B-K lighting Precision2 HP2 Series User manual

RELEASE DATE
7-13-16
REFERENCE NUMBER
INS-1341-00
40429 Brickyard Drive • Madera, CA 93636 • USA
559.438.5800 • FAX [phone]
www.bklighting.com • [email protected]
B-K LIGHTING
THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION OF B-K LIGHTING, INC. AND ITS RECEIPT OR POSSESSION DOES NOT CONVEY ANY RIGHTS TO REPRODUCE, DISCLOSE ITS CONTENTS, OR TO MANUFACTURE, USE OR SELL ANYTHING IT MAY
DESCRIBE. REPRODUCTION, DISCLOSURE OR USE WITHOUT SPECIFIC WRITTEN AUTHORIZATION OF B-K LIGHTING, INC. IS STRICTLY FORBIDDEN.
1/8” Allen Wrench
Wire Connectors
Level
Phillips Screwdriver
Warning Low Voltage Hot Surface
NEEDED
FOR
INSTALLATION:
By Others
Silicone Filled
Wire Nuts
O-Ring
HP2 Shallow
Housing
Concrete Pour
Collar (CPC)
Faceplate
Proper soil preparation is recommended before installation. See the DIG-IT guide at www.bklighting.com/dig-it for more information.
HP2SERIES™
Shallow Housing - Halogen (MR16)
Remote Transformer Installation Instructions
Soil Prep
IMPORTANT SAFETY INFORMATION - READ, FOLLOW, AND SAVE THESE INSTALLATION INSTRUCTIONS
Conduit
trench
A. Determine Soil Type by referencing
DIG-IT Guide.
B. Dig hole 24” wide and 8” deep.
Conduit
Trench
Excavated
for Housing
C. Prep soil according to DIG-IT Guide.
• Product must be installed by a qualified person in a manner
consistent with its intended use and in compliance with the
National Electrical Code, Canadian Electrical Code, and all Local
and Provincial Codes.
• Follow product label information and instructions.
• Qualified Personnel must perform all servicing or relamping of
this product.
• Before wiring to power supply and during servicing or relamping,
turn off power at fuse or circuit breaker before service.
• The use of accessory equipment not recommended by the
manufacturer or installed contrary to instructions may cause an
unsafe condition. The use of damaged components may cause
an unsafe condition and void product warranty.
IMPORTANT SAFETY INFORMATION - READ, FOLLOW, AND SAVE ALL SAFETY
AND INSTALLATION INSTRUCTIONS
• Do not block light emanating from product in whole or part,
as this may cause an unsafe condition.
• Never operate the fixture with missing or damaged lens.
Lens must be cleaned on regular basis.
• Entire fixture may become extremely hot. Do not touch hot
lens or fixture body. Do not touch the lamp at any time. Use
a clean, dry, soft cloth to handle the lamp. Oil from skin may
damage the lamp and cause it to rupture.
• Replace lamp only with correct wattage and type of lamp
marked on fixture label.
• All gaskets, o-rings and sealing surfaces must be kept clean
during installation and service; failure to do this may cause an
unsafe condition and void product warranty.
INSTRUCTIONS PERTAINING TO
A RISK OF FIRE, OR INJURY TO
PERSONS IMPORTANT SAFETY
INSTRUCTIONS
Lighted lamp is HOT!
WARNING - To reduce the risk of FIRE OR INJURY TO PERSONS:
Turn off/unplug and allow to cool before replacing lamp.
Lamp gets HOT quickly! Contact only switch/plug when
turning on.
Do not touch hot lens, guard, or enclosure (see diagram/
picture).
Keep lamp away from materials that may burn.
Do no touch the lamp at any time. Use a soft cloth. Oil
from skin may damage lamp.
Do not operate the luminaire fitting with a missing or
damaged shield.
