AXIOMTEK IPC914-213-FL Series User manual

IPC914-213-FL Series Quick Installation Guide
©Copyright 2012 Axiomtek Co., Ltd.
VersionA1 December 2012
Printed in Taiwan
9416G914030E
4
Step 3 Locate the Hard Disk Drive from the side. Use
assembly parts to fix HDD with the bracket.
Step 4 Install and fix the HDD with the side cover and then
connect the power cable and SATA cable.
There is a User’s Manual CD-ROM for the Fanless System IPC914-213-FL. Please consult your local vendor for
assistance if you have any difficulties in installing. the system.
IPC914-213-FL Series Quick Installation Guide
©Copyright 2012 Axiomtek Co., Ltd.
Version A1 December 2012
Printed in Taiwan
9416G914030E
1
I. Packing List
9IPC914-213-FL Series Finless
System Unit x 1
9Driver CD x 1
9Wall Mount Bracket x 2 9Quick Manual x 1
919V 150W Adapter x1(for AC
Version) 9Screw Pack x 1
9Food Pad x 4 9Thermal Pad for RAM x 1
¾Do not try to apply power to the system if any
damaged components.
II. Installing the CPU
Step 1 Turn off the system, and disconnect the power
connector.
Step 2 Loosen screws to remove the top and right side
cover from the chassis.
Step 3 Loosen the CPU Card screws from the left side
Heatsink and then remove the left side heatsink
cover from the chassis.
Step 4 Align pins of the CPU with pin holes of the socket.
Be careful of the CPU’s orientation that you need to
align the arrow mark on the CPU with the arrow key
on the socket. Place the CPU into the socket, and
use a screwdriver to lock it on to the socket and
stick the thermal grease on CPU.
There is a User’s Manual CD-ROM for the Fanless System IPC914-213-FL. Please consult your local vendor for
assistance if you have any difficulties in installing. the system.

IPC914-213-FL Series Quick Installation Guide
©Copyright 2012 Axiomtek Co., Ltd.
VersionA1 December 2012
Printed in Taiwan
9416G914030E
2
III. Installing the Memory Module
Step 1 Turn off the system, and disconnect the power
connector.
Step 2 Loosen screws to remove the top cover & right
side cover from the chassis
Step 3 Loosen the CPU Card screws from the left side
Heatsink and then remove the left side heatsink
cover from the chassis.
There is a User’s Manual CD-ROM for the Fanless System IPC914-213-FL. Please consult your local vendor for
assistance if you have any difficulties in installing. the system.
IPC914-213-FL Series Quick Installation Guide
©Copyright 2012 Axiomtek Co., Ltd.
Version A1 December 2012
Printed in Taiwan
9416G914030E
3
Step 3 Please follow steps below to install the memory
module:
1. Please attach the thermal pad (1pcs) on the
memory socket before install the memory.
2. Align the memory module with the socket that
notches of memory module must match the
socket keys for a correct installation.
3. Install the memory module into the socket and
push it firmly down until it is fully seated. The
socket latches are clipped on to the edges of
the SO-DIMM.
IV. Installing the Hard Disk Drive
Step 1 Turn off the system, and disconnect the power
connector.
Step 2 Loosen screws to remove the right side cover from
the chassis.
There is a User’s Manual CD-ROM for the Fanless System IPC914-213-FL. Please consult your local vendor for
assistance if you have any difficulties in installing. the system.
