B.E.G. LUXOMAT PD4-M-1C-C-SM User guide

Installation and Operating Instruction for B.E.G. – Occupancy detector PD4-M-1C-C-SM/ FC/ FM
LUXOMAT®PD4-M-1C-C
1. Mounting preparation
Work on the 230V mains supply may only be carried out
by qualified professionals or by instructed persons under
the direction and supervision of qualified skilled electrical
personnel in accordance with electredechnical regulations.
Disconnect supply before installing!
The device is not suited for safe disconnection of the
mains supply.
When in Master/Slave mode of operation, the Master-
appliance must always be installed at the location where
there is least daylight.
GB
2a. Installation of the LUXOMAT®PD4-M-1C-C-SM
3a. Hardware configuration SM
Position LED’s
LED 1 green
LED 2 red
LED 3 white
40
15
30
1
2
5
10 16
TEST
1 2 3
4a. Position DIP-switches SM
DIP 1 Fully automatic/semi automatic mode
DIP 2 LED ON/OFF
DIP 3 Change between corridor mode and standard
mode
The DIP switch settings are overriden using the remote control.
Surface
mounting
OFF ON
VA
LED
HA
COR
ONOFF
DIP
Potentiometer1 Lux
Potentiometer2 Time
40
15
30
1
2
5
10 16
TEST
1 2 3
5. DIP switch functions
DIP-
switch
ON OFF
1 Semi automatic mode Fully automatic mode
2 LED OFF LED ON
3 Corridor mode Standard mode
DIP
OFF ON
1
2
3
The detector must be installed on a
solid and level surface. The circular
cover ring must be removed prior to
assembly. To do this, twist the lens
anticlockwise through approxi-
mately 5° and lift off.
Having connected up the wires
in accordance with regulations,
secure the detector with 2 screws.
After installation replace the lens
and lock (turn clockwise). Mains to
be connected.
The detector has been designed and
developed specifically for installation
in suspended ceilings.
A circular opening of diameter
68mm must first of all be produced
in the ceiling.
Having connected up the cables in accordance with
regulations, the detector is inserted into the opening as
shown in the drawing opposite and fixed into position with
the assistance of the spring clip.
2b. Installation of the LUXOMAT®PD4-M-1C-C-FC
LED 1 green
LED 2 white
LED 3 red
3b. Hardware configuration FC
Position LED’s and potentiometers
1 2
12 3
Potentiometer1 Lux
Potentiometer2 Time
DIP 1 Fully automatic/semi automatic mode
DIP 2 LED ON/OFF
DIP 3 Change between corridor mode and standard mode
The DIP switch settings are overriden using the remote control.
4b. Position DIP-switches
S L L
RRel2
N
Rel1
230 VAC ±10%
50-60 Hz
false ceiling
mounting
ON
OFF
DIP
123
Corridor function: After deactivation by an external push button,
the detector switches off and returns to automatic mode after 5sec.
The DIP settings are enabled again by:
• Adjusting the DIP switches when closed
• Reset with test sun setting at the potentiometers
• Reset when open
close
open
S L L
RRel2
N
Rel1
230 VAC ±10%
50-60 Hz

