mount, entering from the bottom. Install a penny washer and a Nylock nut on each bolt and
tighten.
b. Fit the boss of the mount plate into the shorter barrel of the frangible sleeve. Using a 6mm Allen
key, tighten the socket head cap screw against the stake mount boss.
c. Use a sledge hammer to drive the stake into the soil at the chosen location. Drive the stake down
until the bottom of the stake sleeve is at ground level.
During Installation every effort should be made to ensure that the light is level when installation is
complete. When installing a stake mount into the ground ensure that the stake is installed straight
into the ground and not on an angle. Ensure that the mounting plate is level using a spirit level.
d. Fit the AV-70-RF mount plate assembly on top of the stake. The longer barrel of the Frangible
Sleeve should completely cover the stake sleeve. Using a 6mm Allen key, tighten the bottom
socket head cap screw against the stake sleeve.
1. Before activating the lights, the lights must be layed out on the runway in the
location they will be installed.
2. RF lights should always be installed on mounting plates and stakes. Avlite does
not recommend installation on rubber tiles.
Item Description Qty
1AV-70-RF Solar Airled
Light
1
2Mount Plate 1
3Frangible Sleeve 1
4Stake (355mm) 1
5Bolt, 8mm x 30 4
6Penny Washer, 8mm 4
7 Nylock Nut, 8mm 4
8Socket Head Cap Screw,
8mm x 16
2
9Allen Key, 6mm 1
1
2
5
3
4
6
7
9
8
Figure 3 Frangible Stake Mount Installation

Latest products and information available at www.avlite.com
10
AV-70-RF Solar Aviation Light
with Radio Control
Check the mounting
plate with a spirit
level in all directions
Installing the Light Assembly to the Frangible Concrete Mount
a. Mount the base plate to the concrete using 4 x M8 concrete bolts.
b. Fit the frangible mounting plate onto the concrete base plate and secure using the M8 x 16 SHCS
c. During Installation every effort should be made to ensure that the light is level when installation is
complete.
The following guide lines will help to ensure that the lights will be installed correctly.
- When installing a concrete mount plate ensure that the concrete pad is level using a spirit level.
- Fit the frangible coupling and top mounting plate and using a spirit level check that the light
mounting plate is level using a spirit level.
d. Fit the AV-70-RF to the light mounting plate using M8 SHCS, large at washers and Nylock nuts.
Note: After adjustments, ensure all nuts and bolts are tightened securely and all tools, spares and
packaging are removed from the runway.
Item Description Qty
1AV-70-RF Solar Airled
Light
1
2Mount Plate 2
3Frangible Sleeve 1
4Bolt, 8mm x 25 4
5Penny Washer, 8mm 4
6 Nylock Nut, 8mm 4
7Socket Head Cap Screw,
8mm x 16
2
8Allen Key, 6mm 1
Figure 4 Frangible Concrete Mount
Installation
1. Before activating the lights, the lights must be layed out on the runway in the
location they will be installed.
2. RF lights should always be installed on mounting plates and stakes. Avlite does
not recommend installation on rubber tiles.

Latest products and information available at www.avlite.com
11
AV-70-RF Solar Aviation Light
with Radio Control
How Does the System Work?
The Avlite ALS System works by using a hand held radio controller to activate and setup an entire aireld,
airport or air base. The system utilises an embedded R/F module operating in the 2.4Ghz ISM Band.
The lights can be congured for up to 15 different light groups. This allows the aireld to independently
control different areas, such as multiple runways, taxiways and helipads.
Due to the handheld nature of the Radio Controller, it can be used from any position in the aireld. This can
allow for easy and efcient inspection or activation of different light groups in the aireld without affecting
other lights.
The standard radio controller broadcasts a command message to all lights within range. This range is
approximately 1.4km (0.8 miles). If a higher gain antenna is used the range can be extended. Each light
within range will receive, decode and re-send the message to all surrounding lights. Each light also has an
operational range of 1.4km.
For distances, greater than 1.4km there may be a delay in those lights receiving the command. The further
away the lights are from the controller the longer it will take the command to propagate to all lights.
To get the most from your ALS please use the following setup
1. Set the “Operation Mode” to DUSK till DAWN.
2. Set the “LED Intensity” Setting to LOW
This will allow your lights to automatically turn on at night and turn off during the day. The lights are
completely autonomous in this state and will not require daily control.
If you need to increase the intensity see “LED Intensity” section of this manual.
Standard Operating Procedure
It is best to locate the controller centrally about the runway when sending commands to achieve the
minimum response time.
If the controller is situated at one end of a 3.2km (12 000’) runway, it will take longer to activate all lights
than from a central position.
The battery inside the light will require extra charge time the following day if the lights are run at HIGH
intensity for more than the recommended time. This can be negated by connecting the lights to an external
power supply.
If these lights are plugged into an external power supply they can be run at any intensity for any length of
time without depleting the battery.
Best Practice

