B-K lighting Precision 2 CO2 Series User manual

RELEASE DATE
10-21-2019
REFERENCE NUMBER
INS001399.1
40429 Brickyard Drive • Madera, CA 93636 • USA
559.438.5800 • FAX [phone]
www.bklighting.com • [email protected]
B-K LIGHTING
THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION OF B-K LIGHTING, INC. AND ITS RECEIPT OR POSSESSION DOES NOT CONVEY ANY RIGHTS TO REPRODUCE, DISCLOSE ITS CONTENTS, OR TO MANUFACTURE, USE OR SELL ANYTHING IT MAY
DESCRIBE. REPRODUCTION, DISCLOSURE OR USE WITHOUT SPECIFIC WRITTEN AUTHORIZATION OF B-K LIGHTING, INC. IS STRICTLY FORBIDDEN.
Warning High Voltage Hot Surface
Waterproof Wire
Connectors
Patented
Stability
Flange
1/8” Allen Wrench
Phillips Screwdriver
Level
iOS Device wit Inspiration App
NEEDED
FOR
INSTALLATION:
By Others
IMPORTANT SAFETY INFORMATION - READ, FOLLOW, AND SAVE THESE INSTALLATION INSTRUCTIONS
Quick
Disconnects
Patented
HydroLock®
Plate
Driver Tray
Assembly
CO2 Housing
Optic
CO2SERIES
Inspiration Control System
Installation Instructions
Proper soil preparation is recommended before installation. See the DIG-IT guide at www.bklighting.com/dig-it for more information.
· Suitable for wet locations · Suitable for recessed in ground locations
IMPORTANT LISTINGS AND CERTIFICATIONS
iOS device with installed Inspiration Control System
App is required for Bluetooth® Wireless Control.
Bluetooth® version 4.0 or higher required.
iOS Devices:
iPhone - iPhone 4s or newer
iPad - 3rd Gen iPad or newer
iPad Mini
iPad Air
iPod - iPod Touch 5th Gen or newer
Device Requirements
• Product must be installed by a qualified person in a manner
consistent with its intended use and in compliance with the
National Electrical Code, Canadian Electrical Code, and all Local and
Provincial Codes.
• Follow product label information and instructions.
• Qualified Personnel with appropriate personal protective
equipment must perform all servicing of this product.
• Before wiring to power supply and during servicing, turn off and
lock out power at fuse or circuit breaker before service.
• The use of accessory equipment not recommended by the
manufacturer or installed contrary to instructions may cause an
unsafe condition. The use of damaged components may cause an
unsafe condition and void product warranty.
IMPORTANT SAFETY INFORMATION - READ, FOLLOW, AND SAVE ALL SAFETY
AND INSTALLATION INSTRUCTIONS
• Do not block light emanating from product in whole or part, as
this may cause an unsafe condition.
• Never operate the fixture with missing or damaged lens.
Lens must be cleaned on regular basis.
• Entire fixture may become extremely hot. Do not touch hot
lens or fixture body.
• Replace LED assembly only with correct wattage and type of
power supply appropriate for LED assembly.
• All gaskets, o-rings and sealing surfaces must be kept clean
during installation and service; failure to do this may cause an
unsafe condition and void product warranty.
INSTRUCTIONS PERTAINING TO
A RISK OF FIRE, OR INJURY TO
PERSONS IMPORTANT SAFETY
INSTRUCTIONS
Lighted fixture is HOT!
WARNING - To reduce the risk of
FIRE OR INJURY TO PERSONS:
Turn off/unplug and allow to cool before replacing LED.
Fixture gets HOT quickly! Contact only switch/plug when
turning on. Do not touch hot lens, guard, or enclosure.
Keep fixture away from materials that may burn.
Do not operate the luminaire fitting with a missing or
damaged shield. Do not touch the source at any time. Use
a soft cloth or gloves. Oil from skin may cause damage.
SAVE THESE INSTRUCTIONS
OptiLock®
Silicone ‘O’ Ring CO2 Faceplate