SAVE THESE INSTRUCTIONS
· Suitable for wet locations · Suitable for recessed in ground locations
IMPORTANT LISTINGS AND CERTIFICATIONS
OptiLock®
Assembly
Thumbscrew
Optional
Accessory
Holder
Retaining
Clip

RELEASE DATE
7-13-16
REFERENCE NUMBER
INS-1341-00
40429 Brickyard Drive • Madera, CA 93636 • USA
559.438.5800 • FAX [phone]
www.bklighting.com • [email protected]
B-K LIGHTING
2. Place housing in hole. Align with the path of the
conduit trench.
5. Per DIG-IT Guide, backfill the gap between the
bottom of housing and bottom of hole with
sand for drainage.
Housing Installation
PROJECT:
TYPE:
1. Connect branch conduit connectors (By Others)
to the housing using either the threaded
conduit entries on the bottom of the housing
or through holes drilled into the sides of the
housing.
3. Connect the conduit to the conduit connectors.
4. Pull secondary wiring into junction box.
6. For soil installation: Fill and tamp soil to
the appropriate height leaving room for sod,
pavers, etc. to be level with the top of the
temporary cover.
Soil installation is not drive-over rated.
7. For concrete installation: Fill the hole around
the fixture housing to 12” below the finished
grade with clean fill dirt and tamp carefully to
prevent settling of fixture. Pour concrete and
finish as required flush with the top surface of
the temporary cover.
IMPORTANT SAFETY INFORMATION LISTED ON REVERSE
READ, FOLLOW, AND SAVE ALL SAFETY AND INSTALLATION INSTRUCTIONS
HP2SERIES™
Shallow Housing - Halogen (MR16)
Remote Transformer Installation Instructions
This product is intended for use
ONLY in areas of restricted depth.
The shallow housing does not
permit separation between the
wiring and lamp compartments.
Designer should detail the
following warning in all
specifications documents:
WARNING
MANDATORY: Installer MUST
use water-tight ttings and ensure
a sealed conduit/wiring system or
this xture will leak. Failure to do
so will VOID WARRANTY.

RELEASE DATE
7-13-16
REFERENCE NUMBER
INS-1341-00
40429 Brickyard Drive • Madera, CA 93636 • USA
559.438.5800 • FAX [phone]
www.bklighting.com • [email protected]
B-K LIGHTING
Installation
PROJECT:
TYPE:
WIRING DIAGRAM
LINE 12V
Fixture
COM
Remote
Transformer
COM
1. Remove temporary cover. 2. Make connections using silicone filled wire nuts
(provided) from OptiLock® to secondary wiring.
See wiring diagram.
IMPORTANT SAFETY INFORMATION LISTED ON REVERSE
READ, FOLLOW, AND SAVE ALL SAFETY AND INSTALLATION INSTRUCTIONS
HP2SERIES™
Shallow Housing - Halogen (MR16)
Remote Transformer Installation Instructions
3. Place OptiLock® in HP2 housing and align
keyhole notch under one of (3) #8 screw heads.
Rotate horizontally to desired aiming position,
then tighten (2) #8 Phillips screws using Phillips
screwdriver. Install proper MR16 halogen lamp.
6. Remove any dirt or debris in O-ring groove near
top of housing. Place O-Ring inside of groove.
Failure to clean groove of debris will cause
fixture to fail and void product warranty.
7. Install faceplate using 1/8” Allen wrench and
hand-tighten the (5) #10-24 faceplate screws in
a star pattern to 30 in-lbs. min.
Do not use a power tool to install screws. Do
not exceed 40 in-lbs.
4. For Optional Accessory Holder: Insert
accessory holder tabs into slots on OptiLock®.
5. Aim vertically by turning the thumbscrew on
OptiLock® assembly.