Latest products and information available at www.avlite.com
12
AV-70-RF Solar Aviation Light
with Radio Control
Manual Light Activation via External Momentary Button
(where tted to AV-70-RF)
The AV-70-RF lights are available with optional external momentary button for manual light operation.
The momentary button may be incorporated in the AV-70-RF for emergency use or in case the radio
controller is lost or damaged. This button enables the user to manually turn the light on and step
through the three different intensity levels.
To activate the AV-70-RF using the momentary button:-
a. Hold down the push button for 3 seconds. (The light will activate in LOW intensity mode)
b. Press the momentary button again it will adjust to MEDIUM intensity mode
c. Press the momentary button a third time to achieve HIGH intensity mode
d. Pressing the momentary button again will return the intensity to LOW.
When the light is activated from the momentary button, it will change its operation mode to “Dusk till
Dawn”. This will mean that the light will turn on when the ambient lighting conditions become dark, and
will turn off when it detects daylight.
Notes:
• If the light is activated via the momentary button during daylight hours, it will stay on for 30
seconds before the photo sensor on the circuit board automatically turns the light off.
• When the controller is found or repaired, the lights will revert back to radio control as soon as they
receive a new message/command from the radio controller.
PLEASE NOTE!
• The lights will automatically reduce intensity to low after the TIMEOUT limit is reached. The
timeout is set via the radio controller.

Latest products and information available at www.avlite.com
13
AV-70-RF Solar Aviation Light
with Radio Control
Avlite Radio Controller
The Avlite Radio Controller is a compact handheld unit that allows complete control of the aireld
lighting system. The unit allows you to roam around the aireld for easy activation, inspection and
testing of the aireld lights. The Avlite Radio Controller works on the 2.4GHz ISM Band using a low
power RF module. The backlit, LCD can be seen during day or night. The straightforward menu makes
the ALS easy to operate.
The Avlite Radio Controller comes standard with an IP68 rated charging plug, omni-directional
antenna and ON/OFF switch and cover. It can also be optioned with an RS232 input.
The Radio Controller and charger come in an IP68 ‘Pelican’ Case to protect it from the harsh
environment to which it may be subjected.
The Avlite Radio Controller can be rack mounted in a standard 19” rack for use with other aireld
electronic equipment such as PALC.
Fig 4 Radio Controller Side View Fig 5 Radio Controller Front View
1 LCD Screen
2 MENU Button
3 SEND Button
4 UP Button
5 DOWN Button
6 Antenna
7 Charging Port – IP68 sealed plug. (Charger not shown)
8 RS232 input. (Optional)

Latest products and information available at www.avlite.com
14
AV-70-RF Solar Aviation Light
with Radio Control
Assembly & Installation of Radio Controller
The installation of the Radio Controller includes the following steps:-
• Unpacking
• Initial Inspection
• Assembling & Charging the Radio Controller
• Using the Radio Controller
Unpacking instructions
Unpack all hardware and verify container contents in accordance with Fig. 4 & 5. Please contact your
Avlite ofce if there is any hardware missing.
Initial inspection
Inspect the Radio Controller for damage. If there is any damage, please contact your Avlite ofce.
Retain original packing material for possible future use.
Assembly & Charging
The Radio Controller can be activated after raising the aerial into the upright position, see Fig 5.
It may be necessary to charge the Radio Controller before use.
Turning the Unit On
To turn the unit on, lift the red missile cover and ick the switch.
The radio controller will take 5 seconds to start up.
Charging the Radio Controller
a. Unscrew the protective cap from the charging port, on the left side of the Radio Controller.
b. Insert the charging terminal into the Radio Controller.
c. Plug the charger into a wall socket and turn the charger on.
d. The light on the charger will ash Green, Orange, Red then back to Orange.
e. The charger has a LED to indicate the charge sequence.
i. Green – Unit is fully charged. The Radio Controller can be left connected in state.
ii. Orange – Unit is charging. The unit will charge for a maximum of 8 hours before automatically
shutting down.
iii. Red – A fault is occurring, please contact Avlite Ofce.

