AXIOMTEK NA580 series User manual

NA580 Series
SMB Network Appliance
User’s Manual

ii
Disclaimers
This manual has been carefully checked and believed to contain accurate information.
Axiomtek Co., Ltd. assumes no responsibility for any infringements of patents or any third
party’s rights, and any liability arising from such use.
Axiomtek does not warrant or assume any legal liability or responsibility for the accuracy,
completeness or usefulness of any information in this document. Axiomtek does not make any
commitment to update the information in this manual.
Axiomtek reserves the right to change or revise this document and/or product at any time
without notice.
No part of this document may be reproduced, stored in a retrieval system, or transmitted, in
any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without the prior written permission of Axiomtek Co., Ltd.
CAUTION
If you replace wrong batteries, it causes the danger of explosion. It is recommended by the
manufacturer that you follow the manufacturer’s instructions to only replace the same or
equivalent type of battery, and dispose of used ones.
Copyright 2015 Axiomtek Co., Ltd.
All Rights Reserved
November 2015, Version A1
Printed in Taiwan

iii
Safety Approvals
CE Marking
FCC Class A
FCC Compliance
This equipment has been tested and complies with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. If not installed and used in
accordance with proper instructions, this equipment might generate or radiate radio frequency
energy and cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measurers:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
Consult the dealer or an experienced radio/TV technician for help.
Shielded interface cables must be used in order to comply with emission limits.

iv
Safety Precautions
Before getting started, read the following important cautions.
1. Be sure to ground yourself to prevent static charge when installing the internal
components. Use a grounding wrist strap and place all electronic components in any
static-shielded devices. Most electronic components are sensitive to static electrical
charge.
2. Disconnect the power cords from the NA580 Series before making any installation. Be
sure both the system and the external devices are turned OFF. Sudden surge of power
could ruin sensitive components. Make sure the NA580 Series is properly grounded.
3. Do not open the system’s top cover. If opening the cover for maintenance is a must, only
a trained technician is allowed to do so. Integrated circuits on computer boards are
sensitive to static electricity. To avoid damaging chips from electrostatic discharge,
observe the following precautions:
Before handling a board or integrated circuit, touch an unpainted portion of the
system unit chassis for a few seconds. This will help to discharge any static
electricity on your body.
When handling boards and components, wear a wrist-grounding strap, available
from most electronic component stores.
Trademarks Acknowledgments
Axiomtek is a trademark of Axiomtek Co., Ltd.
Windows®is a trademark of Microsoft Corporation.
IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation.
Intel®and Pentium®are trademarks of Intel Corporation.
AMI is trademark of American Megatrend Inc.
Other brand names and trademarks are the properties and registered brands of their
respective owners.

v
Table of Contents
Disclaimers.....................................................................................................ii
Safety Approvals...........................................................................................iii
Safety Precautions........................................................................................iv
Chapter 1 Introduction .......................................... 1
1.1 General Description............................................................................1
1.2 Features...............................................................................................1
1.3 Specifications......................................................................................2
1.4 Dimensions and Outlines ...................................................................5
1.5 I/O Outlets............................................................................................6
1.5.1 Front Panel.................................................................................................. 6
1.5.2 Rear Panel .................................................................................................. 8
Chapter 2 Hardware and Installation .................... 9
2.1 Check List............................................................................................9
2.2 Board Layout.....................................................................................10
2.3 Jumper Settings................................................................................12
2.3.1 LAN Bypass Control Selection Jumper (JP1, JP2, JP3)........................... 13
2.3.2 CMOS Clear Jumper (JP4)....................................................................... 13
2.3.3 Auto Power Button Model Jumper (JP6)................................................... 14
2.3.4 TACT SW1 Function Selection Jumper (JP8)........................................... 14
2.4 Connectors ........................................................................................15
2.4.1 LCM Connector (LCM1)............................................................................ 16
2.4.2 TPM Module Connector (TPM1) ............................................................... 16
2.4.3 Front Panel Bezel Connector (JP7) .......................................................... 17
2.4.4 Serial Port1 & USB3.0 Port1/2 Connector (CN10).................................... 18
2.4.5 ATX Power Connector (CN1).................................................................... 18
2.4.6 ATX +12V CPU Power Connector (ATX1) ................................................ 19
2.4.7 Serial ATA Connectors (SATA1.2.3.4) ....................................................... 19
2.4.8 USB Port Connectors (USB2)................................................................... 19
2.4.9 CFast Socket (CFAST).............................................................................. 20
2.4.10 Serial Port 2 Connector (COM2)............................................................... 20
2.4.11 FAN Connector (FAN1.FAN2.FAN3)......................................................... 21
2.4.12 VGA Connector (VGA1) ............................................................................ 21
2.4.13 Mini Card Connector (CN6)....................................................................... 22
2.4.14 Mini Card Connector for mSATA (CN4)..................................................... 23
2.5 Hardware Installation........................................................................24

