AWH Tanko EX-S10 Product guide

OPERATING/INSTALLATION INSTRUCTION
(Translation)
Container cleaning devices
Spate cleaner TANKO®EX-S
Type series
TANKO-EX-S10
TANKO-EX-S20
TANKO-EX-S30
TANKO-EX-S40
TANKO-EX-S50
II 1 G Ex h IIB T6 Ga
II 1 D Ex h IIIC T60°C Da
TPS 20 ATEX 055073 0008 X
Spray cleaner TANKO®EX-RB
Type series
TANKO-EX-RB30
TANKO-EX-RB40
TANKO-EX-RB64
TANKO-EX-RB90
II 1 G Ex h IIB T6 Ga
II 1 D Ex h IIIC T60°C Da
TPS 20 ATEX 055073 0008 X
Armaturenwerk Hötensleben GmbH
Schulstr. 5-6
D-39393 Hötensleben, Germany
Telephone: [phone]
Fax: [phone]
E-mail: [email protected]
Homepage: http://www.awh.eu ID no.: 664BA010706ENX –2020/01 Rev.1
0044
0044

NOTE
These instructions are an essential part of the device and must be available to operating
and maintenance personnel at all times throughout its entire life cycle. The safety
precautions contained therein must be observed.
If the device is resold, the instructions must always be transferred to the new owner.
Translation
The operating instructions must be written in an official European Community language acceptable to
the manufacturer of the machinery in which the partly completed machinery will be assembled, or to his
authorized representative. If any discrepancies arise in the translated text, the original operating
instructions (German) must be consulted for clarification, or the manufacturer must be contacted.
This manual and all figures contained therein are protected by copyright. Any use beyond the confines
of copyright law is not permissible and liable to prosecution without the prior written approval of the
publisher. This applies in particular to reproductions, translations, microfilming, and storage and
processing in electronic systems.
© 2020 - Armaturenwerk Hötensleben GmbH. All rights reserved.

ATEX Spate Cleaner TANKO-EX-S and ATEX Spray Cleaner TANKO-EX-RB
Contents Translation - Operating/installation instructions 2020/01 Rev. 1 I
Contents
Contents ............................................................................................................................................I
List of Figures ...................................................................................................................................II
List of Tables....................................................................................................................................III
Abbreviations and Units...................................................................................................................IV
1 Introduction .................................................................................................................................. 1
1.1 Means of Presentation............................................................................................................... 1
1.1.1 Explanation of Signal Words............................................................................................ 1
1.1.2 Explanation of the Warnings ........................................................................................... 2
1.1.3 Pictograms and Symbols ................................................................................................. 4
1.2 Warranty and Liability................................................................................................................. 5
1.3 Product Names and Trademarks............................................................................................... 5
1.4 Related Documents.................................................................................................................... 5
2 Safety............................................................................................................................................ 6
2.1 Intended Use............................................................................................................................... 7
2.2 Spare Parts, Replacement Parts and Accessories .................................................................12
2.3 Duties of the Operating Company ...........................................................................................12
2.4 Requirements for Personnel....................................................................................................15
2.4.1 Personal Protective Equipment.....................................................................................16
2.5 Labeling.....................................................................................................................................17
2.5.1 Type Designation............................................................................................................17
2.5.2 Type Plate.......................................................................................................................17
2.5.3 Labeling for Explosion Protection .................................................................................18
3 Construction and Function ......................................................................................................... 23
3.1 Structure ...................................................................................................................................23
3.2 General Function Description ..................................................................................................24
3.3 Technical Data..........................................................................................................................26
3.4 Cleaning Media.........................................................................................................................39
4 Transportation and Storage........................................................................................................ 44
4.1 Packaging..................................................................................................................................45
4.2 Transport...................................................................................................................................45
4.3 Storage......................................................................................................................................46
5 Installation.................................................................................................................................. 47
5.1 Safety Instructions for Installation ..........................................................................................47
5.2 Installation ................................................................................................................................50
5.2.1 Interfaces........................................................................................................................51
5.2.2 Installation Position .......................................................................................................52
5.2.3 Installing the Device ......................................................................................................53
6 Commissioning ........................................................................................................................... 57
6.1 Safety Instructions for Commissioning ...................................................................................57
6.2 Functional Check/Trial Run .....................................................................................................60
6.3 Switch-on Procedure ................................................................................................................61

