Axminster Trade AT406SS User manual

AT406SS, AT535SS, AT762SS
Scroll Saws
AT406SS
AT535SS
AT762SS
AT406SS Code 101771
AT535SS Code 101772
AT762SS Code 101773
(KC-16)
(KC-21)
(KC-30)
Original Instructions
AT&M: 18/03/2020
BOOK REF: 101814
BOOK VERSION: 2

Index of Contents
2
EU Declaration of Conformity
EU Declaration of Conformity 02
Rules For Safe Operation 03
Safety Instructions 04
Electrical Requirements 05
Identification of Main Parts & Components 06
Unpacking & Set Up 07
Installation & Assembly 07-08
Choosing & Installing a Saw Blade 08-09-10
Operating Instructions 10-11-12-13
Maintenance, Adjustments & Servicing 14-15
Changing the Fuse 15
Specifications 15
Optional Accessories 16
Stand Assembly 17
Exploded Diagrams/Lists
KC-16,KC-21-KC-30 Exploded Diagram (A) 18-19
KC-16,KC-21-KC-30 Exploded Diagram (B) 20-21
KC-16,KC-21-KC-30 Exploded Diagram (C) 22-23
Base Mounting Holes 24
Wiring Diagram 25
Notes 27
The symbols below advise the correct safety procedures when using this machine.
Fully read manual
and safety instructions
before use
Eye protection
should be worn
Ear protection
should be worn
Keep hands away
from moving parts and
cutting area
Dust mask
should be worn
Cert No: KC-16, KC-21, KC-30
Axminster Tools & Machinery Ltd
Axminster Devon
EX13 5PH UK
axminster.co.uk
Type Scroll Saw
Model AT406SS, AT535SS, AT762SS and conforms to the machinery example for which the
EC Type-Examination Certificate No AM 50328372
has been issued by The Kingcraft Machinery Co., Ltd.
at: No. 26, Gong Yeh 12 Road, 41280 Dah Li Dist.,Taichung City Taiwan
and complies with the relevant essential health and safety requirements.
2006/42/EC
06/42/EC - Annex I/05.2006
EN 61029-1:2009+A11
declares that the machinery described:-
This machine complies with the following directives:
EU Declaration of Conformity
Signed
Andrew Parkhouse
Operations Director Date: 26/02/2016

Rules for Safe Operation
3
1. Be sure to read, understand and follow all safety warnings and
instructions in the supplied Operator’s Manual.
2. Do not operate the saw when tired, distracted, or under the
effects of drugs, alcohol or any medication that impairs reflexes
or alertness. Stay alert! Give your work your undivided attention.
3. Keep the work area well lit, clean and free of debris. Cluttered
areas and benches invite injuries.
4. Keep children and shop visitors at a safe distance while
operating the saw; do not permit them to operate the scroll saw.
5. Childproof and tamper proof your shop and all machinery
with locks, master electrical switches and switch keys, to prevent
unauthorised or unsupervised use. Fine particulate dust is a
carcinogen that can be hazardous to health. Work in a well
ventilated area and use a dust collector whenever possible.
7. Wear approved safety glasses, dust mask and nonskid
footwear. Do not wear loose clothing, gloves, bracelets, necklaces
or jewellery while operating the saw. Keep long hair contained by
wearing protective hair covering.
8. Be sure all adjustment tools, wrenches or other
clutter are removed from the machine and/or the table surface
before operation. When not in use, tools should be locked-up
in a dry place, out of children’s reach and away from flammable
substances.
9. Keep hands well away from saw blade and all moving parts.
Use a brush, not hands, to clear away chips and sawdust.
10. Be sure that the saw blade is properly installed, and in the
correct cutting direction, before operation. Always use a clean,
properly sharpened blade. Dirty or dull blades are unsafe and can
lead to accidents. Also, be sure the blade has gained full operating
speed before beginning to cut.
11. Do not push or force wood into the blade. The saw will perform
better and more safely when working at the rate for which it was
designed. Do not use for purposes not intended.
12. Avoid working from awkward or off balance positions. Do not
overreach while cutting; keep both feet on floor. Never lean over
or reach behind the blade and never pull the work piece through
the cut from behind.
13. Never stand or lean on the saw. Serious injury could occur if the
unit is tipped over or if the blade is unintentionally contacted.
14. Use of parts and accessories NOT recommended by Axminster
Tool Centre may result in equipment malfunction or risk of injury.
15. Never leave the machine unattended while running or with
the power “ON”.
16. Always turn off and disconnect from power source before
servicing or changing accessories, blades, bits, and cutters, or
before performing any maintenance or adjustments.
17. Make sure that switch is in the “OFF” position before plugging
in the power cord. Do not use the saw if the power switch is
defected, have defective switches replaced by an authorized
service centre.
18. Make sure saw is properly grounded. If equipped with a three
prong plug it should be used with a three-pole receptacle. Never
remove the third prong. Avoid body contact with grounded
surfaces (e.g. pipes, radiators, stoves, refrigerators).
19. Repairs to the saw should only be carried out by qualified
people using original spare parts. A guard or other damaged part
should be properly repaired or replaced by an authorized service
centre.
20. Inspect power cords and extension wires periodically. If
damaged, have them repaired by an authorized service facility.
Never yank cords and wires and keep away from heat, oil, and
sharp edges.
21. This tool is for indoor use only. Do not expose to rain or use
in wet or damp locations.
To help ensure safe operation, please take a moment to learn the machine’s
applications and limitations, as well as potential hazards. Axminster Tool
Centre disclaims any real or implied warranty and holds itself harmless for any
injury that may result from the improper use of its equipment.