vi
2.5.1 Installing the CPU...................................................................................... 24
2.5.2 Installing the Memory................................................................................ 27
2.5.3 Installing the Hard Disks............................................................................ 28
Chapter 3 AMI BIOS Setup Utility........................ 29
3.1 Starting...............................................................................................29
3.2 Navigation Keys ................................................................................29
3.3 Main Menu..........................................................................................30
3.4 Advanced Menu.................................................................................31
3.5 Chipset Menu.....................................................................................45
3.6 Security Menu....................................................................................48
3.7 Boot Menu..........................................................................................49
3.8 Save & Exit Menu ..............................................................................50
Appendix A LAN Bypass Configuration.................. 55
About LAN Bypass.......................................................................................55
LAN Bypass Register Configuration..........................................................56
Appendix B WDT Timer for System Reset.............. 59
Appendix C LAN Module Expansion ....................... 61
LAN Bypass Control Jumper (JP2/JP3).....................................................61
Appendix D Warning ............................................... 69

NA580 Series User’s Manual
Introduction 1
Chapter 1
Introduction
This chapter contains general information and detailed specifications of the NA580 Series
Network Appliance Server. It contains the following sections:
General Description
Features
Specifications
Dimensions and Outlines
I/O Outlets
1.1 General Description
The NA580 is a 1U rackmount network appliance based on the 6th Generation Intel® Xeon E3/
Core i Processors with Intel® C236 / H110 Chipset (Skylake), The appliance sets the target at
greatly improved CPU performance and reduced power consumption based on Intel’s new
architecture. It provides greater performance and power efficiency to equipment providers.
For greater flexibility, the NA580 has one front-accessible expansion slots that allow
developers to expand one different LAN modules based on their solution requirements. This
expansions need to be requested before production. The one expandable LAN module via the
PCIe 3.0 interface, support max up to 18 LAN ports. To avoid the influences of shutdown by
the environment, the NA580’s motherboard supports data protection via 2 pairs of latch-type
LAN bypass for fail-over option.
For storing event log data, the NA580 utilizes two 2.5” SATA HDDs or one 3.5”SATAHDD. And
NA580 supports four dual channel up to 64GB DDR4-2400 non-ECC/ECC memory and one
standard PCIe x8 expansion slot for optional network security card.
The NA580 is designed for network enterprise business. NA580 not only provides high
performance processor, memory, storage interface and LAN connection, but also includes
outstanding management capability.
1.2 Features
LGA1151 Intel® 6th Generation Xeon® E3/Core™ i processor
Two UDIMM sockets for H110 chipset, up to 32GB none-buffer none-ECC (DDR4 2400)
Four UDIMM sockets for C236 chipset, up to 64GB none-buffer none-ECC / ECC memory
(DDR4 2400)
Supports One LAN modules expansion (NA580 optional)
Supports BIOS redirected to COM port
Supports two 2.5” SATA HDDs or one 3.5”SATA HDD (optional)
Suitable for VPN, network bandwidth controller, firewall applications

NA580 Series User’s Manual
2 Introduction
1.3 Specifications
System
System CPU
Intel® 6th Generation Xeon® E3 / Core i processors
System Chipset
Intel® C236 / H110
System Memory
NA580 (PCH: C236): 4 x DDR4 2400 DIMM sockets, up to 64GB none-buffer
none-ECC / ECC memory
NA580 (PCH: H110): 2 x DDR4 2400 DIMM sockets, up to 32GB none-buffer
none-ECC memory
BIOS
AMI 128Mbit PnP Flash BIOS with function of BIOS redirected to COM port
HDD Interface
Two 2.5”SATA HDDs or one 3.5”SATA HDD (optional)
LAN
The default is 8 x 10/100/1000Mbps LAN ports and 2 pairs LAN bypass.
NA580: Expandable up to 18 LAN ports via LAN modules.