ATEX Spate Cleaner TANKO-EX-S and ATEX Spray Cleaner TANKO-EX-RB
II Translation - Operating/installation instructions 2020/01 Rev. 1 Contents
6.4 Operation...................................................................................................................................62
7 Maintenance .............................................................................................................................. 66
7.1 Safety Instructions for Maintenance .......................................................................................66
7.2 Switch-off Procedure ................................................................................................................69
7.3 Removal.....................................................................................................................................70
7.3.1 Removing the Device .....................................................................................................71
7.4 Maintenance .............................................................................................................................72
7.4.1 Maintenance Intervals ...................................................................................................74
7.4.2 Tools and Tightening Torque Values .............................................................................76
7.4.3 Notes on Cleaning..........................................................................................................77
7.5 Spare Parts and Customer Service..........................................................................................79
7.5.1 Spare parts .....................................................................................................................80
8 Faults.......................................................................................................................................... 81
8.1 Safety Instructions for Troubleshooting ..................................................................................81
8.2 Faults and Remedial Action .....................................................................................................82
8.3 What to Do in Case of an Emergency......................................................................................83
9 Decommissioning....................................................................................................................... 84
9.1 Disposal.....................................................................................................................................84
Index.............................................................................................................................................. 86
Appendices .................................................................................................................................... 88
Notes ............................................................................................................................................. 94
List of Figures
Illustration 2.5-1: Type Plate Position ...........................................................................................................17
Illustration 3.1-1: Overview of designs..........................................................................................................23
Illustration 3.2-1: Actuator structure (example TANKO-S) ...........................................................................24
Illustration 3.3-1: Spray pattern.....................................................................................................................26
Illustration 3.3-2: External dimensions .........................................................................................................26
Illustration 3.3-3: Consumption data S10 ....................................................................................................32
Illustration 3.3-4: Range S10.........................................................................................................................32
Illustration 3.3-5: Consumption data S20 ....................................................................................................33
Illustration 3.3-6: Range S20.........................................................................................................................33
Illustration 3.3-7: Consumption data S30 ....................................................................................................34
Illustration 3.3-8: Range S30.........................................................................................................................34
Illustration 3.3-9: Consumption data S40 ....................................................................................................35
Illustration 3.3-10: Range S40 ......................................................................................................................35
Illustration 3.3-11: Consumption data S50 ..................................................................................................36
Illustration 3.3-12: Range S50 ......................................................................................................................36

ATEX Spate Cleaner TANKO-EX-S and ATEX Spray Cleaner TANKO-EX-RB
Contents Translation - Operating/installation instructions 2020/01 Rev. 1 III
Illustration 3.3-13: Range RB30 360°.........................................................................................................37
Illustration 3.3-14: Range RB40 360°.........................................................................................................37
Illustration 3.3-15: Range RB64 360°.........................................................................................................38
Illustration 3.3-16: Range RB90 360°.........................................................................................................38
Illustration 5.2-1: Interfaces of the devices (similar to illustration) ............................................................51
Illustration 5.2-2 Weld-on version .................................................................................................................53
Illustration 5.2-3: Installation of threaded connection ................................................................................54
Illustration 5.2-4: Clip-on dimensions ...........................................................................................................55
Illustration 5.2-5: Clip-on installation............................................................................................................56
Illustration 7.4-1: Maintenance points..........................................................................................................75
List of Tables
Table 1.1-1: Overview of Signal Words ........................................................................................................... 1
Table 2.5-1: Type series.................................................................................................................................17
Table 2.5-2: Relationship between zones and equipment protection levels (EPL)....................................18
Table 2.5-3: EX labeling explanation –Gas..................................................................................................20
Table 2.5-4: EX labeling explanation –dust.................................................................................................21
Table 3.3-1: Operating parameters of the device TANKO-EX-S ...................................................................28
Table 3.3-2: Operating parameters of the device TANKO-EX-RB ................................................................30
Table 3.3-3: Material combinations body - balls ..........................................................................................30
Table 3.3-4: Material combinations device - locking pin (examples)..........................................................31
Table 5.2-1: Recommended Filler Materials ................................................................................................54
Table 5.2-2: Clip-on dimensions....................................................................................................................55
Table 7.4-1: Inspection and Maintenance Work ..........................................................................................76
Table 7.5-1: Spare part wire locking pin for clip-on .....................................................................................80
Table 8.2-1: Operating Faults –Cause and Remedy ...................................................................................82