Warning Hot Surface
TOOLS
NEEDED:
By Others
HP2& CO2 SERIES
MR16 / ES16
Lamp and Accessory Holder Installation
t 1SPEVDU NVTU CF JOTUBMMFE CZ B RVBMJGJFE QFSTPO JO B NBOOFS
DPOTJTUFOU XJUI JUT JOUFOEFE VTF BOE JO DPNQMJBODF XJUI UIF
/BUJPOBM&MFDUSJDBM$PEF$BOBEJBO&MFDUSJDBM$PEFBOEBMM-PDBM
BOE1SPWJODJBM$PEFT
t 'PMMPXQSPEVDUMBCFMJOGPSNBUJPOBOEJOTUSVDUJPOT
t 2VBMJGJFE1FSTPOOFMNVTUQFSGPSNBMMTFSWJDJOHPSSFMBNQJOHPG
UIJTQSPEVDU
t #FGPSFXJSJOHUPQPXFSTVQQMZBOEEVSJOHTFSWJDJOHPSSFMBNQJOH
UVSOPGGQPXFSBUGVTFPSDJSDVJUCSFBLFSCFGPSFTFSWJDF
t 5IF VTF PG BDDFTTPSZ FRVJQNFOU OPU SFDPNNFOEFE CZ UIF
NBOVGBDUVSFSPSJOTUBMMFEDPOUSBSZUPJOTUSVDUJPOTNBZDBVTFBO
VOTBGFDPOEJUJPO5IFVTFPGEBNBHFEDPNQPOFOUTNBZDBVTF
BOVOTBGFDPOEJUJPOBOEWPJEQSPEVDUXBSSBOUZ
IMPORTANT SAFETY INFORMATION - READ, FOLLOW, AND SAVE ALL SAFETY
AND INSTALLATION INSTRUCTIONS
t %POPUCMPDLMJHIUFNBOBUJOHGSPNQSPEVDUJOXIPMFPSQBSU
BTUIJTNBZDBVTFBOVOTBGFDPOEJUJPO
t /FWFS PQFSBUF UIF GJYUVSF XJUI NJTTJOH PS EBNBHFE MFOT
-FOTNVTUCFDMFBOFEPOSFHVMBSCBTJT
t &OUJSF GJYUVSF NBZ CFDPNF FYUSFNFMZ IPU %P OPU UPVDI IPU
MFOTPSGJYUVSFCPEZ%POPUUPVDIUIFMBNQBUBOZUJNF6TF
BDMFBOESZTPGUDMPUIUPIBOEMFUIFMBNQ0JMGSPNTLJONBZ
EBNBHFUIFMBNQBOEDBVTFJUUPSVQUVSF
t 3FQMBDF MBNQ POMZ XJUI DPSSFDU XBUUBHF BOE UZQF PG MBNQ
NBSLFEPOGJYUVSFMBCFM
t "MM HBTLFUT 0SJOHT BOE TFBMJOH TVSGBDFT NVTU CF LFQU DMFBO
EVSJOHJOTUBMMBUJPOBOETFSWJDFGBJMVSFUPEPUIJTNBZDBVTFBO
VOTBGFDPOEJUJPOBOEWPJEQSPEVDUXBSSBOUZ
INSTRUCTIONS PERTAINING TO
A RISK OF FIRE, OR INJURY TO
PERSONS IMPORTANT SAFETY
INSTRUCTIONS
-JHIUFEMBNQJT)05
8"3/*/(5PSFEVDFUIFSJTLPG'*3&03*/+63:501&340/4
5VSOPGGVOQMVHBOEBMMPXUPDPPMCFGPSFSFQMBDJOHMBNQ
-BNQHFUT)05RVJDLMZ$POUBDUPOMZTXJUDIQMVHXIFO
UVSOJOHPO
%POPUUPVDIIPUMFOTHVBSEPSFODMPTVSFTFFEJBHSBN
QJDUVSF
,FFQMBNQBXBZGSPNNBUFSJBMTUIBUNBZCVSO
%POPUPVDIUIFMBNQBUBOZUJNF6TFBTPGUDMPUI0JM
GSPNTLJONBZEBNBHFMBNQ
%POPUPQFSBUFUIFMVNJOBJSFGJUUJOHXJUIBNJTTJOHPS
EBNBHFETIJFME

SAVE THESE INSTRUCTIONS
· Suitable for wet locations · Suitable for recessed in ground locations