NA580 Series User’s Manual
Introduction 3
LAN Modules
Slim Module
Ports
Chipset
Bypass
NA580
GbE Copper Modules
AX93316-8GI
8
Intel 82580EB
0
v
AX93316-8GIL
8
Intel 82580EB
4
v
AX93336-4GI
4
Intel i210AT
2
v
AX93336-4GIL
4
Intel i350
2
v
GbE Fiber Modules
AX93322-8FI
8
Intel 82580EB
0
v
AX93322-8MIL
4+4
Intel 82580EB
2
v
AX93336-4FI
4
Intel i350
0
v
10GbE Copper Modules
AX93317-2GIL
2
Intel X540
1
v
10GbE Fiber Modules
AX93307-2FI
2
Intel 82599ES
0
v
AX93307-2FIL
2
Intel 82599ES
1
v
AX93327-4FI
4
Intel XL710
0
v
Limitation: The PCIe devices are total 14 devices. Therefore user should check how
many LAN chip configuration are installed in NA580.
Flash
One CFast socket
Super I/O
Controller: Winbond NCT6102D
Serial Ports: Totally 2 asynchronous ports (2 x RS-232; one is 10-pin header onboard
but RX/TX signal is co-lay used for LCM module connector, the other one is RJ-type
connector with Cisco define)
I/O Interface
One console RJ-type connector, 2 x USB 3.0 connectors and 8 x RJ-45 connectors
(default) or up to 18 LAN ports (expandable).
LED: 1x4 LED for LAN bypass 1~2, Power and HDD
1x2 LED for GPO 1~2
1 x LAN modules (optional)
Tact switch x2 (up : GPI button)、(down: hardware system reset button)
Watchdog Timer
One for System Reset: 255 levels, 1-255 sec
LAN Modules for LAN bypass: 7 levels, 1-64 sec
USB
Two USB 3.0 ports one front side, two USB 2.0 are internal pin headers (NA580)
Hardware Monitoring
Controller Winbond NCT6102D
CPU temperature, system temperature, power and fan speed detection
Expansion Slot
One external PCIe slot (optional by AX98618 expansion card and AX96708 Riser
card)
Limitation: The PCIe devices are total 14 devices. Therefore user should check how
many PCIe devices configuration are installed in NA580.

NA580 Series User’s Manual
4 Introduction
Other Features
NA580 supports one front-accessible expansion slot allows our customers to
configure different LAN modules based on their solution requirements before
production. It provides copper and fiber modules, up to 6 groups LAN bypass for
option.(AX98618 daughter board is expansion for 1pcs LAN module. Expansion slot
PCIe x 8 slot only support C236 sku.)
Power Supply
270W single power supply
1U 280W redundant power supply (1+1) (optional)
Note:
Indicates to unplug all AC power cord(s) to disconnect AC Power
OS Compatibility
Linux 2.6.x / 3.x
Mechanical/Environmental
Form Factor
1U rackmount
LED
Power, HDD, GPIO LEDs, LAN bypass LEDs
Operation Temperature
0°C ~ 45°C (32°F ~113°F) (ATX Power Supply)
0°C ~ 40°C (32°F ~104°F) (Redundant Power Supply)
Storage Temperature
-20°C ~ 85°C (-4°F ~ 185°F)
Humidity
10% - 95% RH, non-condensing
Chassis Material
Steel
Dimensions
44mm (1.73”) (H) x 430mm (16.84”) (W) x 450mm (20.59”) (D)
Certificate
FCC class A / CE class A
Note: All specifications and images are subject to change without notice.

NA580 Series User’s Manual
Introduction 5
1.4 Dimensions and Outlines
The following diagram shows you dimensions and outlines of the NA580 Series.
Default: 8 LAN ports max up to 18 LAN ports

NA580 Series User’s Manual
6 Introduction
1.5 I/O Outlets
Locate front and rear panel I/O outlets on the NA580 Series server to connect serial and
ethernet interface devices.
1.5.1 Front Panel
Power LED (Green)
LED light up when the server is powered on to perform diagnostic tests and proper
operation checking.
HDD LED (Green)
LED flashes when HDD is transmitting or receiving data.
Programmable LED GPIO1, GPIO2 (Green)
The GPIO1 and GPIO2 LEDs are controlled by programmable GPIO. A sample
code will be provided that allow users to define their own function. The sample
codes for the above features can be found in the CD, and they are only for
customers’ reference as remarked.
“Default” Tact Switch
The sample code will be provided that allows users to define their own function. For
example, when the system has any problems, this switch can support to reset it to
the customer’s OS default settings if our customer’s OS supports this application.
“Reset” Tact Switch
It is for reset the system to reboot your computer instead of turning OFF the power
switch. It is a better way to reboot your system for a longer life of the system’s
power supply.
Console Port
This is a Cisco RJ-type connector console port for command line interface and
diagnostic support by P.O.S.T (Power On Self Test).
USB3.0 Ports
Two USB 3.0 ports supported.
LAN bypass LED
While running the LAN By-Pass function, the LED always lights up.