ATEX Spate Cleaner TANKO-EX-S and ATEX Spray Cleaner TANKO-EX-RB
IV Translation - Operating/installation instructions 2020/01 Rev. 1 Contents
Abbreviations and Units
Abbreviations
ATEX
ATmosphère EXplosible; Synonym for the ATEX Directive of the European Union; comprises
measures for explosion protection for explosive atmospheres
AWH
Armaturenwerk Hötensleben GmbH
BetrSichV
Betriebssicherheitsverordnung (German industrial safety ordinance); ordinance concerning
health and safety when using work equipment; German implementation of Directive
2009/104/EC of the European Parliament concerning the minimum safety and health
requirements for the use of work equipment by workers at work
or
or
approx.
approximately
CIP
Cleaning in Place; a local (automated) cleaning process without dismantling plant parts.
Denotes a procedure for cleaning processing plants, predominantly in sectors with
particularly critical hygiene requirements, such as the pharmaceutical industry, food and
beverage industry or biofuel plants.
DIN
Deutsches Institut für Normung e.V.; is a national standards organization in the Federal
Republic of Germany; The standards of this organization are referred to as DIN standards.
DK
Head diameter
EN
European Standard
EPL
Protection level of the device (equipment protection level)
ISO
International Organization for Standardization
L
Length
LEX,8h
Daily noise exposition level
LPA
Emission noise pressure level at workplace
MC [MA]
Media connection
In the context of these instructions, this colloquial term describes the interface used
in cleaning technology for supplying cleaning agent from the supply line to the device.
max.
maximum
min.
minimum
up/down
Spray pattern up/down
PC [PA]
Process connection
In the context of these instructions, this colloquial term describes the interface used in
cleaning technology for the connection to the process from the device to the container.
Ra
Average roughness value (dimension for the surface roughness)
SI
Système international d’unités; the most widely used international system of units for
physical variables

ATEX Spate Cleaner TANKO-EX-S and ATEX Spray Cleaner TANKO-EX-RB
Contents Translation - Operating/installation instructions 2020/01 Rev. 1 V
SN
Serial number
SW
Width across flats [wrench size]
TRBS
“Technische Regeln für Betriebssicherheit” (German technical rules for operational
reliability and safety); these rules put the “Betriebssicherheitsverordnung”(BetrSichV)
into concrete terms with regard to the identification and assessment of hazards and the
derivation of suitable measures.
TRGS
“Technische Regel für Gefahrstoffe” (German technical rules for hazardous materials);
these rules reflect the state of the art, occupational medicine and occupational hygiene
as well as other sound scientific knowledge for activities involving hazardous materials,
including their classification and labeling.
etc.
and so on
veff
effective vibration velocity
Units of Measure
The following indicated factors are intended for orientation and the conversion of the SI units to
common units of measure for the American market.
bar
Unit of measure for pressure p [bar]
All pressure [bar] specifications stand for positive pressure [bar] [barg] unless expressly
described otherwise.
Conversion: 1 bar = 14.50376… psi [pound-force per square inch]
°C
Unit of measure for temperature T [degrees Celsius]
Conversion from Celsius to Fahrenheit: °C 1.8 + 32 = °F [degrees Fahrenheit]
h
Unit of measure for time t [hour]
K
Unit of measure for temperature T and temperature differences ΔT [Kelvin]
Conversion: 273.15 K = 0°C
kg
Unit of measure for mass m [kilograms]
Conversion: 1 kg = 2.20462 … lb [Latin libra; pound]
l/min
Unit of measure for volume flow rate V [liters per minute]
Conversion: 1 l/min = 0.06 m3/h [cubic meters per hour]
1 l/min = 0.26417 … gpm (US) [gallons per minute (US)]
1 m3/h = 4.40286 … gpm (US) [gallons per minute (US)]
lx
Unit of measure for illuminance Ev[Lux]
m
Unit of measure for length l [meters]
Conversion: 1 m = 3.28083… ft [feet]
mm
Unit of measure for length l [millimeters]
Conversion: 1 mm = 1/25.40005 in [inches] = 0.03937 in [inches]
Nm
Unit of measure for moment/torque M [newton meters]
Conversion: 1 Nm = 0.737 lbft [pound-force feet]

