2N Indoor View
®
User guide
Firmware: 2.29
Version: 2.29

The 2N TELEKOMUNIKACE a.s. is a Czech manufacturer and supplier of
telecommunications equipment.
The product family developed by 2N TELEKOMUNIKACE a.s. includes GSM gateways,
private branch exchanges (PBX), and door and lift communicators. 2N
TELEKOMUNIKACE a.s. has been ranked among the Czech top companies for years
and represented a symbol of stability and prosperity on the telecommunications
market for almost two decades. At present, we export our products into over 120
countries worldwide and have exclusive distributors on all continents.
2N is a registered trademark of 2N TELEKOMUNIKACE a.s. Any product and/or other
®
names mentioned herein are registered trademarks and/or trademarks or brands
protected by law.
2N TELEKOMUNIKACE a.s. administers the FAQ database to help you quickly find
information and to answer your questions about 2N products and services. On www.
faq.2n.cz you can find information regarding products adjustment and instructions for
optimum use and procedures „What to do if...".
2N TELEKOMUNIKACE a.s. hereby declares that the 2N product complies with all
basic requirements and other relevant provisions of the 1999/5/EC directive. For the
full wording of the Declaration of Conformity see the CD-ROM (if enclosed) or our
website at www.2n.cz.
The 2N TELEKOMUNIKACE a.s. is the holder of the ISO 9001:2009 certificate. All
development, production and distribution processes of the company are managed by
this standard and guarantee a high quality, technical level and professional aspect of
all our products.

2N TELEKOMUNIKACE a.s., www.2n.cz 3/112
Content:
1. Product Description
1.1 Product Description
1.2 Differences between Models and Associated Products
1.3 Terms and Symbols Used
1.4 Safety Precautions
2. Description and Installation
2.1 Before You Start
2.2 Quick installation guide
2.3 Installation Conditions
2.4 2N® Indoor View LAN Location via 2N® Network Scanner
2.5 IP Address Lookup
3. Configuration
3.1 Factory Reset
3.2 Software Configuration
4. Device Control via Display
4.1 Access Logs
4.2 Directory
4.3 Settings
5. Operational Statuses
6. Technical Parameters
7. Supplementary Information
7.1 Troubleshooting
7.2 Directives, Laws and Regulations - General Instructions and Cautions

2N TELEKOMUNIKACE a.s., www.2n.cz 4/112
1. Product Description
In this section, we introduce the product, outline its application 2N Indoor View
®
options and highlight the advantages following from its use. The section also includes
safety precautions.
1.1 Product Description
1.2 Differences between Models and Associated Products
1.3 Terms and Symbols Used
1.4 Safety Precautions

2N TELEKOMUNIKACE a.s., www.2n.cz 5/112
1.1 Product Description
2N Indoor View
® is a stylish, compact-design indoor IP/SIP unit providing audio and
video communication with the . The device includes a 4 mm enhanced 2N IP intercoms
glass touchscreen panel, Speakerphone, high-quality microphone with excellent
audibility and intelligibility properties, Ethernet LAN interface and induction loop and
doorbell external supply connectors. is a top-quality, cost efficient 2N Indoor View
®
and easy to install and configure answering unit. One installation can combine variable
answering units manufactured by 2N Telekomunikace a.s.
2N Indoor View
® is equipped with a specific user interface for an increased user
comfort and safety.
2N Indoor View
® basic features
7" color LCD video display
full duplex handsfree HD audio communication
LAN interface with PoE supply option
easy flush mounting
the device can be combined in installations with , 2N Indoor Touch
®2N Indoor ®
or answering units,Compact 2N Indoor Talk
®
remote administration and configuration via 2N Remote Configuration
®
call setup option via on a smartphone2N Mobile Video
®
DND mode and parental lock
remote door lock control
time display at relax
display of the current weather,
integrated administrator web interface,
external doorbell button input
external power supply input
induction loop output

