AXIOMTEK NA362 User manual

NA362 Series
Network Appliance
User’s Manual

ii
Disclaimers
This manual has been carefully checked and believed to contain accurate information.
AXIOMTEK Co., Ltd. assumes no responsibility for any infringements of patents or any third
party’s rights, and any liability arising from such use.
AXIOMTEK does not warrant or assume any legal liability or responsibility for the accuracy,
completeness or usefulness of any information in this document. AXIOMTEK does not make
any commitment to update the information in this manual.
AXIOMTEK reserves the right to change or revise this document and/or product at any time
without notice.
No part of this document may be reproduced, stored in a retrieval system, or transmitted, in
any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without the prior written permission of AXIOMTEK Co., Ltd.
Copyright 2017 AXIOMTEK Co., Ltd.
All Rights Reserved
December 2017, Version A3
Printed in Taiwan

iii
Safety Approvals
CE Marking
FCC Class B
FCC Compliance
This equipment has been tested and complies with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. If not installed and used in
accordance with proper instructions, this equipment might generate or radiate radio frequency
energy and cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measurers:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
Shielded interface cables must be used in order to comply with emission limits.

iv
Safety Precautions
Before getting started, read the following important cautions.
1. Be sure to ground yourself to prevent static charge when installing the internal
components. Use a grounding wrist strap and place all electronic components in any
static-shielded devices. Most electronic components are sensitive to static electrical
charge.
2. Disconnect the power cords from the NA362 Series before making any installation. Be
sure both the system and the external devices are turned OFF. Sudden surge of power
could ruin sensitive components. Make sure the NA362 Series is properly grounded.
3. Do not open the system’s top cover. If opening the cover for maintenance is a must, only
a trained technician is allowed to do so. Integrated circuits on computer boards are
sensitive to static electricity. To avoid damaging chips from electrostatic discharge,
observe the following precautions:
Before handling a board or integrated circuit, touch an unpainted portion of the
system unit chassis for a few seconds. This will help to discharge any static
electricity on your body.
When handling boards and components, wear a wrist-grounding strap, available
from most electronic component stores.
Trademarks Acknowledgments
AXIOMTEK is a trademark of AXIOMTEK Co., Ltd.
IBM, PC/AT, PS/2, VGA are trademarks of International
Business Machines Corporation.
Intel®and Pentium®are registered trademarks of Intel Corporation. MS-DOS, Microsoft C
and QuickBASIC are trademarks of Microsoft Corporation.
Other brand names and trademarks are the properties and registered brands of their
respective owners.

v
Table of Contents
Disclaimers.............................................................................................................ii
Safety Approvals...................................................................................................iii
Safety Precautions ............................................................................................... iv
CHAPTER 1 INTRODUCTION .......................................................................1
1.1 General Description...........................................................................1
1.2 Features..............................................................................................1
1.3 Specifications ....................................................................................2
1.3.1 System ..............................................................................................................2
1.3.2 Mechanical / Environmental ...........................................................................3
1.4 Dimensions and Outlines..................................................................4
1.5 I/O Outlets ..........................................................................................6
1.5.1 Front Panel of NA362.......................................................................................6
1.5.2 Rear Panel for NA362.......................................................................................7
1.5.3 Front Panel for NA362R...................................................................................8
1.5.4 Rear Panel for NA362R....................................................................................9
CHAPTER 2 HARDWARE DESCRIPTION..................................................11
2.1 Checklist...........................................................................................11
2.2 Memory Module (UDIMM/RDIMM) and HDD ...................................11
2.3 Board Layout.................................................................................... 13
2.4 Jumper Settings...............................................................................15
2.4.1 Clear CMOS Jumper (JP3) ............................................................................16
2.4.2 LAN Bypass Control Selection (JP7, JP8, JP9) ..........................................16
2.4.3 TACT SW1 Selection (JP10)..........................................................................17
2.4.4 Case Open Connector (CN5) ........................................................................17
2.5 Connectors....................................................................................... 18
2.5.1 LCM Connector (LCM1, optional for NA362R) ............................................19
2.5.2 Digital Input / Output Connector (DIO1) ......................................................19
2.5.3 SIM card connector (SIM1)............................................................................20
2.5.4 Serial Port2 Connector (COM2)....................................................................20
2.5.5 FAN Connector (FAN1, FAN2, FAN3) ...........................................................21
2.5.6 Serial ATA Connector: (SATA1, SATA2, SATA3, SATA4)...........................21
2.5.7 SATA Power Connector: (CN1, CN2) ...........................................................21
2.5.8 Mini Card Connector (CN4)...........................................................................22
2.5.9 Mini Card Connector (CN7)...........................................................................23
2.5.10 Case Open Connector (CN5) ........................................................................24
2.5.11 Front Panel Bezel Connector (JP2)..............................................................24
2.5.12 DC-In Power Jack (CN14)..............................................................................25
2.5.13 4P Wafer Power Input Connector (ATX2, optional for NA362R) ...............25
2.5.14 Power Switch Connector (ATX1)..................................................................25
2.5.15 Port0 SFP+ Cage Connector (CN8)..............................................................26
2.5.16 Port1 SFP+ Cage Connector(CN16).............................................................27
2.5.17 Console (COM1) and USB connector (CN13) .............................................28
2.5.18 LED1~LED15 ..................................................................................................29
CHAPTER 3 AMI BIOS SETUP UTILITY.....................................................31