ATEX Spate Cleaner TANKO-EX-S and ATEX Spray Cleaner TANKO-EX-RB
VI Translation - Operating/installation instructions 2020/01 Rev. 1 Contents
rpm
Unit of measure for speed n [revolutions per minute]
Conversion: 1 U/min = 1 rpm [revolutions per minute]
µm
Unit of measure for length l [micrometers]
pS/m
Unit of measure for electrical conductivity of materials κ [piko Siemens per meter]

ATEX Spate Cleaner TANKO-EX-S and ATEX Spray Cleaner TANKO-EX-RB
Abbreviations and Units Translation - Operating/installation instructions 2020/01 Rev. 1 1/1
1Introduction
These operating/installation instructions (referred to hereinafter as the instructions) are a component
part of the device. They provide you with all the information required for smooth operation of the
TANKO®EX-S/TANKO®EX-RB cleaning system (referred to hereinafter as the device).
The instructions must be read, understood, and applied by all persons employed to carry out installation
and assembly, commissioning, maintenance, cleaning and troubleshooting on the device. This applies
in particular to the listed safety instructions.
After studying the manual, you will be able to
–Assemble, install and operate the device safely,
–Clean and service the device correctly and
–Take the correct measures if a fault occurs.
In addition to these instructions, generally applicable, statutory and other binding regulations in regard
of the prevention of accidents and in regard of environmental protection in the country of use must also
be observed.
The instructions must be kept at the location of use of the device so that they are available in legible
condition at all times. If the device is resold, the instructions must always be transferred to the
new owner.
Download the instructions, if necessary, from the http://www.awh.eu/de/downloads Internet page.
1.1 Means of Presentation
1.1.1 Explanation of Signal Words
The warnings are introduced with a signal word which describes the extent of the hazard. The meaning
and their classification in case of hazardous situations are explained in the following overview.
Signal Word
Meaning
Consequences of Failure to Observe
DANGER
Hazard with a high level of risk
Death or severe physical injury
WARNING
Hazard with a medium level
of risk
Death or severe physical injury
CAUTION
Hazard with a low level of risk
Minor or moderate physical injury
NOTE
Hazard with a low risk
Risk of material damage
NOTE ON
EXPLOSION
PROTECTION
Important note on explosion
protection
Loss of explosion protection and resulting
hazards
Table 1.1-1: Overview of Signal Words

ATEX Spate Cleaner TANKO-EX-S and ATEX Spray Cleaner TANKO-EX-RB
2/1 Translation - Operating/installation instructions 2020/01 Rev. 1 1 Introduction
1.1.2 Explanation of the Warnings
Section-related Warnings
The section-related warnings apply not only to one particular action, but rather to all actions within a
section. In addition, the pictograms and symbols indicate a general or specific danger.
DANGER
This warning warns of a hazard with a high level of risk!
Failure to observe it can lead to death or severe physical injury.
Measure(s) to prevent the danger
WARNING
This warning warns of a hazard with a medium level of risk!
Failure to observe it can lead to death or severe physical injury.
Measure(s) to prevent the danger
CAUTION
This warning warns of a hazard with a low level of risk!
Failure to observe it can lead to minor or moderate injury.
Measure(s) to prevent the danger
NOTE
This warning warns of a hazard with a minor level of risk!
Failure to observe it can lead to material damage.
Measure(s) to prevent the danger
NOTE ON EXPLOSION PROTECTION
This note contains instructions regarding explosion protection.
Non-compliance results in the explosion protection being removed, thus leading
to hazards.
Embedded Warnings
The embedded warnings apply to specific actions and are integrated directly into the action before
the specific action step.
The embedded warnings are structured as follows.
SIGNAL WORD Type and source of the danger
Possible consequences in case of failure to observe
Measure(s) to prevent the danger

ATEX Spate Cleaner TANKO-EX-S and ATEX Spray Cleaner TANKO-EX-RB
Abbreviations and Units Translation - Operating/installation instructions 2020/01 Rev. 1 3/1
Further Means of Presentation
The “Info”symbol provides useful information, additional tips and recommendations.
–
Texts which follow this mark are bulleted lists.

