Axiom SW210P User manual
SW210P
low prole passive subwoofer
USER MANUAL
revision 2023-09-01
2
Watch for these symbols:
The lightning ash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated
“dangerous voltage” within the product’s enclosure, that may be of sucient magnitude to constute a risk of electric shock to
persons.
The exclamaon point within an equilateral triangle is intended to alert the user to the presence of important operang and
maintenance (servicing) instrucons in the literature accompanying the appliance.
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instrucons.
2. Keep these instrucons.
3. Heed all warnings.
4. Follow all instrucons.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any venlaon openings. Install in accordance with the manufacturer’s instrucons.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliers) that
produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than
the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or the third prong are provided
for your safety. If the provided plug does not t into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched, parcularly at plugs, convenience receptacles, and the point where
they exit from the apparatus.
11. Only use aachments/accessories specied by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specied by the manufacturer, or sold with the apparatus. When a cart
is used, use cauon when moving the cart/apparatus combinaon to avoid injury from p-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of me.
14. Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been damaged in any way, such
as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate normally, or has been dropped.
15. Warning: to reduce the risk of re or electric shock, do not expose this apparatus to rain or moisture.
16. Do not expose this equipment to dripping or splashing and ensure that no objects lled with liquids, such as vases, are placed
on the equipment.
17. To completely disconnect this apparatus from the ac mains, disconnect the power supply cord plug from the ac receptacle.
18. The mains plug of the power supply cord shall remain readily operable.
19. This apparatus contains potenally lethal voltages. To prevent electric shock or hazard, do not remove the chassis, input
module or ac input covers. No user serviceable parts inside. Refer servicing to qualied service personnel.
20. The loudspeakers covered by this manual are not intended for high moisture outdoor environments. Moisture can damage
the speaker cone and surround and cause corrosion of electrical contacts and metal parts. Avoid exposing the speakers to
direct moisture.
21. Keep loudspeakers out of extended or intense direct sunlight. The driver suspension will prematurely dry out and nished
surfaces may be degraded by long-term exposure to intense ultra-violet (UV) light.
22. The loudspeakers can generate considerable energy. When placed on a slippery surface such as polished wood or linoleum,
the speaker may move due to its acouscal energy output.
23. Precauons should be taken to assure that the speaker does not fall o a stage or table on which it is placed.
24. The loudspeakers are easily capable of generang sound pressure levels (SPL) sucient to cause permanent hearing damage
to performers, producon crew and audience members. Cauon should be taken to avoid prolonged exposure to SPL in excess
of 90 dB.
This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end
of its working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate
this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources. Household users
should contact either the retailer where they purchased this product, or their local government oce, for details of where and
how they can take this item for environmentally safe recycling. Business users should contact their supplier and check the terms
and condions of the purchase contract. This product should not be mixed with other commercial wastes for disposal.
3
LIMITED WARRANTY
Proel warrants all materials, workmanship and proper operaon of this product for a period of two years from the original date of purchase. If any
defects are found in the materials or workmanship or if the product fails to funcon properly during the applicable warranty period, the owner
should inform about these defects the dealer or the distributor, providing receipt or invoice of date of purchase and defect detailed descripon.
This warranty does not extend to damage resulng from improper installaon, misuse, neglect or abuse. Proel S.p.A. will verify damage on returned
units, and when the unit has been properly used and warranty is sll valid, then the unit will be replaced or repaired. Proel S.p.A. is not responsible
for any “direct damage” or “indirect damage” caused by product defecveness.
• This unit package has been submied to ISTA 1A integrity tests. We suggest you control the unit condions immediately aer unpacking it.
• If any damage is found, immediately advise the dealer. Keep all unit packaging parts to allow inspecon.
• Proel is not responsible for any damage that occurs during shipment.
• Products are sold “delivered ex warehouse” and shipment is at charge and risk of the buyer.
• Possible damages to unit should be immediately noed to forwarder. Each complaint for package tampered with should be done within eight
days from product receipt.
CONDITIONS OF USE
Proel do not accept any liability for damage caused to third pares due to improper installaon, use of non-original spare parts, lack of
maintenance, tampering or improper use of this product, including disregard of acceptable and applicable safety standards. Proel strongly
recommends that this loudspeaker cabinet be suspended taking into consideraon all current Naonal, Federal, State and Local regulaons. The
product must be installed be qualied personal. Please contact the manufacturer for further informaon.