IMPORTANT LISTINGS AND CERTIFICATIONS
w"MMFO8SFODI
RELEASED
7-13-16
REFERENCE NUMBER
INS-2151-00
%ULFN\DUG'ULYH0DGHUD&$86$
)$;
ZZZENOLJKWLQJFRPLQIR#ENOLJKWLQJFRP
B-K LIGHTING
5)*4%0$6.&/5$0/5"*/4 13013*&5"3: */'03."5*0/ 0'#,-*()5*/( */$ "/% *543&$&*1503 1044&44*0/ %0&4 /05 $0/7&:"/:3*()54 50 3&130%6$& %*4$-04&*54$0/5&/54 03 50 ."/6'"$563&64&034&-- "/:5)*/( *5 .":
%&4$3*#&3&130%6$5*0/%*4$-0463&0364&8*5)06541&$*'*$83*55&/"65)03*;"5*0/0'#,-*()5*/(*/$*4453*$5-:'03#*%%&/
IMPORTANT SAFETY INFORMATION - READ, FOLLOW, AND SAVE THESE INSTALLATION INSTRUCTIONS
 3FNPWFGBDFQMBUFVTJOHw"MMFOXSFODI*GUIFSFJT
BOPQUJPOBMBDDFTTPSZIPMEFSDBSFGVMMZTRVFF[FUBCT
POTJEFTBOEHFOUMZQVMMGSPNTMPUTPO0QUJ-PDL¥
B 'JSNMZJOTFSUQSPQFS.3MBNQJOUPTPDLFUUPNBLF
DPOOFDUJPO
Do not exceed the maximum wattage listed on
the fixture label before installing.
 For Optional Accessory Holder: *OTFSU BDDFTTPSZ
IPMEFSUBCTJOUPTMPUTPO0QUJ-PDL¥
C 'JSNMZJOTFSUQSPQFS&4MBNQQJOTJOUPTPDLFUUIFO
HFOUMZUXJTUUPNBLFDPOOFDUJPO
Do not exceed the maximum wattage listed on
the fixture label before installing.
Lamp Installation Or Re-Lamping if Required for MR16 / ES16 Lamp
MR16 Lamp Installation ES16 Lamp Installation
 "JN WFSUJDBMMZ CZ UVSOJOH UIF UIVNCTDSFX PO
0QUJ-PDL¥BTTFNCMZ
 3FNPWFBOZEJSUPSEFCSJTJO0SJOHHSPPWFOFBSUPQ
PGIPVTJOH1MBDF03JOHJOTJEFPGHSPPWF
Failure to clean groove of debris will cause fixture
to fail and void product warranty.

PROJECT:
TYPE:
HP2& CO2 SERIES
MR16 / ES16
Lamp and Accessory Holder Installation
SUBMITTAL DATE
7-13-16
REFERENCE NUMBER
INS-2151-00
%ULFN\DUG'ULYH0DGHUD&$86$
)$;
ZZZENOLJKWLQJFRPLQIR#ENOLJKWLQJFRP
B-K LIGHTING
IMPORTANT SAFETY INFORMATION LISTED ON REVERSE
READ, FOLLOW, AND SAVE ALL SAFETY AND INSTALLATION INSTRUCTIONS
 5VSOBDDFTTPSZIPMEFSVQTJEFEPXOBOESFNPWF
SFUBJOFSDMJQ*OTFSUVQUPBDDFTTPSJFT
Insert any accessory lens with the smooth
side towards the lamp. If using a honeycomb
baffle, position it farthest from the lamp.