Texts which follow this mark describe measures for prevention of the danger.
1.
Texts which follow this numbering describe the first step of a task, followed by further numbered
steps which have to be performed in the specified order.
a)
Texts which follow this lettering as a subitem of a numbering (e.g. 1) describe the first step of
a task for a higher-level task, followed by further lettered steps which have to be performed in
the specified order.
(1)
Numbers in brackets reflect the item numbers in figures or parts lists.
“ ”
Texts in quotation marks are (direct) quotes from documents (e.g. directives or standards)
or words, word groups and parts of a text or word with a special meaning.
Important, significant information is shown with additional bold type, in italics or CAPITAL LETTERS
for emphasis of individual words or phrases.

ATEX Spate Cleaner TANKO-EX-S and ATEX Spray Cleaner TANKO-EX-RB
4/1 Translation - Operating/installation instructions 2020/01 Rev. 1 1 Introduction
1.1.3 Pictograms and Symbols
The following pictograms and symbols are used as a supplementary measure in these instructions
to clarify the sources of dangers and measures. They can appear at all levels of danger.
Warning about
electrical voltage
Warning about
explosive atmosphere
Warning about
hand injuries
Warning about
a hot surface
Warning about
corrosive substances
Warning about
substances which are
a water hazard
Unauthorized access
prohibited
Wear protective
work clothing
Wear safety shoes
Wear protective gloves
Wear safety goggles
Wear a hard hat
Wear hearing protection
Wear a welding mask
Isolate from voltage
before work
Obey instructions
Protective grounding
connection required
Secure against power
being switched back on
Return for recycling
Operating equipment
for Ex zone

ATEX Spate Cleaner TANKO-EX-S and ATEX Spray Cleaner TANKO-EX-RB
Abbreviations and Units Translation - Operating/installation instructions 2020/01 Rev. 1 5/1
1.2 Warranty and Liability
The commitments agreed in the contract of supply and delivery, the general terms and conditions
and the terms of delivery of Armaturenwerk Hötensleben GmbH (referred to hereinafter as AWH)
and the statutory regulations valid at the time the contract was concluded shall apply.
Warranty and liability claims in case of personal injury and damage to property shall be excluded,
in particular if these can be attributed to one or more of the following causes:
–improper or incorrect use of the device,
–improper assembly and installation, commissioning, operation and maintenance of the device,
–failure to observe the instructions in the instructions regarding assembly and installation,
commissioning, operation and maintenance of the device,
–constructional modifications to the device (Conversions or other modifications to the device must
not be made without previous written approval from AWH. In case of infringement, the device will
lose its EU conformity and the operating authorization.),
–use of spare parts that do not comply with the specified technical requirements,
–improperly performed repairs,
–disasters, the effects of foreign objects and force majeure.
Disclaimer
AWH reserves the right to make alterations to this document at any time and without prior notice.
AWH provides no guarantee (neither expressed nor implied) with regard to all information in this
document, including but not limited to the implied warranty of merchantability and suitability for
a particular purpose. Furthermore, AWH does not guarantee the correctness or completeness
of information, text, graphics or other parts in this document.
1.3 Product Names and Trademarks
The product names and trademarks included in these instructions are brands or registered trademarks of
the respective owners. TANKO®and AWH®are registered trademarks of Armaturenwerk Hötensleben GmbH.
1.4 Related Documents
The following documents may contain supplementary information for these instructions:
–Manufacturer's declaration and/or certificates of conformity
–Certificates
–Additional documents for any attached or upstream components, e.g. Drawings, technical data,
information on accessories etc.
–Supplements to these instructions (e.g. special versions)
–AWH catalog, product data sheet