Safety Instructions
4

Electrical Requirements
5
aa

Identification of Main Parts & Components
6
i
k
o
p
l
j
n
q
m
a
e
f
g
h
b
d
c
a
e
f
g
h
i
k
o
p
l
j
b
n
q
d
m
c
AT535SS
NVR power isolating switch
ON/OFF Switch (A)
Speed Control Dial (B)
B
A

Installation & Assembly
Unpacking & Set Up
7
AT406SS (KC-16)
AT535SS (KC-21)
AT762SS (KC-30)

Installation & Assembly
8
d
a
e
f
g
b
d
c
Choosing & Installing a Saw Blade
It is strongly recommended that you mount the machine to a workbench or to
a purpose built stand, a pad between the scroll saw and the workbench/stand
is also recommended to reduce vibration.
Drill four 8mm holes in your workbench/stand and secure using
nuts bolts washers (Not Included).
abcd
Slot the guard clamping arm (d) through the pre-drilled hole in the hexagon clamp (c). Insert the hexagon
clamp (c) into the brackets hexagon recess, place the washer (b) over the hexagon clamp thread and secure
using the butterfly clamping knob (a).
NOTE: DO NOT OVERTIGHTEN otherwise you may strip the thread Saw guard assembly (d) assembled
ab
c
d
Saw guard assembly
NVR Switch assembly
A power NVR switch has
been attached to isolate the
scroll saw while not in use,
see fig A.
• Press the ‘GREEN’ button
to put power to the scroll
saw then press the ‘ON’
button (B) to start the saw.
•Once operation has
be completed, press
the ‘RED’ button to isolate
the scroll saws power.
NOTE: MAKESURE THE
SPEED CONTROL DIAL (C)
IS SET TO LOW BEFORE
YOU START UP THE SAW!
A
B
C

Choosing & Installing a Saw Blade
9

Choosing & Installing a Saw Blade
10
aa
a
b
b
b
a
b
d
c
a
1
12
2
bd
c
!
Operating Instructions