 1JODISFUBJOFSDMJQUBCTBOEMJOFVQOPUDIFTXJUI
TMPUT PO BDDFTTPSZ IPMEFS 'JU JOUP BDDFTTPSZ
IPMEFSUPIPMEBDDFTTPSJFTJOQMBDF
 *OTUBMM GBDFQMBUF VTJOH w "MMFO XSFODI BOE
IBOEUJHIUFO UIF GBDFQMBUF TDSFXT JO B TUBS
QBUUFSOUPJOMCTNJO
Do not use a power tool to install screws. Do
not exceed 40 in-lbs.
Optional Accessory Holder Installation for MR16 / ES16
 *OTFSU BDDFTTPSZ IPMEFS UBCT JOUP TMPUT PO
0QUJ-PDL¥

SUBMITTAL DATE
5-15-14
REFERENCE NUMBER
INS-2158-00
%ULFN\DUG'ULYH0DGHUD&$86$
)$;
ZZZENOLJKWLQJFRPLQIR#ENOLJKWLQJFRP
B-K LIGHTING
THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION OF B-K LIGHTING, INC. AND ITS RECEIPT OR POSSESSION DOES NOT CONVEY ANY RIGHTS TO REPRODUCE, DISCLOSE ITS CONTENTS, OR TO MANUFACTURE, USE OR SELL ANYTHING IT MAY
DESCRIBE. REPRODUCTION, DISCLOSURE OR USE WITHOUT SPECIFIC WRITTEN AUTHORIZATION OF B-K LIGHTING, INC. IS STRICTLY FORBIDDEN.
1/8” & 7/64” Allen Wrench
Warning Hot Surface
NEEDED
FOR
INSTALLATION:
By Others
HP2SERIES
Faceplate Accessories
Accessories Installation Instructions
IMPORTANT SAFETY INFORMATION - READ, FOLLOW, AND SAVE THESE INSTALLATION INSTRUCTIONS
t 1SPEVDU NVTU CF JOTUBMMFE CZ B RVBMJGJFE QFSTPO JO B NBOOFS
DPOTJTUFOU XJUI JUT JOUFOEFE VTF BOE JO DPNQMJBODF XJUI UIF
/BUJPOBM&MFDUSJDBM$PEF$BOBEJBO&MFDUSJDBM$PEFBOEBMM-PDBM
BOE1SPWJODJBM$PEFT
t 'PMMPXQSPEVDUMBCFMJOGPSNBUJPOBOEJOTUSVDUJPOT
t 2VBMJGJFE1FSTPOOFMNVTUQFSGPSNBMMTFSWJDJOHPSSFMBNQJOHPG
UIJTQSPEVDU
t #FGPSFXJSJOHUPQPXFSTVQQMZBOEEVSJOHTFSWJDJOHPSSFMBNQJOH
UVSOPGGQPXFSBUGVTFPSDJSDVJUCSFBLFSCFGPSFTFSWJDF
t 5IF VTF PG BDDFTTPSZ FRVJQNFOU OPU SFDPNNFOEFE CZ UIF
NBOVGBDUVSFSPSJOTUBMMFEDPOUSBSZUPJOTUSVDUJPOTNBZDBVTFBO
VOTBGFDPOEJUJPO5IFVTFPGEBNBHFEDPNQPOFOUTNBZDBVTF
BOVOTBGFDPOEJUJPOBOEWPJEQSPEVDUXBSSBOUZ
IMPORTANT SAFETY INFORMATION - READ, FOLLOW, AND SAVE ALL SAFETY
AND INSTALLATION INSTRUCTIONS
t %POPUCMPDLMJHIUFNBOBUJOHGSPNQSPEVDUJOXIPMFPSQBSU
BTUIJTNBZDBVTFBOVOTBGFDPOEJUJPO
t /FWFS PQFSBUF UIF GJYUVSF XJUI NJTTJOH PS EBNBHFE MFOT
-FOTNVTUCFDMFBOFEPOSFHVMBSCBTJT