Latest products and information available at www.avlite.com
15
AV-70-RF Solar Aviation Light
with Radio Control
Radio Controller Menu
This section of the document will provide a short explanation of all the menu screens on the control unit.
Modes of Operation
The operational Mode denes how the light will respond to different environmental conditions & user inputs.
There are three operational modes that can be selected via the controller. ALWAYS ON, STANDBY &
DUSK till DAWN.
ALWAYS ON Operational Mode
The light is Always On. The light will be lit both day & night. While the light is in this mode it will only
turn off when the battery drops below the Flat Battery Voltage level. (AV-70-RF = 3.2V)
STANDBY Operational Mode
The light is Always Off. While the light is in this mode it will still respond to and pass on commands,
sent by the controller. This mode should be used if the lights have been installed outside but are not
currently required.
Note: The light is not completely powered down in a manner suitable for storage. If the light is to be
stored in a warehouse or other dark environment the ON/OFF switch should be turned off.
DUSK till DAWN Operational Mode
The light is turned on and off based on the light sensor internal to each light. If the light is in the
darkness, it will turn on. If the light is in daylight, it will turn off.
Light Group
This menu is used to select the current light group. The light group of each light is selected via rotary switch
A found on the bottom of the circuit board, in the Light Head. The controller can select any one of the 10
individual light groups
(0 -> 9) or select all radio lights at once.
Note: The units are set with a light group of 0 in the factory.
LED Intensity
Default = LOW
This menu is used to select the intensity of the LEDs on the light. The options include Low, Medium & High.
a. Low – LED intensity is set to low setting (approx 10%)
b. Medium - LED intensity is set to medium intensity (approx 30%).
c. High - LED intensity is set to high intensity (approx 100%)
Note: this menu will not be enabled if the selected operational mode is STANDBY
Timeout Mode
This menu is used to setup the LED high intensity timeout feature found in each light. The options include
Enabled LOW, Disable.
a. Enabled LOW – The immediate LED intensity is selected via the LED Intensity menu, after Timer
Duration the LED Intensity will revert back to the LOW setting
b. Disable – The high intensity LED timeout is disabled. The LED intensity will be selected via the LED
intensity menu.
Note: this menu will not be enabled if the selected operational mode is STANDBY

Latest products and information available at www.avlite.com
16
AV-70-RF Solar Aviation Light
with Radio Control
Timeout Duration
This menu is only visible when the timeout Mode is enabled. This menu is used to select the timeout
duration, the time before the LED intensity reverts back to its LOW intensity state. The timeout duration
can be set from 1 minute to 60 minutes.
LED Bank Setup
All Avlite ALS systems can have the option of having the lights built with multiple colours, in different LED
banks. This can allow a runway to be changed from Visible to I/R at the press of a button.
The options include VISIBLE & IR.
Note: this menu will not be enabled if the selected operational mode is STANDBY
Battery Diagnostic
Default = Disable
This feature can be used to check the battery voltage in every light in the ALS. The command can be
sent any time and it will not affect the current state of the light. If the light is in STANDBY mode the light
will turn on as shown below and revert to STANDBY mode after the diagnostic has been completed.
• If the battery voltage is within operational range the light will turn off for 1 second, ash once, then
turn off for 1 second.
• If the battery voltage is low the light with turn off for 1 second, ash twice, then turn off for 1 second.
Sending Commands
Every time the SEND button is pressed a command is sent containing all the current settings in the Radio
Controller.
The SEND button can be used after changing one setting or after changing multiple settings.
For further information see section under “How does the System Work”.

Latest products and information available at www.avlite.com
17
AV-70-RF Solar Aviation Light
with Radio Control
9. Using the Radio Control to Activate the
Aireld Lighting System (ALS)
The Radio Controller is very easy to use and by reading through the How To section below, all of the
advanced features will be well within your grasp.
Make sure that all the lights in the same Light Group have had the rotary switches set correctly, see
“Assembling the Light” section for details.
Turn All the Lights ON
• Turn the Radio Controller On
• Use the arrow keys to adjust the operational Mode to ALWAYS ON
• Press MENU button once to reach Light Group
• Set the Light Group to ALL
• Press SEND button
• Every radio light within range of the control unit will now turn on.
Setup the Lights to Operate in DUSK till DAWN mode
• Turn the Control unit On
• Use the arrow keys to adjust the operational Mode to DUSK till DAWN
• Press MENU button once to reach Light Group
• Set the Light Group to ALL
• Press SEND button
• Every radio light within range of the control unit will now turn on at night, during the day the lights will
turn off automatically.
Runway B Only is to be HIGH Intensity, but Runway A will Remain in Current
Conguration
• On Runway A, set the rotary switches to A=0 B=0 inside the light head.
• On Runway B, set the rotary switches to A=1 B=0 inside the light head. Rotary Switch A can be set to
any value that is different from Runway A.
• Turn the Control unit On
• Use the arrow keys to adjust the operational Mode to ALWAYS ON
• Press MENU button once to reach Light Group
• Set the Light Group to 1
• Press MENU button once to reach LED Intensity
• Use the arrow keys to adjust the LED Intensity to HIGH
• Press MENU button until you reach LED Bank Setup
• Use the arrow keys to adjust the LED Bank to Visible
• Press SEND button
- Runway A will not change state.
- Runway B will now be High Intensity.