vi
3.1 Starting.............................................................................................31
3.2 Navigation Keys...............................................................................31
3.3 Main Menu........................................................................................ 32
3.4 Advanced Menu................................................................................33
3.5 IntelRCSetup ....................................................................................58
3.6 Security Menu .................................................................................. 67
3.7 Boot Menu ........................................................................................68
3.8 Save & Exit Menu............................................................................. 72
APPENDIX A LAN BYPASS CONFIGURATION .........................................79
About LAN Bypass ..........................................................................................79
LAN Bypass Register Configuration ..............................................................80
APPENDIX B WDT TIMER FOR SYSTEM RESET......................................85
APPENDIX C WARNING..............................................................................87

NA362 Series Network Appliance User’s Manual
Introduction
1
CHAPTER 1
INTRODUCTION
This chapter contains general information and detailed specifications of the NA362 Series
Network Appliance Server. Chapter 1 contains the following sections:
General Description
Features
Specifications
Dimensions and Outlines
I/O Outlets
1.1 General Description
The NA362 is a 1U desktop and NA362R is a 1U rack mount network security hardware
platform for VPN, firewall and other network security applications, which consists can support
of Intel®ATOM C3000 family processors. This platform supports the 1U desktop and 1U rack
mount form factor, and the system supports DDR4 U-DIMM/R-DIMM memory up to maximum
64/128 GB. In the meantime, the platform also can support 6 Gigabit LAN ports and 4 10G
SFP+ depends on CPU SKU which can provide best throughput. For the purpose to store
event log data, it can deploy one 2.5” SATA3 HDD (NA362) or two 2.5’’ SATA3 HDD
(NA362R), and one mSATA. This platform can be easily enabled through application
programs to make a user-friendly appliance for customers, and provide the highest ever
performance of encryption and decryption.
1.2 Features
Low power and high performance for network security field applications. NA362 series
supports Intel®ATOM C3000 family processors.
Supports six 10/100/1000Mbps Ethernet ports
Support four 10G SFP+ fiber ports depends on CPU SKU
Supports BIOS redirected to COM port features
Supports one 2.5” SATA Hard Disk (NA362),two 2.5” SATA Hard Disk(NA362R)
Supports one mSATA
Support 2 or 4 U-DIMM/R-DIMM, up to 64/128GB memory
Reasonable computing performance and throughput for processor and LAN ports
Suitable for Network Appliance; VPN, network bandwidth controller, firewall and UTM