ATEX Spate Cleaner TANKO-EX-S and ATEX Spray Cleaner TANKO-EX-RB
6/1 Translation - Operating/installation instructions 2020/01 Rev. 1 2 Safety
2Safety
The device has been built in accordance with state-of-the-art technology and the recognized rules of
safety. Nevertheless, use of the device may represent a danger to the life and limb of the user and third
parties or a risk of impairments to the device and other objects of material value as a result of its function.
The following basic safety instructions are intended to prevent injury to personnel and material damage.
The operating company must ensure that the basic safety instructions are observed and adhered to.
These instructions contain basic notes on installation, operation, maintenance and servicing of the
device which must be complied with.
Anyone involved in installation, operation, maintenance and servicing must have read and understood
these instructions.
The safety systems and safety instructions described in these instructions must be adhered to.
WARNING
Failure to comply with this manual, incorrectly performed installation and repair work or
incorrect operation could lead to malfunctions on the device and to dangerous situations!
There is a risk of death or severe physical injury.
All work performed on the device must be carried out only by a specialist and in
compliance with
–the corresponding detailed operating and installation instruction(s),
–the warning and safety signs on the device,
–the regulations and requirements specific to the plant and
–the national/regional regulations for safety and the prevention of accidents.
Never install damaged devices or components.
The figures in this manual are intended to provide basic understanding, and are primarily
representations of the principles involved. They may differ from the actual design of the device.
For maintenance and repair, we recommend a training course provided by the manufacturer
or a person authorized by the manufacturer.
If questions or doubts about handling the cleaning device arise during maintenance, please
contact AWH.

ATEX Spate Cleaner TANKO-EX-S and ATEX Spray Cleaner TANKO-EX-RB
Abbreviations and Units Translation - Operating/installation instructions 2020/01 Rev. 1 7/1
Built-in Safety Systems
The built-in safety devices used by the higher-level plant in which the device is installed are to be tested
at regular intervals.
WARNING
Dangerous situations arising from changing or disabling safety devices!
Only functional safety devices can ensure safe operation and prevent inadmissible
operating conditions.
Changing or disabling safety devices can lead to unpredictable and dangerous situations.
There is a risk of death or severe physical injury.
Disabling the safety devices or changing the way they operate is strictly prohibited.
2.1 Intended Use
WARNING
Risk of hazardous situations caused by use going beyond intended use and/or other
types of use of the device!
There is a risk of death or severe physical injury.
Only use the device for the intended use.
–Only ever use the device in accordance with the specifications contained in these
instructions and the specifications on the device’s type plate.
–All the specifications in these instructions must be adhered to at all times.
–Always keep the operating instructions at the location where the device is used.
–Keep all signs on the device in legible condition.
–Only use original spare parts.
Modifications or conversions to the device are NOT permitted.

ATEX Spate Cleaner TANKO-EX-S and ATEX Spray Cleaner TANKO-EX-RB
8/1 Translation - Operating/installation instructions 2020/01 Rev. 1 2 Safety
WARNING
Danger from the incorrect use of materials/agents!
The materials/agents to be used for the intended operation of the device are procured
and utilized by the operating company for the device.
If unsuitable materials or agents are selected, strong chemical reactions could lead to
fatal injury or severe physical injuries.
The proper selection and treatment of these materials/agents is solely the
responsibility of the operating company.
When selecting the materials/agents, make sure that the permitted technical
parameters of the device are NOT exceeded.
The cleaning agents and media must be approved for all of the materials of the device
(e.g. washers, bushings) and for the substances in the container to be cleaned which
come into contact with them.
Adhere to the specified chemical limitations for use in the material data sheets.
Adhere to the safety data sheets supplied by the manufacturers of the materials and
media, in particular for hazardous substances:
–Comply with the hazard and disposal instructions.
–Set out protective measures and compile operating instructions for hazardous
substances.
–This also applies to hazardous substances that may arise during work processes.
Refer to the order confirmation/parts list from AWH for the materials used in the device.
The TANKO-EX-S is a cleaning device without an external actuator and is a member of the spate
cleaners group. The TANKO-EX-RB is a cleaning device without an external actuator and is a member of
the spray cleaners group. The device is driven by the cleaning medium. The device is used for cleaning
the interiors of containers with and without installed equipment.
For the purpose of these instructions the word “container”refers to closed tanks, silos, barrels,
containers, pipes, etc. that are provided with an outlet that ensures a free flow of the supplied cleaning
medium.