Latest products and information available at www.avlite.com
18
AV-70-RF Solar Aviation Light
with Radio Control
Runway B Only is to be HIGH Intensity, with a Timeout of 8 Minutes and Runway A will
be I/R Low Intensity
• On Runway A, set the rotary switches to A=0 B=0 inside the light head.
• On Runway B, set the rotary switches to A=1 B=0 inside the light head. Rotary Switch A can be set to
any value that is different from Runway A.
• Turn the Control unit On
• Use the arrow keys to adjust the operational Mode to On
• Press MENU button once to reach Light Group
• Set the Light Group to 1
• Press MENU button once to reach LED Intensity
• Use the arrow keys to adjust the LED Intensity to HIGH
• Press MENU button once to reach Timeout Mode
• Use the arrow keys to adjust the Timeout Mode to Enabled LOW
• Press MENU button once to reach Timeout Duration
• Use the arrow keys to adjust the Timeout Duration to 8 Minutes
• Press MENU button once to reach LED Bank Setup
• Use the arrow keys to adjust the LED Bank to Visible
• Press SEND button
- Runway A will not change state.
- Runway B will now be High Intensity. After 8 minute Runway will revert back to LOW intensity.
• Press MENU button until you reach Light Group
• Set the Light Group to 0
• Press MENU button once to reach LED Intensity
• Use the arrow keys to adjust the LED Intensity to LOW
• Press MENU button until you reach LED Bank Setup
• Use the arrow keys to adjust the LED Bank to IR
• Press SEND button
- Runway A will be in LOW Intensity IR mode
- Runway B will not change state. Lights on Runway B will still receive and pass on the message
intended for Runway A.

Latest products and information available at www.avlite.com
19
AV-70-RF Solar Aviation Light
with Radio Control
Flash Codes
All AV-70-RF lights are programmed to be Steady On. Alternatively they are able to be programmed to
ash in any of the 250 different ash codes, if the option is activated.
All lights controlled by the Radio Controller can be set to any ash code. Lights may be set up into “light
groups” and then allocated the required ash setting per light group as required.
For example, VQ (6) + LFL 10 S means 6 very quick ashes followed by a long ash, during a 10-second
interval.
The amount of power your light draws through the night depends on the duty cycle, i.e. the amount of
time on as a proportion to the timing cycle. For example, 0.5 seconds on and 4.5 seconds off equals
a 10% duty cycle. It is best to operate at the lowest duty cycle appropriate to the actual needs of the
application.
AVLITE® code reference is listed by number of ashes
For the latest version of this document visit www.avlite.com,
or email [email protected]
Symbols
FL Flash followed by number Eg. FL 1 S, one ash every second
F Fixed
Q Quick ash
VQ Very quick ash
OC Occulting; greater period on than off
ISO Isophase; equal period on and off
LFL Long ash long
MO Morse code ( ) contains letter