NA362 Series Network Appliance User’s Manual
Introduction
2
1.3 Specifications
1.3.1 System
System CPU
Intel®C3000 family processors.
BIOS
AMI SPI flash BIOS
System Memory
Two or four DDR4 U-DIMM/R-DIMM, non-buffer non-ECC memory, up to 64/128GB
Storage Interface
One 2.5” SATA3 HDD for NA362/ Two 2.5” SATA3 HDD for NA362R
One mSATA
Expansion Slot
Two PCI Express Mini Card Socket
One Full size, Support USB & M-SATA(default) or PCIe signal with SIMM Socket
One Full size, Support USB & PCIe(default) or M-SATA signal
Network Interface
Six 10/100/1000Mbps Ethernet (Intel®i210)
Four 10GbE SFP+ depends on CPU SKU
One groups LAN by pass support latch relay for optional
Watchdog Timer
One for LAN by pass :8 levels,1-64 seconds
One for system reset: 255 levels,1-255 sec
USB
Two USB2.0 ports in the rear side
Console
RS-232 Console port is the rear side(RJ-type)
Power
NA362 :1 x 12V, 5A/7A power adapter (NA362)
NA362R: AC/DC 120W open frame (NA362R)
OS Compatibility
Yocto, Linux, Windows Server 2012 R2, Windows Server 2016.

NA362 Series Network Appliance User’s Manual
Introduction
3
1.3.2 Mechanical / Environmental
Form Factor
NA362 :1U Desktop
NA362R:1U Rack mount
LED
Power, HDD, Link/Act with transfer rate
LAN by pass LED and programmable LED
Operation Temperature
NA362 :0°C ~ 40°C (32°F ~ 104°F)
NA362R: 0°C ~ 45°C (32°F ~ 113°F)
Storage Temperature
-20°C ~ 70°C (-4°F ~ 158°F)
Humidity
10% - 95% RH, non-condensing
Chassis Material
Steel
Dimensions
NA362 :44mm (1.73”) (H) x 231mm (9.09”) (W) x 197mm (7.75”)
NA362R: 44mm (1.73”) (H) x 430mm (16.93”) (W) x 250mm (9.84”)
Weight (Net/Gross)
NA362 :1.64 kg /2.69kg
NA362R: 3.5 kg/ 4.5 kg
NOTE: All specifications and images are subject to change without notice.

NA362 Series Network Appliance User’s Manual
Introduction
4
1.4 Dimensions and Outlines
NA362

NA362 Series Network Appliance User’s Manual
Introduction
5
NA362R

NA362 Series Network Appliance User’s Manual
Introduction
6
1.5 I/O Outlets
Locate the front panel I/O outlets on the NA362 Series server to connect serial and Ethernet
interface devices.
1.5.1 Front Panel of NA362
LAN By-Pass LED
While running the LAN By-Pass function, the LED always lights up.
Programmable LED
A sample code will be provided that allow users to define their own function.
NOTE: If you need sample codes please contact our FAE directly, and they are only for
customers’ reference as remarked.
Power LED
It will be lighting when the server is powered on to perform diagnostic tests and check a
proper operation.
LAN Link LED
It will be lighting when a twisted pair is connected to another Ethernet device on the port. It
shows network transfer rate while making a connection.
LAN Activity LED
It will be lighting when the server is transmitting or receiving a packet through the twisted pair
ports.
SFP+ Link LED
It will be lighting when a SFP+ transceiver module is connected.
SFP+Activity LED
It will be lighting when the server is transmitting or receiving a packet through the SFP+
transceiver modules
HDD LED
The LED flashes when transmitting or receiving any signals.
Power LED
HDD LED
Programmable LEDs
Bypass LEDs
SFP+ LEDs
LAN LEDs

NA362 Series Network Appliance User’s Manual
Introduction
7
1.5.2 Rear Panel for NA362
Console port
RS-232 Console port is for the command of line interface and of diagnostic support by
P.O.S.T (Power on Self Test).
Reset Switch
It is for reset the system to reboot your computer instead of turning OFF the power switch. It is
a better way to reboot your system for a longer life of the system’s power supply.
Default Switch
The sample code will be provided that allows users to define their own function. For example,
when the system has any problems, this switch can support to reset it to the customer’s OS
default settings if our customer’s OS supports this application.
Power Switch
After plug in power supply, it can use power switch to power On/Off device.
USB 2.0
Two A type USB 2.0 host. It supports 500mA power supply.
SFP+ ports (depends on CPU SKU)
Four 10G SFP+ fiber ports. It depends on CPU SKU.
10/100/1000 Mbps Ethernet ports
Six 10/100/1000 Mbps Ethernet ports, it complies IEEE 802.3.
Active LED for LAN port #1, port#2, port#3, port#4, port#5, port#6 and SFP+ port #1,
port#2, port#3, port#4.
The Amber LED is on when the LAN/Fiber port connection is working.
LAN Ports
DC Jack
Reset
Power switch
Default switch
SFP+
RJ45 LAN ports
USB2.0
Console