RELEASE DATE
10-21-2019
REFERENCE NUMBER
INS001399.1
40429 Brickyard Drive • Madera, CA 93636 • USA
559.438.5800 • FAX [phone]
www.bklighting.com • [email protected]
B-K LIGHTING
2. Place housing in hole. Align junction box in the
path of the conduit trench.
3. Insert (4) pieces of ½” EMT conduit through the
Stability Flange™. Hammer into substrate until
secure.
Leave sufficient clearance to elevate housing
to finished grade.
4. To accommodate the overhang and allow for
proper sealing between the faceplate and
housing, you’ll need to elevate the housing at
least a 1/4” above the finish grade. Use a level
to aid in leveling housing.
5. When housing is level, tighten screws on
Stability Flange™ to secure housing to EMT.
Remove excess EMT as needed.
Housing Installation
Threaded Entry
Side Flats
1. Connect branch conduit connectors (By Others)
to the junction box using either the threaded
conduit entries on the bottom of the junction
box or through holes drilled into the sides of the
junction box.
6. Connect the conduit to the conduit connectors.
7. Pull primary branch circuit wiring into junction
box.
IMPORTANT SAFETY INFORMATION LISTED ON REVERSE
READ, FOLLOW, AND SAVE ALL SAFETY AND INSTALLATION INSTRUCTIONS
CO2SERIES
Inspiration Control System
Installation Instructions
iOS device (Not Included) with installed B-K Lighting Inspiration Application required for use.
Soil Prep
Conduit
trench 18”
Dia.
A. Determine Soil Type by referencing DIG-IT
Guide.
B. Dig hole 18” wide and 20” deep.
Conduit
Trench
Excavated
for Housing
C. Prep soil according to DIG-IT Guide.

RELEASE DATE
10-21-2019
REFERENCE NUMBER
INS001399.1
40429 Brickyard Drive • Madera, CA 93636 • USA
559.438.5800 • FAX [phone]
www.bklighting.com • [email protected]
B-K LIGHTING
IMPORTANT SAFETY INFORMATION LISTED ON REVERSE
READ, FOLLOW, AND SAVE ALL SAFETY AND INSTALLATION INSTRUCTIONS
Installation
CO2SERIES
Inspiration Control System
Installation Instructions
iOS device (Not Included) with installed B-K Lighting Inspiration Application required for use.
8. Per DIG-IT Guide, backfill the gap between the
bottom of housing and bottom of hole with
sand for drainage.
9. For soil installation: Fill and tamp soil to
the appropriate height leaving room for sod,
pavers, etc. to be level with the top of the
temporary cover.
Soil installation is not drive-over rated.
10. For concrete installation: Fill the hole around
the fixture housing to 12” below the finished
grade with clean fill dirt and tamp carefully to
prevent settling of fixture. Pour concrete and
finish as required flush with the top surface of
the temporary cover.
1. Remove temporary cover. 2. Make watertight connections using waterproof
wire connectors (provided) to leads on the
bottom of Patented HydroLock® Barrier Plate
Assembly. See wiring diagram.
Number of connections may vary depending
on wiring controls chosen as per lighting
plan. See wiring diagram.
WIRING DIAGRAM - Wireless Bluetooth® Controls
with Inspiration Application on iOS device
iOS device controls dimming, CCT, Saturation,
and Hue using Bluetooth® wireless controls and
the application.
iOS device (iPad, iPod, iPhone) with installed
B-K Lighting Inspiration application is
required.
WIRING DIAGRAM - Hybrid
Secondary wiring from remote driver connects
to fixture leads. 0-10V dimming connects to
module. 0-10V Continuous CCT connects to
module. iOS device controls Saturation and Hue.
iOS device (iPad, iPod, iPhone) with installed
B-K Lighting Inspiration application is
required.
WIRING DIAGRAM - 0-10V Wired
Secondary wiring from remote driver connects
to fixture leads. 0-10V dimming connects to
module. 0-10V Continuous CCT connects to
module and controls CCT.
iOS device (iPad, iPod, iPhone) with installed
B-K Lighting Inspiration application is
required.
Hydrolock Plate
Line (Black)
Neut (White)
Ground (Green)
iOS
Bluetooth®
0-10V DIM + (Green)
0-10V DIM - (Black)
0-10V CCT + (Blue)
0-10V CCT - (White)
Hydrolock Plate
Line (Black)
Neut (White)
Ground (Green)
0-10V DIM + (Green)
0-10V DIM - (Black)
0-10V CCT + (Blue)
0-10V CCT - (White)
Lutron E2 +(ORANGE)
Hydrolock Plate
Lutron E1 - (WHITE)
Line Black
Neut White
Ground Green
WIRING DIAGRAM - Lutron
Wire Gauge Maximum & EcoSystem-Compliant
Loop Wire Length.
4.0 mm2 (12 AWG) 671 m (2200 FT)
2.5 mm2 (14 AWG) 427 m (1400 FT)
1.5 mm2 (16 AWG) 275 m (900 FT)
1.0 mm2 (18 AWG) 175 m (570 FT)
Maximum of 32 devices per loop.
Hydrolock Plate
Line (Black)
Neut (White)
Ground (Green)
iOS
Bluetooth®