Operating Instructions
11
a
b
c
a
b
c
Adjusting the Osolation (Front to Back) Top & Bottom Blade holder Alignment
Place a 90˚ square upagainst the blade, the blade movement
can be set between course and fine for different cutting tasks,
this can be adjusted by rotating the motor within its’ mounts.
Loosen the motor mounting cap head bolts, see figs A enough
to be able to rotate the motor (this can be quite stiff to turn),
start the machine and run at approximately 1/4 speed. By
rotating the motor, see fig B and carefully observing the blade
you will be able to see the blade changing its setting. The
finest setting is where the blade moves vertically with the
least amount of movement, see fig C backward and forwards
horizontally. This should also be where the machine vibrates
the least. When you have the setting where you wish it to be,
tighten the motor mounting bolts.
If the blade is out of alignment please follow the procedures below for
adjusting the top and bottom blade holders:
Place a 90˚ square upagainst the blade, see fig A. Using a 4mm
Hex key (a) adjust the grub screw and butterfly nut (b), see fig
B, until the blade is parallel with the square. (See figs C and D).
a
b
Fig A Fig B
Fig C Fig D
Fig A Fig B
Fig C Fig D

Operating Instructions
12

Operating Instructions
13
a
a
e
b
d
c
a
e
f
f
b
d
c

aa
b
b
Maintenance, Adjustments & Servicing
14

Maintenance, Adjustments & Servicing
15
Changing the Fuse
The Trade scroll saws takes a 5 Amp 20 x 5mm glass fuse,
follow the instrctions below on how to change the fuse.
1. Unplug the scroll saw from the mains.
2. Unscrew the fuse cap to the rear of the scroll saw
and remove the 5 AMP fuse.
3. Insert a new 5 AMP fuse into the end cap holder.
4. Re-insert the fuse assembly and finger tighten.
Specifications
Code 101771 101772 101773
Model AT406SS (KC-16) AT535SS (KC-21) AT762SS (KC-30)
Rating Trade Trade Trade
Power 230V 50Hz 320W 230V 50Hz 320W 230V 50Hz 320W
Throat 406mm 535mm 762mm
Stroke 18mm 18mm 18mm
Cuts per Minute 400 -1,400 400 -1,550 400-1,550
Max Depth of Cut 51mm 51mm 51mm
Noise Level dB (A) 67dB(A) 67dB(A) 67dB(A)
Table Size 305 x 470mm 345 x 597mm 358 x 825mm
Arm Tilt Left 35° Right -45° Left 35° Right -45° Left 35° Right -45°
Overall L x W x H 686 x 380 x 432mm 812 x 380 x 387mm 1,100 x 394 x 387mm
Weight 24.5kg 29.5kg 52kg
Lock nut
Tension screw

16
Stand Assembly
Foot Switch with Trailing Plug & Socket
These two foot-operated safety switches are equipped with
trailing plugs and sockets and can easily be inserted between the
mains supply and any machine fitted with a no volt release switch,
such as a drill, bandsaw or lathe.
Operation of the switch interrupts the supply to the solenoid
and the machine is stopped; re-starting can only be achieved by
operating the NVR switch on the machine, creating an excellent
safety measure in those situations where safety is of paramount.
C
B
E
6
1
2
3
4
5
6
1
2
3
B
E
C
Step 2Step 1
A E B C D
x4 M8
Bolts
x24 M8
Coatch Bolts
x32 M8
Washers
x28 M8
Nuts
x4 Thread Rubber
Foot
A
B
1
2
3
C
4
5
D
D
Optional Accessories

3
6
E B C
A B C
4
5
6
D
Stand assembled
Step 7Step 3
Step 4
Lower the scroll saw on top of the stand and lineup the holes,
secure using the four bolts (A) washers (B) and Nuts (C)
Step 5
Step 6
Use the holes in the bracket (6) to adjust the stand height
Stand Assembly
17

Exploded Diagrams/Lists
18
KC-16 - KC-21 - KC-30 Diagram A
(KC-16) (KC-21) (KC-30)