6.Putting into operation / Settings
Initialization
In the first 60 seconds after connecting the power supply the LUXOMAT®
PD4-M-1C-C will go through a self test cycle. During this time the device
doesn´t respond to movement, but will stay on the status depending on the
selected initialization mode on or off (INI OFF or ON).
Warning: In the IIN-OFF mode, does not switch on lights at power
start up. After 60 seconds, detector would switch on lights on upon
detecting movement.
Potentiometer 1 – Adjustment twilight-switch for light control
The switch-on value for the light can be set at between 10 and
2000 Lux. Using the potentiometer, the luminance set points
can be set as desired.
Symbol : Night operation
Symbol : Day/Night operation
Determining the current brightness
Set potentiometer 2 to the “Test“ setting. The green LED lights
up permanently as soon as the value set at the potentiometer
exceeds the current measured brightness.
Potentiometer 2 – Adjustment follow-up time channel 1 “Light“
Symbol TEST: Test mode, reacts on motion only. Every
movement switches on the light for a period of 2 seconds,
switching it off for a period of 2 seconds. The time can be set
infinitely variably at between 15 sec. and 30 minutes.
The potentiometer settings are overriden using the remote control.
Pulse spacing PD-Slave
2 or 9 seconds can be set for the pause between 2 pulses sent
to the master. The setting can be made with activated
() or deactivated ( ) LED indicator.
For devices with a separate slave input, 2sec. can be set.
120 6050
40
30
15
10
A
16 10 5
2
1
30
15
TEST
2000
1200
600
200
40
5
120 6050
40
30
15
10
A
16 10 5
2
1
30
15
TEST
2000
1200
600
200
40
5
9s 2s
LED ON
LED OFF
8. Putting into operation of the remote
control IR-PD-1C (optional)
Check Battery:
Open battery compartment by press-
ing the plastic springs together and
removing the battery-holder.
Caution: Settings with remote control supersede the
settings by potentiometers.
1 2
120 6050
40
30
15
10
A
16 10 5
2
1
30
15
TEST
2000
1200
600
200
40
5
120 6050
40
30
15
10
A
16 10 5
2
1
30
15
TEST
2000
1200
600
200
40
5
7. Reset and default settings
1. Default settings
If the potentiometers are in the
“Test“ and “Sun“ position and
the detector is unprogrammed,
the factory program is acti-
vated: 500 Lux and 10min.
2. Reset
If both potentiometers are returned to the “Test“ and “Sun“
setting from any other position, a reset is executed. All
values programmed with the remote control are deleted.
Option: Remote control IR-PD-1C (92520)
(Label to be used with IR-PD)
An adhesive film for the surface of the IR-PD-1C is inclu-
ded with the device. If required, this can be used for any
B.E.G. remote control with 27 keys.
LUXOMAT
®
PD3
B.E.G.
500
200
400
100 20
IR-PD-1C
PIR
CdS
ON/OFF
HA
B.E.G. LUXOMAT® B.E.G. LUXOMAT®
Wall bracket for remote control
IR-PD-1C
9. Settings by remote control
Unlocking device – Activation of the
programming mode
Locking device – Exit programming mode
If there is not reaction for about 3 minutes the
programming mode will be deactivated.
Change between fully-automatic and semi-automatic
mode (HA) => (see page 3, point 15)
Luminance set point for channel 1
20 - 1000Lux
Automatic reading in the current light value as
new luminance set point => (see page 3, point 12)
Change between motion detector and
photo electric switch
Increase the current light level
by 20 resp. 50Lux
Light ON/OFF
HA
ON/OFF
Resetting when
open: Deletes all
values set with
the remote con-
trol, light OFF.
Potentiometer
and DIP switches
are enabled for
setting.
or
1000
20 to
+
Follow-up time channel 1 (light)
5 - 30 min. or impuls


to
LED ON/OFF (by holding down the push button)
or Detection sensitivity
reduced or normal
Daytime operation, detector only activated by motion
or
PI R
CdS
Permanent protection against sabotage
White LED fl ashes
when choosing CdS
10. Key functions in closed state
Light ON/OFF during the detection of motion
plus follow-up time; Activation of the 12 h-ON/
OFF-function by holding down the push button
=> (see page 3, point 13)
Switches channel off and is immediately active again,
exits all timers, interruption of light measurement
Activation/Deactivation of the test function
After 3 minutes the test mode will be
automatically closed.
Changes to “open“ state
Changes to “closed“ state
Permanent protection against sabotage
This function blocks the unit permanently. This operat-
ing mode can only be activated during the period of 5
seconds (white LED flash) after pressing the “lock“ but-
ton. The procedure for leaving this mode is as follows:
1. Switch off the current
2. Apply current for 31 - 59 seconds
3. Switch of the current again
4. Apply current, wait for selftest cycle
5. Open detector
max
50
Lux
1500
Lux
ON
OFF
11a. In the initialisation period
During initialization phase/self test cycle
Lights can be set to on or off status during initialization
(60 Seconds) by using INI OFF/ON mode.
12h Light ON/OFF (party function)
Activated by “Light“ push button
Deactivated by “Reset“ push button (default)
Corridor function (see point 13a)
Activated by “outside“ push button
Deactivate by “inside“ push button (default)
Forced shutdown (see point 13c)
Activated by “sun“ push button
Deactivate by “moon“ push button (default)
11b. In opened state
This push button opens the detector and the following
functions can then be programmed.
Attention: The detector is closed automatically:
• after every voltage recovery
• after 3 minutes
The state changes to “closed“.
In the first 5 seconds, the white LED flashes every
0.5 seconds. During this time, sabotage protection
can be activated.
The device distinguishes between 2 procedures:
• Reading in with lighting switched on:
The switch-on value is determined automatically.
Determining the switch-on value:
1. Press the “eye“ push button
2. Switch off the light (2 seconds later)
3. Read in the brightness
4. Switch-on value = Read brightness
• Reading in with lighting switched off:
When the push button is pressed, the current
brightness is specified as the switch-on value. The
switch-off value is determined automatically.
If the brightness has been modified, the switch-off
threshold is recalculated.
Each time the push button is pressed, the device
increases the current switch-on value in increments of
20 Lux for a current switch-on value of < 100Lux and
in increments of 50Lux for a current switch-on value
of > 100Lux.
1000
Lux
20
Lux
Standard sensitivity for most applications
Reduced sensitivity for outdoor applications
When the pulse function is active, a pulse of 1sec. is generated
every 9 sec. If the pulse function is activated via remote control,
the pause between 2 pulses can be modified. After activating
the function via the “Pulse“ push button, select the desired time
within 5 sec.:


5
min = 9 sec., 

10
min = 10 sec., 

15
min = 15 sec., 

30
min = 30 sec.
The “Test“ push button can be used to set the LED ON/OFF
function. To do this, hold down the push button for 3sec.
Please note that in the open state and in test mode, the LED
indicators are always ON.
Twilight switch function (CdS)
If the CdS function is active, the detector acts as a simple twilight
switch. Only the brightness can be set in this mode. Movements
are no longer indicated by the red LED.
Push button acknowledgement:
Each push of a button is indicated by lamp acknowledgement
and by the white LED.
“Light ON“ status: OFF/ON (approx. 0.5sec. each)
“Light OFF“ status: ON/OFF (approx. 0.5sec. each)
+
PI R
CdS
11. Explanation of the remote control button functions
optionaloptionaloptionaloptionaloptional optional
t < 5 sec.
t < 5 sec.
5
min
max
50
Lux
1500
Lux
ON
OFF
!

The “Corridor“ and “Light ON/OFF“ functions are mutually
exclusive. If both are activated, the detector performs the corridor
function.
The behaviour when the push button is pressed is defined
as follows:
Corridor function activated
Light ON:
Push button pressed briefly: Light OFF -> Active after 5sec.
Push button held down: Light OFF -> Active after 5sec.
Light OFF:
Push button pressed briefly: Light ON as long as motion + Lag time
Push button held down: Light ON as long as motion + Lag time
13a. Behaviour of external push button/IR “Light“
12h Light ON/OFF activated
Light ON:
Push button pressed briefly: Light OFF -> Active after 5sec.
Push button held down: 12 h OFF
Light OFF:
Push button pressed briefly: Light ON as long as motion + Lag time
Push button held down: 12 h ON
12h Light ON/OFF deactivated
Light ON:
Push button pressed briefly: Light OFF as long as motion + Lag time
Push button held down: Light OFF as long as motion + Lag time
Light OFF:
Push button pressed briefly: Light ON as long as motion + Lag time
Push button held down: Light ON as long as motion + Lag time
13b. Behaviour of external push button/IR “Light“
Activation of light for 12 h via mains interruption
1. Interrupt current
2. Apply current for 2 to 5sec.
3. Interrupt current again
4. Apply current
5. Detector is now ON for 12 h
Exiting sabotage
1. Interrupt current
2. Apply current for 30 to 60sec.
3. Interrupt current again
4. Apply current
5. Detector is in simple closed state
230 V AC permanently at the slave input
If 230 V AC is applied at the slave input for longer than 10sec., the
light is switched on permanently. When the 230 V is removed, the
light is switched off and automatic mode is activated.
230 V AC for 1 – 3sec. at push button connection S
If 230 V AC is applied for 1 – 3sec. at push button connection S,
this is interpreted as a slave signal at slave connection R. This ensu-
res that the detector is compatible with previous versions.
14. Other functions
15. Fully automatic and semi automatic mode
(see functions IR-PD-1C)
Fully automatic operation
In this operating mode, the lighting switches automatically
on and off for increased comfort, depending on presence
and brightness.
- Channel 1 switches on in the event of motion if “dark“ is
detected.
Semi automatic operation
In this operating condition, in order to gain increased
savings, the lighting is energized only after being manually
switched on.
Switch-off takes place automatically or manuelly.
The semi automatic mode basically behaves like the fully
automatic one. However, the difference is that switching-on
must always be carried out manually!
As many (closer-contact) buttons as desired can be wired in
parallel on the “S” button input (ON/OFF).
Triggering in semi automatic mode: If the detector switches
off in semi automatic mode (lag timer elapsed), the detector
is switched on again within 10 sec. by motion (despite semi
automatic mode).
HA
ON/OFF
18. Technical data PD4-Master-1C-C
1. If the switch-on threshold has been modified by the potentiometer
or remote control, the switch-off threshold stored in the EEPROM is
deleted and is then recalculated on the next activation.
Determining the switch-off value
1. Switch on for 5 min. with dark and motion
2. Light OFF for 2 sec.
3. Internal calculation of the switch-off value
2. If the eye push button is pressed, the switch-off threshold is
recalculated. See also Remote control–> Eye section
3. Switch-off delay
If the determined switch-off threshold is exceeded during operation,
the detector only switches off after a delay of approx. 15 minutes.
This compensates for any brief fluctuations in the brightness.
12. Switch-off threshold brightness
Forced shutdown active
Light OFF:
Light OFF: Push button pressed briefly: Light ON for approx.
30min., then forced shutdown if the set brightness is still excee-
ded.
13c. Behaviour of external push button/IR
„Forced shutdown“
19. Wiring diagram
Standard mode with Master 1-channel occupancy
detectors (N/O) with R and S terminal