CO2SERIES
Inspiration Control System
Installation Instructions
RELEASE DATE
10-21-2019
REFERENCE NUMBER
INS001399.1
40429 Brickyard Drive • Madera, CA 93636 • USA
559.438.5800 • FAX [phone]
www.bklighting.com • [email protected]
B-K LIGHTING
IMPORTANT SAFETY INFORMATION LISTED ON REVERSE
READ, FOLLOW, AND SAVE ALL SAFETY AND INSTALLATION INSTRUCTIONS
iOS device (Not Included) with installed B-K Lighting Inspiration Application required for use.
4. Turn HydroLock® Barrier Plate clockwise ¼” to
lock.
Patented HydroLock® Barrier Plate must be
completely seated to ensure proper seal or
water may intrude. This step must be done
as stated or you will void your warranty.
3. Wipe inside of housing where HydroLock® plate
will sit clean of debris before inserting patented
HydroLock® plate on to junction box. Align
HydroLock® plate with pins in housing and seat
it firmly in place.
5. Connect driver assembly to Patented
HydroLock™Barrier plate with quick disconnect.
Number of plugs and size of plugs may vary
depending on wiring controls chosen as per
lighting plan.
6. Attach driver assembly to housing by aligning
keyhole notch under one (1) of three (3) #8 screw
heads.
7. Tighten the Phillips screws to secure driver
plate to housing.
8. Attach OptiLock® assembly to installed driver
assembly with quick disconnect. Place OptiLock®
assembly in housing, resting the OptiLock® on
the pins provided inside the housing.
10. To aim OptiLock® horizontally: lift OptiLock®
from resting position, and rotate to desired
angle. Set down on pins provided in housing.
OptiLock® is gravity held in place.
WIRING DIAGRAM - DMX
Leads are labeled. Recommended wire:
- Liberty Cable
24-2P-285 Non Plenum
24-2P-P485 Plenum
- Belden Cable
9842 Non-Plenum
89842 Plenum
Maximum of 30 fixtures per DMX runs.
Please refer to wire manufacturer’s lighting
catalog for and equals as required by code.
Hydrolock Plate
Line (Black)
Neut (White)
Ground (Green)
DMX In Common (Blue)
DMX Out Data + (White)
DMX Out Data - (Black)
DMX Out Common (Green)
DMX In Data - (White)
DMX In Data (Orange/White)
9. HP2 Accy Holder Installation/Removal
For Optional Accessory Holder: Loosen the
thumbscrew and then tilt the Accessory Holder
up off the reflector so the second screw can
clear the edge of the reflector.

12. Remove any dirt or debris in O-ring groove near
top of housing. Place O-Ring inside of groove.
Failure to clean groove of debris will cause
fixture to fail and void product warranty.
13. Install faceplate using 1/8” Allen wrench and
hand-tighten the faceplate screws in a star
pattern to 30 in-lbs. min.
Do not use a power tool to install screws. Do
not exceed 40 in-lbs.
RELEASE DATE
10-21-2019
REFERENCE NUMBER
INS001399.1
40429 Brickyard Drive • Madera, CA 93636 • USA
559.438.5800 • FAX [phone]
www.bklighting.com • [email protected]
B-K LIGHTING
IMPORTANT SAFETY INFORMATION LISTED ON REVERSE
READ, FOLLOW, AND SAVE ALL SAFETY AND INSTALLATION INSTRUCTIONS
CO2SERIES
Inspiration Control System
Installation Instructions
iOS device (Not Included) with installed B-K Lighting Inspiration Application required for use.
11. To aim OptiLock® vertically: loosen two (2) 1/4-20
screws using 3/16” Allen wrench. Tilt swivel arm
with LED and optic in desired aiming direction.
Tighten two (2) 1/4-20 screws with 3/16” Allen
wrench to secure position.
2. Use a Phillips screwdriver to unscrew the 2 screws
holding the reflector adapter and LED module.
Remove wire ribbon connector from LED module.
Clean all Arctic Silver Ceramique thermal grease
from heatsink.
2. Apply a thin and even coating of Arctic Silver
Ceramique thermal grease provided with
replacement LED module to the bottom of the new
LED module. Snap the wire ribbon connector to the
LED module. Place the LED module on the heatsink.
Place reflector adapter to top of LED module and
align all the screw holes together.
3. Screw down the LED module and reflector adapter.
1. To replace the LED module: Twist reflector off.
LED Replacement