t &OUJSF GJYUVSF NBZ CFDPNF FYUSFNFMZ IPU %P OPU UPVDI IPU
MFOTPSGJYUVSFCPEZ%POPUUPVDIUIFMBNQBUBOZUJNF6TF
BDMFBOESZTPGUDMPUIUPIBOEMFUIFMBNQ0JMGSPNTLJONBZ
EBNBHFUIFMBNQBOEDBVTFJUUPSVQUVSF
t 3FQMBDF MBNQ POMZ XJUI DPSSFDU XBUUBHF BOE UZQF PG MBNQ
NBSLFEPOGJYUVSFMBCFM
t "MM HBTLFUT PSJOHT BOE TFBMJOH TVSGBDFT NVTU CF LFQU DMFBO
EVSJOHJOTUBMMBUJPOBOETFSWJDFGBJMVSFUPEPUIJTNBZDBVTFBO
VOTBGFDPOEJUJPOBOEWPJEQSPEVDUXBSSBOUZ
INSTRUCTIONS PERTAINING TO
A RISK OF FIRE, OR INJURY TO
PERSONS IMPORTANT SAFETY
INSTRUCTIONS
-JHIUFEMBNQJT)05
8"3/*/(5PSFEVDFUIFSJTLPG'*3&03*/+63:501&340/4
5VSOPGGVOQMVHBOEBMMPXUPDPPMCFGPSFSFQMBDJOHMBNQ
-BNQHFUT)05RVJDLMZ$POUBDUPOMZTXJUDIQMVHXIFO
UVSOJOHPO
%POPUUPVDIIPUMFOTHVBSEPSFODMPTVSFTFFEJBHSBN
QJDUVSF
,FFQMBNQBXBZGSPNNBUFSJBMTUIBUNBZCVSO
%POPUPVDIUIFMBNQBUBOZUJNF6TFBTPGUDMPUI0JM
GSPNTLJONBZEBNBHFMBNQ
%POPUPQFSBUFUIFMVNJOBJSFGJUUJOHXJUIBNJTTJOHPS
EBNBHFETIJFME
SAVE THESE INSTRUCTIONS
· Suitable for wet locations · Suitable for recessed in ground locations
IMPORTANT LISTINGS AND CERTIFICATIONS
3PDL(VBSEXJUI0QUJDBM0QFOJOH 3PDL(VBSE
'PS6TF8JUI
(MBSF4IJFME" (MBSF4IJFME#
)BMG%PNF" )BMG%PNF#

SUBMITTAL DATE
5-15-14
REFERENCE NUMBER
INS-2158-00
%ULFN\DUG'ULYH0DGHUD&$86$
)$;
ZZZENOLJKWLQJFRPLQIR#ENOLJKWLQJFRP
B-K LIGHTING
Faceplate Accessories
PROJECT:
TYPE:
IMPORTANT SAFETY INFORMATION LISTED ON REVERSE
READ, FOLLOW, AND SAVE ALL SAFETY AND INSTALLATION INSTRUCTIONS
HP2SERIES
Faceplate Accessories
Accessories Installation Instructions
 6TJOHBw"MMFOXSFODIMPPTFOUIF
TFUTDSFXTPOUIFGBDFQMBUFUPBMMPXBDDFTTPSZUP
SPUBUFGSFFMZ
 "DDFTTPSZ DBO SPUBUF ¡ JOEFQFOEFOUMZ PG
GBDFQMBUF
 8IFOTFUJOGJOBMQPTJUJPOUJHIUFOTFU
TDSFXTVTJOHw"MMFOXSFODI
 *OTUBMM GBDFQMBUF VTJOH w "MMFO XSFODI BOE
IBOEUJHIUFOUIFGBDFQMBUFTDSFXTJO
BTUBSQBUUFSOUPwMCTNJO
Do not use a power tool to install screws. Do
not exceed 40” lbs.
 #FGPSF *OTUBMMBUJPO PG GBDFQMBUF DMFBO PSJOH
HSPPWFBOEDPMMBSPGEFCSJTGPSBQSPQFSTFBM
Failure to clean groove of debris will cause
fixture to fail and void product warranty.