NA580 Series User’s Manual
Introduction 7
Transfer Rate for LAN port
The double-color LED light indicates 10/100/1000Mbps transfer rate.
LED Light Color
Transfer Rate
Dark
10Mbps
Green
100Mbps
Orange
1000Mbps
If the LED is dark and Active/Link LED is lighting on flashing, the transfer rate
should be 10Mbps.
When the green-color LED light is radiating, the transfer rate should be
100Mbps.
When the orange-color LED light is radiating, the transfer rate should be
1000Mbps.
When this LED and Link/Active LED both are dark, no networking devices are
attached.
Active/Link LED for LAN Port
The orange LED is on when the LAN port connection is working.
The LED flashes when transmitting or receiving any signals to or from the
appliance.
The LED is dark when the appliance is off.
Note: Optional LAN module LED definition in Appendix C.

NA580 Series User’s Manual
8 Introduction
1.5.2 Rear Panel
Power Supply
System power use power cord to connect the power supply to electrical outlet (AC).
System Fans
These are fans for cooling down system temperature.

NA580 Series User’s Manual
Hardware and Installation 9
Chapter 2
Hardware and Installation
The NA580 Series are convenient for your various hardware configurations. This chapter will
help you get familiar with the hardware.
2.1 Check List
The package bundled with your NA580 Series should contain the following items:
The NA580 Series network appliance hardware platform
Power cord x 1
Utility CD (including user’s manual and sample code)
Mounting brackets for rack installation (left/right) x 2
Plastic stand for stack–up x 4
Mounting screws for disk drive and additional screws for this appliance’s spare
parts
SATA cable x 2 for 2.5”SATA HDDs
If you can not find this package or any items are missing, please contact Axiomtek distributors
immediately. If you order any optional components, the package might contain those additional
hardware or documents accordingly.

NA580 Series User’s Manual
10 Hardware and Installation
2.2 Board Layout
TOP

NA580 Series User’s Manual
Hardware and Installation 11
BOTTOM

NA580 Series User’s Manual
12 Hardware and Installation
2.3 Jumper Settings
Jumper is a small component consists of jumper clip and jumper pins. Install jumper clip on 2
jumper pins to close. And remove jumper clip from 2 jumper pins to open. Below illustration
shows how to set up jumper.
This section provides the information about jumpers and connectors of NA580 Series. Properly
configure jumper settings on the main board in this appliance to meet your application purpose.
Below we list a summary table of all jumpers and default settings for onboard devices.
Jumper
Definition
Jumper Setting
JP1
JP2
JP3
LAN Bypass Trigger When
Power On
(1-2)/(1-2)/(1-2)：
Mother board/SEGN1 ~2 Bypass as same as Power Off status
(1-2)/(1-2)/(2-3)：
Mother board/SEGN1~2 Bypass Disable(Default)
(1-2)/(2-3)/(2-3)：
Mother board/SEGN1 ~2 Bypass Enable
JP4
Clear CMOS Setting
1-2：Normal (Default)
2-3：Clear CMOS
JP6
Auto Power Button Mode
Selection
1-2：Always Off
No Jumper：Always On (Default)
JP8
TACT SW1 Selection
1-2：Power button On/Off
2-3：Reset (Default)
4-5：GPI

NA580 Series User’s Manual
Hardware and Installation 13
2.3.1 LAN Bypass Control Selection Jumper (JP1, JP2, JP3)
Description
Function
Jumper Setting
LAN Bypass Trigger
when Power On
Mother board/SEGN1 ~2
Bypass as same as Power Off status
JP1
JP2
JP3
Mother board/SEGN1 ~2
Bypass Disable(Default)
JP1
JP2
JP3
Mother board/SEGN1 ~2
Bypass Enable
JP1
JP2
JP3
Note: When the system is turned on, you can select LAN bypass function by Jumper
and Bios when power on state, when enter the OS, you can select LAN bypass
function at power on/ off state by software.
2.3.2 CMOS Clear Jumper (JP4)
Use this jumper to erase and restore CMOS memory and BIOS setting. Put jumper clip to
pin 2-3 for a few seconds then move it back to pin 1-2. By doing this procedure CMOS
data resets to its safe default settings.
Description
Function
Jumper Setting
COMS Clear
Normal (Default)
JP4
Clear CMOS
JP4

NA580 Series User’s Manual
14 Hardware and Installation
2.3.3 Auto Power Button Model Jumper (JP6)
Description
Function
Jumper Setting
Auto Power Button
Mode Selection
Always Power Off
ATX Mode
JP6
Always Power On
(Default)
JP6
2.3.4 TACT SW1 Function Selection Jumper (JP8)
Description
Function
Jumper Setting
TACT SW1 Function
Selection
Power On/Off
JP8
Reset (Default)
JP8
GPI
JP8