Latest products and information available at www.avlite.com
20
SWITCH FLASH CODE ON OFF
A B
0 0 F (Steady light)
D 3 VQ 0.5 S 0.2 0.3
E 3 VQ 0.6 S 0.2 0.4
F 3 VQ 0.6 S 0.3 0.3
7 3 Q 1 S 0.2 0.8
8 3 Q 1 S 0.3 0.7
9 3 Q 1 S 0.4 0.6
A 3 Q 1 S 0.5 0.5
8 4 Q 1 S 0.8 0.2
B 3 Q 1.2 S 0.3 0.9
9 4 Q 1.2 S 0.5 0.7
C 3 Q 1.2 S 0.6 0.6
F 4 FL 1.5 S 0.2 1.3
1 0 FL 1.5 S 0.3 1.2
0 5 FL 1.5 S 0.4 1.1
0 4 FL 1.5 S 0.5 1.0
2 0 FL 2 S 0.2 1.8
3 0 FL 2 S 0.3 1.7
4 0 FL 2 S 0.4 1.6
5 0 FL 2 S 0.5 1.5
6 0 FL 2 S 0.7 1.3
7 0 FL 2 S 0.8 1.2
1 2 ISO 2 S 1.0 1.0
8 0 FL 2.5 S 0.3 2.2
9 0 FL 2.5 S 0.5 2.0
D 6 FL 2.5 S 1.0 1.5
1 5 FL 3 S 0.2 2.8
A 0 FL 3 S 0.3 2.7
2 5 FL 3 S 0.4 2.6
B 0 FL 3 S 0.5 2.5
3 5 FL 3 S 0.6 2.4
C 0 FL 3 S 0.7 2.3
D 0 FL 3 S 1.0 2.0
2 2 ISO 3 S 1.5 1.5
5 4 OC 3 S 2.0 1.0
E 2 OC 3 S 2.5 0.5
4 6 OC 3.5 S 2.5 1.0
4 5 FL 4 S 0.2 3.8
5 5 FL 4 S 0.3 3.7
E 0 FL 4 S 0.4 3.6
F 0 FL 4 S 0.5 3.5
6 5 FL 4 S 0.6 3.4
0 1 FL 4 S 0.8 3.2
1 1 FL 4 S 1.0 3.0
2 1 FL 4 S 1.5 2.5
3 2 ISO 4 S 2.0 2.0
3 6 OC 4 S 2.5 1.5
F 2 OC 4 S 3.0 1.0
3 1 FL 4.3 S 1.3 3.0
8 5 FL 5 S 0.2 4.8
4 1 FL 5 S 0.3 4.7
5 1 FL 5 S 0.5 4.5
9 5 FL 5 S 0.9 4.1
6 1 FL 5 S 1.0 4.0
SWITCH FLASH CODE ON OFF
A B
7 1 FL 5 S 1.5 3.5
4 2 ISO 5 S 2.5 2.5
8 2 LFL 5 S 2.0 3.0
0 3 OC 5 S 3.0 2.0
1 3 OC 5 S 4.0 1.0
2 3 OC 5 S 4.5 0.5
C 6 FL 6 S 0.2 5.8
B 5 FL 6 S 0.3 5.7
C 5 FL 6 S 0.4 5.6
8 1 FL 6 S 0.5 5.5
9 1 FL 6 S 0.6 5.4
A 1 FL 6 S 1.0 5.0
7 5 FL 6 S 1.2 4.8
B 1 FL 6 S 1.5 4.5
5 2 ISO 6 S 3.0 3.0
9 2 LFL 6 S 2.0 4.0
6 4 OC 6 S 4.0 2.0
3 3 OC 6 S 4.5 1.5
4 3 OC 6 S 5.0 1.0
A 4 FL 7 S 1.0 6.0
9 6 FL 7 S 2.0 5.0
5 6 OC 7 S 4.5 2.5
D 5 FL 7.5 S 0.5 7.0
C 1 FL 7.5 S 0.8 6.7
E 5 FL 8 S 0.5 7.5
B 4 FL 8 S 1.0 7.0
6 2 ISO 8 S 4.0 4.0
A 2 LFL 8 S 2.0 6.0
6 6 OC 8 S 5.0 3.0
B 2 LFL 8 S 3.0 5.0
F 5 FL 9 S 0.9 8.1
C 4 FL 9 S 1.0 8.0
7 6 OC 9 S 6.0 3.0
0 6 FL 10 S 0.2 9.8
1 6 FL 10 S 0.3 9.7
D 1 FL 10 S 0.5 9.5
2 6 FL 10 S 0.8 9.2
E 1 FL 10 S 1.0 9.0
1 4 FL 10 S 1.5 8.5
C 2 LFL 10 S 2.0 8.0
D 2 LFL 10 S 3.0 7.0
7 2 ISO 10 S 5.0 5.0
2 4 LFL 10 S 4.0 6.0
8 6 OC 10 S 6.0 4.0
5 3 OC 10 S 7.0 3.0
6 3 OC 10 S 7.5 2.5
F 1 FL 12 S 1.2 10.8
D 4 FL 12 S 2.5 9.5
3 4 LFL 12 S 2.0 10.0
0 2 FL 15 S 1.0 14.0
4 4 LFL 15 S 4.0 11.0
7 4 OC 15 S 10 5.0
A 6 LFL 20 S 2.0 18.0
E 4 FL 26 S 1.0 25.0