2N TELEKOMUNIKACE a.s., www.2n.cz 6/112
1.2 Differences between Models and
Associated Products
2N ® Indoor View indoor units
2N Part No. 91378601
Axis Part No. 02087-001 2N Indoor View
® – black
Indoor answering audio/video unit with
touchscreen designed for all 2N IP
intercoms
2N Part No. 91378601WH
Axis Part No. 02088-001 2N Indoor View
® – white
Indoor answering audio/video unit with
touchscreen designed for all 2N IP
intercoms

2N TELEKOMUNIKACE a.s., www.2n.cz 7/112
Other Indoor Units and Accessories
Part Numbers:
913783752N Part No.
Axis Part No. 01668-001
913783762N Part No.
Axis Part No. 01670-001
2N Indoor Touch 2.0
® – black
WiFi version (third and fourth Part Nos.)
2N Indoor Touch 2.0
®, an elegant indoor touch
panel, is designed for all of the . The 2N IP intercoms
display panel shows you the person standing at
your door and helps you make conversation with
the visitor, open the door lock or switch on the
entrance hall lights.
913783822N Part No.
Axis Part No. 01425-001 2N Indoor Touch
® – desk stand black

2N TELEKOMUNIKACE a.s., www.2n.cz 8/112
Part Numbers:
91378375WH2N Part No.
Axis Part No. 01669-001
91378376WH2N Part No.
Axis Part No. 01671-001
2N Indoor Touch 2.0
® – white
WiFi version (third and fourth Part Nos.)
2N Indoor Touch 2.0
®, an elegant indoor touch
panel, is designed for all of the . The 2N IP intercoms
display panel shows you the person standing at
your door and helps you make conversation with
the visitor, open the door lock or switch on the
entrance hall lights.
2N Part No. 91378382W
Axis Part No. 01426-001 2N Indoor Touch
® – desk stand white
2N Part No. 91378501
Axis Part No. 01935-001 2N Indoor Compact
® – black
Indoor answering audio/video unit with touchscreen
designed for all 2N IP intercoms

2N TELEKOMUNIKACE a.s., www.2n.cz 9/112
2N Part No. 91378501WH
Axis Part No. 01936-001 2N Indoor Compact
® – white
Indoor answering audio/video unit with touchscreen
designed for all 2N IP intercoms
2N Part No. 91378401
Axis Part No. 01698-001 2N Indoor Talk
® – black
Indoor answering audio unit with touchscreen
designed for all 2N IP intercoms
2N Part No. 91378401WH
Axis Part No. 01699-001 2N Indoor Talk
® – white
Indoor answering audio unit with touchscreen
designed for all 2N IP intercoms

2N TELEKOMUNIKACE a.s., www.2n.cz 10/112
Mounting Accessories
913788002N Part No.
Axis Part No. 01700-001
Installation box for 2N indoor answering units for
installation in a wall or plasterboard.
Not included in the package.2N Indoor View
®
913788022N Part No.
Axis Part No. 02039-001
Stand for the 2N indoor answering unit.
Not included in the package.2N Indoor View
®

2N TELEKOMUNIKACE a.s., www.2n.cz 11/112
VoIP Phones
913783582N Part No.
Axis Part No. 01421-001
Grandstream GXV3240 VoIP video telephone
GXV3240 is the successor to the popular GXV3140 model,
which provides comfortable video calls in the IP network.
Touchscreen and keypad control.
913783572N Part No.
Axis Part No. 01422-001
Grandstream GXV3275 VoIP video telephone
GXV3275 is the successor to the popular GXV3175 model,
which provides comfortable video calls in the IP network.
Touchscreen control.

2N TELEKOMUNIKACE a.s., www.2n.cz 12/112
1.3 Terms and Symbols Used
The following symbols and pictograms are used in the manual:
Safety
Always abide by this information to prevent persons from injury.
Warning
Always abide by this information to prevent damage to the device.
Caution
Important information for system functionality.
Tip
Useful information for quick and efficient functionality.
Note
Routines or advice for efficient use of the device.