*OTUSVDUJPOT"QQMZUP
3PDL(VBSE
XJUI0QUJDBM
0QFOJOH
3PDL(VBSE (MBSF4IJFME" (MBSF4IJFME# )BMG%PNF" )BMG%PNF#

RELEASE DATE
7-13-16
REFERENCE NUMBER
INS-1341-01
40429 Brickyard Drive • Madera, CA 93636 • USA
559.438.5800 • FAX [phone]
www.bklighting.com • [email protected]
B-K LIGHTING
THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION OF B-K LIGHTING, INC. AND ITS RECEIPT OR POSSESSION DOES NOT CONVEY ANY RIGHTS TO REPRODUCE, DISCLOSE ITS CONTENTS, OR TO MANUFACTURE, USE OR SELL ANYTHING IT MAY
DESCRIBE. REPRODUCTION, DISCLOSURE OR USE WITHOUT SPECIFIC WRITTEN AUTHORIZATION OF B-K LIGHTING, INC. IS STRICTLY FORBIDDEN.
1/8” Allen Wrench
Waterproof Wire Connectors
Level
Phillips Screwdriver
Warning Low Voltage Hot Surface
NEEDED
FOR
INSTALLATION:
By Others
Waterproof Wire
Connectors
O-Ring
HP2 Shallow
Housing with ICEE™
Concrete Pour
Collar (CPC)
with ICEE™
Faceplate
with ICEE™
Proper soil preparation is recommended before installation. See the DIG-IT guide at www.bklighting.com/dig-it for more information.
HP2SERIES WITH ICEETM
Shallow Housing - Halogen (MR16)
Remote Transformer Installation Instructions
Soil Prep
IMPORTANT SAFETY INFORMATION - READ, FOLLOW, AND SAVE THESE INSTALLATION INSTRUCTIONS
Conduit
trench
A. Determine Soil Type by referencing
DIG-IT Guide.
B. Dig hole 24” wide and 10” deep.
Conduit
Trench
Excavated
for Housing
C. Prep soil according to DIG-IT Guide.
• Product must be installed by a qualified person in a manner
consistent with its intended use and in compliance with the
National Electrical Code, Canadian Electrical Code, and all Local
and Provincial Codes.
• Follow product label information and instructions.
• Qualified Personnel must perform all servicing or relamping of
this product.
• Before wiring to power supply and during servicing or relamping,
turn off power at fuse or circuit breaker before service.
• The use of accessory equipment not recommended by the
manufacturer or installed contrary to instructions may cause an
unsafe condition. The use of damaged components may cause
an unsafe condition and void product warranty.
IMPORTANT SAFETY INFORMATION - READ, FOLLOW, AND SAVE ALL SAFETY
AND INSTALLATION INSTRUCTIONS
• Do not block light emanating from product in whole or part,
as this may cause an unsafe condition.
• Never operate the fixture with missing or damaged lens.
Lens must be cleaned on regular basis.
• Entire fixture may become extremely hot. Do not touch hot
lens or fixture body. Do not touch the lamp at any time. Use
a clean, dry, soft cloth to handle the lamp. Oil from skin may
damage the lamp and cause it to rupture.
• Replace lamp only with correct wattage and type of lamp
marked on fixture label.
• All gaskets, o-rings and sealing surfaces must be kept clean
during installation and service; failure to do this may cause an
unsafe condition and void product warranty.
INSTRUCTIONS PERTAINING TO
A RISK OF FIRE, OR INJURY TO
PERSONS IMPORTANT SAFETY
INSTRUCTIONS
Lighted lamp is HOT!
WARNING - To reduce the risk of FIRE OR INJURY TO PERSONS:
Turn off/unplug and allow to cool before replacing lamp.
Lamp gets HOT quickly! Contact only switch/plug when
turning on.
Do not touch hot lens, guard, or enclosure (see diagram/
picture).
Keep lamp away from materials that may burn.