ATEX Spate Cleaner TANKO-EX-S and ATEX Spray Cleaner TANKO-EX-RB
Abbreviations and Units Translation - Operating/installation instructions 2020/01 Rev. 1 9/1
When using the device, it is necessary to distinguish between the following operating states.
Operating state - cleaning process (cleaning > cleaning medium is sprayed and spray head rotates)
In this case, ignitable gases, steams, mists or flammable dusts may already be present in the container
or are only added by the intended cleaning process in the form of sprayed fluid (aerosol).
Ignitable steams and mists must be expected as soon as flammable fluids with a flash point of 15 K
over the cleaning medium temperature are sprayed (including those permitted in accordance with
Section 3.4 Cleaning Media). For this reason, both the conditions in the container and the type and
temperature of the cleaning medium must be taken into account when determining the following three
process conditions:
A) During cleaning, no explosive mixture is present, nor is it possible for one to arise from the cleaning
medium. (Explosive mixtures consist of ignitable gases, steams, mists or stirred up flammable dust
in the air or another oxidizing agent that reacts to a self-propagating flame when an ignition source
becomes active, generally causing a sudden increase in temperature and pressure).
Pressure in the container: 0 to 0.5 bar (0 to 7.25 psi g)
Temperature of the cleaning medium: +5°C to +180°C
Ambient temperature in the container to be cleaned: +5°C to +180°C
B) An explosive atmosphere (ATEX conditions) is present during cleaning.
(An explosive atmosphere is a mixture with air as an oxidizing agent under atmospheric conditions
(ambient temperature of - 20°C to +60°C and absolute pressure of 0.8 bar a to 1.1 bar a, that is
already present before the use of the device, or that arises during spraying of a cleaning medium
during the cleaning process)
Pressure in the container: 0 to 0.1 bar (0 to 1.45 psi g)
Temperature of the NON-flammable cleaning medium: +5°C to +60°C
Temperature of the flammable cleaning medium: +5°C to flash point T flash point -15°C (max. +60°C)
Ambient temperature in the container to be cleaned: +5°C to +60°C
C) An explosive mixture is present during cleaning, but there is no explosive atmosphere.
Cleaning is PROHIBITED! If necessary, the process conditions must be changed before use of the
device so that process conditions exist in accordance with A) or B).
For processes that are outside atmospheric conditions, the operating company must make a
differentiated assessment of the effects.
The necessary safety-related parameters must be determined and an additional risk assessment
must be created for explosion hazards in order to demonstrate the suitability of the device used.
The cleaning process with the tank cleaning devices TANKO-EX-S and TANKO-EX-RB is prohibited in
operating conditions that lead to explosive mixtures outside atmospheric conditions (outside
temperatures of - 20 °C to +60 °C and absolute pressures of 0.8 bar a to 1.1 bar a) in the container to
be cleaned or in the presence of oxidizing agents other than air.
The cleaning process with the tank cleaning devices TANKO-EX-S and TANKO-EX-RB is also prohibited in
the presence of explosive mixtures with ignitable substances such as hydrogen, ethylene, acetylene,
carbon disulfide, carbon monoxide, ethylene oxide, and trichlorosilane.

ATEX Spate Cleaner TANKO-EX-S and ATEX Spray Cleaner TANKO-EX-RB
10/1 Translation - Operating/installation instructions 2020/01 Rev. 1 2 Safety
Operating state - idle state (NO cleaning > cleaning medium is NOT sprayed and spray head is stationary)
Pressure in the container: Depending on the permissible maximum pressure of the container and
the attached fittings including media supply. The media supply must be closed tightly, the cleaning
device does not have its own shut-off device.
Ambient temperature in the container to be cleaned: -20°C to 180°C
The device was developed, engineered and built exclusively for industrial and commercial use. It must
not be used for private use.
Operation may also be carried out if an explosive dust or gas atmosphere is present, or can develop,
inside the tank that is to be cleaned.
The TANKO-EX-S or TANKO-EX-RB is suitable for use in an explosive Zone 0 or Zone 20 atmosphere.
Please note the additional information on the type plate for the Ex labeling (see Section 2.5.3 Labeling
for Explosion Protection).
In all cases, operating company must check whether the device is suitable for its application.
NOTE ON EXPLOSION PROTECTION
The area of application of the device must always be adjusted to the relevant operating
conditions and the materials in contact with the product. These materials must be
selected to ensure that they do not react with the cleaning medium or the substances in
the container to be cleaned in any way that could impair the explosion protection.
It must be ensured that no hybrid mixtures can occur in the container or the environment
(a hybrid mixture is a mixture of air with combustible substances in different states of
aggregation - e.g. gas/steam and dust).
Non-compliance can result in the loss of explosion protection.
Locations for containers in which the device is to be installed are usually enclosed spaces. In different
setups, the operating company must ensure the protection of the device from harmful weather and
environmental influences while maintaining the specified application limitations/conditions
(see Section 3.3 Technical Data).