DECLARATION OF CONFORMITY
The product is in compliance with:
RoHS Direcve 2011/65/EU and 2015/863/EU, WEEE Direcve 2012/19/EU.
The product is in compliance with:
S.I. 2012/3032 The Restricon of the Use of Certain Hazardous Substances in Electrical and
Electronic Equipment Regulaons 2012
4
INTRODUCTION
The SW210P is a compact, powerful, low-prole subwoofer that provides extended low frequency response for specic models in
the ED series of high performance point source loudspeakers. Due to its low prole is ideal for corporate and A/V applicaons and
for permanent installaons in live music venues, nightclubs and bars, house of worship where subs may have to be ed under
seang or in conned spaces.
The 10” low frequency transducers are equipped with waterproof cones and this feature, together with the moisture resistant
cabinet, makes the SW210P suitable for use in light duty outdoor applicaons. The transducer technology combines 3” sandwich
voice coil with berglass former, progressive wave Konex spider, cloth surround with DAR technology, high excursion ferrite magnet
circuit with demodulang ring, venlated voice coil and magnet to reduce power compression and to provide always very high
performances.
Recessed handles are provided for easy liing and handing, and the included polyurethane wheels aid transportaon, while stacking
feet and matching recesses enable secure ground stacks. Four M10 ying points are also provided to allow suspension in permanent
installaons. Two Neutrik® speakON™ NL4 connectors provide input and link connecons.
TECHNICAL SPECIFICATION
SYSTEM POWER HANDLING
System’s Acousc Principle Direct radiaon, vented AES Pink Noise Power 350 W + 350 W
Frequency response (±3 dB) 45 Hz - 120 Hz (Processed) Program Power 700 W + 700 W
Nominal Impedance 8 Ω + 8 Ω Peak Power 1200 W + 1200 W
Minimum Impedance 5.13 Ω + 5.13 Ω @ 36 Hz ENCLOSURE & CONSTRUCTION
Sensivity (1.41V @ 1m, 2Pi) 97 dBspl Width 650 mm (25.6”)
Maximum Peak SPL @ 1m 130 dBspl Height 310 mm (12.2”)
TRANSDUCERS Depth 410 mm (16.1”)
Type Two 10” (254mm) LF drivers, 3” (76mm)
voice coil, 8Ω Enclosure material 15mm, reinforced phenolic birch
plywood
Cone Waterproof Cone Paint High resistance, black or white water
based paint
Voice Coil Type Venlated voice coil
Suspension Cloth surround, Progressive wave Konex
spider
Flying system 4 x M10 ying points
Transport 2 handles
INPUT CONNECTIONS Net Weight 30 Kg (66 lbs.)
Connector Type Neutrik® Speakon® NL4 x 2
Input Wiring LF1 = Pin 1+/1-; LF2 = Pin 2+/2-
INDEX
INTRODUCTION ...........................4
TECHNICAL SPECIFICATION ..................4
MECHANICAL DRAWING ....................5
OPTIONAL ACCESSORIES ....................5
SPARE PARTS ..............................5
INPUT ...................................6
LINK .....................................6
5
MECHANICAL DRAWING
OPTIONAL ACCESSORIES
NL4FX Neutrik Speakon® PLUG
see hp://www.axiomproaudio.com/ for detailed descripon and other available accessories.
SPARE PARTS
98SW210WZ8 10’’ woofer - 3” VC - 8 ohm
NL4MP Neutrik Speakon® panel socket
31 cm
12.2"
65 cm
25.6"
41 cm
16.1"
M10 Flying Point
M10 Flying Point
6
INPUT
Power input for the external amplier. The SW210P does not include a passive crossover for ltering the signal. The connecons
are the following:
INPUT - LINK
NL4 pin number internal connecon
1+ LF1+
1- LF1-
2+ LF2+
2- LF2-
WARNING!
To avoid speaker damage during use both loudspeaker must be always connected and driven with same input signal and
equal amplied power.
LINK
Power output in parallel with the INPUT socket for connecng the unit to another speaker. The number of SW210P cabinets that
can be connected in parallel depends on the amplier load capacity.
7
PROEL S.p.A. (World Headquarters) - Via alla Ruenia 37/43 - 64027 Sant’Omero (Te) - ITALY
Tel: +39 0861 81241 Fax: +39 0861 887862 www.axiomproaudio.com