Do no touch the lamp at any time. Use a soft cloth. Oil
from skin may damage lamp.
Do not operate the luminaire fitting with a missing or
damaged shield.
SAVE THESE INSTRUCTIONS
· Suitable for wet locations · Suitable for recessed in ground locations
IMPORTANT LISTINGS AND CERTIFICATIONS
OptiLock®
Assembly
Thumbscrew
Optional
Accessory
Holder
Retaining
Clip

RELEASE DATE
7-13-16
REFERENCE NUMBER
INS-1341-01
40429 Brickyard Drive • Madera, CA 93636 • USA
559.438.5800 • FAX [phone]
www.bklighting.com • [email protected]
B-K LIGHTING
2. Place housing in hole. Align with the path of the
conduit trench.
5. Per DIG-IT Guide, backfill the gap between the
bottom of housing and bottom of hole with
sand for drainage.
Housing Installation
PROJECT:
TYPE:
1. Connect branch conduit connectors (By Others)
to the housing using either the threaded
conduit entries on the bottom of the housing
or through holes drilled into the sides of the
housing.
3. Connect the conduit to the conduit connectors.
4. Pull secondary wiring into junction box.
6. For soil installation: Fill and tamp soil to
the appropriate height leaving room for sod,
pavers, etc. to be level with the top of the
temporary cover.
Soil installation is not drive-over rated.
7. For concrete installation: Fill the hole around
the fixture housing to 12” below the finished
grade with clean fill dirt and tamp carefully to
prevent settling of fixture. Pour concrete and
finish as required flush with the top surface of
the temporary cover.
IMPORTANT SAFETY INFORMATION LISTED ON REVERSE
READ, FOLLOW, AND SAVE ALL SAFETY AND INSTALLATION INSTRUCTIONS
HP2SERIES WITH ICEETM
Shallow Housing - Halogen (MR16)
Remote Transformer Installation Instructions
This product is intended for use
ONLY in areas of restricted depth.
The shallow housing does not
permit separation between the
wiring and lamp compartments.
Designer should detail the
following warning in all
specifications documents:
WARNING
MANDATORY: Installer MUST
use water-tight ttings and ensure
a sealed conduit/wiring system or
this xture will leak. Failure to do
so will VOID WARRANTY.

RELEASE DATE
7-13-16
REFERENCE NUMBER
INS-1341-01
40429 Brickyard Drive • Madera, CA 93636 • USA
559.438.5800 • FAX [phone]
www.bklighting.com • [email protected]
B-K LIGHTING
Installation
PROJECT:
TYPE:
WIRING DIAGRAM
LINE 12V
Fixture
COM
Remote
Transformer
COM
1. Remove temporary cover. 2. Make watertight connections using waterproof
wire connectors (provided) from OptiLock® to
secondary wiring. See wiring diagram.
IMPORTANT SAFETY INFORMATION LISTED ON REVERSE
READ, FOLLOW, AND SAVE ALL SAFETY AND INSTALLATION INSTRUCTIONS
HP2SERIES WITH ICEETM
Shallow Housing - Halogen (MR16)
Remote Transformer Installation Instructions
3. Place OptiLock® in HP2 housing and align
keyhole notch under one of (3) #8 screw heads.
Rotate horizontally to desired aiming position,
then tighten (2) #8 Phillips screws using Phillips
screwdriver. Install proper MR16 halogen lamp.
6. Remove any dirt or debris in O-ring groove near
top of housing. Place O-Ring inside of groove.
Failure to clean groove of debris will cause
fixture to fail and void product warranty.
7. Install faceplate using 1/8” Allen wrench and
hand-tighten the (5) #10-24 faceplate screws in
a star pattern to 30 in-lbs. min.
Do not use a power tool to install screws. Do
not exceed 40 in-lbs.
4. For Optional Accessory Holder: Insert
accessory holder tabs into slots on OptiLock®.
5. Aim vertically by turning the thumbscrew on
OptiLock® assembly.