ATEX Spate Cleaner TANKO-EX-S and ATEX Spray Cleaner TANKO-EX-RB
Abbreviations and Units Translation - Operating/installation instructions 2020/01 Rev. 1 11/1
In the process, the following must always be observed:
Only operate the device when installed inside an enclosed container.
Never direct the cleaning jet or torrent from the device at persons.
Protect the device from freezing (e.g. risk of frost from possible residual water).
Use a suitable filter system in the supply line for the cleaning medium.
Operate the device only within the approved parameters, e.g. pressure and temperature
(see Section 3.3 Technical Data). If necessary, appropriate monitoring and limiting systems
(e.g. for pressure and temperature) should be implemented.
Only cleaning agents which are compatible with the materials of the device (see Section 3.4
Cleaning Media) may be used.
The preferred installation position for the device is vertical with the cleaning head pointing
downwards. Other installation positions are possible.
The device may generate vibrations when cleaning the container. Any vibrations going beyond this
must be avoided (see Section 7.4.1 Maintenance Intervals).
The device is designed for fixed pipe installation only. Installation on a hose is PROHIBITED.
Non-Intended Use
The device is NOT suitable for the following applications:
The device is NOT suitable for private use.
The device is NOT suitable for use outside of containers.
Holding the device with your hand during operation is PROHIBITED.
The device must NOT be immersed in the product of the production process (NOT even partially).
This could cause the product to enter into the device. The spray holes may become blocked. The free
movement of the actuator may be obstructed.
The device must NOT by operated with gases (e.g. air) over a long period, as the cleaning medium is
used for lubrication of the bearings.
The device is intended exclusively for the purpose outlined above. Any other use beyond that described
here or alteration of the device without written approval from the manufacturer is considered
IMPROPER use.
The manufacturer accepts NO liability for damage arising from such use. The operating company is
solely responsible for the risk.
The device must not be put into operation until it has been assured that all the safety devices are fully
functional and the plant in which the device is installed meets the safety requirements of all relevant
European directives (e.g. the Machinery Directive).

ATEX Spate Cleaner TANKO-EX-S and ATEX Spray Cleaner TANKO-EX-RB
12/1 Translation - Operating/installation instructions 2020/01 Rev. 1 2 Safety
2.2 Spare Parts, Replacement Parts and Accessories
WARNING
Risk of damage, malfunction or complete failure of the device!
Incorrect or faulty spare/replacement parts and accessories put the functional safety
and reliability of the device at risk. This can result in failure of components or a device
malfunction, as well as material damage and consequential damage.
There is a risk of death or severe physical injury.
Use only the manufacturer's original spare parts.
We expressly draw attention to the fact that spare parts and accessories NOT supplied by AWH have
NOT been checked or approved by AWH. The installation and/or use of such products could therefore,
under certain circumstances, result in changes with negative results to the properties of the device
specified by its design and the higher-level plant.
AWH is not liable for any damage arising from the use of non-original parts or non-original accessory
parts. Standard parts can be obtained from specialist dealers.
Section 7.5.1 Spare parts includes a list of spare parts.
2.3 Duties of the Operating Company
The device is used in the commercial sector. The operating company is thus subject to the legal
obligations regarding occupational safety.
In the EEA (European Economic Area), the national implementation of the Framework Directive
89/391/EEC on carrying out measures for improving safety and protecting the health of employees
during work, as well as the associated individual directives shall be observed and complied with in their
current valid versions.
Of particular importance in this connection is Directive 2009/104/EC on the minimum specifications
for safety and health protection of employees using work equipment in their work.
NOTE ON EXPLOSION PROTECTION
For applications in the presence of explosive atmospheres, the Directive (1999/92/EC
with Annexes I and II) on minimum requirements for improving the safety and health
protection of workers potentially at risk from explosive atmospheres also applies.
If this is not observed, the explosion protection could be disabled.
As a basic rule, in Germany the Industrial Safety Regulation (BetrSichV) must be observed.
In other countries, the respective national guidelines, statutes and country-specific regulations
regarding occupational safety and accident prevention must be complied with.
At the same time, the following, non-exhaustive instructions apply in particular:
–The operating company must ensure that the device is used only as intended (see Section 2.1
Intended Use).