Exploded Diagrams/Lists
19
REF. PART NO. DESCRIPTION SPECIFICATION QTY
01 EX21-A01 Main Body
EX16-A78 Main Body
EX30-A01 Main Body
03N EX21-A03N Top Cover
EX16-A79 Top Cover
EX30-A03 Top Cover
04 EX21-A04 Allen Screw #10-32x1/4
05 EX21-A05 Switch Cover
06 EX21-A06 Switch
12 EX21-A12 Air Nozzle
18 EX21-A18 BOLT 1/4-20x1/2
19 EX21-A19 Upper & Lower
Tension Plate
20 EX21-A20 Hold Down Mount
Plate
21 EX21-A21 Allen Screw #10-32x3/8
22 EX21-A22 Hold Down Clamp
Knob
23 EX21-A23 Washer 1/4x16x1.8
24 EX21-A24 Hold Down Clamp
Screw
25 EX21-A25 Hold Down Bar
26 EX21-A26 Cap Screw #10-32x1/2
27 EX21-A27 Hold Down Forks
28 EX21-A28 Dust Blower
29 EX21-A29 Tap Screw #8-32UNF3/8” 4
30 EX21-A30 VR Knob
31 EX21-A31CE VR
32 EX21-A32CE Control Cable
EX16-A81 Control Cable
EX30-A32CE Control Cable
EX21-
A31/32CE
VR-With control
cable
33 EX21-A33 Screw M4x8 4
35 EX21-A35 Allen Screw 1/4-20x1/2 3
40 EX21-A40 Gear Cover 1
41 EX21-A41 Nut 3/8xT5. 5 1
45 EX21-A45 Allen Screw #10-32x2-1/4 4
46 EX21-A46 Screw 3/8x5/8 1
47 EX21-A47 Washer #8 8
48 EX21-A48 Screw #8-32x1/4 8
49 EX21-A49 Motor Label 1
50 EX21-A50 Warning Label 1
51 EX21-A51 Nylon Nut #10-32 4
52 EX21-A52 Nylon Nut 1/4-20UNC 2
53 EX21-A53 Lock Washer 1/4. 1
54 EX21-A54 Flat Washer 1/4. (0. D. 13) 1
55 EX21-A55 Label 2
56 EX21-A56 Screw 1/4*2-1/2 2
57 EX21-A57 Upper Arm
EX16-A80 Upper Arm
EX30-A57 Upper Arm
58 EX21-A58 Knob
EX21-A58ASSY Upper arm rising
knob assembly
59 EX21-A59 Nut M8
60 EX21-A60 Adjusting lever
61 EX21-A61 Control Box
62 EX21-A62 Cross Block
Retainer
63 EX21-A63 Housing Cross
Block
64 EX21-A64 Flat Washer M6x16x2
65 EX21-A65 Nylon Nut M6
66 EX21-A66 Allen Screw #10-32x1/2
67 EX21-A67 R Fastener ACC2
68 EX21-A68 Washer #10
69 EX21-A69 Nylon Nut #10-32
70 EX21-A70 Allen Screw #10-32x5/16
71 EX21-A71 Button
72 EX21-A72 Set Screw M4x5
73 EX21-A73 Ground Plate
74 EX21-A74 Ground Label
75 EX21-A75 Strain Relief PG11
76 EX21-A76 Motor Control Set
EX16-A82 Motor Control Set
EX30-A76 Motor Control Set
77 EX21-A77 Label
83 EX21-A83 Label
84 EX21-A84 Switch Box
85 EX21-A85 Control plate
86 EX21-A86 Fixing plate
87 EX21-A87 Switch
88 EX21-A88 Round Head
Screw
#10-24UNCx3/4”
89 EX21-A89 Round Head
Screw
#10-24UNCx5/8”
90 EX21-A90 Fixing plate
91 EX21-A91 Fuseholder
92 EX21-A92 Power Cord
93 EX21-A93 Protection
bracket-Up
94 EX21-A94 Protection
bracket-Down
95 EX21-A95 Short power cord
96 EX21-A96 Strain relief PG9 2
KC-16 - KC-21 - KC-30 Diagram A

Exploded Diagrams/Lists
20
KC-16 - KC-21 - KC-30 Diagram B
(KC-16) (KC-21) (KC-30)