 




    




Typ SM FC FM
PD4-M-1C-C (Master) 92587 92586 –
PD4-S-C (Slave) 92442 92444 92445
LUXOMAT®Remote control:
IR-PD-1C (incl. wall bracket) 92520
IR-PD-Mini 92159
Accessory:
BSK Ball basket guard 92199
Wall bracket for remote control as
replacement 92100
20. Article / Part nr. / Accessory
16. Range of Coverage
In case the sensing area of the LUXOMAT®PD4-M-1C-C
is too large or areas are being covered that should not be
monitored, the range can be reduced or limited through
use of the enclosed masking clips.
17. Exclude sources of interferences
SM
FC
10 m 20 m
40 m
20 m
8 m
24 m
3 m
5 m
20 m
3 m
5 m
5 m
20 m
20 m
20 m
5 m
5 m
2.50 m
2
walking towards
walking across
1
Sensor and power supply in one case
Power supply: 110 – 240 VAC, 50/60 Hz
Power consumption: < 1W
Ambient temperature: -25°C – +50°C
Degree of protection/class : AP=IP54, DE= IP20 / II /
Settings : Potentiometer, DIP-switch and by
remote control
Light values
- IR-PD-1C: 20 - 1000Lux
Extension of the detection area: with Slave-devices
Area of coverage: narrow detection area, ideal for
corridors
Range of coverage Ø H 2.50m / T=18°C:
tangential 40m / radial 20m
Mounting height: 2.40 - 2.60 m
Light measurement: daylight + artificial light
Lux values - Potentiometer: 10 - 2000 Lux
• 1 Relay/Channel for light-connection
Type of contact:
NOC / with pretravel tungsten
contact
Contact load: 2300 W, cos ϕ=1 /
1150 VA, cos ϕ= 0.5, µ- Contact
Time-settings:
15sec. - 16min./ test with potentiometer
5 min. - 30min./ test with remote control
Dimensions H x Ø [mm] SM FC
PD4-M-1C-C 76 x 101 104 x 97
Visible portion when built into ceiling FC: 30x97mm
Version: v.01
Technical data PD4-Slave-C
Power supply: 230 V~ ±10 %
Impulse output: Optocoupler max. 2 W
Impulse duration: 2 sec. or 9 sec.
Dimensions: see above
Declaration of Conformity: The product complies with the
low voltage recommendation 2006/95/EC and the EMV
recommendation 2004/108/EC.
PD4-M-1C-C-SM and FC
Optional
T1 = NO-button for semi automatic mode;
Extension of the detection area with Slave-devices
1
2

21. PD4-M-1C-C-SM – Connection
21. PD4-M-1C-C-FC – Connection
22. LED function displays
MAN 7403 –270814–6
LED function indicators after each mains recovery (60 sec. initialisation period)
Operating state LED function indicators
Factory program
active
White, red and green flash in quick succession for 10sec., then initialisation indicators,
see below
Double-locked white and green shines for 5 sec. all 20sec., afterwards initialising notification
Indicator
unprogrammed
Indicator
programmed
Indicator also when forced shutdown
is activated
Standard mode Red flashes Red flashes quickly Every 5 sec., 4 x white, red and
green in quick succession
12 h ON/OFF
active
Red and green
flash
Red and green flash
quickly
Every 5 sec., 4 x white, red and
green in quick succession
Corridor active Red and white flash Red and white flash
quickly
Every 5 sec., 4 x white, red and
green in quick succession
12 h ON/OFF &
corridor active
Red, green and
white flash
Red, green and white flash
quickly
Every 5 sec., 4 x white, red and
green in quick succession
CdS active – Red and white flash Then no red LED for motion detection
LED function indicators during operation
Process LED function indicators
Motion detection Red flashes on each detected movement
Semi-automatic mode
active
White is ON
Impulse active red and green flash one time all 4sec.
Corridor active White ON 1sec. and OFF 4sec.
Corridor and
semi-automatic mode
active
White ON 4sec. and OFF 1sec.
Too bright detected Green flashes
Light measurement
active
Green flashes once every 10sec.
12 h ON/OFF func-
tion active
Red and green flash alternately
Duration ON active
(by slave)
Red flashes quickly
IR command White flashes once
IR command „Open“
and sabotage active
White and green flash once slowly
RN N L
LNO
SNO
T1
E1
Slave
L
N
--
R
R
L
N
R
NO NO
T1 E1
S-
L L NN -
Slave