NA362 Series Network Appliance User’s Manual
Introduction
8
1.5.3 Front Panel for NA362R
SFP+ RJ45 LAN ports
Power on LED
System and power on
HDD LED
Link/Active LED (single color)
1. The green LED is on when it is a normal HD connection.
2. The LED flashes when transmitting or receiving any signals.
LAN By-Pass LED
While running the LAN By-Pass function, the LED always lights up.
GPIO LED
A sample code will be provided that allow users to define their own function.
NOTE: If you need sample codes please contact our FAE directly, and they are only for
customers’ reference as remarked.
Active LED for LAN port #1, port#2, port#3, port#4, port#5, port#6 and SFP+ port #1,
port#2, port#3, port#4.
The Amber LED is on when the LAN/Fiber port connection is working.
SFP+ Link LED
It will be lighting when a SFP+ transceiver modules is connected.
SFP+Activity LED
It will be lighting when the server is transmitting or receiving a packet through the SFP+
transceiver modules.
Console port
RJ RS-232 Console port is for the command of line interface and of diagnostic support by
P.O.S.T (Power on Self Test).
Reset Switch
It is for reset the system to reboot your computer instead of turning OFF the power switch. It is
a better way to reboot your system for a longer life of the system’s power supply.
Default Switch
The sample code will be provided that allows users to define their own function. For example,
when the system has any problems, this switch can support to reset it to the customer’s OS
default settings if our customer’s OS supports this application
LCM
USB2.0 Console

NA362 Series Network Appliance User’s Manual
Introduction
9
1.5.4 Rear Panel for NA362R
System Fan System Fan AC Inlet/Switch

NA362 Series Network Appliance User’s Manual
Introduction
10
This page is intentionally left blank.

NA362 Series Network Appliance User’s Manual
Hardware Description
11
CHAPTER 2
HARDWARE DESCRIPTION
The NA362 Series are convenient for your various hardware configurations. The chapter 2 will
help you get familiar with the hardware.
2.1 Checklist
The package bundled with your NA362 Series should contain the following items:
The NA362 Series network appliance hardware platform
DC Power Adapter x 1,Power cord x 1(NA362);power cord x 1 (NA362R)
Mounting screws for disk drive
cable kits (1 x SATA cable, 1 x SATA power cable for NA362;2 x SATA cable, 1 x SATA
power cable for NA362R)
Plastic stand for stack–up x 4
Rack mount ear kit (NA362R)
If you cannot find this package or any items are missing, please contact AXIOMTEK
distributors immediately. If you order any optional components, the package might contain
those additional hardware or documents accordingly.
2.2 Memory Module (UDIMM/RDIMM) and HDD
The main board supports two or four DDR4 UDIMM/RDIMM socket. Maximum memory
capacity is up to 64/128GB ECC/Non-ECC unbuffer memory.
The following steps show you how to install the memory modules:
1 Push down each side of the DIMM socket.
2 Align the memory module with the socket that notches of memory module must match
the socket keys for a correct installation.
3 Install the memory module into the socket and push it firmly down until it is fully seated.
The socket latches are levered upwards and clipped on to the edges of the DIMM.
4 Install any remaining DIMM modules.

NA362 Series Network Appliance User’s Manual
Hardware Description
12
DIMM1
DIMM0
Channel B
DIMM1
DIMM2
Channel A
DIMM3
DIMM4
NOTE: if processor is dual core ,please install the memory from DIMM4(channel A
DIMM0),if the processor is quad core or 8 core can support dual channel
from DIMM4(channel A DIMM0) and DIMM2(channel B DIMM0)
Connects SATA cable and SATA power cable from HDD to SATA connector (SATA1) and
SATA power connector (CN1 or CN2) together then installs HDD by HDD rack and screws
properly (NA362)

NA362 Series Network Appliance User’s Manual
Hardware Description
13
2.3 Board Layout
Component Side

NA362 Series Network Appliance User’s Manual
Hardware Description
14
Bottom Side