2N TELEKOMUNIKACE a.s., www.2n.cz 13/112
1.4 Safety Precautions
The manufacturer reserves the right to modify the product in order to improve its
qualities. The manufacturer continuously responds to the clients' requirements by
improving the software. Refer to the company websites for the latest www.2n.cz 2N
®
firmware and User Manual.Indoor View
Where necessary, the device can be installed at a safe distance from the
prohibited area and an Ethernet cable can only be carried to the required site.
Install out of reach of sensitive devices and human bodies as it 2N Indoor View
®
emits electromagnetic interference.
The permitted scope of operating temperatures is specified in chapter 6.
.Technical Parameters
The device may not be operated at places exposed to direct sunlight or near
heat sources.
2N Indoor View
®is designed for indoor use. It may not be exposed to rain,
flowing water, condensing moisture, fog, and so on.
It may not be exposed to aggressive gases, acid and solvent vapors, etc.
It is designed for LAN connection.
Caution
This product and its installation and configuration techniques are not
intended for persons with diminished physical, sensory or mental
capacities or persons with limited experience and knowledge unless
expertly supervised or duly advised as to the use of this product by a
person responsible for their safety.

2N TELEKOMUNIKACE a.s., www.2n.cz 14/112
2. Description and Installation
This section describes how to install and connect properly.2N Indoor View
®
Here is what you can find in this section:
2.1 Before You Start
2.2 Quick installation guide
2.3 Installation Conditions
2.4 2N® Indoor View LAN Location via 2N® Network Scanner
2.5 IP Address Lookup

2N TELEKOMUNIKACE a.s., www.2n.cz 15/112
2.1 Before You Start
Package Completeness Check
Please check the product delivery before starting installation: Contents:
1x
2N Indoor View
®
2x External power and doorbell button terminals
1x Certificate of ownership
1x 2.5 mm hexagon key wrench
1x Quick Start manual
1x display cleaning cloth

2N TELEKOMUNIKACE a.s., www.2n.cz 16/112
1.
2.
3.
4.
Front Layout
Display
Microphone
Speaker
Anchoring holes

2N TELEKOMUNIKACE a.s., www.2n.cz 17/112
1.
2.
3.
4.
5.
Backside Connectors
Output for connection of an external induction loop
Reset button
Doorbell button input
12 V / 1 A DC power supply input
Ethernet
2N Indoor View
® is designed for flush mounting (brick, plasterboard, wood). Use the
flush mounting box (Part No. 91378800), which is not included in the package.
Alternatively, the product can be mounted into a desk stand (Part No. 91378802),
which is not included in the package.

2N TELEKOMUNIKACE a.s., www.2n.cz 18/112

2N TELEKOMUNIKACE a.s., www.2n.cz 19/112
Cut a circular hole in the wall of the diameter of 103 mm and depth of 50 mm before
installation. It is assumed that all necessary cables of the maximum length of 25 cm
will lead to the hole. Put the flush mounting box in the hole to make sure that the hole
is deep enough. If the hole complies with the box size, wall in the box and level the
box using a water level on the holding clips. When the mortar hardens, break off the
clips and cap the box with the cover provided. Use anchoring elements to fix the
device into plasterboard.
Tip
Drill template.pdf
For actual fixing of the to the flush-mount box, have the 2.5 mm 2N Indoor View
®
Allen key which is included in the box of the at the ready.2N Indoor View
®
Note
When installing the into the wall, the local standards 2N Indoor View
®
relating to installation of electrical devices in flammable material must
be taken into consideration.

2N TELEKOMUNIKACE a.s., www.2n.cz 20/112
2.2 Quick installation guide
Remove the cover from the walled-in flush mounting box. Remove 2N Indoor View
®
the pre-prepared cabling, UTP cable, doorbell twin cable and power supply cable.
Shorten the cables to 150 mm or less as required. Connect the doorbell twin cable or
power supply cable to the connector provided. Crimp the RJ-45 connector onto the
UTP cable. Take and lean its bottom edge against the wall below the 2N Indoor View
®
flush mounting box. First plug the green power/doorbell connector. Connect the LAN
connector. Put the cables carefully in the pre-drilled back slot to 2N Indoor View
®
prevent them from blocking any horizontal levelling movement during the final
installation stage. Insert in the flush mounting box making sure that 2N Indoor View
®
